  • Page 1 2022 DODGE DURANGO OWNER’S MANUAL...
  • Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this manual that are not on this vehicle.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........................7 GETTING TO KNOW YOUR VEHICLE ..................13 GETTING TO KNOW YOUR INSTRUMENT PANEL ............72 STARTING AND OPERATING ....................88 MULTIMEDIA ..........................135 SAFETY ............................156 IN CASE OF EMERGENCY .....................199 SERVICING AND MAINTENANCE ..................216 TECHNICAL SPECIFICATIONS ....................
  • Page 4 INTRODUCTION DOORS ................20 UCONNECT VOICE RECOGNITION ........36 Manual Door Locks............20 Introducing Voice Recognition........36 SYMBOLS KEY ............... 8 Power Door Locks............21 Basic Voice Commands ..........37 ROLLOVER WARNING ............8 Get Started ..............37 Keyless Enter ‘n Go™ — VEHICLE MODIFICATIONS/ALTERATIONS .......
  • Page 5 EXTERIOR LIGHTS .............43 Power Inverter — If Equipped........62 Yellow Warning Lights ..........82 Multifunction Lever ............. 43 Wireless Charging Pad — If Equipped ......62 Yellow Indicator Lights ..........85 Headlight Switch ............43 WINDOWS ................63 Green Indicator Lights..........85 Power Windows............63 Daytime Running Lights (DRLs) ........
  • Page 6 SAFETY Shifting Procedure ............98 VEHICLE LOADING ............119 TOW N GO — IF EQUIPPED..........99 Certification Label............. 119 SAFETY FEATURES ............156 Guidelines For Track Use..........99 TRAILER TOWING ............120 Anti-Lock Brake System (ABS) .........156 Common Towing Definitions ........120 FUEL SAVER TECHNOLOGY 5.7L ONLY —...
  • Page 7 TECHNICAL SPECIFICATIONS Jack Location............. 202 Body Lubrication ............. 226 Spare Tire Stowage........... 203 Windshield Wiper Blades ........226 VEHICLE IDENTIFICATION NUMBER (VIN) .....262 Spare Tire Removal........... 203 Exhaust System ............229 BRAKE SYSTEM ..............262 Jacking Instructions ..........205 Cooling System ............230 WHEEL AND TIRE TORQUE SPECIFICATIONS .....262 JUMP STARTING ..............
  • Page 8 Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) ..............269 Service Contract ............269 WARRANTY INFORMATION ..........269 MOPAR® PARTS.............. 269 REPORTING SAFETY DEFECTS ........269 In The 50 United States And Washington, D.C..269 In Canada ..............270 PUBLICATION ORDER FORMS ........

  • Page 9: Introduction

    FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service remember that authorized dealers know your Dodge best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.

  • Page 10: Symbols Key

    SYMBOLS KEY in an unsafe manner, all vehicles can go out of control. Because of the higher center of gravity, if this vehicle is out of control, it may roll over while some other vehicles may not. These statements are against operating procedures that Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions that can WARNING! could result in a collision, bodily injury and/or death.

  • Page 11: Symbol Glossary

    SYMBOL GLOSSARY Red Warning Lights Some car components have colored labels with symbols indicating precautions to be Electronic Throttle Control (ETC) Warning Light observed when using this component. It is important to follow all warnings when operating page 81 Ú your vehicle.
  • Page 12 Red Warning Lights Yellow Warning Lights Vehicle Security Warning Light Anti-Lock Brake System (ABS) Warning Light page 82 page 82 Ú Ú Service Forward Collision Warning (FCW) Light Yellow Warning Lights Ú page 83 Engine Check/Malfunction Indicator Warning Light (MIL) Service Adaptive Cruise Control (ACC) Warning Light page 83 Ú...
  • Page 13 Yellow Indicator Lights Green Indicator Lights Forward Collision Warning (FCW) OFF Indicator Light LaneSense Indicator Light Ú page 85 page 85 Ú All Wheel Drive (AWD) Low Indicator Light Parking/Headlights On Indicator Light page 85 Ú page 85 Ú NEUTRAL Indicator Light Sport Mode Indicator Light Ú...
  • Page 14 White Indicator Lights LaneSense Indicator Light page 86 Ú Blue Indicator Lights High Beam Indicator Light page 86 Ú...

  • Page 15: Getting To Know Your Vehicle

    GETTING TO KNOW YOUR VEHICLE KEYS To Lock/Unlock The Doors And Liftgate Push and release the unlock button on the key fob once to unlock the driver’s door, or twice within five seconds to unlock all the doors and the liftgate. To lock all the doors Your vehicle is equipped with a key fob which supports and the liftgate, push the lock button once.
  • Page 16 GETTING TO KNOW YOUR VEHICLE The vehicle’s horn will rapidly chirp three times along with Remove the emergency key (2) by sliding the a single flash of the vehicle’s exterior lights. emergency key release (1) on the back of the key fob and pulling the emergency key out with your other NOTE: hand.

  • Page 17: Sentry Key

    GETTING TO KNOW YOUR VEHICLE NOTE: WARNING!  When having the Sentry Key Immobilizer system  Keep new and used batteries away from children. If serviced, bring all vehicle keys with you to an autho- the battery compartment does not close securely, rized dealer.

  • Page 18: Ignition Switch

    GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH If the Vehicle Security Light turns on during normal vehicle The push button ignition can be placed in the following operation (vehicle running for longer than 10 seconds), it modes: indicates that there is a fault in the electronics. Should ‘...

  • Page 19: Remote Start - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE:  When opening the driver's door with the ignition in ON/ WARNING! RUN (engine not running), a chime will sound to remind If the ignition position does not change with a push of the you to place the ignition in the OFF position.

  • Page 20: How To Use Remote Start

    GETTING TO KNOW YOUR VEHICLE  Liftgate closed equipped). Then, prior to the end of the 15 minute cycle, EMOTE TART push and release the START/STOP ignition button.  Hazard switch off Push and release the Remote Start button on the key fob The Remote Start system will turn the engine off if the ...

  • Page 21: Remote Start Comfort Systems - If Equipped

    GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY SYSTEM — IF EQUIPPED — NOTE: EMOTE TART OMFORT YSTEMS These features will stay on through the duration of Remote QUIPPED Start until the ignition is placed in the ON/RUN position. The The Vehicle Security system monitors the vehicle doors for climate control settings will change if manually adjusted by unauthorized entry and the Keyless Enter ‘n Go™...

  • Page 22: To Disarm The System

    GETTING TO KNOW YOUR VEHICLE door, the alarm will sound. If this occurs, disarm the handle to the first detent. To unlock the rear doors, pull ISARM YSTEM Vehicle Security system. the door lock knob on the door trim panel upward. If the The Vehicle Security system can be disarmed using any of lock knob is down when the door is closed, the door will If the Vehicle Security system is armed and the battery...

  • Page 23: Power Door Locks

    GETTING TO KNOW YOUR VEHICLE If the lock knob is down when the door is closed, the door NOTE: WARNING! will lock. Make sure the key fob is not inside the vehicle  Passive Entry may be programmed on/off within Ucon- before closing the door.
  • Page 24 GETTING TO KNOW YOUR VEHICLE To Unlock From The Driver Or Passenger Side: If one of the vehicle doors is open, and the door panel switch is used to lock the vehicle, once all open doors have With a valid Passive Entry key fob within 5 ft (1.5 m) of the been closed, the vehicle checks the inside and outside of door handle, grab the handle to unlock the vehicle.

  • Page 25: Automatic Unlock On Exit Feature - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: UTOMATIC NLOCK This feature will cause the horn to chirp when the doors — I EATURE QUIPPED are locked with the door handle lock button. This feature can be turned on or off within Uconnect Settings If Auto Unlock is enabled within Uconnect Settings Ú...

  • Page 26: Steering Wheel

    GETTING TO KNOW YOUR VEHICLE STEERING WHEEL To Engage Or Disenga ge The Child Protection Door Lock WARNING! System Do not adjust the steering column while driving. Open the rear door. ANUAL ELESCOPING TEERING Adjusting the steering column while driving or driving Insert the tip of the emergency key into the lock and —...

  • Page 27: Heated Steering Wheel - If Equipped

    GETTING TO KNOW YOUR VEHICLE Use the four-way control to adjust the steering column.  Press the heated steering wheel button a second time  Side mirrors to turn the heating element off. NOTE:  Power tilt and telescopic steering column (if equipped) NOTE: For vehicles equipped with Driver Memory Settings ...

  • Page 28: Programming The Memory Feature

    GETTING TO KNOW YOUR VEHICLE ROGRAMMING EMORY EATURE INKING NLINKING EMOTE EMORY OSITION ECALL EYLESS NTRY EMORY To create a new memory profile, perform the following: NOTE: If a recall is attempted when the vehicle is not in PARK, a NOTE: Your key fobs can be programmed to recall one of two message will be displayed in the instrument cluster...

  • Page 29: Manual Adjustment (Front Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE Manual Front Passenger Seatback ANUAL DJUSTMENT Adjustment — Recline ) — I RONT EATS QUIPPED To adjust the seatback, lift the lever located on the outboard side of the seat, lean back to the desired WARNING! position and release the lever.

  • Page 30: Manual Adjustment (Rear Seats)

    GETTING TO KNOW YOUR VEHICLE Front Passenger Seat Fold-Flat Feature — CAUTION! If Equipped Do not place any article under a power seat or impede To fold the seatback to the flat load-floor position, lift the its ability to move as it may cause damage to the seat recline lever and push the seatback forward.
  • Page 31 GETTING TO KNOW YOUR VEHICLE EASY ACCESS FOR THIRD ROW Rear Captain’s Chairs — If Equipped Either side of the rear seat can be tumbled forward to SECOND ROW CAPTAIN’S CHAIRS FOLD-FLAT allow passengers to easily access the third row seats. SEATS Pull upward on the release lever to release the seat.
  • Page 32 GETTING TO KNOW YOUR VEHICLE NOTE: You may experience deformation in the seat cushion from the seat belt buckles if the seats are left folded for an extended period of time. This is normal and by simply unfolding the seats to the open position, over time the seat cushion will return to its normal shape.

  • Page 33: Power Adjustment (Front Seats) - If Equipped

    GETTING TO KNOW YOUR VEHICLE Folding Third Row NOTE: The second row seats must be in their full upright position, Both third row seats can be folded forward to increase the folded flat or tumbled when folding the third row seats. cargo area.

  • Page 34: Power Passenger Seat Adjustment - If Equipped

    GETTING TO KNOW YOUR VEHICLE Reclining The Seatback Power Lumbar — If Equipped rear stop. The seat will return to its previously set position when you place the vehicle’s ignition in the The angle of the seatback can be adjusted forward or Vehicles equipped with power driver or passenger seats ACC or RUN position.

  • Page 35: Heated Seats - If Equipped

    GETTING TO KNOW YOUR VEHICLE Adjusting The Seat Up Or Down Front Heated Seats — If Equipped CAUTION! The height of the seats can be adjusted up or down. Pull The front heated seats control buttons are Do not place any article under a power seat or impede upward or push downward on the rear of seat switch, the located on the center stack below the radio its ability to move as it may cause damage to the seat...

  • Page 36: Front Ventilated Seats

    GETTING TO KNOW YOUR VEHICLE Front Head Restraints independently. The heated seat switches for each heater NOTE: are located on the rear of the center console. The engine must be running for the ventilated seats to Your vehicle is equipped with front four-way driver and operate.
  • Page 37 GETTING TO KNOW YOUR VEHICLE Head Restraints — Rear Seats To adjust the head restraint forward, pull the top of the NOTE: head restraint toward the front of the vehicle as desired For proper routing of a Child Seat Tether, see page 168.

  • Page 38: Uconnect Voice Recognition

    GETTING TO KNOW YOUR VEHICLE UCONNECT VOICE RECOGNITION Power Folding Third Row Head Restraints For improved visibility when in REVERSE, the third row NTRODUCING OICE ECOGNITION head restraints can be folded using the Uconnect system. Press the Controls button located on the bottom of the Start using Uconnect Voice Recognition (VR) with these Uconnect display.

  • Page 39: Basic Voice Commands

    OMMANDS DDITIONAL NFORMATION words include “Hey Uconnect” or “Hey Dodge”. The following Voice Commands can be given at any point © 2022 FCA US LLC. All rights reserved. Mopar and  A passenger can press the VR button shortcut on the while using your Uconnect system.

  • Page 40: Illuminated Vanity Mirrors

    GETTING TO KNOW YOUR VEHICLE NOTE: UTSIDE IRRORS The Automatic Dimming Mirror feature is disabled when The outside mirror(s) can be adjusted to the center of the the vehicle is in REVERSE to improve rear view viewing. adjacent lane of traffic to achieve the optimal view. You can turn the feature on or off by pushing the button at the base of the mirror.

  • Page 41: Power Mirrors

    GETTING TO KNOW YOUR VEHICLE UNIVERSAL GARAGE DOOR OPENER — I OWER IRRORS EATED IRRORS QUIPPED (HOMELINK®) — IF EQUIPPED The power mirror switch is located on the driver's side door These mirrors are heated to melt frost or ice. trim panel.

  • Page 42: Before You Begin Programming Homelink

    GETTING TO KNOW YOUR VEHICLE ® T  To operate HomeLink®, push and release any of the NOTE: ROGRAMMING programmed HomeLink® buttons. These buttons will Erasing all channels should only be performed when ARAGE PENER activate the devices they are programmed to with each programming HomeLink®...

  • Page 43: Programming Homelink® To A Miscellaneous Device

    GETTING TO KNOW YOUR VEHICLE Rolling Code Garage Door Opener Final Steps EPROGRAMMING INGLE WARNING! NOTE: ® B UTTON  Your motorized door or gate will open and close while You have 30 seconds in which to initiate rolling code final you are programming the universal transceiver.

  • Page 44: Security

    GETTING TO KNOW YOUR VEHICLE It may be helpful to unplug the device during the cycling  To program the two remaining HomeLink® ROUBLESHOOTING process to prevent possible overheating of the garage buttons, repeat each step for each remaining door or gate motor. button.

  • Page 45: Exterior Lights

    GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS NOTE: Vehicles sold in Canada are equipped with a headlight switch with an AUTO and ON detent but without an OFF ULTIFUNCTION EVER detent. Headlights will be deactivated when the headlight switch is placed in the parking lights position. However, The multifunction lever is located on the left side of the the Daytime Running Lights (DRLs) will be activated along steering column.

  • Page 46: Daytime Running Lights (Drls)

    GETTING TO KNOW YOUR VEHICLE lever six full on/off cycles within 10 seconds of ignition WITCH CAUTION! ON. System will return to default setting upon ignition Push the multifunction lever toward the instrument panel off. Do not use abrasive cleaning components, solvents, to switch the headlights to high beams.

  • Page 47: Automatic Headlights With Wipers

    GETTING TO KNOW YOUR VEHICLE NOTE: IGHTS EMINDER Vehicles sold in Canada are equipped with a headlight If the headlights, parking lights, or cargo lights are left on switch with an AUTO and ON detent but without an OFF detent. Headlights will be deactivated when the headlight after the ignition is placed in the OFF position, the vehicle will chime when the driver’s door is opened.

  • Page 48: Lane Change Assist - If Equipped

    GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS — I Front Map/Reading Lights — If Equipped HANGE SSIST QUIPPED Lights are mounted in the overhead console. Each light can Lightly push the multifunction lever up or down, without Courtesy and dome lights are turned on when the front be turned on by pushing the switch on either side of the moving beyond the detent, and the turn signal will flash doors are opened or when the dimmer control is rotated to...

  • Page 49: Windshield Wipers And Washers

    GETTING TO KNOW YOUR VEHICLE Ambient Light — If Equipped Illuminated Entry The overhead console is equipped with an ambient light When programmed with the Uconnect system, the feature. This light illuminates for improved visibility of the headlights and courtesy lights will turn on when you use floor and center console area.

  • Page 50: Rain Sensing Wipers - If Equipped

    GETTING TO KNOW YOUR VEHICLE (first detent), to a cycle every one second (fourth detent). NOTE: CAUTION! If the vehicle is moving less than 10 mph (16 km/h), delay The Mist feature does not activate the washer pump; times will be doubled. therefore, no washer fluid will be sprayed on the wind- Always remove any buildup of snow that prevents the shield.

  • Page 51: Rear Window Wiper/Washer

    GETTING TO KNOW YOUR VEHICLE The Rain Sensing system has protection features for the NOTE: wiper blades and arms, and will not operate under the As a protective measure, the pump will stop if the switch following conditions: is held for more than 20 seconds. Once the switch is released the pump will resume normal operation.
  • Page 52 GETTING TO KNOW YOUR VEHICLE AUTO Button Rear Defrost Button conditioning system. When the air conditioning system is turned on, cool dehumidified air will flow through the Press and release this button on the Press and release the button on the outlets into the cabin.
  • Page 53 GETTING TO KNOW YOUR VEHICLE Driver And Passenger Temperature operation. The speeds can be selected using either the shut-off wheel located below the air vanes to shut off or blower control knob on the faceplate or the buttons on the adjust the amount of airflow from these outlets.
  • Page 54 GETTING TO KNOW YOUR VEHICLE Climate Control OFF Button REAR AUTO BUTTON Press and release this button to turn the Press and release this button on the Climate Control ON/OFF. touchscreen to change the current setting. The REAR AUTO indicator will illuminate when REAR AUTO is on.
  • Page 55 GETTING TO KNOW YOUR VEHICLE BI-LEVEL MODE Rear Automatic Temperature Control passenger temperature, mode, or blower settings while in SYNC will automatically exit this feature. Press this button on the touchscreen to The rear system temperature control buttons are located NOTE: change the air distribution mode to Bi-Level on the headliner on the passenger side of the vehicle.

  • Page 56: Automatic Temperature Control (Atc)

    GETTING TO KNOW YOUR VEHICLE REAR TEMPERATURE CONTROL adjusted to direct the flow of air. Moving the air vanes of The rear ATC is located in the headliner, near the center of the outlets to one side will shut off the airflow. the vehicle.

  • Page 57: Climate Voice Recognition

    GETTING TO KNOW YOUR VEHICLE When the system is set up for your comfort level, it is Did you know: Voice Command for Climate may only be Recirculation mode during Winter months is not not necessary to change the settings. You will used to adjust the interior temperature of your vehicle.

  • Page 58: Interior Storage And Equipment

    GETTING TO KNOW YOUR VEHICLE Cabin Air Filter Front Center Console WEATHER CONTROL SETTINGS The Climate Control system filters out dust and pollen The front center console contains both an upper and a Set the mode control to from the air. Contact an authorized dealer to service your lower storage area.
  • Page 59 GETTING TO KNOW YOUR VEHICLE Sunglasses Bin Door NOTE: Lower storage compartment light is always on with ignition At the front of the console a compartment is provided for in the ON/RUN position. the storage of a pair of sunglasses. The storage The upper storage compartment may also be lifted compartment access is a “push/push”...

  • Page 60: Usb/Aux Control

    GETTING TO KNOW YOUR VEHICLE Rear Mini Center Console — If Equipped When lifted forward there is access to the lower storage compartment. An open storage area, or cubby bin with removable liner, is located in the front of the console. Fold-Flat Mode Open storage areas, or cubby bins with removable liners, are located rearward of the cupholders and in the lower...
  • Page 61 GETTING TO KNOW YOUR VEHICLE Connecting The AUX Audio Input Or Second Row USB Charging Port — Once a device is connected to the USB port, it will begin charging and is ready for use with the system. Type C and External USB Device If Equipped Type A charge-only USB ports can be used at the same...

  • Page 62: Lighted Cupholders - If Equipped

    GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: Charge unsupported devices with the Charge Only USB  All accessories connected to the battery powered ports. If an unsupported device is plugged into a Media outlets should be removed or turned off when the USB port, a message will display on the touchscreen that vehicle is not in use to protect the battery against the device is not supported by the system.
  • Page 63 GETTING TO KNOW YOUR VEHICLE In addition to the front power outlet, there is also a power The rear cargo power outlet is located in the right rear outlet located in the storage area of the center console. cargo area. Power Outlet Fuse Locations 1 —...

  • Page 64: Power Inverter - If Equipped

    GETTING TO KNOW YOUR VEHICLE — IRELESS HARGING CAUTION! QUIPPED  Many accessories that can be plugged in draw power from the vehicle's battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle's battery will discharge suffi- ciently to degrade battery life and/or prevent the engine from starting.

  • Page 65: Windows

    GETTING TO KNOW YOUR VEHICLE LED Indicator Status: instances, the device may shut down for a brief period The passenger door windows can also be operated by of time (when the device reaches a certain tempera- using the single window controls on the passenger door ...

  • Page 66: Wind Buffeting

    GETTING TO KNOW YOUR VEHICLE Auto-Up Feature With Anti-Pinch Protection — Driver And Push the window switch down firmly to the second to minimize the buffeting. If the buffeting occurs with the Front Passenger Door Only detent to open the window completely and continue sunroof open, adjust the sunroof opening to minimize the to hold the switch down for an additional two seconds buffeting or open any window.

  • Page 67: Opening And Closing The Sunroof

    GETTING TO KNOW YOUR VEHICLE Manual Open/Close WARNING! WARNING! Push and hold the switch rearward; the sunroof and There is no anti-pinch protection when the sunroof is  In a collision, there is a greater risk of being thrown sunshade will open and automatically stop at full open almost closed.

  • Page 68: Hood

    GETTING TO KNOW YOUR VEHICLE HOOD LIFTGATE — I PENING OWER IFTGATE QUIPPED To open the hood, two latches must be released. The power liftgate may be opened by pushing the liftgate release handle page 21 or by Ú Pull the release lever located underneath the pushing the liftgate button on the key fob.

  • Page 69: Cargo Area Features

    GETTING TO KNOW YOUR VEHICLE When the liftgate button on the key fob is pushed two from the liftgate before pushing any of the power lift- ARGO EATURES times, the turn signals will flash to signal that the liftgate gate switches. Cargo Storage is opening or closing (if Flash Lamps with Lock is enabled ...

  • Page 70: Roof Luggage Rack - If Equipped

    GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED The liftgate may be opened with the cargo cover in WARNING! place. The crossbars and side rails are designed to carry weight  Cargo tie-downs are not safe anchors for a child seat WARNING! on vehicles equipped with a luggage rack.

  • Page 71: Deploying The Crossbars

    GETTING TO KNOW YOUR VEHICLE Position the crossbars across the roof making sure EPLOYING ROSSBARS the letters on the crossbars align with the matching Starting with one crossbar, completely loosen the letters on the side rail. thumb screws at both ends of the crossbar. Removing Crossbars CAUTION! Use care when removing and handling the crossbars to...

  • Page 72: Stowing The Crossbars

    GETTING TO KNOW YOUR VEHICLE Slide the crossbar into the deploy position by moving it towards the matching letter in the side rail. Be sure the crossbar is fully deployed with the crossbar pushed as far into the slot as possible. Once the crossbar is in place, tighten both thumb screws completely.
  • Page 73 GETTING TO KNOW YOUR VEHICLE Slide the crossbar outward, away from the center of Repeat the procedure to stow the second crossbar on CAUTION! the roof. The crossbar will nest fully within the side the opposite side. rail.  To prevent damage to the roof of your vehicle, DO NOT carry any loads on the roof rack without the crossbars deployed.

  • Page 74: Getting To Know Your Instrument Panel

    GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...

  • Page 75: Instrument Cluster Descriptions

    GETTING TO KNOW YOUR INSTRUMENT PANEL your vehicle’s systems and features. Using a driver NSTRUMENT LUSTER ESCRIPTIONS CAUTION! interactive display located on the instrument panel, your Tachometer instrument cluster display can show how systems are Driving with a hot engine cooling system could damage working and give you warnings when they are not.
  • Page 76 GETTING TO KNOW YOUR INSTRUMENT PANEL The system allows the driver to select information by the information screens or submenu screens of a main messages. These pop-up messages fall into several pushing the following buttons mounted on the steering menu item. categories: wheel: ...

  • Page 77: Engine Oil Life Reset

    GETTING TO KNOW YOUR INSTRUMENT PANEL Vehicles Equipped With Keyless Enter ‘n Go™ — Ignition NOTE: NGINE ESET If the indicator message illuminates when you start the Use the steering wheel instrument cluster display controls Oil Change Required vehicle, the oil change indicator system did not reset. If for the following procedure(s): necessary, repeat this procedure.

  • Page 78: Display And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL ISPLAY ESSAGES Includes the following, but not limited to: Front Seat Belts Unbuckled Driver Seat Belt Unbuckled Passenger Seat Belt Unbuckled Traction Control Off Washer Fluid Low Oil Pressure Low Oil Change Due Fuel Low Service Anti-lock Brake System Service Electronic Throttle Control Service Power Steering...

  • Page 79: Instrument Cluster Display Menu Items

    GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Economy  If one or more tires have low pressure, “Inflate Tire To NSTRUMENT LUSTER ISPLAY XX” is displayed with the vehicle icon and the tire pres- TEMS Push and release the up or down arrow button until sure values in each corner of the icon with the pressure...
  • Page 80 GETTING TO KNOW YOUR INSTRUMENT PANEL Trailer Tow — If Equipped shows the number of stored warning messages. Pushing Favorite Menus the left or right arrow button will allow you to see Push and release the up or down arrow button until Performance Audio (Show/ what the stored messages are.

  • Page 81: Battery Saver On/Battery Saver Mode Message - Electrical Load Reduction Actions - If Equipped

    GETTING TO KNOW YOUR INSTRUMENT PANEL Defaults (Restores All Settings To Default Settings)  If the Battery Charge Warning Light is on it may indicate  The battery was recently replaced and was not charged completely. a problem with the charging system page 81.

  • Page 82: Warning Lights And Messages

    GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES detected, it will stay on until the fault is cleared. If the light NOTE: is either not on during startup, stays on, or turns on while The light may flash momentarily during sharp cornering driving, have the system inspected at an authorized dealer maneuvers, which change fluid level conditions.
  • Page 83 GETTING TO KNOW YOUR INSTRUMENT PANEL Battery Charge Warning Light Electronic Throttle Control (ETC) Warning continuous chime will sound for four minutes or until the engine is able to cool, whichever comes first. Light This warning light will illuminate when the If the light turns on while driving, safely pull over and stop battery is not charging properly.

  • Page 84: Yellow Warning Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Oil Pressure Warning Light functioning and service is required as soon as possible. WARNING! However, the conventional brake system will continue to This warning light will illuminate to indicate operate normally, assuming the Brake Warning Light is not If you continue operating the vehicle when the low engine oil pressure.
  • Page 85 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) OFF Engine Check/Malfunction Indicator CAUTION! Warning Light Warning Light (MIL) Prolonged driving with the Malfunction Indicator Light This warning light indicates the ESC is off. The Engine Check/Malfunction Indicator Light (MIL) on could cause damage to the vehicle control (MIL) is a part of an Onboard Diagnostic system.
  • Page 86 GETTING TO KNOW YOUR INSTRUMENT PANEL Service Stop/Start System Warning Light — Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not If Equipped operating properly. The TPMS malfunction indicator is Do not continue driving with one or more flat tires as This warning light will illuminate when the combined with the low tire pressure telltale.

  • Page 87: Yellow Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL Adaptive Cruise Control (ACC) Set Without Parking/Headlights On Indicator Light ELLOW NDICATOR IGHTS Target Light — If Equipped This indicator light will illuminate when the All Wheel Drive (AWD) Low Indicator parking lights or headlights are turned on This will display when the ACC is set and the Light —...

  • Page 88: White Indicator Lights

    GETTING TO KNOW YOUR INSTRUMENT PANEL multifunction lever rearward (toward the rear of the HITE NDICATOR IGHTS NBOARD IAGNOSTIC YSTEM vehicle) to turn off the high beams. If the high beams are (OBD II) C YBERSECURITY Adaptive Cruise Control (ACC) Ready off, pull the lever toward you for a temporary high beam on, “flash to pass”...

  • Page 89: Emissions Inspection And Maintenance

    GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND NOTE: If your OBD II system is not ready, you should see an authorized dealer or repair facility. If your vehicle was If you crank or start the engine, you will have to start this MAINTENANCE PROGRAMS recently serviced or had a battery failure or replacement, test over.

  • Page 90: Starting And Operating

    STARTING AND OPERATING STARTING THE ENGINE ORMAL TARTING WARNING! To Turn On The Engine Using The ENGINE START/STOP Before starting your vehicle, adjust your seat, adjust the  Do not leave children or animals inside parked vehi- Button inside and outside mirrors, fasten your seat belt, and if cles in hot weather.

  • Page 91: Autopark

    STARTING AND OPERATING If the gear selector is not in PARK and the ENGINE detected on both pedals simultaneously, a warning  Vehicle is not in PARK START/STOP button is pushed once with the vehicle message will display in the instrument cluster page 73.

  • Page 92: Extended Park Starting

    STARTING AND OPERATING The message “Vehicle Speed is Too High to Shift to P” will automatically, run for 10 seconds, and then disengage. XTENDED TARTING be displayed in the instrument cluster if vehicle speed is Once this occurs, release the accelerator pedal and brake above 1.2 mph (1.9 km/h).

  • Page 93: Cold Weather Operation (Below -22°F Or −30°C)

    STARTING AND OPERATING NOTE: When the parking brake is applied with the ignition switch EATHER PERATION in the ON/RUN position, the Brake Warning Light in the A new engine may consume some oil during its first few –22°F O −30°C) ELOW instrument cluster will illuminate.

  • Page 94: Automatic Transmission

    STARTING AND OPERATING CAUTION! WARNING! WARNING! If the Brake Warning Light remains on with the parking  Never leave children alone in a vehicle, or with  It is dangerous to shift out of PARK or NEUTRAL (N) if brake released, a brake system malfunction is access to an unlocked vehicle.

  • Page 95: Ignition Park Interlock

    STARTING AND OPERATING Ensure that the transmission is in PARK, and the ignition When the Fuel Economy (ECO) mode is enabled, the WARNING! is OFF (not in ACC position) before exiting the vehicle. vehicle control systems will change the following: ...
  • Page 96 STARTING AND OPERATING The electronically controlled transmission adapts its shift NOTE: When exiting the vehicle, always: schedule based on driver inputs, along with environmental If the gear selector cannot be moved to the PARK,  Apply the parking brake. and road conditions. REVERSE, or NEUTRAL position (when pushed forward) it ...
  • Page 97 STARTING AND OPERATING REVERSE (R) and the best fuel economy. The transmission Vehicle performance may be severely degraded and the automatically upshifts through all forward gears. engine may stall. In some situations, the transmission may This range is for moving the vehicle backward. Shift into not re-engage if the engine is turned off and restarted.

  • Page 98: Sport Mode - If Equipped

    STARTING AND OPERATING SPORT MODE — IF EQUIPPED AutoStick — If Equipped  The transmission will automatically downshift to FIRST gear when coming to a stop. After a stop, the driver AutoStick is a driver-interactive transmission feature should manually upshift (+) the transmission as the Your vehicle is equipped with a SPORT Mode feature.

  • Page 99: Electronically Shifted Transfer Case - If Equipped

    STARTING AND OPERATING cause increased tire wear and damage to the driveline LECTRONICALLY HIFTED RANSFER WARNING! components. — I QUIPPED Always engage the parking brake when powering down Transfer Case Position Indicator Messages the vehicle if the SERV AWD Warning Light is This is an electronically shifted transfer case and it is The Transfer Case Position Indicator message (AWD LOW) illuminated.

  • Page 100: Shifting Procedure

    STARTING AND OPERATING N (Neutral)  If all the requirements to select a new transfer case Alternate Procedure position have been met, the current position indicator This range disengages both the front and rear driveshafts Bring the vehicle to complete stop. light will turn off, the selected position indicator light from the powertrain.

  • Page 101: Tow N Go - If Equipped

    STARTING AND OPERATING TOW N GO — IF EQUIPPED feature will reset to AUTO upon an ignition cycle. To  Prior to each track event, verify all fluids are at the correct levels. turn off Electronic Stability Control (ESC) page 158. Ú...

  • Page 102: Fuel Saver Technology 5.7L Only

    STARTING AND OPERATING POWER STEERING NOTE: Occasionally, a second burnish session is required. If the brake pads begin to emit an odor during the next It is recommended that you target below 42 psi (290 kPa) track session, reduce vehicle speed and braking when tires are hot at the conclusion of each track session.

  • Page 103: Stop/Start System - If Equipped

    STARTING AND OPERATING driving conditions are safe, pull over and let the vehicle It may be possible for the vehicle to be driven several OSSIBLE EASONS NGINE idle for a few moments until the icon and message turn times without the Stop/Start system going into a STOP/ UTOSTOP off.

  • Page 104: To Manually Turn Off The Stop/Start System

    STARTING AND OPERATING ANUALLY YSTEM ALFUNCTION RUISE ONTROL TART YSTEM If there is a malfunction in the Stop/Start system, the When engaged, the Cruise Control takes over accelerator system will not shut down the engine. A “SERVICE STOP/ operations at speeds greater than 20 mph (32 km/h). START SYSTEM”...
  • Page 105 STARTING AND OPERATING indicator lamp, along with set speed will also appear and The Cruise Control system maintains speed up and down WARNING! stay on in the instrument cluster when the speed is set. hills. A slight speed change on moderate hills is normal. On steep hills, a greater speed loss or gain may occur so it Cruise Control can be dangerous where the system To Vary The Speed Setting...

  • Page 106: Adaptive Cruise Control (Acc)

    STARTING AND OPERATING (ACC) DAPTIVE RUISE ONTROL WARNING! WARNING! Adaptive Cruise Control (ACC) increases the driving  Adaptive Cruise Control (ACC) is a convenience  Will bring the vehicle to a complete stop while convenience provided by Cruise Control while traveling on system.
  • Page 107 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control (ACC) Menu The instrument cluster display will return to the last display selected after five seconds of no ACC display The buttons on the right side of the steering wheel operate The instrument cluster display will show the current ACC activity.
  • Page 108 STARTING AND OPERATING To Activate/Deactivate To Cancel WARNING! Push and release the Adaptive Cruise Control (ACC) on/off The following conditions cancel the ACC or Fixed Speed In Fixed Speed Cruise Control mode (ACC not enabled), button. The ACC menu in the instrument cluster displays Cruise Control systems: the system will not react to vehicles ahead.
  • Page 109 STARTING AND OPERATING To Resume U.S. Speed (mph)  The ACC system maintains set speed when driving uphill and downhill. However, a slight speed change on  Pushing the SET (+), or SET (-) button once will result in If there is a set speed in memory, push the RES (resume) moderate hills is normal.
  • Page 110 STARTING AND OPERATING To increase the distance setting, push the Distance NOTE: WARNING! Increase button and release. Each time the button is The “BRAKE!” screen in the instrument cluster display is a pushed, the distance setting increases by one bar (longer). warning for the driver to take action and does not neces- When the ACC system is resumed, the driver must sarily mean that the Forward Collision Warning system is...
  • Page 111 STARTING AND OPERATING “CLEAN FRONT WINDSHIELD” WARNING SERVICE ACC/FCW WARNING If weather conditions are not a factor, the driver should examine the sensor. It may require cleaning or removal of The “ACC/FCW Limited Functionality Clean Front If the system turns off, and the instrument cluster display an obstruction.
  • Page 112 STARTING AND OPERATING OFFSET DRIVING USING ACC ON HILLS ACC may not detect a vehicle in the same lane that is ACC performance may be limited when driving on hills. offset from your direct line of travel, or a vehicle merging ACC may not detect a vehicle in your lane depending on in from a side lane.

  • Page 113: Parksense Front/Rear Park Assist

    STARTING AND OPERATING STATIONARY OBJECTS AND VEHICLES NOTE:  The driver must stay in full control of the vehicle's acceleration and braking and is responsible for the  The driver can disable the automatic braking function ACC does not react to stationary objects or vehicles. For vehicle's movements.

  • Page 114: Parksense Display

    STARTING AND OPERATING ENSE ISPLAY The warning display will turn on indicating the system status when the vehicle is in REVERSE or when the vehicle is in DRIVE and an obstacle has been detected. The system will indicate a detected obstacle by showing a single arc in the left and/or right front or rear regions based on the object’s distance and location relative to the vehicle. If an object is detected in the left and/or right rear region, the display will show a single arc in the left and/or right rear region and the system will produce a tone.
  • Page 115 STARTING AND OPERATING The vehicle is close to the obstacle when the instrument cluster display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Rear Distance Greater than 79-59 inches...

  • Page 116: Parksense Warning Display

    STARTING AND OPERATING Front Park Assist Audible Alerts REVERSE and the system is disabled, the instrument NOTE: cluster display will display the “PARKSENSE OFF” For more information on the Integrated Trailer Brake ParkSense will turn off the Front Park Assist audible alert message for as long as the vehicle is in REVERSE.

  • Page 117: Cleaning The Parksense System

    STARTING AND OPERATING cluster display will display a "PARKSENSE UNAVAILABLE  Use the ParkSense switch to turn the ParkSense ENSE YSTEM SAGE WIPE REAR SENSORS", "PARKSENSE UNAVAILABLE WIPE system off if objects such as bicycle carriers, trailer RECAUTIONS FRONT SENSORS" or "PARKSENSE UNAVAILABLE SERVICE hitches, etc.

  • Page 118: Lanesense - If Equipped

    STARTING AND OPERATING The driver may manually override the haptic warning by ENSE ARNING ESSAGE CAUTION! applying force to the steering wheel at any time. The LaneSense system will indicate the current lane drift  ParkSense is only a parking aid and it is unable to When only a single lane marking is detected and the driver condition through the instrument cluster display.
  • Page 119 STARTING AND OPERATING Lane Approached (Flashing Yellow Line With Lanes Sensed (White Lines) With Green Telltale Lane Sensed (Solid Yellow Line With Solid Yellow Telltale) Flashing Yellow Telltale)  When the LaneSense system senses a lane drift situa-  When the LaneSense system senses the lane has been tion, the left lane line will turn solid yellow.

  • Page 120: Changing Lanesense Status

    STARTING AND OPERATING PARKVIEW REAR BACK UP CAMERA conditions occur: the vehicle speed exceeds 8 mph (13 km/h), the vehicle is shifted into PARK, the vehicle’s ignition is placed in the OFF position, or the touchscreen X Your vehicle is equipped with the ParkView Rear Back Up button to disable the display of the Rear View Camera is Camera that allows you to see an on-screen image of the pressed.

  • Page 121: Refueling The Vehicle

    STARTING AND OPERATING REFUELING THE VEHICLE CAUTION! WARNING! Open the fuel filler door by pushing on the outer  To avoid vehicle damage, ParkView should only be  Never have any smoking materials lit in or near the edge of the fuel door. used as a parking aid.

  • Page 122: Trailer Towing

    STARTING AND OPERATING Inflation Pressure Hour of manufacture. The bar code that appears on the WARNING! bottom of the label is your VIN. This is the cold tire inflation pressure for your vehicle for Gross Vehicle Weight Rating (GVWR) Do not load your vehicle any heavier than the GVWR or all loading conditions up to full GAWR.
  • Page 123 STARTING AND OPERATING Tongue Weight (TW) Weight-Distributing Hitch temporary) loaded in or on the trailer in its "loaded and ready for operation" condition. The TW is the downward force exerted on the hitch ball by A weight-distributing system works by applying leverage The recommended way to measure GTW is to put your fully the trailer.
  • Page 124 STARTING AND OPERATING RECOMMENDED DISTRIBUTION HITCH Attach the trailer to the vehicle without the weight Measurement Example Example Height (mm) distribution bars connected. ADJUSTMENT Measure the height from the top of the front wheel Measure the height from the top of the front wheel opening on the fender to the ground;...

  • Page 125: Trailer Hitch Classification

    STARTING AND OPERATING RAILER ITCH LASSIFICATION The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.

  • Page 126: Trailer Hitch Receiver Cover Removal - If Equipped

    STARTING AND OPERATING NOTE: To reinstall the cover after towing, repeat the procedure in reverse order.  The trailer tongue weight must be considered as part of NOTE: the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire Be sure to engage all tabs of the hitch receiver cover in the and Loading Information placard page 243.

  • Page 127: Towing Requirements

    STARTING AND OPERATING Consider the following items when computing the weight Perform the maintenance listed in Scheduled Servicing WARNING! on the rear axle of the vehicle: page 216. When towing a trailer, never exceed the Ú GAWR or GCWR ratings. ...
  • Page 128 STARTING AND OPERATING Integrated Trailer Brake Module (ITBM) —  An electronically actuated trailer brake controller is The user interface consists of the following: required when towing a trailer with electronically actu- If Equipped Manual Brake Control Lever ated brakes. When towing a trailer equipped with a Slide the manual brake control lever to the left to activate Your vehicle may have an ITBM for electric and Electric hydraulic surge actuated brake system, an electronic...
  • Page 129 STARTING AND OPERATING Adjusting GAIN If the trailer wheels lockup (indicated by squealing NOTE: tires), reduce the GAIN setting; if the trailer wheels NOTE:  An aftermarket controller may be available for use with turn freely, increase the GAIN setting. This should only be performed in a traffic free environment trailers with air or EOH trailer brake systems.

  • Page 130: Towing Tips

    STARTING AND OPERATING while in DRIVE, you can use the AutoStick shift control to manually select a lower gear. If equipped with Tow N Go, it is recommended to place the vehicle in tow mode by pushing the TOW button. NOTE: Using a lower gear while operating the vehicle under heavy loading conditions, will improve performance and extend...

  • Page 131: Recreational Towing (Behind Motorhome)

    STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE All-Wheel Drive Models With All-Wheel Drive Models With Towing Condition Wheels OFF The Ground Rear-Wheel Drive Models Single-Speed Transfer Case Two-Speed Transfer Case  See Instructions:  Transmission In PARK Flat Tow NONE NOT ALLOWED...

  • Page 132: Recreational Towing - All-Wheel Drive Models (Single-Speed Transfer Case)

    STARTING AND OPERATING — A Shifting Into N (Neutral) NOTE: ECREATIONAL OWING HEEL If the Mopar® Flat Tow Harness kit is installed, the EPS will RIVE ODELS INGLE PEED use power from the battery to keep the EPS powered WARNING! during a flat tow.
  • Page 133 STARTING AND OPERATING NOTE: CAUTION!  Steps 1 through 3 are requirements that must be Damage to the transmission may occur if the met before pushing the N (Neutral) button, and transmission is shifted into PARK with the transfer case must continue to be met until the shift has been in N (Neutral) and the engine running.

  • Page 134: Driving Tips

    STARTING AND OPERATING  The ignition must be in the ON/RUN mode for a 12. Start the engine. speeds in excess of 25 mph (40 km/h) should be avoided shift to take place and for the position indicator when in 4WD Low. 13.
  • Page 135 STARTING AND OPERATING Hill Climbing Traction Downhill Flowing Water If the water is swift flowing and rising (as in storm run-off), NOTE: Shift the transmission into a low gear, and the transfer avoid crossing until the water level recedes and/or the case into AWD Low.
  • Page 136 STARTING AND OPERATING  After extended operation in mud, sand, water, or  If you experience unusual vibration after driving in WARNING! similar dirty conditions, have the radiator, fan, brake mud, slush or similar conditions, check the wheels for rotors, wheels, brake linings, and axle yokes inspected impacted material.

  • Page 137: Multimedia

    MULTIMEDIA UCONNECT SYSTEMS UCONNECT SETTINGS version of vehicle software (such as Uconnect software) is installed. For detailed information about your Uconnect 4C/4C NAV The Uconnect system uses a combination of buttons on WARNING! With 8.4-inch Display or Uconnect 5 NAV With 10.1-inch the touchscreen and buttons on the faceplate located on Display systems, refer to your Uconnect Owner’s Manual the center of the instrument panel.

  • Page 138: Customer Programmable Features

    MULTIMEDIA For the Uconnect 4C/4C NAV With 8.4-inch Display side of the screen will allow you to toggle up or down USTOMER ROGRAMMABLE EATURES through the available settings. Press the Apps button, then press the Settings button For the Uconnect 5 NAV With 10.1-inch Display on the touchscreen to display the menu settings screen.
  • Page 139 MULTIMEDIA Display When the Display button is pressed on the touchscreen, the system will display the options related to the theme (if equipped), brightness, and color of the touchscreen. The available settings are: NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system.
  • Page 140 MULTIMEDIA Setting Name Description This setting will allow you to set the Control Screen to turn off automatically after five Controls Screen Timeout seconds or stay open until manually closed. Show Main Category Bar Labels This setting will allow the main category bar labels to be shown on or off. Navigation Next Turn Pop-Ups Displayed in Cluster This setting will display navigation prompts in the Instrument Cluster Display.
  • Page 141 This setting will allow you to change the voice options for the radio to “Male” or “Female”. This setting will change the system’s “Wake Up” word. The available options are “Hey Wake Up Word Uconnect” and “Hey Dodge”. Voice Barge-in This setting will allow voice barge-in to be turned on and off.
  • Page 142 MULTIMEDIA Setting Name Description This setting will allow you to have pop-up notifications for missed calls. This setting Missed Calls Message options are “On” and “Off”. This setting will recall preset radio stations and driver seat position that have been linked Personal Settings Linked to Key Fob to the key fob.
  • Page 143 MULTIMEDIA Setting Name Description This setting will turn the Forward Collision Warning (FCW) system on or off. The “Off” setting will deactivate the FCW system. The “Warning Only” setting will provide only an Forward Collision Warning audible chime when a collision is detected. The “Warning + Active Braking” setting will provide an audible chime and apply some brake pressure when a collision is detected.
  • Page 144 MULTIMEDIA Setting Name Description Hill Start Assist This setting will turn the Hill Start Assist system on or off. Units When the Units button is pressed on the touchscreen, the system displays the different measurement options. The selected unit of measurement will display in the instrument cluster display and Navigation system (if equipped).
  • Page 145 MULTIMEDIA Setting Name Description This setting will allow you to set the hours. Sync Time With GPS must be off for this setting Set Time Hours to be available. The “+” setting will increase the hours. The “-” setting will decrease the hours.
  • Page 146 Show Command List provide a brief description of what the command does. The “Never” setting will turn the Command List off. This setting will change the system’s “Wake Up” word. The available options are “Hey Wake Up Word Uconnect” and “Hey Dodge”.
  • Page 147 MULTIMEDIA Setting Name Description Voice Barge-in This setting will turn the Voice Barge-in function on or off. Navigation — If Equipped When the Navigation button is pressed on the touchscreen, the system displays options related to the vehicle’s built-in Navigation system. These settings can change which icons display on the map, how “time to arrival is calculated”, and route types.
  • Page 148 MULTIMEDIA Camera — If Equipped When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will add a timed delay to the ParkView Backup Camera when shifting out of ParkView Backup Camera Delay REVERSE.
  • Page 149 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE:  When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchased.
  • Page 150 MULTIMEDIA Doors & Locks When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors. NOTE:  The Auto Door Locks feature default condition is enabled. When enabled, the door locks will lock automatically when the vehicle’s speed exceeds 15 mph (24 km/h). The Auto Door Locks feature can be enabled or disabled by an authorized dealer per written request of the customer.
  • Page 151 MULTIMEDIA Setting Name Description This setting will chime an audible alert when the power liftgate is raising or lowering. Power Liftgate Alert Selectable settings are “On” and “Off”. Seats & Comfort/Auto-On Comfort — If Equipped When Seats & Comfort/Auto-On Comfort button is pressed on the touchscreen, the system displays the options related to the vehicle’s comfort systems when remote start has been activated or the vehicle has been started.
  • Page 152 MULTIMEDIA Key Off/Engine Off Options When the Key Off /Engine Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shutoff. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary.
  • Page 153 MULTIMEDIA Setting Name Description This setting will adjust audio volume as speeds increase. At a higher setting, the volume Speed Adjusted Volume will increase more as the vehicle speeds up. The available settings are “Off”, “1”, “2”, and “3”. Surround Sound This setting will turn the Surround Sound system on or off.
  • Page 154 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® satellite radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: ...
  • Page 155 MULTIMEDIA Accessibility — If Equipped When the Accessibility button is pressed on the touchscreen, the system will display the option related to the vehicle’s theater system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description The “Accessibility” feature announces a function prior to performing the action selected when using DVD/Blu-ray™...
  • Page 156 MULTIMEDIA System Information — If Equipped When the System Information button is pressed on the touchscreen, the system displays the radio system information. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Version Information When this feature is selected, the radio version build will be displayed. When this feature is selected, a Software License screen will appear, displaying the License Information system software version.

  • Page 157: Steering Wheel Audio Controls

    MULTIMEDIA STEERING WHEEL AUDIO CONTROLS ADIO PERATION EGULATORY AFETY NFORMATION Pushing the top of the switch will seek up for the next The Remote Sound System controls are located on the available station, and pushing the bottom of the switch will rear surface of the steering wheel.

  • Page 158: Safety

    SAFETY SAFETY FEATURES Anti-Lock Brake System (ABS) Warning WARNING! Light (ABS)  The ABS contains sophisticated electronic equip- RAKE YSTEM The yellow ABS Warning Light will turn on when the ignition ment that may be susceptible to interference caused is placed in the ON/RUN mode and may stay on for as long by improperly installed or high output radio transmit- The ABS provides increased vehicle stability and brake as four seconds.

  • Page 159: Electronic Brake Control (Ebc) System

    SAFETY (EBC) receives that the feature is active is the torque applied to LECTRONIC RAKE ONTROL WARNING! the steering wheel. YSTEM The Brake Assist System (BAS) cannot prevent the NOTE: natural laws of physics from acting on the vehicle, nor The DST feature is only meant to help the driver realize the Your vehicle is equipped with an advanced Electronic can it increase the traction afforded by prevailing road...
  • Page 160 SAFETY The ESC Activation/Malfunction Indicator Light located in WARNING! WARNING! the instrument cluster will start to flash as soon as the ESC system becomes active. The ESC Activation/Malfunction Many factors, such as vehicle loading, road conditions  Vehicle modifications, or failure to properly maintain Indicator Light also flashes when the Traction Control and driving conditions, influence the chance that wheel your vehicle, may change the handling characteris-...
  • Page 161 SAFETY To enter the “Partial Off” mode, momentarily push the ESC see an authorized dealer as soon as possible to have the brake pressure and the vehicle will roll down the hill as OFF button and the ESC OFF Indicator Light will illuminate. problem diagnosed and corrected.

  • Page 162: Auxiliary Driving Systems

    SAFETY Disabling And Enabling HSA Ready Alert Braking (RAB) wheels to attempt to stop the trailer from swaying. TSC is disabled when the ESC system is in the “Partial Off” mode. This feature can be turned on or turned off. To change the RAB may reduce the time required to reach full braking current setting see page 135.
  • Page 163 SAFETY When the vehicle is started, the BSM Warning Light will in the cluster, both mirror lights will illuminate, and The BSM system notifies the driver of objects in the momentarily illuminate in both outside rearview mirrors to BSM and RCP alerts will not occur. This is normal oper- detection zones by illuminating the BSM Warning Light let the driver know that the system is operational.
  • Page 164 SAFETY Entering From The Side Overtaking Traffic The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, Vehicles that move into your adjacent lanes from either If you pass another vehicle slowly (with a relative speed of berms, etc.

  • Page 165: Forward Collision Warning (Fcw) With Mitigation

    SAFETY Rear Cross Path (RCP) are blocked by other structures or vehicles, the system will detected object are present on the same side at the same not be able to alert the driver. time, both the visual and audible alerts will be issued. In RCP is intended to aid the driver when backing out of addition to the audible alert the radio (if on) will also be parking spaces where their vision of oncoming vehicles...
  • Page 166 SAFETY NOTE: WARNING! FCW monitors the information from the forward looking sensors as well as the Electronic Brake Controller (EBC) to Forward Collision Warning (FCW) is not intended to calculate the probability of a forward collision. When the avoid a collision on its own, nor can FCW detect every system determines that a forward collision is probable, the type of potential collision.

  • Page 167: Tire Pressure Monitoring System (Tpms)

    SAFETY time than the “Far” and “Medium” settings, which allows system performance is no longer present, the system will threshold for any reason, including low temperature for a more dynamic driving experience. return to its full performance state. If the problem persists, effects, or natural pressure loss through the tire.
  • Page 168 SAFETY  Driving on a significantly underinflated tire causes the NOTE: CAUTION! tire to overheat and can lead to tire failure. Underinfla- It is particularly important for you to regularly check the tion also reduces fuel efficiency and tire tread life, and tire pressure in all of your tires and to maintain the proper ...
  • Page 169 SAFETY instrument cluster display will display a “SERVICE TPM then display dashes (--) in place of the pressure value. For SYSTEM” message for a minimum of five seconds. This each subsequent ignition switch cycle, a chime will sound, message is then followed by a graphic display, with “--“ in the TPMS Warning Light will flash on and off for 75 place of the pressure value(s), indicating which Tire seconds and then remain on solid, and the instrument...

  • Page 170: Occupant Restraint Systems

    SAFETY message in the instrument cluster but dashes (--) will properly, to keep you and your passengers as safe as If the air bag system in this vehicle needs to be remain in place of the pressure values. possible. modified to accommodate a disabled person, see page 268 for customer service contact Ú...
  • Page 171 SAFETY Enhanced Seat Belt Use Reminder System BeltAlert warning sequence may repeat based on vehicle shoulder part of the seat belt to move freely with you speed until the driver and occupied outboard front seat under normal conditions. However, in a collision the seat (BeltAlert) passenger seat belts are buckled.
  • Page 172 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! WARNING! Enter the vehicle and close the door. Sit back and  Wearing your seat belt incorrectly could make your  A seat belt that is too loose will not protect you prop- adjust the seat. injuries in a collision much worse.
  • Page 173 SAFETY When the seat belt is long enough to fit, insert the Slide the latch plate upward over the folded webbing. latch plate into the buckle until you hear a “click.” The folded webbing must enter the slot at the top of the latch plate.
  • Page 174 SAFETY NOTE: Belt Extender is not required for a different occupant, it Seat belts must be worn by all occupants including must be removed. pregnant women: the risk of injury in the event of an The adjustable upper shoulder belt anchorage is equipped accident is reduced for the mother and the unborn child if with an Easy Up feature.
  • Page 175 SAFETY Switchable Automatic Locking Retractor occupant’s mid-section so as to not activate the ALR. If the ALR is activated, you will hear a clicking sound as the seat (ALR) belt retracts. Allow the webbing to retract completely in The seat belts in the passenger seating positions are this case and then carefully pull out only the amount of equipped with a Switchable Automatic Locking Retractor webbing necessary to comfortably wrap around the...

  • Page 176: Supplemental Restraint Systems (Srs)

    SAFETY Allow the seat belt to retract. As the seat belt retracts, optional equipment on others. If you are not sure, ask an the ACC position, the air bag system is not on and the air you will hear a clicking sound. This indicates the seat authorized dealer.
  • Page 177 SAFETY (ORC) may also be disabled. In this condition the air bags instrument panel, above the glove compartment. The WARNING! may not be ready to inflate for your protection. Have an words “SRS AIRBAG” or “AIRBAG” are embossed on the air authorized dealer service the air bag system immediately.
  • Page 178 SAFETY Front Air Bag Operation Occupant Classification System (OCS) — This vehicle may be equipped with driver and/or front passenger seat track position sensors that may adjust the Front Passenger Seat Front Air Bags are designed to provide additional inflation rate of the Advanced Front Air Bags based upon protection by supplementing the seat belts.
  • Page 179 SAFETY The OCS will NOT prevent deployment of the Passenger  The front passenger seat is occupied by a small  The front passenger is not properly seated or his or her Advanced Front Air Bag. The OCS may reduce the inflation passenger, including a child;...
  • Page 180 SAFETY  Sitting with their back against the seatback and the Passenger Advanced Front Air Bag. Increasing the front WARNING! seatback in an upright position passenger’s seated weight on the front passenger seat may result in a full-power deployment of the Passenger ...
  • Page 181 SAFETY The OCS determines the front passenger’s most probable WARNING! classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output  Always wear your seat belt and sit properly, with the signal to the OCS that is different from the occupant’s seatback in an upright position, your back against properly seated weight input, for example: the seatback, sitting upright, facing forward, in the...
  • Page 182 SAFETY any modifications to the front passenger seat Supplemental Seat-Mounted Side Air Bags (SABs) are WARNING! components, assembly, or to the seat cover. If the seat, located in the outboard side of the front seats. The SABs trim cover, or cushion needs service for any reason, take are marked with “SRS AIRBAG”...
  • Page 183 SAFETY SABICs may help reduce the risk of head and other injuries Side Impacts WARNING! to front and rear seat outboard occupants in certain side The Side Air Bags are designed to activate in certain side impacts, in addition to the injury reduction potential Do not use accessory seat covers or place objects impacts.
  • Page 184 SAFETY Rollover Events  Seat Belt Buckle Switch WARNING! Side Air Bags and seat belt pretensioners are designed to  Supplemental Side Air Bags  Seat belts (and child restraints where appropriate) activate in certain rollover events. The Occupant Restraint ...
  • Page 185 SAFETY tion, rinse the area with cool water. For nose or throat  Flash hazard lights as long as the battery has power. system by following the procedure described below. If you irritation, move to fresh air. If the irritation continues, have any doubt, contact an authorized dealer.

  • Page 186: Child Restraints

    SAFETY These data can help provide a better understanding of the WARNING! WARNING! circumstances in which crashes and injuries occur. In a collision, an unrestrained child can become a  Do not attempt to modify any part of your air bag NOTE: projectile inside the vehicle.
  • Page 187 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who have not Either an Infant Carrier or a Convertible Child Restraint, facing Infants and Toddlers reached the height or weight limits of their child restraint rearward in a rear seat of the vehicle...
  • Page 188 SAFETY Children Too Large For Booster Seats If the answer to any of these questions was “no,” then the WARNING! child still needs to use a booster seat in this vehicle. If the Children who are large enough to wear the shoulder belt child is using the lap/shoulder belt, check seat belt fit ...
  • Page 189 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of the Restraint Type LATCH – Lower Anchors LATCH – Lower Anchors + Seat Belt + Top Tether Child + Child Restraint Seat Belt Only Only Top Tether Anchor Anchor...
  • Page 190 SAFETY 60/40 Second Row LATCH Positions (7 Passenger) Captain’s Chairs Second Row LATCH Positions (6 Passenger) Lower Anchorage Symbol (2 Anchorages Per Seating Lower Anchorage Symbol (2 Anchorages Per Seating Position) Position) Top Tether Anchorage Symbol Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined weight of the What is the weight limit (child’s weight + weight of the child restraint) for...
  • Page 191 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Never “share” a LATCH anchorage with two or more child restraints. If the center position does not have dedicated LATCH lower Can two child restraints be attached using a common lower LATCH anchorages, use the seat belt to install a child seat in the center anchorage? position next to a child seat using the LATCH anchorages in an...
  • Page 192 SAFETY Six And Seven Passenger Vehicles: 2nd Row Upper Tether Anchorage Locations There are tether strap anchorages behind each rear seating position located on the back of the seat. Seven Passenger Second Row Lower Anchorages Pulling Down The Carpet Floor Panel To Access Top Tether Strap Anchorage (Five Passenger) Locating The Upper Tether Anchorages Five Passenger Vehicles: 2nd Row Upper Tether...
  • Page 193 SAFETY tether anchorage and a way to tighten the strap after it is To access the center seat arm rest tether, first lower attached to the anchorage. the arm rest. The tether is located behind the armrest and hooked onto the plastic seat backing. Center Seat LATCH —...
  • Page 194 SAFETY Installing Child Restraints Using The Always follow the directions of the child restraint Test that the child restraint is installed tightly by manufacturer when installing your child restraint. Not all pulling back and forth on the child seat at the belt Vehicle Seat Belt child restraint systems will be installed as described here.
  • Page 195 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle 60/40 Second Row (7 Passenger) Automatic Locking Captain’s Chairs Second Row (6 Passenger) Automatic Retractor (ALR) Locations Locking Retractor (ALR) Locations ALR — Switchable Automatic Locking Retractor ALR — Switchable Automatic Locking Retractor 60/40 Second Row (5 Passenger) Automatic Locking Top Tether Anchorage Symbol Top Tether Anchorage Symbol...
  • Page 196 SAFETY Installing A Child Restraint With A Installing Child Restraints Using The Top Slide the latch plate into the buckle until you hear a “click.” Switchable Automatic Locking Retractor Tether Anchorage Pull on the webbing to make the lap portion tight (ALR): against the child seat.
  • Page 197 SAFETY To access the top tether strap anchorages behind the rear seat, pull the carpeted floor panel away from the seat back, this will expose the top tether strap anchorages. Third Row Top Tether Strap Anchorage (Located On Seatback) Bench Seat Top Tether Strap Mounting (5 Passenger Seating) Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.

  • Page 198: Safety Tips

    SAFETY WARNING! WARNING!  The top tether anchorages are not visible until the  Do not allow people to ride in any area of your vehicle gap panel is folded down. Do not use the visible that is not equipped with seats and seat belts. cargo tie down hooks, located on the floor behind the ...

  • Page 199: Safety Checks You Should Make Inside The Vehicle

    SAFETY while driving, have an authorized dealer service the WARNING! WARNING! vehicle immediately page 168. Ú It is not possible to know or to predict all of the possible Defroster  ALWAYS REMOVE THE EXISTING outcomes if your vehicle’s systems are breached. It may FLOOR MAT FROM THE VEHICLE before Check operation by selecting the defrost mode and place be possible that vehicle systems, including safety...

  • Page 200: Periodic Safety Checks You Should Make Outside The Vehicle

    SAFETY signal and high beam indicator lights on the instrument The best protection against carbon monoxide entry into the WARNING! panel. vehicle body is a properly maintained engine exhaust system. Door Latches  NEVER place any objects under the floor mat (e.g., Whenever a change is noticed in the sound of the exhaust towels, keys, etc.).

  • Page 201: In Case Of Emergency

    IN CASE OF EMERGENCY HAZARD WARNING FLASHERS NOTE: WARNING! With extended use, the Hazard Warning Flashers may discharge the battery. The Hazard Warning Flashers button is located on the ALWAYS obey traffic laws and pay attention to the road. switch bank just below the climate controls. ALWAYS drive safely with your hands on the steering SOS AND ASSIST MIRROR —...
  • Page 202 IN CASE OF EMERGENCY the cancellation button on the Device Screen. Termination NOTE: WARNING! of the SOS Call will turn off the green LED light on the  Your vehicle may be transmitting data as autho- Rearview Mirror.  The SOS Call system is embedded into the vehicle’s rized by the subscriber.
  • Page 203 IN CASE OF EMERGENCY  The Device Screen will display the following message  Equipment malfunction at the SOS operator facility CAUTION! “Vehicle device requires service. Please contact an  Operator error by the SOS operator authorized dealer.” To avoid damage to the mirror during cleaning, never ...

  • Page 204: Jacking And Tire Changing

    IN CASE OF EMERGENCY JACKING AND TIRE CHANGING OCATION WARNING! The scissor-type jack and tire changing tools are located in Do not attempt to change a tire on the side of the WARNING! rear cargo area, below the load floor. vehicle close to moving traffic.

  • Page 205: Spare Tire Stowage

    IN CASE OF EMERGENCY To remove, press down firmly on the upper tabs of the jack PARE TOWAGE PARE EMOVAL storage cover to release. The spare tire is stowed under the rear of the vehicle by Remove the spare tire before attempting to jack up the means of a cable winch mechanism.
  • Page 206 IN CASE OF EMERGENCY Winch Location Spare Tire Spare Tire Retainer NOTE: Slide the metal stamping up the steel extension tube and winch cable. Rotate the metal stamping and Depending on the vehicle trim, the vehicle may come push it through the hole in the plastic plate (if equipped with both, a metal retainer and plastic plate or a applicable) and wheel.

  • Page 207: Jacking Instructions

    IN CASE OF EMERGENCY If your vehicle is equipped with a spare tire retainer CAUTION! WARNING! and plastic plate. Pinch the three short and two long tubes to remove the protective plate from the steel Do not attempt to raise the vehicle by jacking on ...
  • Page 208 IN CASE OF EMERGENCY NOTE: Placement for the front and rear jacking locations are critical. See the following images for proper jacking loca- tions. Front Jacking Location Rear Jacking Location For a rear tire, place the jack in the slot on the rear Raise the vehicle by turning the jack screw clockwise.
  • Page 209 IN CASE OF EMERGENCY Install the spare wheel/tire on the vehicle and install Finish tightening the wheel bolts. Push down on the the lug nuts with the cone-shaped end toward the wrench while at the end of the handle for increased wheel.

  • Page 210: Jump Starting

    IN CASE OF EMERGENCY NOTE: Expand the jack on the bracket by turning the thumb CAUTION! screw clockwise until it is tight to prevent rattles. Double check to ensure the tire is snug against the underbody of the vehicle. Damage to the winch cable may Do not use a portable battery booster pack or any other 15.

  • Page 211: Jump Starting Procedure

    IN CASE OF EMERGENCY NOTE: Connecting The Jumper Cables WARNING! Be sure that the disconnected cable ends do not touch Connect the positive (+) end of the jumper cable to each other, or either vehicle, before properly connected  Remove any metal jewelry such as rings, watch the remote positive (+) post of the discharged for jump starting.

  • Page 212: Refueling In Emergency

    IN CASE OF EMERGENCY REFUELING IN EMERGENCY Disconnecting The Jumper Cables Disconnect the negative (-) end of the jumper cable The vehicle is equipped with a refueling funnel for a from the remote negative (-) post of the discharged Cap-Less Fuel System. The fuel funnel can be found in the vehicle.

  • Page 213: If Your Engine Overheats

    IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS Insert funnel into same filler pipe opening as the fuel WARNING! nozzle. If the vehicle is overheating, it will need to be serviced by You or others can be badly burned by hot engine an authorized dealer.
  • Page 214 IN CASE OF EMERGENCY In order to move the vehicle in cases where the CAUTION! transmission will not shift out of PARK (P) (such as a depleted battery), a Manual Park Release is available. Closing the armrest while the Manual Park Release is activated may damage the Manual Park Release Follow these steps to use the Manual Park Release: mechanism, the transmission, and/or the armrest.

  • Page 215: Freeing A Stuck Vehicle

    IN CASE OF EMERGENCY Once the tension has been released and the lever NOTE: CAUTION! has been unlocked, be sure it is stowed properly and Shifts between DRIVE (D) and REVERSE (R) can only be locks into position. achieved at wheel speeds of 5 mph (8 km/h) or less. ...

  • Page 216: Towing A Disabled Vehicle

    IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled 4x4 vehicles may also be towed as described under page 129. Ú...

  • Page 217: Rear Wheel Drive Models

    IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM straight position) with the rear wheels raised and the front HEEL RIVE ODELS wheels ON the ground. (EARS) FCA US LLC recommends towing your vehicle with all four HEEL RIVE ODELS wheels OFF the ground using a flatbed. This vehicle is equipped with an Enhanced Accident If flatbed equipment is not available, and the transmission FCA US LLC recommends towing with all wheels OFF the...

  • Page 218: Servicing And Maintenance

    SERVICING AND MAINTENANCE SCHEDULED SERVICING Have your vehicle serviced as soon as possible, within the Once A Month Or Before A Long Trip: next 500 miles (805 km).  Check engine oil level Your vehicle is equipped with an automatic oil change An authorized dealer will reset the oil change indicator ...
  • Page 219 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
  • Page 220 SERVICING AND MAINTENANCE Mileage Or Time Passed (Whichever Comes First) Or Years: Or Kilometers: Inspect accessory drive belt tensioner and pulley, replace if necessary. Change transfer case fluid - Normal Usage. Change transfer case fluid - Severe Usage (police, taxi, fleet, off-road or frequent trailer towing).

  • Page 221: Engine Compartment

    SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L E NGINE 1 — Remote Jump Start Negative Terminal 6 — Brake Fluid Reservoir Cap 2 — Remote Jump Start Positive Terminal 7 — Engine Coolant Pressure Cap 3 — Power Distribution Center (Fuses) 8 —...

  • Page 222: L Engine

    SERVICING AND MAINTENANCE 5.7L E NGINE 1 — Remote Jump Start Negative Terminal 6 — Engine Coolant Reservoir Cap 2 — Remote Jump Start Positive Terminal 7 — Engine Coolant Pressure Cap 3 — Power Distribution Center (Fuses) 8 — Engine Oil Dipstick 4 —...

  • Page 223: Checking Oil Level

    SERVICING AND MAINTENANCE HECKING EVEL DDING ASHER LUID AINTENANCE ATTERY To ensure proper engine lubrication, the engine oil must The instrument cluster display will indicate when the Your vehicle is equipped with a maintenance-free battery. be maintained at the correct level. Check the oil level at washer fluid level is low.

  • Page 224: Pressure Washing

    SERVICING AND MAINTENANCE American Petroleum Institute (API) WARNING! CAUTION! Approved Engine Oil You can be badly injured working on or around a motor  If a “fast charger” is used while the battery is in the These symbols mean that the oil has been certified by the vehicle.

  • Page 225: Engine Oil Filter

    SERVICING AND MAINTENANCE Disposing Of Used Engine Oil And Oil Engine Air Cleaner Filter Selection Remove the engine air cleaner filter from the housing assembly. Filters The quality of replacement filters varies considerably. Only high quality Mopar® certified filters should be used. Care should be taken in disposing of used engine oil and Engine Air Cleaner Filter Inspection and oil filters from your vehicle.

  • Page 226: Air Conditioner Maintenance

    SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling ONDITIONER AINTENANCE WARNING! R-134a — If Equipped For best possible performance, your air conditioner should Do not remove the cabin air filter while the vehicle is R-134a Air Conditioning Refrigerant is a Hydrofluo- be checked and serviced by an authorized dealer at the running, or while the ignition is in the ACC or ON/RUN rocarbon (HFC) that is an ozone-friendly substance.

  • Page 227: Accessory Drive Belt Inspection

    SERVICING AND MAINTENANCE There are glove compartment travel stops on both Remove the filter cover by disengaging the retaining CAUTION! sides of the glove compartment door. Partially close tab and mid way snap that secures the filter cover to the glove compartment door and push inward to the HVAC housing.

  • Page 228: Body Lubrication

    SERVICING AND MAINTENANCE  Rib or belt wear The external lock cylinders should be lubricated twice a WARNING! year, preferably in the Autumn and Spring. Apply a small  Longitudinal belt cracking (cracks between two ribs) amount of a high quality lubricant, such as Mopar® Lock ...
  • Page 229 SERVICING AND MAINTENANCE If a wiper blade or wiper arm is damaged, replace the To disengage the wiper blade from the wiper arm, flip affected wiper arm or blade with a new unit. Do not up the release tab on the wiper blade and while attempt to repair a wiper arm or blade that is damaged.
  • Page 230 SERVICING AND MAINTENANCE Slide the wiper blade up into the hook on the wiper Lift the rear wiper arm fully off the glass. arm and rotate the wiper blade until it is flush against the wiper arm. Fold down the latch release tab and snap it into its locked position.

  • Page 231: Exhaust System

    SERVICING AND MAINTENANCE Insert the wiper blade pivot pin into the opening on Under normal operating conditions, the catalytic converter WARNING! the end of the wiper arm. Grab the bottom end of the will not require maintenance. However, it is important to wiper arm with one hand, and press the wiper blade keep the engine properly tuned to ensure proper catalyst ...

  • Page 232: Cooling System

    SERVICING AND MAINTENANCE system for leaks. DO NOT REMOVE THE COOLANT products, as they may not be compatible with the OOLING YSTEM PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. radiator engine coolant and may plug the radiator. Cooling System — Drain, Flush And Refill ...

  • Page 233: Brake System

    SERVICING AND MAINTENANCE higher concentrations (not to exceed 70%) if tempera- If an examination of your engine compartment shows no WARNING! tures below −34°F (−37°C) are anticipated. Please evidence of radiator or hose leaks, the vehicle may be contact an authorized dealer for assistance. safely driven.

  • Page 234: Automatic Transmission

    SERVICING AND MAINTENANCE WARNING! CAUTION! WARNING! Riding the brakes can lead to brake failure and possibly Do not use chemical flushes in your transmission as the  To avoid contamination from foreign matter or mois- a collision. Driving with your foot resting or riding on the chemicals can damage your transmission components.

  • Page 235: Front/Rear Axle Fluid

    SERVICING AND MAINTENANCE Drain contaminated (with water, etc.), or if the transmission is CAUTION! disassembled for any reason. First remove fill plug, then remove drain plug. Do not overtighten the plugs as it could damage them Selection Of Lubricant Recommended tightening torque for drain and fill plugs is and cause them to leak.
  • Page 236 SERVICING AND MAINTENANCE Underhood Fuses WARNING! The Power Distribution Center is located in the engine  Before replacing a fuse, make sure that the ignition compartment near the battery jump start posts. This is off and that all the other services are switched off center contains cartridge fuses, micro fuses, relays, and and/or disengaged.
  • Page 237 SERVICING AND MAINTENANCE Power Distribution Center Location Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – – Spare 60 Amp Yellow – Rad Fan *...
  • Page 238 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 60 Amp Yellow – ESP Pump – – Spare 40 Amp Green – ABS Pump * 30 Amp Pink – Starter Solenoid – – Spare 30 Amp Pink –...
  • Page 239 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 30 Amp Pink – ESP / ECU Valves – – Spare 20 Amp Blue – Trlr Tow B/U * 20 Amp Blue – Trlr Tow Park * 30 Amp Pink –...
  • Page 240 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – 10 Amp Red ICS / HVAC – 20 Amp Yellow ELSD * – 15 Amp Blue KIN / RF HUB – – Spare – 20 Amp Yellow Trlr Tow LT Turn / Stop * –...
  • Page 241 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 20 Amp Yellow Fuel Pump Mtr – 30 Amp Green Amplifier */ ANCM * – 10 Amp Red ECM * – 15 Amp Blue HID Headlamp - RT * –...
  • Page 242 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red Rr Console Lamp * / RR Pwr Outlet – 20 Amp Yellow Cigar Lighter – 10 Amp Red Sbw / Tcase Sw – 10 Amp Red Rr Cam / Blind Spot Snsr * –...

  • Page 243: Bulb Replacement

    SERVICING AND MAINTENANCE EPLACEMENT Replacement Bulbs, Names, And Part Numbers In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. NOTE: See an authorized dealer for LED bulb replacement. Interior Bulbs Bulb Name Bulb Number Glove Compartment Lamp Grab Handle Lamp...
  • Page 244 SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Front Fog Lamps Rear Tail Lamps/Side Marker Lamps Rear Stop/Turn Signal Lamps Rear Liftgate Tail Lamps Rear Backup Lamps 921 (W16W) Rear License Lamps Center High Mounted Stop Lamp (CHMSL) Bulb Replacement FRONT TURN SIGNAL FRONT FOG LAMPS NOTE:...

  • Page 245: Tires

    SERVICING AND MAINTENANCE Tire Markings Remove/replace bulb(s). NOTE: Reinstall the socket(s).  P (Passenger) — Metric tire sizing is based on US design standards. P-Metric tires have the letter “P” molded Reverse process to reinstall the liftgate trim. into the sidewall preceding the size designation. Example: P215/65R15 95H.
  • Page 246 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
  • Page 247 SERVICING AND MAINTENANCE EXAMPLE: Load Identification: Absence of the following load identification symbols on the sidewall of the tire indicates a Standard Load (SL) tire:  XL = Extra load (or reinforced) tire, or  LL = Light load tire or ...
  • Page 248 SERVICING AND MAINTENANCE EXAMPLE: 01 = Number representing the year in which the tire was manufactured (two digits)  01 means the year 2001  Prior to July 2000, tire manufacturers were only required to have one number to represent the year in which the tire was manufactured. Example: 031 could represent the 3rd week of 1981 or 1991 Tire Terminology And Definitions Term...
  • Page 249 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: Number of people that can be carried in the vehicle. NOTE: The proper cold tire inflation pressure is listed on the Total weight your vehicle can carry. driver’s side B-pillar or the rear edge of the driver's side Tire size designed for your vehicle.
  • Page 250 SERVICING AND MAINTENANCE (4) The resulting figure equals the (6) If your vehicle will be towing a trailer, Steps For Determining Correct Load Limit— available amount of cargo and luggage load from your trailer will be transferred (1) Locate the statement “The combined load capacity.

  • Page 251: Tires - General Information

    SERVICING AND MAINTENANCE NOTE:  If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. The following table shows examples on how to calculate total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations and number and size of occupants. This table is for illustration purposes only and may not be accurate for the seating and load carry capacity of your vehicle.
  • Page 252 SERVICING AND MAINTENANCE Safety Fuel Economy Inflation pressures specified on the placard are always “cold tire inflation pressure”. Cold tire inflation pressure is Underinflated tires will increase tire rolling resistance WARNING! defined as the tire pressure after the vehicle has not been resulting in higher fuel consumption.
  • Page 253 SERVICING AND MAINTENANCE vehicle dealer for recommended safe operating speeds, Consult an authorized tire dealer for tire repairs and WARNING! loading and cold tire inflation pressures. additional information. Fast spinning tires can be dangerous. Forces generated Damaged Run Flat tires, or Run Flat tires that have WARNING! by excessive wheel speeds may cause tire damage or experienced a loss of pressure should be replaced...
  • Page 254 SERVICING AND MAINTENANCE These indicators are molded into the bottom of the tread NOTE: WARNING! grooves. They will appear as bands when the tread depth Wheel valve stem must be replaced as well when installing becomes 1/16 of an inch (1.6 mm). When the tread is new tires due to wear and tear in existing tires.

  • Page 255: Tire Types

    SERVICING AND MAINTENANCE Snow Tires YPES CAUTION! Some areas of the country require the use of snow tires All Season Tires — If Equipped Because of the reduced ground clearance, do not take during the Winter. Snow tires can be identified by a your vehicle through an automatic car wash with a All Season tires provide traction for all seasons (Spring, “mountain/snowflake”...

  • Page 256: Wheel And Wheel Trim Care

    SERVICING AND MAINTENANCE Do not install a wheel cover or attempt to mount a Do not install a wheel cover or attempt to mount a equipment tire, replace (or repair) the original equipment conventional tire on the compact spare wheel, since the conventional tire on the collapsible spare wheel, since the tire and reinstall on the vehicle at the first opportunity.
  • Page 257 SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or Low Gloss CAUTION! CAUTION! Clear Coat Wheels Avoid products or automatic car washes that use acidic Do not use scouring pads, steel wool, a bristle brush, CAUTION! solutions or strong alkaline additives or harsh brushes. metal polishes or oven cleaner.

  • Page 258: Snow Traction Devices

    SERVICING AND MAINTENANCE RACTION EVICES Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance, the following snow traction devices are recommended. Follow these recommendations to guard against damage.  Snow traction device must be of proper size for the tire, as recommended by the snow traction device manufacturer. ...

  • Page 259: Tire Rotation Recommendations

    SERVICING AND MAINTENANCE OTATION ECOMMENDATIONS WARNING! The tires on the front and rear of your vehicle operate at Using tires of different size and type (M+S, Snow) different loads and perform different steering, handling, between front and rear axles can cause unpredictable and braking functions.

  • Page 260: Treadwear

    SERVICING AND MAINTENANCE concrete. A tire marked C may have poor represent higher levels of performance READWEAR traction performance. on the laboratory test wheel, than the The Treadwear grade is a comparative minimum required by law. rating, based on the wear rate of the tire WARNING! when tested under controlled conditions WARNING!

  • Page 261: Bodywork

    SERVICING AND MAINTENANCE BODYWORK NDERBODY AINTENANCE CAUTION! Cleaning Headlights  Do not use abrasive or strong cleaning materials ROTECTION TMOSPHERIC such as steel wool or scouring powder that will Your vehicle is equipped with plastic headlights and fog GENTS scratch metal and painted surfaces. lights that are lighter and less susceptible to stone breakage than glass headlights.

  • Page 262: Interiors

    SERVICING AND MAINTENANCE INTERIORS Cleaning Plastic Instrument Cluster WARNING! Lenses A frayed or torn seat belt could rip apart in a collision and EATS ABRIC ARTS The lenses in front of the instruments in this vehicle are leave you with no protection. Inspect the seat belt molded in clear plastic.

  • Page 263: Glass Surfaces

    SERVICING AND MAINTENANCE NOTE: LASS URFACES CAUTION! If equipped with light colored leather, it tends to show any All glass surfaces should be cleaned on a regular basis foreign material, dirt, and fabric dye transfer more so than Do not use Alcohol and Alcohol-based and/or Ketone darker colors.

  • Page 264: Technical Specifications

    TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) BRAKE SYSTEM ORQUE PECIFICATIONS Base Model Vehicle The VIN is found on a label located on the left front corner Your vehicle is equipped with dual hydraulic brake of the instrument panel pad, visible from outside of the systems.

  • Page 265: Fuel Requirements

    TECHNICAL SPECIFICATIONS NOTE: recommended octane number can cause engine failure EFORMULATED ASOLINE and may void the New Vehicle Limited Warranty. If in doubt about the correct tightness, have them checked Many areas of the country require the use of cleaner with a torque wrench by an authorized dealer or service Poor quality gasoline can cause problems such as hard station.

  • Page 266: Gasoline/Oxygenate Blends

    TECHNICAL SPECIFICATIONS  Poor engine performance. ASOLINE XYGENATE LENDS YSTEM AUTIONS  Poor cold start and cold drivability. Some fuel suppliers blend unleaded gasoline with CAUTION!  Increased risk for fuel system component corrosion. oxygenates such as ethanol. CNG A LP F Follow these guidelines to maintain your vehicle’s YSTEM...

  • Page 267: Fluid Capacities

    TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 3.6L and 5.7L Engines 24.6 Gallons 93 Liters Engine Oil With Filter 3.6L Engine 6 Quarts 5.6 Liters 5.7L Engine 7 Quarts 6.6 Liters Cooling System * 3.6L Engine – Without Trailer Tow Package 10.4 Quarts 9.9 Liters 3.6L Engine –...

  • Page 268: Engine Fluids And Lubricants

    TECHNICAL SPECIFICATIONS ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Engine Coolant Formula OAT (Organic Additive Technology) meeting the requirements of the manufacturer Material Standard MS.90032. We recommend using Mopar® SAE 0W-20 Full Synthetic Engine Oil which meets the requirements of the manufacturer Material Standard MS-6395.

  • Page 269: Chassis Fluids And Lubricants

    TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or equivalent. Failure Automatic Transmission to use the correct fluid may affect the function or performance of your transmission. Transfer Case We recommend using Mopar®...

  • Page 270: Customer Assistance

    CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE IF YOU NEED ASSISTANCE FCA US LLC C USTOMER ENTER FOR YOUR VEHICLE P.O. Box 21–8004 FCA US LLC and its authorized dealers are vitally interested in your satisfaction. We want you to be happy Auburn Hills, MI 48321–8004 with our products and services.

  • Page 271: Puerto Rico And Us Virgin Islands

    CUSTOMER ASSISTANCE US V protection beyond your vehicle’s warranty. If you Use this QR code to access your digital UERTO IRGIN SLANDS purchased a Mopar® Vehicle Protection Plan, you will experience. FCA Caribbean LLC receive Plan Provisions and an Owner Identification Card in the mail within three weeks of the vehicle delivery date.

  • Page 272: In Canada

    CUSTOMER ASSISTANCE remedy campaign. However, NHTSA Diagnostic Procedure Manuals ANADA cannot become involved in individual Diagnostic Procedure Manuals are filled with diagrams, If you believe that your vehicle has a charts and detailed illustrations. These manuals make it problems between you, an authorized safety defect, you should contact the easy to find and fix problems on computer-controlled dealer or FCA US LLC.

  • Page 273: General Information

    CUSTOMER ASSISTANCE GENERAL INFORMATION Le présent appareil est conforme aux CNR d`Innovation, La operación de este equipo está sujeta a las siguientes Science and Economic Development applicables aux dos condiciones: appareils radio exempts de licence. L'exploitation est The following regulatory statement applies to all Radio es posible que este equipo o dispositivo no cause autorisée aux deux conditions suivantes: Frequency (RF) devices equipped in this vehicle:...
  • Page 274 INDEX Air Conditioning Automatic Transmission ......... 88 Rear................53 Adding Fluid............. 232 About Your Brakes ............262 Air Conditioning Filter ........56 Fluid And Filter Change........... 232 Adaptive Cruise Control (ACC) Air Conditioning System ..........54 Fluid Change ............232 (Cruise Control) ...........
  • Page 275 Parking ...............91 Locating The LATCH Anchorages......189 Diagnostic System, Onboard ......... 86 Warning Light .............80 Lower Anchors And Tethers For Children....187 Dipsticks Brake/Transmission Interlock........93 Older Children And Child Restraints.......185 Oil (Engine) .............. 221 Bulb Replacement ..........241 Seating Positions.............187 Disabled Vehicle Towing ..........214 Bulbs, Light..............
  • Page 276 Engine ................219 Flooded Engine Starting ..........90 Gasoline, Reformulated ..........263 Air Cleaner............... 223 Fluid Capacities ............265 Gear Ranges ..............94 Break-In Recommendations ........91 Fluid Leaks ..............198 Glass Cleaning.............. 261 Checking Oil Level ..........221 Fluid Level Checks Gross Axle Weight Rating..........121 Compartment..........
  • Page 277 Switch .................16 Center Mounted Stop ..........243 Illuminated Entry .............47 Cruise............ 83 Key Fob................13 Immobilizer (Sentry Key)..........15 Daytime Running............44 Arm The System............19 Inside Rearview Mirror.......... 37 Dimmer Switch, Headlight........43 Disarm The System ........... 20 Instrument Cluster ...........72 Electric Power Steering..........
  • Page 278 Trailer Brake Disconnected........82 Outside............... 38 Operating Precautions ........... 86 Transmission Temperature ........82 Rearview ............37 Operator Manual Turn Signals ........43 Vanity................38 Owner's Manual ............270 Vanity Mirror...............38 Modifications/Alterations Outside Rearview Mirrors ..........38 Warning Instrument Cluster Descriptions....81 Vehicle................8 Load Shed Battery Saver Mode ........79 Monitor, Tire Pressure System........165 Load Shed Battery Saver On ..........79...
  • Page 279 Pretensioners Remote Starting System ..........17 Operating Instructions ..........170 Seat Belts..............172 Replacement Bulbs ............241 Pregnant Women ............ 172 Replacement Keys............15 Pretensioners ............172 Replacement Tires............252 Rear Seat..............169 Reporting Safety Defects ..........269 Reminder ..............169 Radial Ply Tires............. 251 Restraints, Child ............184 Seat Belt Extender ..........
  • Page 280 Spare Tires ..........203 Towing ..............120 Speed Control Disabled Vehicle............214 Telescoping Steering Column ........24 Accel/Decel............. 103 Guide................ 123 Temperature Control, Automatic (ATC) ......54 Accel/Decel (ACC Only)........... 107 Recreational ............129 Tie Down Hooks, Cargo ..........68 Cancel..............103 Weight..............
  • Page 281 Universal Garage Door Opener (homelink®) — Windshield Defroster ........... 197 If Equipped b ..............39 Windshield Washers ..........47 Warning Flashers, Hazard ..........199 Unleaded Gasoline............263 Fluid ................. 221 Warning Lights (Instrument Cluster Descriptions) ..83 Untwisting Procedure, Seat Belt ......... 171 Windshield Wiper Blades..........
  • Page 283 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Dodge brand vehicle and to provide a convenient reference source for common questions.
  • Page 284 Whether it’s providing information about specific product features, taking a tour through your vehicle’s heritage, knowing what steps to take following an accident or scheduling your next appointment, we know you’ll find the app an important extension of your Dodge brand vehicle. Simply download the app, select your make and model and enjoy the ride. To get this app, go...

Table of Contents
