Wall Channel
COMPONENT CHECKLIST
A
Wall channel
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! This product is compatible with AWM Series products.
! The manufacturer accepts no responsibility for incorrect installation.
B
Top Cap
Top Cap
Screws
(x1)
(x2)
D
M6 x 50mm
Nylon
Countersunk
Anchor (x2)
Screw (x2)

Installation Guide

C
E
AWM-W6
REQUIRED TOOLS
• Power Drill
• 5.5mm (
/
") Drill Bit
1
4
• 8mm (
/
") Drill Bit
5
16
• Phillips Head Screwdriver
AWM-W6 Page 1 of 2
