Summary of Contents for Alfa Network ONE

  • Page 1 NORTH AMERICA ONLY USER MANUAL domestic ovens...
  • Page 2: Using The Oven

    Write in this section the data of your product. Oven Model: Serial number: GENERAL WARNINGS SAFETY WARNINGS Purchase date: POSITIONING THE OVEN NB: The identification label is located on the back of the product. LPG / NG CONNECTION WARNINGS LPG / NG CONNECTION AND INSTALLATION LPG / NG CONVERSION INSTRUCTIONS LIGHTING THE OVEN - WOOD LIGHTING THE OVEN - GAS...
  • Page 3: General Warnings

    PLEASE READ THE FOLLOWING INFORMATION FOR PROPER INSTALLATION AND OPTIMUM PERFORMANCE OF THE OVEN. GENERAL WARNINGS - The identification plate, with technical data, lot number and brand name is visibly applied on the device. Do not remove this label - Remove all protective film before putting the unit into operation. To help RETAIN THIS MANUAL FOR FUTURE REFERENCE facilitate the separation, use warm air (for example, a hair dryer) Additional copies of this manual at www.alfaovens.com...
  • Page 4: Safety Warnings

    SAFETY WARNINGS FOR WOOD-BURNING OVENS ONLY READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THIS APPLIANCE Do not install where prohibited. FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. Also, always keep the area under and around this appliance free and clear of any and all combustible materials WARNING: Improper installation, adjustment, alteration, service or...
  • Page 5: Positioning The Oven

    50 cm 50 cm POSITIONING THE OVEN 20 in 20 in ATTENTION THE OUTER WALLS OF OVEN MAY REACH HIGH TEMPERATURES GREATER THAN 50°C / 120°F. ANY FLAMMABLE MATERIAL SHOULD BE KEPT AT LEAST 3 FEET (1 METRE) AWAY FROM THE OVEN. CAUTION: When being used, place the oven at a safe distance from flammable 20 cm 20 cm...
  • Page 6: Natural Gas Supply

    LPG/NG CONNECTION WARNINGS LPG/NG CONNECTIONS ONLY FOR LPG OVENS CONNECT THE LPG CYLINDER (only for LPG oven) Connect the flexible hose to the back of the oven. Use the supplied conversion kits if changing from factory settings PRESSURE REGULATOR : Liquid Propane Gas (LPG): 11.0”...
  • Page 7 HOW IT IS CONFIGURED FROM THE FACTORY OVEN ALFA ONE and BRIO GAS OVENS COME FROM FACTORY PRE-SET FOR LPG (NG CONVERSION KITS INCLUDED WITH OVEN) Mount the adapter (B) on the gas inlet (C1), followed by the regulator (A).
  • Page 8: Lpg Connection

    CONNECTION TO THE GAS CYLINDER LPG / NG REGULATOR CONVERSION INSTRUCTIONS 1 - Begin by Converting the Regulator to LPG NATURAL GAS SUPPLY (H) UN SCREW THE CAP TO ACCESS THE REGULATOR ADJUSTMENT. THE PLASTIC ADAPTER SHOULD BE TURNED UPSIDE DOWN DEPENDING ON THE TYPE OF GAS SUPPLY.
  • Page 9 GAS ORIFICE AND PILOT SPUD CONVERSION 3.1 REPLACEMENT OF THE PILOT NATURAL GAS (NG) – LIQUID PROPANE GAS (LPG) SPUD Unscrew the fixing screw (h) of the ONLY USE THE COMPONENTS AND pilot light tube.. PARTS SUPPLIED WITH THE CONVERSION KIT WARNING: The following conversion should be performed by authorized professionals when the oven is completely cold.
  • Page 10: Lighting The Oven

    15-20 minutes depending on the size of your oven. Larger ovens can take longer to heat up. Do not put too much wood in at one time and replace the door as noted in section 3 to help keep the flame inside the oven.
  • Page 11: Turning Off

    TURNING OFF • To turn the oven off, close the oven door and wait for ash to form. • When the fire is out and the oven has been completely shut down for 60 minutes or longer and you confirm the coals have cooled down, you can remove the ashes into a fire safe metal ash can.
  • Page 12 LIGHTING THE OVEN ONLY FOR GAS VERSION WARNING: Follow the instructions before turning on the oven. - Check all gas connections for gas leak before starting your oven. - Use the proper PTFE gas piping tape for all threaded connections - Do not lean over the oven when lighting.
  • Page 13 If temp lowers, insert pieces of wood in the center and burning thoroughly needed (one or two pieces) temperature. a small piece of wood or of the oven floor. move to the left side using...
  • Page 14 USE THE DOOR AND SMALL PIECES OF WOOD TO STABILIZE - 3.1 Stabilize the temperature - 3.3 Raise the temperature up The wood fired oven is designed to let the user choose the right temperature The wood fired oven is a machine that can also raise the temperature quickly, with stainless steel dome oven, it’s simply and easy to do.
  • Page 15 400°F and the cooking floor is around 400°F you can insert the bread dough. We suggest closing the door and checking the temperature every 5-10 minutes. The oven should cool down to 325°F in one hour and the bread should be ready (do not cut it till it’s cold).
  • Page 16 YOUR TO-DO LIST FOR A PERFECT PIZZA PARTY ALFA SPECIAL RECIPE FOR THE PERFECT PIZZA DOUGH (WITH BRUSCHETTA) Recipe for 5 medium or 4 big pizzas INGREDIENTS Flour: 1 Kg (look for an Water: 630 grams or ml Brewer Yeast (not dried): Italian brand: “5 Stagioni”...
  • Page 17 side down, in a lightly oiled proofing box or bowl. Cover with a tight fitting lid or plastic wrap. Let the dough rest for 2 hours at room temperature (assuming 70° to 74°F/21° to 23°C) for the initial rise. 4. Shape and Divide into Dough Balls: Moderately flour your work surface about 2 feet wide.
  • Page 18: Regular Maintenance

    REGULAR MAINTENANCE CALENDAR MAINTENANCE 1 - PYROLYSIS CLEANING OF THE OVEN CHAMBER AND COOKING FLOOR. CLEANING TIME SCHEDULE The ALFA oven can be cleaned by the fire itself through a Combustion chamber Daily - Every use process called “pyrolysis” (pyro “fire” + lysis “separating”). The processes involved in charring wood and it has a Cooking floor Daily - Every use...
  • Page 19: Maintenance And Care

    MAINTENANCE AND CARE MAINTENANCE AND CARE SPECIFICATIONS FOR WOOD-FIRED OVENS SPECIFICATIONS FOR GAS-FIRED OVENS - Before lighting the oven make sure that the chimney flue is unobstructed and that 1. MAINTENANCE. The gas burner should be cleaned periodically by any previous ash has been removed. carefully sucking up any food residue.
  • Page 20 MAINTENANCE AND CARE ONLY FOR WOOD VERSION CLEANING When the fire has gone out and the oven is not hot enough, collect the ashes left over from previous cooking with a metallic brush and a pan. MAINTENANCE AND CARE ONLY FOR GAS VERSION MAINTENANCE The gas burner should be cleaned periodically by carefully sucking up any cooking residues.
  • Page 21 WARNING: Major causes of vent related fires is failure to maintain required clearances One of the most common questions for ALFA Oven owners revolves around (air spaces) to combustible materials. venting. Many owners find the need to customize the basic vent pipe and cap Note: The outer walls of oven may reach high temperatures, more than 125°F.
  • Page 22 - Elbows are manufactured in 15-degree and 30-degree angles, measured from the vertical - Do not combine elbows to create steeper angles and never exceed 2 elbows in one pipe or chimney system - A single elbow is defined as a 30-degree bend and then a 30-degree correction lvdistributes.com...
  • Page 23: Troubleshooting

    - It is recommended to close the oven door. ELECTRONIC BUTTON ONLY FOR GAS OVENS - Check that the fire is on one side of the oven and not near the mouth THE OVEN DOES - Fire with vivid flames for 20minutes.
  • Page 24: Warranty

    NOTE The oven is guaranteed for 2 (two) years against defects and craftsmanship; good maintenance and proper use can make sure that the oven lasts much longer. Warranty covers parts and components for 2 years and gas burner for 3 years. Shipping and assembly costs are charged to the customer.
  • Page 25 alfaovens.com...
