Amcrest IP8M-TB2886EW-AI User Manual page 41

To reset to default settings, click the Reset Defaults button. To refresh the page, click the Refresh button. To save
the settings, click the Save button.
Smart Motion Detection
Smart Motion Detection (SMD) uses an advanced algorithm to differentiate human and vehicular shapes within a
scene and send alarms only when a person or vehicle is detected. This option works alongside motion detection to
help prevent false alerts. Below is a description of the features in this menu.
Enable: Use this checkbox to enable Smart Motion Detection.
Effective Object: The object filter checkboxes allow the camera to be triggered only when a specific object, such as
a human or car, is detected by the camera. Both effective object checkboxes can be activated at the same time.
Human: This checkbox allows the camera to be triggered only when a human figure is detected.
Motor Vehicle: This checkbox allows the camera to be triggered only when a vehicle has been detected.
Sensitivity: Use this dropdown menu to select a sensitivity setting for smart motion detection. The sensitivity can
be set as low, medium, or high.
Record: This checkbox allows the user to enable the camera to record once an event is detected.
Record Delay: This field specifies, in seconds, how long the delay between events should be. The default is 10
seconds however this can be modified between 10~300 seconds.
Relay Out: This checkbox allows the user to enable the camera to trigger a connected alarm (connected to the alarm
port on the back of the camera) when a video tamper alarm is triggered.
Alarm Delay: This field specifies in seconds how long the delay between alarm activation and Relay alarm activation
should be.
Send Email: This checkbox allows the user to enable the camera to send an email when an event is triggered.
Siren: This checkbox allows the user to enable a siren or custom audio file to be activated once the rule is triggered.
Snapshot: This checkbox allows a snapshot of the IVS event to be sent via email when triggered.
To reset to default settings, click the Reset Defaults button. To refresh the page, click the Refresh button. To save
the settings, click the Save button.
People Counting
People Counting is used to provide a statistic based up the number of people who enter and exit a certain area on
the live view screen. There is also a second people counting option which will trigger only when a certain number
of people have entered or exited a detection area. Please note, these two people counting rule types cannot be
used simultaneously in the interface.
For optimal results, it is recommended to use this rule type on Internet Explorer, IE mode on Microsoft Edge, or
similar web browser as counting overlays and setting a detection area may require the use of a plugin.
People counting data can be displayed for each rule type in the Report tab. For more information on people
counting please refer to the information provided below.
Using the NumberStat Rule Type
This will be the default rule type for people count. The NumberStat rule type allows the user to count the number
of people who enter or exit an area. It is recommended to use this rule type on Internet Explorer, IE mode on
Microsoft Edge, or similar web browser as the counting overlay may require a plugin. Below is a description of the
features provided in this menu.
Enable: This checkbox is used to enable or disable the people counting feature.
41
