AUSTRALIA - INSTALLATION & USER MANUAL
PLEASE READ BEFORE INSTALLING, CONNECTING AND USING A GAS FIRED PIZZA OVEN
Note: The ALFA USER MANUAL must be read in conjunction with this Manual. Where there
are conflicting statements, this Manual applies for ALL installations within Australia.
Thank you for purchasing the Alfa ONE or BRIO gas fired pizza oven.
This information is provided as a guide only and in good faith. Fornieri – Wood Fired Ovens takes no
responsibility for the accuracy of this information. Please seek independent advice from a Licensed Gasfitter
and/or your relevant Energy Safety Government Authority before installing a gas operated appliance in your
home or business.
1. Is your Alfresco considered to be enclosed or outdoors? Guidelines for Indoor gas oven Installations
2. Connecting to an LPG Cylinder
3. Connecting to Natural Gas
4. Warnings
5. General Safety Information
6. Need Assistance - Contact Us
Please Note: All Natural Gas connections in Australia must be completed by a Licenced Gasfitter.
1 |
P a g e
ALFA ONE and BRIO – Gas Fired Ovens
IMPORTANT INFORMATION
Page - 6
Page - 7
Page - 8
Page - 9
Page - 11
R e v i s i o n 1 . 1
S e p t e m b e r 2 0 2 1
Advertisement
Related Manuals for Alfa Network ONE
Summary of Contents for Alfa Network ONE
- Page 1 Manual applies for ALL installations within Australia. Thank you for purchasing the Alfa ONE or BRIO gas fired pizza oven. This information is provided as a guide only and in good faith. Fornieri – Wood Fired Ovens takes no responsibility for the accuracy of this information.
- Page 2 The area has walls on all sides but at least one permanent opening at ground level and no overhead cover, ...
- Page 3 The standard for commercial and residential gas installations in Australia AS/ NZS 5601.1.2013 was amended in May of 2016 with many new requirements. One significant change that which will affect the installation of gas fired pizza ovens and gas barbecues is a new clause 6.10.1.15. This clause requires that an appliance approved for indoor/commercial use and installed in residential premises, be fitted with an interlock to the gas supply so that the installed extraction system must be in operation before gas will flow to the appliance.
- Page 4 Figure 2. Typical Interlock arrangement. A TYPICAL INTERLOCK ARRANGEMENT FREQUENTLY ASKED QUESTIONS ABOUT EXHAUST HOODS Q. Do I have to install an exhaust hood above my pizza oven or barbecue? If your alfresco area is classed as enclosed (i.e. more than 50% enclosed) then you must install an exhaust hood above your gas fired pizza oven or barbecue which complies with Energy Safety laws.
- Page 5 Q. What height does my exhaust hood need to be? Energy Safety Regulations specify the height at which an exhaust hood must be installed when over a barbecue but not for a gas fired pizza oven. Please follow the same guidelines for your gas fired pizza oven (width of the oven opening as a minimum) but with regards to your flue pipe, your gas pizza oven flue pipe exhaust cap must terminate directly below the exhaust hood with a minimum clearance of 200mm below the exhaust hood.
- Page 6 CONNECTING TO A GAS CYLINDER – LPG GAS ONLY The Alfa ONE and BRIO comes ready to be used with Propane (AUS) gas cylinders. The size of cylinder that can be used with this pizza oven is a 9kg and must be located outdoors in a well-ventilated area. Your pizza oven will come supplied with the correct regulator connection to suit your Propane cylinder and has a pre-set pressure regulator of 2.75 kPa.
- Page 7 CONNECTING TO MAINS GAS – NATURAL GAS ONLY The Alfa ONE and BRIO come supplied with an appliance regulator to use with Natural Gas connections. The gas connection to the pizza oven can only be done by a Licenced Gasfitter and they must ensure that all work is completed in line with the relevant state rules and regulations.
- Page 8 If you need to replace the ignitor cable, disconnect it from the front piezo igniter and from the pilot light end, then before removing it, use a lanyard and tape it to one end of the cable to pull out the old one and thread it the new one in a hassle-free way.
-
Page 9: General Safety Information
GENERAL SAFETY INFORMATION Please Read the Alfa User Manual thoroughly before assembling or using your gas pizza oven. This pizza oven has been tested and certified in accordance with Australian Standards AS/NZS 5263.1.7 and AS 4563 and is approved for sale and distribution in Australia. ... - Page 10 CAUTION: FOR OUTDOOR AND ENCLOSED/INDOOR USE WARNING: The pizza oven must not be used indoors unless the relevant approved markings are displayed on the back of the appliance and the pizza oven is installed with an interlock to the gas supply so that the installed extraction system must be in operation before gas will flow to the appliance (refer to section 1 of this user manual).
- Page 11 If you need to contact the manufacturer for information, technical support or to order spare parts please have this information at hand. SAFETY COMPLIANCE LABEL: While there is a requirement under the regulations for all gas products to be safe, the Australian and New Zealand regulatory environment establishes the limits of fundamental safety. The safety compliance label confirms that this pizza oven has been certified as compliant and deemed suitable for importing and operation in Australia.
