  • Page 1 ™ INSTALLATION GUIDE INTERCONNECTED EDITION...
  • Page 2 Go to Lockly.com/installation to watch a video version of this installation guide.
  • Page 3 Welcome! This guide will walk you through step-by-step how to install and get your Lockly Duo up and running. ™ Installation generally takes less than 30 minutes. If you have any questions please reference our online support at: Lockly.com/support or call (669) 500-8835 for help.
  • Page 4 Preparation To complete the installation you will need: Flathead Screwdriver Tape measure or ruler Phillips Screwdriver Optional Screwdriver with drill bits Pliers Drilling maybe required to install this lock. If you are installing your lock on a brand new door, a drill is required if there are no holes prepared for lock installation.
  • Page 5: Important Notice

    Preparation Remove existing door hardware, latch or deadbolts before installing the new lock. Use provided template to bore new holes if needed. Measure and confirm your door is 1- 3/8"—2" (35mm—50mm) between 1-3/8" - 2" ( 35mm - 50mm). 2-1/8" 54mm 1"...
  • Page 6 Step 1 INSTALLING THE LOCKSET Measure the distance between center of front door hole to the edge of your door hole to determine the backset. Adjust latchbolt and deadbolt according to the backset of your door. Deadbolt Adjustment 2 ⅜"(60mm) 2 ¾"(70mm) extend I.
  • Page 7 Retract deadbolt and make sure bore hole is horizontally positioned. PGA018 PGA019 PGA019S 5.5” 4” For mortise slot Optional: Stainless steel mortise slot cover, 4" or 5.5" Face Plates available. To purchase, please call our Customer Service hotline (855) 562-5599 or email prosales@Lockly.com...
  • Page 8 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS The lock ships with handle default for right in-swing or left out-swing door. Check the diagram below if you are unsure of you door orientation. RIGHT IN-SWING DOOR INTERIOR LEFT IN-SWING DOOR Hinge Side LEFT OUT-SWING DOOR...
  • Page 9 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued Rotate the handle 180° to the other side of the Confirm that your installation was complete lock. by checking if the pins are flush against the handle, and has popped out. Adjust Using your fingers, press the two pins located on the handle accordingly to make sure the the left and right side of the the lock to insert...
  • Page 10 Step 2 CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS continued At the back of the exterior panel, Align the screw hole on point "L" then remove the screw on point "R". insert the removed screw and tighten. Changing the Interior Handle Orientation Remove the handle retaining screw and Insert the handle retaining screw and detach the handle.
  • Page 11 Step 3 PREPARING LOCK FOR INSTALLATION Carefully prepare the lock and ensure the required parts ( ) have been properly attached before installing to door. Peel paper layer OFF the Adhesive tape and prepare for installation. Carefully bend the end of Install Spindle C with the locking pin D with a the holes side into the...
  • Page 12 Step 3 PREPARING LOCK FOR INSTALLATION continued Select exterior cover plate according to front door hole distance. 4" use cover plate 5.5" use cover plate Attach exterior cover plate to exterior assembly . Use screw to secure the cover plate.
  • Page 13 Step 4 INSTALLING EXTERIOR SIDE OF LOCK Exterior While aligning the lock straight up-and-down, pass the wiring cable under the latchbolt then ensure the rod on cover plate passes through the hole Exterior on the lower part of the deadbolt body as shown.
  • Page 14 Step 5 INSTALLING INTERIOR SIDE OF LOCK Select interior cover plate according to door hole distance and install on to door. 4” use cover plate 5.5” use cover plate Ensure the rods on interior cover plate is inserted on the holes of the deadbolt. and the cable and spindle passed through part .
  • Page 15 Step 5 INSTALLING INTERIOR SIDE OF LOCK continued Secure interior cover plate with screws , then remove the positioning tool Check and ensure the spindle is at the center after removing Hole for screw for 5.5" Hole for screw for 4" Check and ensure the spindle is at the center after removing...
  • Page 16 Step 5 INSTALLING INTERIOR SIDE OF LOCK continued according to door handle orientation Left Select the side of the interconnection gear or Right . Insert torque blade to plate according the distance between the latchbolt and deadbolt . Select the correct side of the interconnection gear. For right swing door For left swing door Insert...
  • Page 17 Step 5 INSTALLING INTERIOR SIDE OF LOCK continued Mounting Plate On the interior side of the door install Install plate onto door. Ensure the mounting plate . Be sure to remove torque blade is inserted horizontally protective cover on adhesive tape before to the deadbolt.
  • Page 18 Lockly door sensors comes in Grey (PGA061) and Matte Black (PGA062) that can be TIP: ordered through our customer hotline: (669) 500-8835 or by email: help@Lockly.com.
  • Page 19 Step 6 PREPARING DOOR SENSORS FOR INSTALLATION continued When you are installing the door sensors, make sure the arrow of the wired sensor is placed next to the arrow of the sensor magnet close as possible. IMPORTANT: Do not install the sensor LEFT close to the strike plate RIGHT...
  • Page 20 Step 6 PREPARING DOOR SENSORS FOR INSTALLATION continued The interior assembly comes with the pre-installed For left swing doors, re-route the door sensor wired door sensor setup for a right swing doors with wire through the side channel. Trim excess 2-3/4"...
  • Page 21 Step 7 INSTALLING THE LOCK INTERIOR (N) Make sure the cable is away and not tangling with the spindle Secure the lock interior with 3 screws Plug the cable into the interior side of the lock making sure you match the orientation of the Align the spindle to the lock interior plug by matching the red side on the plug...
  • Page 22 Step 7 INSTALLING INTERIOR SIDE OF LOCK continued Insert 4 AA batteries into the lock by aligning the positive (+) and negative (-) orientation markings on the batteries to the battery chamber. Secure the battery by sliding the cover over the lock and turning the screw clockwise on top until tight.
  • Page 23 Step 8 INSTALLING THE DOOR STRIKE It is recommended that you use the included strike plate. However, if you find the deadbolt and latchbolt works with your existing strike plate free of any binding or resistance you can use use it. Regardless of which strike plate used, deadbolt and latchbolt needs to operate smoothly, free of any binding or resistance.
  • Page 24 The arrows must be aligned or as closed as possible (less than 3/4"). If needed, NOTE: adjust the position of the sensor magnet using provided foam pads to ensure the Lockly logo blinks red when door opens or closes.
  • Page 25 DOWNLOAD LOCKLY APP Congratulations! You have completed the Lockly Duo physical lock installation. To complete ™ your setup, download the Lockly app from the iOS or Google Play Store and follow on-screen instructions. Scan or visit Lockly.com/app IMPORTANT: After you completed the product warranty registration on the App, follow the Lock Configu- ration steps to run a self-check.
  • Page 26 Wi-Fi hub and lock can vary due to circumstances. If you are having difficulty setting up optimal range of 30/ft or less, we’re here to help. Call our customer care team: (669) 500 8835, or visit Lockly.com/help for suggestions and troubleshooting tips.
  • Page 27 Once you have confirmed that your Secure Link Wi-Fi Hub is ready to connect to your lock, open Make sure you are standing between the Wi-Fi hub and the Lockly App from your smartphone. Lockly smart lock, then Add New Device and follow the on screen instructions.
  • Page 28: Add New Device

    ™ ACTIVATION CARD LOCK SERIAL PGDxxxxxxxxxx ACTIVATION CODE xxxxxxxx SCAN & SAVE LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM Lockly Duo ™ If you can't scan LOCK SERIAL, Input Activation Code Scanning LOCK SERIAL Then enter manually ●●●●● AT&T...
  • Page 29 Step 12 CONNECTING YOUR LOCKLY DUO continued ™ Plug in your Secure Link and Click "YES" Confirm lock password Password setting OK Set the Admin Code 9:45 AM 100% 9:46 AM 100% ●●●●● AT&T 9:45 AM 100% ●●●●● AT&T ●●●●● AT&T...
  • Page 30 FCC Radiation Exposure Statement Lockly Duo complies with FCC radiation exposure limits set forth for an uncontrolled environment. It should be installed and operated with minimum distance 20cm between the radiator & your body.
  • Page 31 Exterior Assembly Strike Plate Spindle KEEP THIS CARD! Dust Box ACTIVATION CARD wer Adaptor LOCK SERIAL Activation Card PGDxxxxxxxxxx Keys ACTIVATION CODE xxxxxxxx SCAN & SAVE Locking Pin LOCKLY.COM | HOTLINE: +1(669) 500-8835 | EMAIL: HELP@LOCKLY.COM Latch Strike Plate Spacer (optional)
  • Page 32: Connect With Us

    Connect with us @meetlockly | #lockly...
  • Page 33 Reference installation parts overview foldout.
  • Page 34: We're Here To Help
