24
Returning to the Full-Screen Display
In an emergency, you may wish to return to full-screen display mode.
You can turn windows off, as described above. Alternatively, to return to
full-screen display without data boxes or windows:
Press and hold the DISPLAY key for 2 seconds to return to the currently
selected full-screen display.
Moving Around the Chart
You will normally operate the chartplotter with the chart showing your
vessel's current location. In the default North-Up orientation, the display
is in Standard Motion mode, in which the vessel moves across the
screen. You will need to move the chart if your vessel moves out of the
area currently displayed, or if you wish to examine or place waypoints in
another area. Alternatively, you can home the cursor onto the vessel
using FIND SHIP; this function can also be used on a combined display
to sychronise the radar and chart windows as described in Using FIND
SHIP .
There are four ways in which you can move the chart:
• Use the trackpad to move the cursor to the edge of the chart. The
chart will pan across. This method is useful if the area you wish to see
is only just off the screen.
• Use the context-sensitive cursor to change the chart centre.
• Automatically re-centre the vessel using the FIND SHIP soft key.
• Change the chart scale to zoom out and in to a new area. This method
is useful if the area you wish to see is a long distance away.
Changing the Chart Centre
You can move the area of the chart displayed on the screen using the
context-sensitive cursor. This allows you to centre your vessel in the
middle of the screen, or to move the chart so that your vessel is
displayed off-centre anywhere on the screen.
To centre the chart:
1. Use the trackpad to move the cursor to the vessel's position. The
cursor text POS is displayed.
2. Press CLEAR. The chart is moved so that your vessel's position is in
the centre of the screen.
HSB Series Chartplotter
