1.1 Introduction

How this Handbook is Organised

This handbook describes the HSB Series Chartplotter RC520 and the
charting functions of the combined Radar/Chartplotter RL70RC (refer to
the Pathfinder HSB Series Radar Handbook, also provided with the
combined system, for details on the radar functions). If you are using any
HSB series 7" display unit as a chart repeater display you should refer to
this handbook.
The handbook is organised as follows:
Chapter 1 provides an overview of the features and functions of the
HSB Series Chartplotter. You should read this chapter to familiarise
yourself with the system.
Chapter 2 provides an overview of the controls. It also explains how to
start using the chartplotter and includes operating guidelines for typical
scenarios; these guidelines introduce you to many of the chartplotter
functions.
Chapters 3 provides detailed operating information for the main
chartplotter functions - plotting waypoints and routes, following routes
and showing tracks.
Chapter 4 provides detailed operating information for further chart
functions, including measuring distances, man overboard and cursor
echo. It includes instructions for setting up a differential GPS.
Chapter 5 provides instructions for setting up your chartplotter system to
suit your preferences. You should read Chapter 5 to determine how to
set up the system defaults.
Chapter 6 provides planning considerations and detailed instructions for
installing the chartplotter. It should be referred to when you are ready to
install the chartplotter.
Chapter 7 provides information on user maintenance, and what to do if
you experience problems.
Appendix A lists the technical specifications for the Chartplotter.
A List of Abbreviations, an Index and warranty information are
included at the end of the handbook.
