Summary of Contents for Renogy ONE M1
- Page 1 Renogy ONE VERSION A0 QUICK GUIDE...
- Page 2 This Quick Guide contains important installation, operation, and maintenance instructions for Renogy ONE M1, hereinafter referred to as “Renogy ONE”. Please read the Quick Guide carefully before using the device. For additional support, contact our customer service through renogy.com/contact-us/. Scan the QR code to install DC Home app.
-
Page 3: Table Of Contents
Table of Contents Package Contents ........................02 Product Overview ........................03 Wiring Diagram ........................05 Communication Diagram ......................06 Renogy ONE Communication Architecture ............... 06 Energy Device Communication Connections ..............06 Installation ..........................08 Preparation ........................08 Mounting Location ......................11 Embedding ........................ -
Page 4: Package Contents
Package Contents Quick Guide × 1 M2 Screws × 4 12V Power M4 Mounting Cable (5m) × 1 Screws × 4 ST2 x 1.2 x 6.5 mm ST4 x 2 x 13 mm... -
Page 5: Product Overview
Product Overview Part Part Power Button Panel Switch 2 Screen Panel Switch 3 Panel Switch 1... - Page 6 Power Port IN 2 (External Load Input Terminal) RJ45 Port OUT 2 (External Load Output Terminal) Alternate Power Input Port (Type-C) z Please inspect Renogy ONE for any visible damage including cracks, dents, deformation, and other visible abnormalities before installation.
-
Page 7: Wiring Diagram
Illustrations in the Quick Guide are for reference only. z Renogy ONE is only suitable for safe use in areas below 2,000 meters above sea level. z There are no user serviceable parts inside Renogy ONE. Do not disassemble or attempt to repair it. -
Page 8: Communication Diagram
Charge Controller Inverter Battery Charger Devices To ensure good compatibility, it is recommended to use Renogy's energy devices and smart accessories. Energy Device Communication Connections Bluetooth 1. For devices with a built-in Bluetooth module or 2. For devices connected to Renogy... - Page 9 For REGO series products connected with RV-C daisy chain topology: RV-C Daisy Chain Topology Renogy ONE Device 1 RV-C RV-C Communication Communication Cable Cable RV-C Communication Cable Device 2 Device N For backbone topology, please contact our customer service through renogy.com/contact-us/.
-
Page 10: Installation
Installation Preparation Mounting Location Embedding Wiring Mounting Preparation Required Tools Phillips Screwdriver (#1) Phillips Screwdriver (#2) Insulation Tape Skill Saw... - Page 11 Mounting Template Please tear off this piece of paper and paste it to the mounting location for drilling holes. You can also use another piece of paper as the mounting template. The installation hole comes in 110 mm × 65 mm (4.33 in x 2.56 in). 65mm (2.56in) 110mm (4.33in)
-
Page 13: Mounting Location
A reverse polarity contact will result in abnormal operations. The length of the extension cable should not exceed 10 meters. z Ensure that the base cover of Renogy ONE is firmly mounted to the wall to prevent it from falling off. Power Supply 1.1.1... - Page 14 1.1.5 1.1.6 Tear off the mounting template. Remove the base cover of Renogy ONE. Put the backside of the base cover into the installation hole, and use a Phillips screwdriver to fasten the base cover with four M4 mounting screws through the mounting hole.
-
Page 15: Embedding
Embedding 12V Power Cable z Renogy ONE can be connected to a power supply of up to 16V; otherwise Renogy ONE may be damaged. z Illustrations in this Quick Guide are based on scenarios where REGO 12V 400Ah Lithium Iron Phosphate Battery and REGO 3 Ports 400A Battery Combiner Box are adopted as power supplies. - Page 16 Embedding Wiring Mounting Communication Cables Renogy ONE can communicate with Renogy energy devices in several ways: 1. Bluetooth wireless communication; 2. Wired communication based on RS485 protocol; 3. Wired communication based on RV-C protocol. You can choose an appropriate communication method according to the actual situation. For RS485 or RV-C communication, you need to pre-embed the communication cable in the installation hole.
- Page 17 1.2.2.1 1.2.2.2 Measure whether the communication cable can Pre-embed the RJ45 connector of the be connected to Renogy ONE and other devices. communication cable into the installation hole. Connect the other end of the RV-C Daisy Chain topology RS485 connection...
- Page 18 Mounting External Load Renogy ONE comes with 3 relays which can be connected to 3 DC loads (≤30V DC, ≤5A). You can power on/off the loads via Panel Switches on Renogy ONE. For users who do not need external loads, no adapter cable pre-embedding is required.
- Page 19 Installation Preparation Mounting Location Embedding Wiring Mounting Connect one of the ring terminals of the adapter cable to the negative terminal of the power supply device, and connect the other end to the negative pole of the load. DC load (≤30V DC, ≤5A) 1.2.3.1 Connect the bare wire cable to...
-
Page 20: Wiring
Renogy ONE. For additional support, please contact our customer service through renogy.com/contact-us/. z Risk of electric shock! Please power off the power supply after the test on power-on of Renogy ONE is completed. - Page 21 1.3.3.2 Insert the reserved adapter cable connecting to the positive terminal of the load into the Renogy ONE output terminal (OUT), and use a Phillips screwdriver to turn the wire DC load hatch screw clockwise. (≤30V DC, ≤5A)
- Page 22 Embedding Wiring Mounting Insert the adapter cable connecting to the positive end of the power supply into the Renogy ONE input terminal (IN), and use a screwdriver to turn the wire hatch screw clockwise. 1.3.3.4 Make sure all connections are tight and secure.
-
Page 23: Mounting
Preparation Mounting Location Embedding Wiring Mounting Mounting z Make sure that Renogy ONE is installed securely to prevent it from falling off. Disassemble Panel Switch 1 and Panel Switch 3 from Renogy ONE. 1.4.1 Put the Renogy ONE on the... -
Page 24: Operation
Home binding, and device adding via the activation wizard. z You can tap “Skip” in the upper right corner of the main interface on Renogy ONE to skip some of the wizard steps. You can re-complete the activation operations through “Settings”. -
Page 25: Add Devices
To ensure good compatibility, it is recommended to use Renogy energy devices and smart accessories. z For adding Bluetooth devices to Renogy ONE through DC Home app, refer to the user manual of Renogy ONE at renogy.com. Power On/Off... -
Page 26: Control External Loads
Binding Add Devices Power On/Off Control External Loads Control External Loads The 3 panel switches of Renogy ONE correspond to 3 panel relays respectively. Control CH3 Control CH2 Control CH1 2.2.1 Press the panel switches to power on/off external loads. -
Page 27: Maintenance
Maintenance For optimum performance, it is recommended to perform these tasks regularly. z Ensure Renogy ONE is mounted in a clean, dry, and ventilated area. z Ensure there is no damage or wear on the cables. z Make sure the communication cable connectors and power connectors are secure. - Page 28 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 29 Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
- Page 30 find relevant documentation or get more support via "Contact Us". Renogy reserves the right to change the contents of this manual without notice. Join the Renogy Power Plus Community by downloading the DC Home App. Find your e-warranty here, and more.
