Table of Contents

H-1130, H-3476
BULK SOAP DISPENSERS
TOOLS NEEDED
Drill
1/4" Drill Bit
Dispenser x 1
• Install dispenser above a sink or counter. Never
install where spillage can fall on floor creating
hazardous conditions.
MOUNTING WITH DOUBLE-SIDED TAPE
For use on glazed tile, painted or unpainted metal walls.
1. Thoroughly clean wall surface and let dry.
2. Peel paper backing from tape. Press dispenser
firmly to wall at desired location and hold for
30 seconds to ensure tape is properly adhered.
(See Figures 1-2)
IMPORTANT: Wait 24 hours before filling with
soap to ensure tape has completely adhered
to wall.
PAGE 1 OF 6
1-800-295-5510
uline.com
Phillips Drill Bit
Tape Measure
Dispenser Key x 1
SAFETY
INSTALLATION
Level
PARTS
Wall Anchor x 4
(Not Included)
• Installer is responsible for proper installation.
• Dispenser should be mounted no more than
48" from the ground to be compliant with ADA
regulations.
Figure 1
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Screw x 4
(Not Included)
Figure 2
0523 IH-1130
