Amcrest IP8M-TB2886EW-AI User Manual page 7

1. Stick the installation sticker on the installation surface.
2. Drill 3 holes through the holes on the installation sticker. A 1" paddle bit can also be used if installing wires through
an installation surface.
3. Insert the included wall anchors into the newly drilled holes.
4. Align the bottom bracket of the camera to the installation holes. Then using a Phillips head screwdriver, secure the
camera to the installation surface.
5. To adjust the camera up, down, or side to side, use the included torx wrench to loosen the lock and unlock bracket
bolt on the bottom bracket.
Note: An included analog cable can be used on an analog monitor if needed. The analog connection is found in the
bottom security latch of the camera. The included torx wrench will be needed to open the latch. Secure the latch
when finished.
6. When adjusted, turn the lock and unlock bolt to secure the camera in place.
7. Place the top portion of the casing over the camera and installation bracket and use the included torx wrench to
tighten the security screw back onto the casing. Do not overtighten the security screw as it may not properly be
secured if overtightened.
Camera Access
This section will provide information on how to setup and access your camera through the following methods:
Local PC (Web User Interface (Web UI), Amcrest Surveillance Pro, etc.)
Amcrest View Pro app
Amcrest Surveillance Pro (amcrest.com/downloads)
Amcrest Cloud
Default Username and Password
To login to the system for the first time, use one of the following default username/password combinations. Once
you have successfully logged in, it is highly recommended to change the password for security reasons.
Username: admin
Password: admin
1 Network Camera
2 Mounting Screws
3 Wall Anchors
4 Install Template
Installation Guide
7
