5. Slide the Seat (23) to the front of the Rail (2).
Next, attach the Rear Stop (87) to the Rail (2)
with two M4 x 8mm Screws (104).
Then, attach the Rail Cap (38) to the Rail (2)
with two M4 x 19mm Screws (69).
6. While a second person holds the Console (75)
near the Neck (76), plug the Upright Wire (84)
into the receptacle on the Console.
The connector on the Upright Wire (84)
should slide easily into the receptacle and
snap into place. If the connector does not slide
easily into the receptacle, turn the connector and
try again. If you do not connect the connector
properly, the Console (75) may become dam-
aged when you use the rower.
Insert the excess wire into the Neck (76) or into
the Console (75).
Tip: Avoid pinching the wires. Attach
the Console (75) to the Neck (76) with four
M4 x 12mm Screws (105); start all the Screws,
and then tighten them.
5
104
87
69
38
69
6
75
84
8
23
2
105
76
105
Avoid pinching
the wires
