5.2 Changing the Set Up Parameters
The set up parameters are divided into two sections:
• System, controlling the aspects of the system that are not specific to
the chartplotter
• Chart, controlling the chartplotter, including waypoint information,
vectors and radar/chart synchronisation.
This section provides instructions for displaying and changing the default
values. The following sections list the parameters and their possible
settings, and describe the function of each parameter in turn.
To set the default parameters:
1. Press the MENU key to display the set up soft keys for the current
full-screen mode. For Chart Mode, they are as follows:
2. Press the soft key for the set up you require.
The requested set up menu is displayed, listing the parameters and
their current settings.
3. Use the trackpad to move the selection bar up and down the list. An
arrow is displayed at the top or bottom right-hand corner if you can
scroll the list to display further parameters.
As each line is highlighted, the soft key labels are updated to show
the settings available.
-
-
4. Press the soft key corresponding to the desired setting or, for scroll
lists, use the soft keys to scroll forwards or backwards through the list
until the required setting is highlighted. This setting is retained when
you move the selection bar on to the next parameter in the menu list.
5. Once you have reset all the required values, press ENTER to clear
the menu and return to the set up soft keys.
SYSTEM
CHART
SET UP!
SET UP!
For parameters that have a numeric value, or more than four
possible settings, a scroll list is displayed above two of the soft
keys.
For some parameters, a soft key provides access to a sub-menu
of further options.
HSB Series Chartplotter
TRACK
GPS
SET UP!
SETUP!
D4162-1
