Minimum distance between
oven and wall opening >2cm
Smoke outlet
>150cm from the
edge of the roof
A
=
Well ventilated area
max
45°
>P
P
IMG 2 - Side view
IMG 1 - Front view
Fireproof wall
C
P
= Oven depth
C
>P
P
>P
>P
IMG 3 - View from above
C
=Butterfly Valve for draft
regulation, accessible
from the front
Accessibility
from all
C
Fireproof wall
A
-
sides-
11
