Patent Pending
Model No. PFEX17931
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
If you have questions, or if
there are missing parts, we will
guarantee complete satisfac-
tion through direct assistance
from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Pro-Form GL36
Summary of Contents for Pro-Form GL36
- Page 1 Patent Pending Model No. PFEX17931 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guarantee complete satisfac- tion through direct assistance from our factory.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the exercise cycle. 1. Read all instructions in this manual before readings. The pulse sensor is intended only using the exercise cycle. as an exercise aid in determining heart rate trends in general. -
Page 4: Before You Begin
Congratulations for selecting the new PROFORM ® Service Department toll-free at 1-800-999-3756, GL36 exercise cycle. Cycling is one of the most effec- Monday through Friday, 6 a.m. until 6 p.m. Mountain tive exercises for increasing cardiovascular fitness, Time (excluding holidays). To help us assist you, building endurance, and toning the entire body. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included tools and your own adjustable wrench and Phillips screw- driver Use the part drawings below to identify the small parts used in assembly. - Page 6 1. Identify the Front Stabilizer (2). While another person lifts the front of the Frame (1), attach the Front Stabilizer to the Frame with two M10 x 112mm Carriage Bolts (65) and two M10 Black Nylon Locknuts (63). Make sure that the Front Stabilizer is turned so the Wheels (30) are not touching the floor.
- Page 7 4. Slide the two Handlebar Collars (7) onto the Left Handlebar (50). Insert the Right Handlebar (51) into the Left Handlebar. Connect the Handlebar Collars, the Left Handlebar, and the Right Handlebar with two M4 x 16mm Screws (66). Attach the Handlebar Bracket (15) to the Left and Right Handlebars (50, 51) with four M8 x 22mm Button Screws (74).
- Page 8 8. Attach the Seat (12) to the Seat Bracket (6) with four M8 Nylon Locknuts (10) and four M8 Split Washers (70). Note: The Nylon Locknuts and the Split Washers may be pre-attached to the underside of the Seat. Turn the indicated Adjustment Knob (28) counterclock- wise two or three turns to loosen it.
-
Page 9: How To Operate The Exercise Cycle
HOW TO OPERATE THE EXERCISE CYCLE HOW TO ADJUST THE SEAT POST HOW TO ADJUST THE UPRIGHT For effective exer- The upright can be cise, the seat adjusted to the should be at the height that is the Seat proper height. As most comfortable for Upright you pedal, there... - Page 10 Fan Button Display Buttons On/Reset Button Resistance Buttons FEATURES OF THE CONSOLE sonal trainer in your home. Using a stereo audio cable (available at electronics stores), you can connect the The advanced console offers a selection of features exercise cycle to your home stereo, portable stereo, designed to make your workouts more enjoyable and computer, or VCR and play special iFIT.com CD and effective.
- Page 11 seconds. If you use the handgrip pulse sensor, HOW TO USE THE MANUAL MODE the display will also show your heart rate (see step 5 on page 12). Turn on the console. To view only the distance Upper Button you have pedaled or the Note: The console requires four 1.5V “D”...
- Page 12 To reset the displays, press the On/Reset button. For the most accurate heart rate reading, continue to hold the handgrips for about 30 seconds. Note: Note: The con- When you first hold the handgrips, the large dis- sole can show play will show your heart rate continuously for 30 speed and dis- seconds.
- Page 13 The target pace HOW TO USE A SMART PROGRAM for the current Indicator period will be shown by the Each Smart program will automatically change the arrows in the Arrows resistance of the pedals and prompt you to increase or small display.
- Page 14 to operate properly. Each time you hold the HOW TO USE A HEART RATE PROGRAM handgrips, keep your hands on the metal con- tacts for at least 30 seconds. Note: When you are not holding the handgrips, the letters PLS will Heart Rate program 1 is designed to keep your heart appear in the large display instead of your heart rate between 65% and 85% of your maximum heart...
- Page 15 Note: If you stop pedaling for a few seconds, the HOW TO CONNECT YOUR CD PLAYER, VCR, program will end. To use the program again, rese- OR COMPUTER lect it and start it at the beginning. Follow your progress with the large display. To use iFIT.com CDs, the exercise cycle must be con- nected to your portable CD player, portable stereo, home See step 4 on page 11.
- Page 16 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an RCA-type AUDIO OUT Note: If your stereo has an unused LINE OUT jack, jack, see instruction A below. If your stereo has a see instruction A below.
- Page 17 HOW TO CONNECT YOUR COMPUTER HOW TO CONNECT YOUR VCR Note: If your computer has a 1/8” LINE OUT jack, Note: If your VCR has an unused AUDIO OUT jack, see instruction A. If your computer has only a see instruction A below. If the AUDIO OUT jack is PHONES jack, see instruction B.
- Page 18 The program will function in almost the same way HOW TO USE IFIT.COM CD AND VIDEO as a Smart program (see step 3 on page 13). PROGRAMS However, an electronic “chirping” sound will alert you when the resistance level and/or the target pace is about to change.
- Page 19 Start your Web browser, if necessary, and go HOW TO USE PROGRAMS DIRECTLY FROM to our Web site at www.iFIT.com. OUR WEB SITE Follow the desired links on our Web site to select a program. Our Web site at www.iFIT.com allows you to play iFIT.com programs directly from the internet.
-
Page 20: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise cycle reg- • For the most accurate heart rate reading, hold the ularly. Replace any worn parts immediately. metal contacts for about 30 seconds. To clean the exercise cycle, use a damp cloth and a •... -
Page 21: Conditioning Guidelines
CONDITIONING GUIDELINES The following guidelines will help you to plan your During the first few minutes of exercise, your body exercise program. Remember that proper nutrition uses easily accessible carbohydrate calories for ener- and adequate rest are essential for successful results. gy. -
Page 22: Part List
PART LIST—Model No. PFEX17931 R0603A Key No. Qty. Description Key No. Qty. Description Frame Flywheel Axle Front Stabilizer Flywheel Bearing Rear Stabilizer “C” Magnet Rear Endcap Left Crank Arm Seat Post Reed Switch/Wire Seat Bracket Crank Bearing Assembly Handlebar Collar M5 Nut Foam Grip Adjustment Cable... -
Page 23: Exploded Drawing
EXPLODED DRAWING—Model No. PFEX17931 R0603A... -
Page 24: How To Order Replacement Parts
• The NAME of the product (PROFORM ® GL36 exercise cycle) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 22) PROFORM is a registered trademark of ICON Health &...
