Chapter 4: Storing or Shipping the Instrument

Before you move the instrument, make sure that the new location is a dry, flat work area that
has sufficient space for the instrument, host computer, and required cables.
Tip: Although you can always carry the instrument, depending on the distance that you
are moving it, you might use a rolling cart instead.
If you must store the instrument, then store it in a dry, dust-free, environmentally controlled
area. The storage temperature can range from -20°C to 65°C.
To minimize the possibility of damage during storage or shipment, you should pack the
instrument in the original packaging materials. Correctly repacking the instrument includes
following applicable decontamination procedures and packing instructions.
CAUTION! When transporting the instrument, warranty claims are void if improper
packing results in damage to the instrument.

Packing the Instrument

The original packaging is designed to protect the instrument during shipment and storage. You
must always pack the instrument before you ship it or store it.
To pack the instrument:
1. Make sure the plate drawer chamber and filter cube chamber are empty.
2. Power off the instrument.
3. Disconnect the power cord and USB cable from the rear of the instrument.
4. Locate the transport lock that you stored in the accessories case.
Item
5090341 C
Description
1 Screw #1 fastens the transport lock to the internal frame of the instrument (install last)
2 Screw #2 fastens the transport lock to the plate drawer
3 Screw #3 fastens the transport lock to the plate drawer
4 Plate drawer
5 Plate chamber door in open position
6 Plate drawer transport lock
