  • Page 1 USER MANUAL QUICK SERIES www.alfaforni.com...
  • Page 2 USER MANUAL Download the complete user manual Alfa Forni participates in the SAVE THE PLANET initiative; that’s why the manual has been printed only in English. To download the other languages, scan the QR code or click the link below. Alfa Forni partecipa all’iniziativa SAVE THE PLANET, per questo il manuale è...

  • Page 3: Table Of Contents

    USER MANUAL Index GENERAL WARNINGS............2 INSTALLATION..............6 BASE..................8 OVEN HANDLING..............10 INSTALLATION BEHIND A WALL.........11 FLUE..................13 VENTILATION AND AERATION........14 LPG CONNECTION............17 NATURAL GAS CONNECTION........20 BURNER Q2-4P..............22 BURNER Q6P..............28 BURNER Q6P NORTH AMERICA........32 BURNER CONVERSION Q6P........36 BURNER CONVERSION Q6P NORTH AMERICA..40 BEFORE USE..............43 LIGHTING WOOD OVEN..........44 LIGHTING GAS OVEN.............46 CONTROL UNIT Q6P............48...

  • Page 4: General Warnings

    GENERAL WARNINGS WARNING: Improper connection, as well as any alterations or improper maintenance, may cause material damage to things or people and even death in extreme cases. Please read the instructions carefully before installing and using the appliance. READ THE FOLLOWING INFORMATION CAREFULLY FOR A CORRECT INSTALLATION AND OPTIMAL OPERATION OF THE OVEN - The data plate with the serial number, the model number and the mark is visibly applied to the oven.
  • Page 5 - Keep any electrical wiring and fuel line away from hot surfaces. - Do not use the oven in case of breakage or malfunctioning. - Do not lean or rest objects on the oven: they might compromise its stability. - Keep the oven clear of naked flames. - In the event of unchecked flames, move the food away from the fire until it is extinguished.
  • Page 6 WARNINGS PLEASE READ THE FOLLOWING INSTRUCTIONS BEFORE INSTALLING AND USING THE OVEN. Please read the entire instruction manual before installing this appliance. Failure to follow these instructions could result in personal and property damage or death. Please contact the local authorities for any restrictions on the installation. ONE OF THE MAIN CAUSES OF OVEN FIRE IS DUE TO THE NON-OBSERVANCE OF THE MINIMUM DISTANCE FROM FLAMMABLE MATERIALS OR IMPROPER INSTAL- LATION.
  • Page 7 SAFETY WARNINGS FOR GAS-BURNING OVENS ONLY ATTENTION: Whenever you turn off the gas-fired oven, wait for the thermocouple to cool off to make sure the gas flow is interrupted. NEVER leave the knob in the minimum/maximum position before the probe has completely cooled down: this could create a gas leak and cause an explosion upon ignition.

  • Page 8: Installation

    INSTALLATION THIS APPLIANCE CANNOT BE COATED WITH FLAMMABLE MATERIALS. USE ONLY NON-COMBUSTIBLE MATERIALS TO BUILD IN THE OVEN. THE TOP PART OF THE OVEN CANNOT BE BUILT IN AND IT MUST BE KEPT CLEAR OF FURNITURE THAT COULD COMPROMISE ADEQUATE VENTILATION - ATTENTION: do not occupy the minimum safe distance with insulation or other materials.
  • Page 9 THE TOP VERSION OVENS SHOULD BE PLACED ON TABLES OR OTHER FIREPROOF SURFACES WITH ENOUGH LOAD-BEARING CAPACITY (for the weight, refer to the product data sheet attached to the instruction manual), ADJUST THE LEVELLING FEET TO HOLD THE OVEN STEADY. To move the oven more easily, remove the bricks inside the combustion chamber 50 cm...

  • Page 10: Base

    BASE - Correct assembly: Before using the base, check that all screws and parts are tight- ened tightly to ensure both stability and safety during use. - Load capacity: Comply with the weight limit indicated for the base of the oven with wheels.
  • Page 11 Fix the lateral supports to the front using the screws supplied Once the 3 components of the wheel cover have been fixed, place it under the oven and slide it to the ground.

  • Page 12: Oven Handling

    OVEN HANDLING WHEN PLACING THROUGH TIGHT SPACES Before starting the handling operation, make sure that the eyebolts have been carefully fixed and that the block of the tiles is positioned correctly. Attach the belts supplied to the eyebolts on the side of the oven, taking care to ensure that they have been fastened securely .

  • Page 13: Installation Behind A Wall

    INSTALLATION BEHIND A WALL WARNING: BUILT-IN INSTALLATION IS TO BE UNDERSTOOD INSTALLATION BEHIND A WALL - The oven can be installed behind a fireproof wall leaving the non visible sides of the oven free and accessible (see img 3) - The burner can be removed from the front or rear, so you must leave adequate space for removal.
  • Page 14 =Butterfly Valve for draft regulation, accessible Minimum distance between from the front oven and wall opening >2cm IMG 1 - Front view Smoke outlet Fireproof wall >150cm from the edge of the roof Well ventilated area >P Accessibility from all sides- 45°...

  • Page 15: Flue

    FLUE ONLY FOR WOOD-BURNING OVENS - Wood-fired models must be connected to a smoke evacuation system, the exhaust must be leak-proof. - As a rule, the chimney must serve only one oven; connecting more than one to a single chimney could jeopardise the smooth escape of fumes. - A well-designed chimney must not contain too many joints;...

  • Page 16: Ventilation And Aeration

    VENTILATION AND AERATION OF THE INSTALLATION ONLY FOR GAS-FIRED OVENS 1. VENTILATION Gas appliances must be installed in well-ventilated areas to prevent concentration of substances hazardous to health in the room. 1.1 NATURAL VENTILATION atural ventilation can be obtained by using one or more permanent openings on walls/windows/fixtures or through ventilation ducts.
  • Page 17 1.2 FORCED VENTILATION Forced ventilation can be obtained with systems equipped with electric fans. The actual flow rate must be no less than 1,72 m /h per kW. The air velocity near the installation must not disturb the operators and must have the following characteristics: The air velocity next to the exhaust hood must be between 0,25 m/s and 0,5 m/s.
  • Page 18 2.2 NATURAL AERATION SYSTEMS 2.2.1 Total rated thermal output not exceeding 15 kW. Through permanent openings facing outwards in the room where the appliances are installed. The net area of the openings or the cross section must be no less than 100 cm 2.2.2 Total rated thermal output not exceeding 35 kW.
  • Page 19 CONNECTION ONLY FOR LPG OVENS CONNECT THE LPG BOTTLE Connect the flexible hose to the back of the oven. PRESSURE REGULATOR not included): - Gas flow: 4 Kg/h - Outlet pressure: - 1/2" diameter - Length 1.5 meters - Working pressure: tab page 54 QUICK 2 - We recommend using a minimum 62kg to 20kg gas bottle.
  • Page 20 - During installation, check the correct inlet pressure to the oven in order to ensure optimal operation and avoid damage to the burner. - Never twist the gas hose. - Before using the oven, check that the hose does not have any marks, cracks, abrasions or cuts.
  • Page 21 EXTERNAL LPG BOTTLE CONNECTION OVEN CONNECTION 145L PRESSURE REGULATOR GAS HOSE TANK DOUBLE LPG BOTTLECONNECTION OVEN CONNECTION PRESSURE REGULATOR FLEXIBLE HOSE CONTROL UNIT FLEXIBLE HOSE/TANK CONNECTION TANK...
  • Page 22 CONNECTION ONLY FOR NATURAL GAS OVENS ATTENTION Always contact a qualified technician. Ensure that the furnace has a dedicated methane line with adequate pressure. CONNECT TO THE GAS NETWORK - The natural gas supply must be made with Ø 1/2” galvanized pipe (A) or copper pipe (B) to fit into the burner inlet hole.
  • Page 23 1. We recommend installing a gas-tap between the wall power supply and the connection pipe to the oven. 2. Connect the hose to the wall power supply. 3. Screw the hose to the oven with the help of the right spanner to securely fasten it.
  • Page 24 BURNER DISASSEMBLY LPG-NATURAL GAS ONLY FOR QUICK 2 PIZZE AND QUICK 4 PIZZE The burner can be dismantled either from the front or from the rear. FRONT DISASSEMBLY In this case, it will be necessary to remove the oven's sill. If the oven has been built in and you cannot remove the gas connection in the back (point 2), a gas pipe long enough to allow the burner to be completely removed must be installed.
  • Page 25 3 - Remove knob and locking screw 4 - Remove cable from igniter To remove the gas knob simply pull it by You can remove the igniter's cable by applying little force. Then remove the locking applying little force from an opening under the screw located to the left of the knob with a oven's sill screwdriver.
  • Page 26 REAR BURNER DISASSEMBLY PROCEDURE ONLY FOR QUICK 2 PIZZE AND QUICK 4 PIZZE WARNING Always contact a qualified technician 1 - Turn off the gas 2 - Unscrew and remove the Gas hose Before starting, make sure that the gas flow has been interrupted.
  • Page 27 5 - Unscrew and remove the rear gas 6 - Remove the burner casing To remove the burner, simply pull it towards you so that it comes out of its casing. Unscrew the 4 screws found on the rear gas casing by using a screwdriver.

  • Page 28: Burner Conversion Q6P

    BURNER CONVERSION ONLY FOR QUICK 2 PIZZE AND QUICK 4 PIZZE After having disassembled the burner, (page 20) proceed with replacing the burner's main nozzle. WARNING Always contact a qualified technician 1 - Locate the nozzle to be replaced 2 - Replace the nozzle Once you have removed the burner, you will To remove the nozzle, use an 11 wrench by be able to identify the golden nozzle that...
  • Page 29 CE LPG CE LPG NATURAL OVEN 30mbar 50mbar 20mbar QUICK 2 2,55 2,10 3,80 PIZZE QUICK 4 3,10 2,55 4,50 PIZZE UL LPG UL NATURAL GAS OVEN 27,5mbar 10mbar QUICK 2 2,70 4,90 PIZZE QUICK 4 3,25 5,50 PIZZE...
  • Page 30 BURNER DISASSEMBLY LPG-NATURAL GAS ONLY FOR QUICK 6 PIZZE ELECTRICAL DATA 220-240V 50/60Hz WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 1 - Remove the panel located on the 2 - Once the panel is removed, you left side of the oven base.
  • Page 31 6 - Remove the burner from the 5 - Remove the burner from its compartment housing Place the burner horizontally, so as to facilitate its extraction. If you are in USA or CANADA go to page 32-35...
  • Page 32 BURNER ASSEMBLY LPG-NATURAL GAS ONLY FOR QUICK 6 PIZZE ELECTRICAL DATA 220-240V 50/60Hz WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 1 - Insert the burner into the oven 2 - Slide the burner into its compartment...
  • Page 33 5 - Close the panel on the left side of the oven base Close the side panel by tightening the four screws at the corners of the panel, to do this use an Allen key (size 4). If you are in USA or CANADA go to page 32-35...
  • Page 34 BURNER DISASSEMBLY LPG-NATURAL GAS ONLY FOR QUICK 6 PIZZE INSTRUCTIONS FOR NORTH AMERICA ONLY DATI ELETTRICI 120V 60Hz WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 1 - Remove the panel located on the 2 - Once the panel is removed, you left side of the oven base.
  • Page 35 6 - Remove the burner from the 5 - Remove the burner from its compartment housing Place the burner horizontally, so as to facilitate its extraction. 7 - For assembly, follow the directions given in reverse Place the burner horizontally to facilitate its removal. USA and CANADA only...
  • Page 36 BURNER ASSEMBLY LPG-NATURAL GAS ONLY FOR QUICK 6 PIZZE INSTRUCTIONS FOR NORTH AMERICA ONLY DATI ELETTRICI 120V 60Hz WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 1 - Insert the burner into the oven 2 - Slide the burner into its compartment...
  • Page 37 5 - Close the panel on the left side of the oven base Close the side panel by tightening the four screws at the corners of the panel, to do this use an Allen key (size 4). USA and CANADA only...
  • Page 38 BURNER CONVERSION ONLY FOR QUICK 6 PIZZE After disassembling the burner (page 26) proceeds to conversion. WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 2 - Remove the screw on the air 1 - Place the burner on a surface and regulator...
  • Page 39 5 - Remove the nozzle 6 - Replace the nozzle with the one supplied Complete the removal of the nozzle using your hands. Secure and tighten the nozzle with your hands first, then with an 11 wrench. 8 -Position the air regulator 7 - Close the air regulator Repeat the sequence from point 2 to point 7 Referring to the notch, position the air...
  • Page 40 FLAME SPLITTER REPLACEMENT 1 - Remove burner from oven. 2 - Rotate the electrodes outwards, 3 - Loosen the Allen screws (4mm) so as to make it easier to extract the flame located on the sides of the flame splitter, splitter.
  • Page 41 ADJUSTMENT TABLE FLAME 1 AND FLAME 2 NATURAL GAS OVEN LPG 30mbar 20mbar NOZZLES 2,25 2,25 2,75 3,00 If you are in USA or CANADA go to page 40-42...
  • Page 42 BURNER CONVERSION ONLY FOR QUICK 6 PIZZE INSTRUCTIONS FOR NORTH AMERICA ONLY After disassembling the burner (page 28) proceeds to conversion. WARNING Always contact a qualified technician Before carrying out each operation be sure to disconnect the gas hose It is advisable to have 2 people carry out the operation 1 - Remove the panel located on the 2 - Once you have access to the left side of the oven base.
  • Page 43 5 - Remove the nozzle 6 - Replace the nozzle with the one supplied Complete the removal of the nozzle using your hands. Secure and tighten the nozzle with your hands first, then with an 23 wrench. 8 -Reposition the burner inside the 7 - Position and close the air housing.
  • Page 44 ADJUSTMENT TABLE FLAME 1, FLAME 2 AND FLAME 3 NATURAL GAS OVEN LPG 27,5mbar 10mbar NOZZLES 2,10 2,10 2,10 3,10 3,10 3,10 0,43 in 0,43 in 0,43 in 0,43 in 0,43 in 0,43 in USA and CANADA only...

  • Page 45: Before Use

    BEFORE USE Remove all plastic film protecting the appliance, blowing hot air to make it easier (hairdryer). Never open with sharp objects. SILL Do not use aggressive cleaning products on models that are equipped with a lava stone sill. Water and pure 30% pure alcohol are recommended: alcohol will dissolve the fat found on the stones and the water will capture it.

  • Page 46: Lighting Gas Oven

    LIGHTING THE OVEN ONLY FOR WOOD VERSION WARNING: Follow the instructions before turning on the oven. Do not use flammable liquids or other fuels to light the oven. Make sure that there are no flammable materials near the oven and that the minimum safety distance is respected FIRST IGNITION It is important to carefully control the oven temperature during the first lighting.
  • Page 47 7 - Use an infrared thermometer (not included) to gauge the oven floor temperature 8 - When the oven floor is the right temperature you’re ready to begin cooking your pizzas! Cook pizzas with the oven door off and feel free to replace the oven door with the same gap for air as mentioned in section 3 to keep heat and flame in the oven.
  • Page 48 IGNITION FOR QUICK 2 PIZZE AND QUICK 4 PIZZE GAS MODELS ONLY WARNING: Before firing up the oven, follow the instructions. - Check all gas connections before using the oven. - Do not lean over the oven when lighting it. - Keep your face and your body at least 50 cm away from the oven door.
  • Page 49 OTHER COMMANDS - To extinguish the flame of the main burner and leave only the pilot light on, turn the knob to the star. - To switch off the main burner and the pilot light, turn the knob to the “0” position. - If the flame does not light, release the knob and turn it back to the “0”...
  • Page 50 IGNITION ONLY FOR QUICK 6 PIZZE GAS OVENS RESET BOOSTER 2° FLAME TEMPERATURE If you are in USA or CANADA go to page 61-70...
  • Page 51 CONTROL UNIT FUNCTIONS LIST ONLY FOR QUICK 6 PIZZE GAS Burner on Switch Button to increase the power of the second flame F2”. Button to reduce the power of the second flame F2. Button to increase the set temperature. Booster function enable/disable button. Button to turn off and on the second flame manually.
  • Page 52 CHANGE UNIT OF MEASUREMENT CELSIUS / FAHRENHEIT STEP PICTURE ACTION Disconnect the voltage to the control unit from the main switch inside the room. Undo the 4 screws to open the Drago Control Plus control panel. On the back of the control panel identify the terminal block.
  • Page 53 FIRST IGNITION BLOCK / UNBLOCK BURNER STEP PICTURE ACTION Press the red “MAIN SWITCH" On the green display “OFF” is displayed and the internal temperature of the oven is dis- played on the red display. Press the red button to ignite the burner in “ON”.
  • Page 54 BURNER RELEASE VIA “RESET” BUTTON STEP PICTURE ACTION Check that the green light of the ON-OFF button is on. Press the “RESET” button. Wait approximately 1 minute for the cycle to restart. If the problem persists, vent the gas pipe and then repeat the unlock procedure.
  • Page 55 TEMPERATURE AND FLAME ADJUSTMENT THE MAXIMUM SETTABLE TEMPERATURE IS 450 °C CAUTION! THE SET COOKING TEMPERATURE F2 IS THE SAME AS THE OVEN OPERATING TEMPERATURE. STEP PICTURE ACTION Press the temperature up button until the temperature to be set shows on the green display.
  • Page 56 to obtain a flame as yellow and as bright as possible, however stop before soot depos- its on the cupola. Flame F1 has to switch off only in the case where: • The oven operator switches off the burner using the “ON/OFF”...
  • Page 57 FUNCTION BOOSTER The “Booster” function activates the operation of the 2nd flame F2, at the moment when the oven has reached the set temperature and then switched off. Once the time programmed in the “Booster” function has expired, the 2nd flame F2 starts to operate again in automatic mode.
  • Page 58 BURNER OPERATION WITH DAMAGED PROBE EMERGENCY PROCEDURE IMPORTANT! The emergency procedure must remain active only until the temperature probe has been replaced; then, the normal burner operation must be restored. In the emergency condition, being the temperature probe damaged or not working, it will not detect the temperature inside the oven.
  • Page 59 BURNER IGNITION (WITH EMERGENCY PROCEDURE ACTIVE) STEP PICTURE ACTION Press the “+” button ONCE. The low flame (within 5/10 seconds) and the corresponding LED light up. Press the “Booster” button. The high flame and related LED light up. Bring the oven to the desired temperature. Press the 'Booster' button to extinguish the high flame.
  • Page 60 ERROR MESSAGES COMMUNICATION IMAGE BLOC : Burner block; after three bLoc attempts the burner did not ignite • Check that all the gas valves on the piping are completely open. • Check that the ignition cable is connected to the Sit burner control equipment, to the ignition electrode and detection electrode on the burner.
  • Page 61 ---- - - - - (4 LINES): probe fault • Replace temperature probe...
  • Page 63 IGNITION ONLY FOR QUICK 6 PIZZE GAS OVENS INSTRUCTIONS FOR NORTH AMERICA ONLY USA and CANADA only...

  • Page 64: Control Unit Q6P

    CONTROL UNIT FUNCTIONS LIST ONLY FOR QUICK 6 PIZZE GAS INSTRUCTIONS FOR NORTH AMERICA ONLY Burner ignition Using the burner in auto mode with T° threshold control Manual flame control function Timed maximum boost power Burner block reset Programmed auto start activation Increase display value Decrease display value Faulty temperature probe signal LED.
  • Page 65 CHANGE OF MEASUREMENT CELSIUS / FAHRENHEIT INSTRUCTIONS FOR NORTH AMERICA ONLY STEP PICTURE ACTION Press F1 for 5 seconds. Than release the button Press again F1 and will be showed 00000 Press arrow + till compose 271 Now you are in the menù Select scale by using the arrow.
  • Page 66 BOOST FUNCTION INSTRUCTIONS FOR NORTH AMERICA ONLY STEP PICTURE ACTION Press the BOOST button to activate it The BOOST button activates maximum burner power with relative signal “Boost” on the display. Press buttons (+/-) to set the duration of the BOOST function. USA and CANADA only...
  • Page 67 TURN OFF THE BURNER INSTRUCTIONS FOR NORTH AMERICA ONLY STEP PICTURE ACTION Press the ON/OFF button and wait for the burner to turn off, confirmed by the relative icon on display. PROGRAMMED AUTO START THE MAXIMUM SETTABLE TEMPERATURE IS 450 °C STEP PICTURE ACTION...
  • Page 68 BURNER IGNITION AND USE IN AUTOMATIC MODE INSTRUCTIONS FOR NORTH AMERICA ONLY STEP PICTURE ACTION Press the ON/OFF button to ignite the burner. Press the AUTO button and wait for the flame to ignite. Adjust the oven operating temperature using the buttons (+/-).
  • Page 69 BURNER IGNITION MANUAL MODE INSTRUCTIONS FOR NORTH AMERICA ONLY STEP PICTURE ACTION Press the ON/OFF button to ignite the burner. Press MAN button and wiat for tha flame to ignite Adjust the oven temperautre using the button +/- The oven temperature is that set on the screen.
  • Page 70 TEMPERATURE SENSOR REPLACEMENT INSTRUCTIONS FOR NORTH AMERICA ONLY Pay special attention during sensor replacement, ensuring that the burner is turned off and that the oven temperature is below 40°C. 1. Remove any insulation close to the sensor 2. Extract the thermostat bulb in the oven dome 3.
  • Page 71 ALARMS INSTRUCTIONS FOR NORTH AMERICA ONLY PICTURE ACTION The burner has been blocked: press button R to release and WAIT 5 sec. AND KEEP BUTTON PRESSED FOR AT LEAST 5 sec. Temperature sensor short circuit: REPLACE SENSOR Sensor disconnected: CHECK THAT the connector plug has not been detached.
  • Page 72 1. Close the gas valve. 2. Loosen the bolts under the burner securing the burner to the base. 3. Gently pull the burner downwards ( taking care not to bend or break the ignition and flame detection devices) and remove from the hole. 4.

  • Page 73: Care And Maintenance

    CARE AND MAINTENANCE MAINTENANCE CALENDAR CLEANING TIME SCHEDULE Combustion chamber Every use Cooking floor Every use Oven outside Weekly Stainless-steel parts Weekly Steel protection Monthly Burner Monthly Nozzles Yearly Rust spots Biennially 1. Clean the combustion chamber. Pyrolysis 500°C (932°F). The Alfa ovens clean themselves thanks to a process called pyrolysis (pyro “fire”...
  • Page 74 4. Clean the stainless-steel parts. ALFA ovens are made with 304 stainless-steel outside and 253 stainless-steel inside. To clean these parts, we recommend that you use a stainless-steel cleaner. Please carefully read the warnings and the instructions. Do not use detergents containing acids, white spirit or xylene.
  • Page 75 CARE AND MAINTENANCE SPECIFICATIONS FOR WOOD-FIRED OVENS - Before lighting the oven make sure that the chimney flue is unobstructed and that any previous ash has been removed. - When the fire is out and the oven is cold, collect the ash from previous cooking with a wire brush and a shovel.

  • Page 76: Troubleshooting

    TROUBLESHOOTING WOOD-FIRED OVENS - Check that the firewood is not too wet and the embers are not unburned. - Make sure that you start a fire with a strong and constant THE OVEN flame so as to achieve complete combustion. SMOKES - If the oven is installed indoors, check that the chimney flue is not clogged and that the bends are no greater than...
  • Page 77 TROUBLESHOOTING GAS-FIRED OVENS - Check that no moisture or water have seeped into the oven. THE OVEN - Maybe you are lighting the oven for the first time, or you COOLS DOWN are doing it after the oven stood idle for too long. TOO EARLY - Refrain from making short-lived fires that would not heat the oven thoroughly.
  • Page 78 Country Pressure Country Pressure Albania 30 mbar Montenegro 30 mbar Andorra 30 mbar Norway 30 mbar Armenia 30 mbar Netherlands 30 mbar Austria 50 mbar Poland 37 mbar Azerbaijan 30 mbar Portugal 30 mbar Belgium 30 mbar 37 mbar Belarus 30 mbar Czech Rep.

  • Page 79: Warranty

    WARRANTY ALFA professional ovens are covered by a legally-required 12-month warranty against conformity defects. Good maintenance and proper use of the product will contribute to extending its lifespan. The time limit for reporting defects is 8 days from their discovery. For legal warranty regulations, please refer to the provisions of the individual national legislation of reference.
  • Page 80 The warranty does not cover the following: Damage caused by the carrier in provided, over the event of such damage not being 500°C (932° F), due to improper use of indicated immediately on the transport wood fuel; document by marking the product The case of the label on the back of “accepted with reservation”...
  • Page 82 NOTE...
  • Page 83 NOTE...
  • Page 84 www.alfaforni.com...
