Pro-Form PFEX16718.5 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

proform.com
Model No. PFEX16718.5
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today,
go to my.proform.com.
CUSTOMER CARE
For service at any time, go to
support.proform.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form PFEX16718.5

Summary of Contents for Pro-Form PFEX16718.5

  • Page 1 Model No. PFEX16718.5 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal REGISTER YOUR PRODUCT To register your product and activate your warranty today, go to my.proform.com. CUSTOMER CARE For service at any time, go to support.proform.com.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 STANDARD SERVICE PLANS...

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the new PROFORM ® reading this manual, please see the front cover of this SMART POWER 10.0 exercise bike. Cycling is an manual. To help us assist you, note the product model effective exercise for increasing cardiovascular fit- number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 7: Assembly

    ASSEMBLY 1. To use the assembly steps in this manual, first see the helpful tips below. • To hire an authorized service technician to • In addition to the included tool(s), assembly assemble this product, call 1-800-445-2480. requires the following tool(s): one Phillips screwdriver •...
  • Page 8 2. If there are shipping tubes (not shown) attached to the front and rear of the Frame (1), remove and discard the shipping tubes and the hardware attaching them. Orient the Front Stabilizer (2) as shown, and attach it to the Frame (1) with two M10 x 25mm Screws (69).
  • Page 9 4. Tip: See the inset drawing to learn how to operate the Adjustment Handle (14). Loosen handle Locate the Adjustment Handle (14) on the rear of the Frame (1). Pull the Adjustment Handle Pull handle outward, and insert the Saddle Post (7) into the Frame.
  • Page 10 6. Note: You can attach your own pedals if desired. Identify the Right Pedal (16). Using the included wrench, firmly tighten the Right Pedal clockwise into the Right Crank Arm (18). Firmly tighten the Left Pedal (17) counter- clockwise into the Left Crank Arm (not shown).
  • Page 11 8. See the inset drawing. Connect the connector on the Handlebar Wire (90) to the connector on the Frame Wire (82). Next, tighten the zip tie (C) around the indicated mark (D) on the Handlebar Wire (90). Then, cut off the excess zip tie. 9.
  • Page 12 10. While a second person holds the Console Mount (5) near the Handlebar (4), connect the Mount Wire (91) in the Console Mount to the Handlebar Wire (90) in the Handlebar. Tip: Avoid pinching the wires. Gently pull on Avoid pinching the wire tie (E) as you slide the Console Mount the wires (5) onto the Handlebar (4).
  • Page 13 12. Connect the connectors on the Console Wire (I) to the connectors on the Mount Wire (91). Next, insert the connectors into the Console Mount (5), and then press the Wire Protector (98) into the Console Mount. Tip: It may be helpful to insert the connectors into the Console Mount one at a time.
  • Page 14 14. Plug the Power Adapter (86) into the receptacle in the Frame (1). Note: To plug the Power Adapter (86) into an outlet, see HOW TO PLUG IN THE POWER ADAPTER on page 15. To register your product and activate your warranty today, go to my.proform.com.

  • Page 15: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO PLUG IN THE POWER ADAPTER HOW TO ADJUST THE ANGLE OF THE SADDLE IMPORTANT: If the exercise bike has been exposed You can adjust the angle of the saddle to the position to cold temperatures, allow it to warm to room tem- that is most comfortable.
  • Page 16 HOW TO ADJUST THE SADDLE POST HOW TO ADJUST THE HANDLEBAR For effective exercise, the saddle should be at the To adjust the proper height. As you pedal, there should be a slight height of the bend in your knees when the pedals are in the lowest handlebar, first position.
  • Page 17 HOW TO USE THE PEDALS HOW TO USE THE BRAKE KNOB To use the pedals To change the resis- (G), insert your shoes tance of the pedals, into the toe cages press the buttons on and pull the ends of the console (see step the toe straps.

  • Page 18: How To Use The Console

    HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals with the touch The advanced console offers an array of features of a button. designed to make your workouts more effective and enjoyable.
  • Page 19 HOW TO ACTIVATE THE CONSOLE HOW TO USE THE TOUCH SCREEN The included power adapter must be used to operate The console features a tablet with a full-color touch the exercise bike. See HOW TO PLUG IN THE screen. The following information will help you use the POWER ADAPTER on page 15.
  • Page 20 HOW TO SET UP THE CONSOLE 5. Check for firmware updates. Before you use the exercise bike for the first time, set First, touch the menu button (three horizontal lines up the console. symbol), touch Settings, touch Maintenance, and then touch Update. The console will check for firm- 1.
  • Page 21 HOW TO USE THE MANUAL MODE Drag upward on the screen to enter the fullscreen display mode. Drag downward on the screen to 1. Touch the screen or press any button on the view the workout information displays. console to turn on the console. Touch the various workout information displays See HOW TO ACTIVATE THE CONSOLE on to view more options.
  • Page 22 HOW TO USE A FEATURED WORKOUT OR AN To draw your own map for a workout, see HOW TO ONBOARD WORKOUT CREATE A DRAW-YOUR-OWN-MAP WORKOUT on page 24. 1. Touch the screen or press any button on the console to turn on the console. When you select a workout, the screen will show an overview of the workout that includes details See HOW TO ACTIVATE THE CONSOLE on...
  • Page 23 If the resistance level is too high or too low, you When the workout ends, a workout summary will can manually override the setting by pressing the appear on the screen. If desired, you can select Digital Quick Resistance buttons. If you press a options such as adding the workout to your sched- Digital Quick Resistance button, you can then ule (see HOW TO USE AN IFIT WORKOUT on...
  • Page 24 HOW TO CREATE A DRAW-YOUR-OWN-MAP If you make a mistake, touch Undo in the map WORKOUT options. 1. Touch the screen or press any button on the The screen will display the elevation and distance console to turn on the console. statistics for your workout.
  • Page 25 HOW TO USE AN IFIT WORKOUT To switch users within your iFit account, touch the menu button, touch Settings, and then touch To use an iFit workout, the console must be connected Manage Accounts. If more than one user is associ- to a wireless network (see HOW TO CONNECT TO A ated with the account, a list of users will appear.
  • Page 26 HOW TO CHANGE CONSOLE SETTINGS 3. Customize the unit of measurement and other settings. IMPORTANT: Some of the settings and features described may not be enabled. Occasionally, a To customize the unit of measurement, the time firmware update may cause your console to function zone, or other settings, touch Equipment Info or slightly differently.
  • Page 27 HOW TO CONNECT TO A WIRELESS NETWORK Note: You must have your own wireless network and an 802.11b/g/n router with SSID broadcast To use iFit workouts and to use several other features enabled (hidden networks are not supported). of the console, the console must be connected to a wireless network.
  • Page 28 HOW TO USE THE SOUND SYSTEM THE OPTIONAL CHEST HEART RATE MONITOR To play music or audio books through the console Whether your sound system while you exercise, plug a 3.5 mm male goal is to to 3.5 mm male audio cable (not included) into the burn fat or to jack on the right side of the console and into a jack on strengthen your...

  • Page 29: Fcc Information

    FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 30: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING HOW TO MAINTAIN THE EXERCISE BIKE operation is complete, the console will turn off and then turn back on. If it does not, unplug and then plug in the Regular maintenance is important for optimal power adapter. Once the console turns on, check for performance and to reduce wear.
  • Page 31 HOW TO ADJUST THE DRIVE BELT Then, tighten the M10 x 50mm Screw (65) until the Drive Belt (not shown) is tight. If the pedals slip while you are pedaling, even when the resistance is adjusted to the highest level, the drive When the Drive Belt (not shown) is tight, reattach the belt may need to be adjusted.

  • Page 32: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 33: Part List

    PART LIST Model No. PFEX16718.5 R1220A Key No. Qty. Description Key No. Qty. Description Frame Foot Front Stabilizer Leveling Foot Rear Stabilizer Stabilizer Cap Handlebar/Upper Wire Saddle Post Cap Console Mount Bracket Mount Console Reed Switch/Wire Saddle Post Clamp Saddle...

  • Page 34: Exploded Drawing

    EXPLODED DRAWING A Model No. PFEX16718.5 R1220A...
  • Page 35 EXPLODED DRAWING B Model No. PFEX16718.5 R1220A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
