Atdec AWMS-DW6 Installation Manual page 3

1. Install Wall Channel - Ensure all fasterners are installed
1.1 Masonry
2. Fit channel clamp to wall channel
2.1 Ensure knob is undone.
3. Fit top cap to wall channel
3.1 Fit Top Cap
8mm ( 5 /
16
Nylon anchors
M6 x 50mm
Screws
2.2 Slide clamp into channel.
2. Slide clamp into channel
Phillips Head
Screwdriver
Top Cap
1.2 Timber stud
") holes
3. Hold clamp in desired position on post a
knob to lock in place
Push knob to
Tip: push knob
aid insertion
to aid insertion
4mm (
M6 x 50mm
Screws
2.3 Hold clamp in desired position on post
and turn knob to lock in place.
AWMS-DW6 | Page 3 of 7
5 / ") holes
32
