INSTRUCTION MANUAL: SKU#272-1863/272-1977/272-1978
CAUTION: Read all instructions before assembly. Failure to do so may result in faulty assembly and potential injury.
SPECIAL WARNINGS: Assemble on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item.
Noted: Identify all parts packed in carton against the parts list. Remove all the protective material carefully and DO NOT use
a knife to prevent scratching the surfaces. USE ONLY ON LEVEL SURFACES. INSPECT VISUALLY BEFORE EACH USE AND
ENSURE ALL HARDWARE IS PROPERLY TIGHTENED.
CUSTOMER SERVICE
: For questions, assistance or repair parts,
between 9am and 5pm Eastern Time, Monday through Friday.
A
B
X 2
H
I
X 1
4-PIECE HIGHLAND HILLS SEATING SET
C
D
X 2
X 2
J
K
X 1
X 4
please call at: 1-877-898-3958, or pa�oparts@gmail.com
E
X 2
L
X 4
F
G
X 2
X 1
M
N
X 1
X 4
X 1
X 1
Advertisement
Table of Contents
Related Manuals for Backyard Creations 272-1863
Summary of Contents for Backyard Creations 272-1863
- Page 1 INSTRUCTION MANUAL: SKU#272-1863/272-1977/272-1978 4-PIECE HIGHLAND HILLS SEATING SET CAUTION: Read all instructions before assembly. Failure to do so may result in faulty assembly and potential injury. SPECIAL WARNINGS: Assemble on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item.
- Page 2 PARTS LIST X 12 X 12 X 56 M6 * 20 M6 * 30 M6 * 40 M6 * 60 X 20 M4 * 12 ASSEMBLY INSTRUCTIONS Fig.1 ● Assemble right/le� armrest (A/B) and part (C), using bolt (1) + washer (5) Fig.2 ●...
- Page 3 ASSEMBLY INSTRUCTIONS Fig.3 ● Assemble Fig.2 and chair back panel (E) using bolt (2) and washer (5) Fig.4 ● Put back & seat cushion on assembled frame Fig.5 ● Assemble right/le� armrest (G/F) and loveseat seat panel (H) using bolt (4), 2 pcs washer (5) + Lock nut (6)
- Page 4 ASSEMBLY INSTRUCTIONS Fig.6 ● Assemble Fig.5 and loveseat back panel (I) using bolt (2) + washer (5) Fig.7 ● Put back & seat cushion on assembled frame Fig.8 ● Insert table leg (M) into table frame (L)
- Page 5 ● Assemble table support ring (N) to table legs using bolt (3), washers (5) and lock nut (6) BACKYARD CREATIONS® MANUFACTURER‘S WARRANTY (Limited 1-Year Warranty) This product is covered under the manufacturer’s one year limited warranty against defects in workmanship and materials. If your product fails structurally during normal use within one year of purchase, the manufacturer will repair or replace the defective unit at no charge.
