54
If you wish to name the route press the YES soft key. Use the
trackpad to move the cursor right or left to the character you wish to
edit. Then use the top or bottom of the trackpad to increase or
decrease the letter or number.
5. Press ENTER to finish and clear the Name List, then to return to the
default soft key display, press ENTER again.

Clearing the Current Route

You can clear the current route from the screen. When you select
CLEAR ROUTE if the current route has not been saved, you have the
option of saving it and, if you are following the current route, you have the
option to stop.
To clear the current route:
1. Press the ROUTE default soft key or place the cursor over a route
CLEAR
leg until the text RTE is displayed.
ROUTE
Press the CLEAR ROUTE soft key.
2. If you are following the current route the STOP FOLLOW soft keys
are displayed.
To cancel the CLEAR operation press NO.
To stop following and clear the route press YES.
3. If the route has not been saved the SAVE ROUTE soft keys are
displayed.
To clear the route, without saving it in the route database, press NO.
To save the route in the database, press YES. The Name route soft
keys are displayed and you should continue as described in the
previous section, Saving the Current Route.
The current route is cleared from the screen and the default soft keys are
displayed. You can now use the ROUTE soft keys to make a route, or to
show another route from the database.

Retrieve a Route From the Database

You can select a route as the current route from the database list. The
list is accessed from the second set of ROUTE soft keys.
To select a route as the current route:
1. Press the ROUTE soft key, followed by MORE, then press ROUTE
ROUTE
LIST
LIST. The route list is displayed. The grey selection bar indicates the
selected route.
HSB Series Chartplotter
