NOTE
• When using separate power supplies, always remove the jumpers from terminals R1/L11 and S1/L21. The inverter may be
damaged if the jumpers are not removed.
• The voltage should be the same as that of the main control circuit when the control circuit power is supplied from other than
the input side of the MC.
• The power capacity necessary when separate power is supplied from R1/L11 and S1/L21 is 80 VA.
• If the main circuit power is switched OFF (for 0.1 s or more) then ON again, the inverter is reset and a fault output will not be
held.
• When a power supply is provided for the control circuit separately from the main circuit and a capacitive device (such as an
EMC filter or a radio noise filter) is connected, connect a noise filter (example: RTMN5006 manufactured by TDK-Lambda
Corporation) to the control circuit power supply.
2.6.7
When supplying 24 V external power to the
control circuit
Connect a 24 V external power supply across terminals +24 and SD. Connecting a 24 V external power supply enables
I/O terminal ON/OFF operation, operation panel displays, control functions, and communication during communication
operation even during power-OFF of inverter's main circuit power supply. When the main circuit power supply is turned
ON, the power supply changes from the 24 V external power supply to the main circuit power supply.
Specification of the applied 24 V external power supply
Item
Input voltage 23 to 25.5 VDC
Input current 1.4 A or less
Commercially available products (as of October 2020)
Model
Specifications: Capacity 50 W, output voltage 24 VDC, output current 2.2 A
S8FS-G05024C Installation method: Direct installation, screw type terminal block with cover

Input: Single-phase 100 to 240 VAC
Specifications: Capacity 60 W, output voltage 24 VDC, output current 2.5 A
S8VK-S06024 Installation method: DIN rail, push-in (spring) type terminal block

Input: Single-phase 100 to 240 VAC
Specifications: Capacity 240 W, output voltage 24 VDC, output current 10 A
S8VK-WA24024 Installation method: DIN rail, push-in (spring) type terminal block

Input: Three-phase 200 to 240 VAC

For the latest information about OMRON power supply, contact OMRON corporation.
Rated specification
Product overview
Control circuit
Manufacturer
OMRON Corporation
