Summary of Contents for Dodge Durango

Page 1 Durango 2 0 1 2 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and the features and equipment that are either standard or optional name Chrysler Canada Inc.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Warnings And Cautions ....8 Rollover Warning .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION handles on different road surfaces. Your driving skills Congratulations on selecting your new Chrysler Group will improve with experience. When driving off-road or LLC vehicle. Be assured that it represents precision working the vehicle, don’t overload the vehicle or expect workmanship, distinctive styling, and high quality - all the vehicle to overcome the natural laws of physics.
Page 7: Rollover Warning
INTRODUCTION 5 NOTE: After reviewing the owner information, it Do not attempt sharp turns, abrupt maneuvers, or other should be stored in the vehicle for convenient referenc- unsafe driving actions that can cause loss of vehicle ing and remain with the vehicle when sold. control.
Page 8: How To Use This Manual
6 INTRODUCTION Failure to use the driver and passenger seat belts pro- HOW TO USE THIS MANUAL vided is a major cause of severe or fatal injury. In fact, the Consult the Table of Contents to determine which section U.S. government notes that the universal use of existing contains the information you desire.
Page 9 INTRODUCTION 7...
Page 10: Warnings And Cautions
8 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 11: Vehicle Modifications/Alterations
INTRODUCTION 9 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Right Front Body VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 13: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....14 Vehicle Security Alarm — If Equipped ..20 Wireless Ignition Node (WIN) .
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using The Panic Alarm ....26 Windows ......42 Programming Additional Transmitters .
Page 15 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Energy Management Feature ... . . 60 Event Data Recorder (EDR) ....80 Seat Belt Pretensioners .
Page 16: A Word About Your Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN) Your vehicle uses a keyless ignition system. This system The Wireless Ignition Node (WIN) operates similar to an consists of a Key Fob with Remote Keyless Entry (RKE) ignition switch.
Page 17: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.
Page 18: Removing Key Fob From Ignition
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Removing Key Fob From Ignition at the top of the Key Fob sideways with your thumb and Place the shift lever in PARK. Turn the Key Fob to the then pull the key out with your other hand.
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 • The power window switches, radio, power sunroof (if CAUTION! (Continued) equipped), and power outlets will remain active for up • Leave the Key Fob in the ignition and either: to 10 minutes after the ignition switch is turned to the •...
Page 20: Key-In-Ignition Reminder
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Key-In-Ignition reminder only sounds WARNING! (Continued) when the Key Fob is placed in the OFF or ACC ignition • Do not leave the key fob in or near the vehicle, and position.
Page 21: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 vehicle can be used to start and operate the vehicle. The CAUTION! system will shut the engine off in two seconds if an invalid Key Fob is used to start the engine. The Sentry Key Immobilizer system is not compat- ible with some after-market remote starting systems.
Page 22: Customer Key Programming
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Key Programming CAUTION! Programming Key Fobs or RKE transmitters may be • Always remove the Key Fobs from the vehicle and performed at an authorized dealer. lock all doors when leaving the vehicle unat- General Information tended.
Page 23: Rearming The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 audio and visual signals, the horn will sound, the head- To Arm The System lights will turn on, park lamps and/or turn signals will Follow these steps to arm the Vehicle Security Alarm: flash repeatedly for three minutes.
Page 24: To Disarm The System
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Cycle the vehicle ignition system out of the OFF exterior zone (refer to Keyless Enter-N-Go in Things To Know Before Starting Your Vehicle for further informa- position. tion). • For vehicles equipped with Keyless Enter-N-Go, •...
Page 25: Tamper Alert
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 • When the Vehicle Security Alarm is armed, the interior Tamper Alert power door lock switches will not unlock the doors. If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times and the The Vehicle Security Alarm is designed to protect your exterior lights blink three times when you unlock the vehicle;...
Page 26: Remote Keyless Entry (Rke)
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: NOTE: Inserting the Key Fob with RKE transmitter into • The front courtesy overhead console and door cour- the ignition switch disables the system from responding tesy lights will turn on if the dimmer control is in the to any button presses from that RKE transmitter.
Page 27: To Unlock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 To Unlock The Doors Flash Lamps With Lock Press and release the UNLOCK button on the RKE This feature will cause the turn signal lamps to flash transmitter once to unlock the driver’s door or twice to when the doors are locked or unlocked with the RKE unlock all doors.
Page 28: To Lock The Doors
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Lock The Doors Using The Panic Alarm Press and release the LOCK button on the RKE transmit- To turn the Panic Alarm feature on or off, press and hold ter to lock all doors. The turn signal lamps will flash and the PANIC button on the RKE transmitter for at least one the horn will chirp to acknowledge the signal.
Page 29: Transmitter Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Transmitter Battery Replacement The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate • Do not touch the battery terminals that are on the back housing or the printed circuit board.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the tip of the emergency key or a #2 flat blade screwdriver into the slot and gently pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal.
Page 31: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 4. To assemble the RKE transmitter case, snap the two If your RKE transmitter fails to operate from a normal halves together. distance, check for these two conditions: 1. A weak battery in the RKE transmitter. The expected General Information life of the battery is a minimum of three years.
Page 32: How To Use Remote Start
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • System not disabled from previous remote start event How To Use Remote Start All of the following conditions must be met before the • Vehicle theft alarm not active engine will remote start: •...
Page 33: To Enter Remote Start Mode
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 Remote Start Abort Message On Electronic Vehicle To Enter Remote Start Mode Information Center (EVIC) — If Equipped Press and release the REMOTE START button The following messages will display in the EVIC if the on the RKE transmitter twice within five sec- vehicle fails to remote start or exits remote start prema- onds.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The engine can be started two consecutive times with To Exit Remote Start Mode And Drive The Vehicle the RKE transmitter. However, the ignition must be Before the end of 15 minute cycle, press and release the cycled by pushing the START/STOP button twice (or UNLOCK button on the RKE transmitter to unlock the the ignition switch must be cycled to the ON/RUN...
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 • For vehicles not equipped with the Keyless Enter- Remote Start Comfort Systems — If Equipped N-Go feature, the message “Remote Start Active — When remote start is activated, the heated steering Insert Key and Turn to Run”...
Page 36: Door Locks
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks The power door locks can be manually locked from inside the vehicle by using the door lock knob. To lock each door, push the door lock knob on each door trim panel downward.
Page 37: Power Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Power Door Locks WARNING! The power door lock switch is located on each front door • For personal security and safety in the event of an panel. Press the switch to lock or unlock the doors. accident, lock the vehicle doors when you drive, as well as when you park and leave the vehicle.
Page 38: Child-Protection Door Lock System - Rear Doors
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the door lock switch while the Key Fob is in Vehicle Information Center (EVIC)/Personal Settings the ignition switch and the driver’s door is open, the (Customer-Programmable Features)” in “Understanding doors will not lock.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 3. Repeat steps 1 and 2 for the opposite rear door. Child-Protection Door Lock Function Child-Protection Door Lock Location WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged (locked).
Page 40: Keyless Enter-N-Go
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: For emergency exit with the system engaged, the handle may time out. Pulling the deactivated front move the lock knob up (unlocked position), roll down the door handle will reactivate the door handle’s Passive window and open the door with the outside door handle.
Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 To Unlock From The Passenger Side: With a valid Passive Entry RKE transmitter within 5 ft (1.5 m) of the passenger door handle, grab the front passenger door handle to unlock all four doors automati- cally.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If one of the vehicle doors is open and the door panel switch is used to lock the vehicle, once all open doors have been closed the vehicle checks the inside and outside of the vehicle for any valid Passive Entry RKE transmitters.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 refer to “Electronic Vehicle Information Center (EVIC)/ With one of the vehicle’s Passive Entry RKE transmitters Personal Settings (Customer-Programmable Features)” in within 5 ft (1.5 m) of the driver or passenger front door “Understanding Your Instrument Panel”.
Page 44: Windows
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows The power window controls are located on the driver’s door trim panel. There is a single switch on the front passenger door/rear doors which operates the front passenger/rear passenger door windows. The window controls will operate only when the ignition switch is in the ON/RUN or ACCESSORY position.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Auto-Down To stop the window from going all the way up during the Both the driver and front passenger window switches Auto Up operation, push down on the switch briefly. have an “Auto-Down” feature. Press the window switch To close the window part way, lift the window switch to past the first detent, release, and the window will go the first detent and release when you want the window to...
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Resetting The Auto Up Feature Should the Auto Up feature stop working, the window probably needs to be reset. To reset Auto Up: 1. Pull the window switch up to close the window completely and continue to hold the switch up for an additional two seconds after the window is closed.
Page 47: Wind Buffeting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 48: Power Liftgate - If Equipped
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Liftgate — If Equipped When the LIFTGATE button on the RKE transmitter is The power liftgate may be opened by pulling pressed two times, the turn signals will flash twice to up on the liftgate handle or by pressing the signal that the liftgate is opening or closing (if Flash LIFTGATE button on the Remote Keyless Entry...
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 button to operate. If the liftgate is not fully open, press WARNING! the Liftgate button on the Key Fob to fully open the liftgate, and then press it again to close. During power operation, personal injury or cargo damage may occur.
Page 50: Occupant Restraints
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If the power liftgate encounters multiple obstructions WARNING! (Continued) within the same cycle, the system will automatically • If you are required to drive with the liftgate open, stop and the liftgate must be opened or closed manu- make sure that all windows are closed, and the ally.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 • Supplemental Active Head Restraints (AHR) located way out and then adjusting the belt to the desired on top of the front seats (integrated into the head length to restrain a child seat or secure a large item in restraint) a seat —...
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying air bag: children to slide the shoulder belt behind them or under their arm.
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 4. Do not lean against the door or window. If your WARNING! (Continued) vehicle has side air bags, and deployment occurs, the • Being too close to the steering wheel or instrument side air bags will inflate forcefully into the space panel during Advanced Front Air Bag deployment between you and the door.
Page 54: Lap/Shoulder Belts
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even WARNING! on short trips. Someone on the road may be a poor driver • Wearing a seat belt incorrectly is dangerous. Seat and cause a collision that includes you.
Page 55: Lap/Shoulder Belt Operating Instructions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 2. The seat belt latch plate is above the back of your seat. WARNING! (Continued) Grasp the latch plate and pull out the belt. Slide the latch • It is dangerous to ride in a cargo area, inside or plate up the webbing as far as necessary to make the belt outside of a vehicle.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt that is buckled into the wrong buckle will not protect you properly.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 4. Position the lap belt across your thighs, below your WARNING! (Continued) abdomen. To remove slack in the lap portion, pull up a • A belt that is worn under your arm is dangerous. bit on the shoulder belt.
Page 58: Lap/Shoulder Belt Untwisting Procedure
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Position the shoulder belt on your chest so that it is 6. To release the belt, push the red button on the buckle. comfortable and not resting on your neck. The retractor The belt will automatically retract to its stowed position.
Page 59: Adjustable Upper Shoulder Belt Anchorage
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 60: Seat Belts In Passenger Seating Positions
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The adjustable upper shoulder belt anchorage is Driver Center Passenger equipped with an Easy Up feature. This feature allows First Row the shoulder belt anchorage to be adjusted in the upward Second Row position without pushing the release button.
Page 61: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 out only the amount of webbing necessary to comfort- 3. Allow the belt to retract. As the belt retracts, you will ably wrap around the occupant’s mid-section. Slide the hear a clicking sound. This indicates the safety belt is latch plate into the buckle until you hear a click.
Page 62: Energy Management Feature
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Energy Management Feature Seat Belt Pretensioners This vehicle has a safety belt system with an Energy The seat belts for both front seating positions are Management feature in the front seating positions to help equipped with pretensioning devices that are designed to further reduce the risk of injury in the event of a head-on remove slack from the seat belt in the event of a collision.
Page 63: Supplemental Active Head Restraints (Ahr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Supplemental Active Head Restraints (AHR) When AHRs deploy during a rear impact, the front half These head restraints are passive, deployable compo- of the head restraint extends forward to minimize the gap nents, and vehicles with this equipment cannot be readily between the back of the occupant’s head and the AHR.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Active Head Restraints (AHR) may or may not deploy in the event of a front or side impact. However if during a front impact, a secondary rear impact occurs, the AHR may deploy based on several factors, including the severity and type of the impact.
Page 65: Resetting Active Head Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 1. Grasp the deployed AHR from the rear seat. CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a collision.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. 3 — Final Downward Movement To Engage Locking Mechanism 4. The AHR front soft foam and trim half should lock 1 —...
Page 67: Enhanced Seat Belt Use Reminder System (Beltalert )
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Enhanced Seat Belt Use Reminder System (BeltAlert ) BeltAlert is a feature intended to remind the driver and front passenger (if equipped with front passenger BeltAlert ) to fasten their seat belts. The feature is active whenever the ignition is on.
Page 68: Seat Belts And Pregnant Women
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE unbuckled while traveling at speeds greater than 5 mph Seat Belts And Pregnant Women (8 km/h), BeltAlert will provide both audio and visual We recommend that pregnant women use the seat belts notification.
Page 69: Supplemental Restraint System (Srs) - Air Bags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Air Bags have a multistage inflator This vehicle is equipped with Supplemental Seat- design. This allows the air bag to have different rates of Mounted Side Air Bags (SAB) to provide enhanced inflation based on several factors, including the severity protection for an occupant during a side impact.
Page 71: Advanced Front Air Bag Features
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 • Instrument Panel Advanced Front Air Bag Features The Advanced Front Air Bag system has multistage • Knee Impact Bolster driver and front passenger air bags. This system provides • Driver Advanced Front Air Bag output appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), •...
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Air Bags (SAB) WARNING! Supplemental Seat-Mounted Side Air Bags (SAB) may • No objects should be placed over or near the air provide enhanced protection to help protect an occupant bag on the instrument panel, because any such during a side impact.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Air Bag covers may not be obvious in the interior trim, WARNING! (Continued) but they will open during air bag deployment. • Do not use accessory seat covers or place objects •...
Page 75: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Along with seat belts and pretensioners, Advanced Front Advanced Front Air Bags are designed to provide addi- Air Bags work with the knee bolsters to provide im- tional protection by supplementing the seat belts in proved protection for the driver and front passenger.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Because air bag sensors measure vehicle deceleration Also, the ORC turns on the Air Bag Warning over time, vehicle speed and damage by themselves are Light in the instrument panel for approxi- not good indicators of whether or not an air bag should mately four to eight seconds for a self-check have deployed.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 are possible, based on the collision type and severity. The WARNING! steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as Ignoring the Air Bag Warning Light in your instru- the air bags inflate to their full size.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Based on several factors, including the severity and type A quantity of non-toxic gas is generated to inflate the of collision, the side air bag inflator on the crash side of SABIC. The inflating SABIC pushes the outside edge of the vehicle may be triggered, releasing a quantity of the headliner out of the way and covers the window.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 • Turn on the interior lights, which remain on as long as Front And Side Impact Sensors In front and side impacts, front and side impact sensors the battery has power or until the ignition key is can aid the ORC in determining the appropriate response removed.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you do have a collision which deploys the air bags, any throat irritation, move to fresh air. If the irritation or all of the following may occur: continues, see your doctor. If these particles settle on your clothing, follow the garment manufacturer’s in- •...
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Maintaining Your Air Bag System WARNING! (Continued) • Do not attempt to modify any part of your air bag WARNING! system. The air bag may inflate accidentally or may • Modifications to any part of the air bag system not function properly if modifications are made.
Page 82: Event Data Recorder (Edr)
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light NOTE: If the speedometer, tachometer, or any engine You will want to have the air bags ready to related gauges are not working, the Occupant Restraint inflate for your protection in a collision. The Controller (ORC) may also be disabled.
Page 83: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 • Whether or not the driver and passenger safety belts In addition to the vehicle manufacturer, other parties, were buckled/fastened; such as law enforcement, that have the special equip- ment, can read the information if they have access to the •...
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seat Owner’s Manual to ensure you have the right seat facing child safety seat. Two types of child restraints can for your child. Use the restraint that is correct for your be used rearward-facing: infant carriers and convertible child.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Here are some tips for getting the most out of your child WARNING! restraint: • Rearward-facing child seats must never be used in • Before buying any restraint system, make sure that it the front seat of a vehicle with the front passenger has a label certifying that it meets all applicable Safety air bag.
Page 86 84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE restraint and slide the latch plate into the buckle. Then, NOTE: For additional information, refer to pull the shoulder belt until it is fully extended from the www.seatcheck.org or call 1–866–SEATCHECK. retractor. Allow the belt to return into the retractor, Canadian residents should refer to Transport Canada’s pulling on the excess webbing to tighten the lap website for additional information: http://www.tc.gc.ca/...
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 • If the shoulder belt contacts the face or neck, move the All children whose weight or height is above the forward-facing limit for the child seat should use a child closer to the center of the vehicle. Never allow a belt-positioning booster seat until the vehicle’s seat belts child to put the shoulder belt under an arm or behind fit properly.
Page 88 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE connection to the top tether anchorages have been avail- lower anchors can be are just visible when you lean into able for some time. For some older child restraints, many the rear seat to install the child restraint. You will easily child restraint manufacturers offer add-on tether strap feel them if you run your finger along the intersection of kits or retro-fit kits.
Page 89 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 87 Installing The LATCH-Compatible Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.
Page 90 88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Latch Anchorages (Captain’s Chair) Pulling Down The Carpet Floor Panel To Access Top Tether Strap In addition, there are top tether strap anchorages behind each rear seating position located on the back of the seat. To access the top tether strap anchorages behind the rear seat, pull the carpeted floor panel away from the seat back, this will expose the top tether strap anchorages.
Page 91 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 89 Top Tether Strap Anchorage (Located on Seatback) Top Tether Strap Mounting (60/40 Seat)
Page 92 90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Many, but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or connector for attachment to the lower anchorage and a means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a...
Page 93 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 91 gap panel. They are not visible until you fold the gap Installing Child Restraints Using The Vehicle Seat panel down. Do not use the cargo tie down hooks Belts located on the floor behind the seat. Finally, tighten all The seat belts in the passenger seating positions are three straps as you push the child restraint rearward and equipped with an Automatic Locking Retractor to secure...
Page 94 92 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE extract all the seat belt webbing out of the retractor and Driver Center Passenger then allow the belt to retract into the retractor. As the belt CRS Lock CRS Lock CRS Lock retracts, you will hear a ratcheting sound.
Page 95 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 93 the buckle around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position. To attach a child restraint tether strap: For rearward facing infant seats secured in the center seat position with the vehicle seat belts, the rear center seat position has an armrest tether that secures the arm rest in...
Page 96 94 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Pull down on the tether to unhook it from the plastic seat and attach the hook to the top tether anchor located on the backing, then raise the armrest and attach the tether hook back of the seat.
Page 97 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 95 Top Tether Strap Anchorage (Located on Seatback) Top Tether Strap Mounting (60/40 Seat)
Page 98 96 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly be- hind the child seat to secure a child restraint top tether strap.
Page 99: Engine Break-In Recommendations
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 97 behind the gap panel. Please note the top tether anchor- While cruising, brief full-throttle acceleration within the ages are not visible until you fold the gap panel down. limits of local traffic laws contributes to a good break-in. Do not use the cargo tie down hooks located on the Wide-open throttle acceleration in low gear can be detri- floor behind the seats.
Page 100: Safety Tips
98 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SAFETY TIPS Exhaust Gas Transporting Passengers WARNING! NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. WARNING! Breathing it can make you unconscious and can •...
Page 101: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 99 Safety Checks You Should Make Inside The WARNING! (Continued) Vehicle • If it is necessary to sit in a parked vehicle with the Seat Belts engine running, adjust your heating or cooling Inspect the belt system periodically, checking for cuts, controls to force outside air into the vehicle.
Page 102 100 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Defroster WARNING! (Continued) Check operation by selecting the defrost mode and place • Always make sure that floor mats are properly the blower control on high speed. You should be able to attached to the floor mat fasteners.
Page 103: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 101 and cracks. Inspect sidewalls for cuts, cracks and bulges. WARNING! (Continued) Check the wheel nuts for tightness. Check the tires • Always make sure that objects cannot fall into the (including spare) for proper cold inflation pressure. driver footwell while the vehicle is moving.
Page 105: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......110 Tilt Mirrors In Reverse (Available With Memory Seat Only) —...
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features ....132 Power Lumbar — If Equipped ... 162 Uconnect™...
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Driver Memory Seat — If Equipped ..182 Daytime Running Lights — If Equipped ..191 Setting Memory Positions And Linking Headlight Delay ..... 191 Remote Keyless Entry Transmitter To Parking Lights And Panel Lights .
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Flash-To-Pass ..... . . 197 Electronic Speed Control ....205 High/Low Beam Switch .
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 To Cancel ......215 Parksense Rear Park Assist — If Equipped . . . 237 To Turn Off .
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Parkview On Or Off — Without Troubleshooting Tips ....258 Navigation/Multimedia Radio ... 248 General Information .
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Sunroof Fully Closed ....262 Cargo Area Features ....279 Electrical Power Outlets .
Page 112: Mirrors
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. The mirror should be adjusted while set in the day position (toward the windshield).
Page 113: Outside Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 in the button will illuminate to indicate when the dim- CAUTION! ming feature is activated. The mirror is twisted on the windshield button counterclockwise and requires no To avoid damage to the mirror during cleaning, never tools for mounting.
Page 114: Outside Mirrors Folding Feature
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Automatic Dimming Mirrors — If WARNING! Equipped The drivers outside mirror will automatically adjust for Vehicles and other objects seen in the passenger side glare from vehicles behind you. This feature is controlled convex mirror will look smaller and farther away by the inside automatic dimming mirror and can be than they really are.
Page 115: Heated Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the rear window defroster. Refer to “Rear Window Features” in “Understanding The Features Of Your Vehicle” for fur- ther information.
Page 116: Illuminated Vanity Mirrors
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Tilt Mirrors in Reverse feature is not en- abled when delivered from the factory. The Tilt Mirrors in Reverse feature can be enabled or disabled in the Electronic Vehicle Information Center (EVIC). Refer to “Electronic Vehicle Information...
Page 117: Blind Spot Monitoring - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 BLIND SPOT MONITORING — IF EQUIPPED When the vehicle is started, the BSM warning light will The Blind Spot Monitoring (BSM) system uses two radar- be momentarily illuminated in both outside rear view based sensors, located inside the rear bumper fascia, to mirrors to let the driver know that the system is opera- detect highway licensable vehicles (automobiles, trucks,...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The BSM system detection zone DOES NOT change if your vehicle is towing a trailer. Therefore, visually verify the adjacent lane is clear for both your vehicle and trailer before making a lane change. If the trailer or other object (i.e., bicycle, sports equipment) extends beyond the side of your vehicle, this may result in the BSM warning light remaining illuminated the entire...
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Entering From The Side Vehicles that move into your adjacent lanes from either side of the vehicle. BSM Warning Light The BSM system monitors the detection zone from three different entry points (Side, Rear, Front) while driving to see if an alert is necessary.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Entering From The Rear Overtaking Traffic Vehicles that come up from behind your vehicle on either If you pass another vehicle slowly (with a relative speed side and enter the rear detection zone with a relative of less than 10 mph (16 km/h) and the vehicle remains in speed of less than 30 mph (48 km/h).
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 The BSM system is designed not to issue an alert on stationary objects such as guardrails, posts, walls, foliage, berms, etc. However, occasionally the system may alert on such objects. This is normal operation and your vehicle does not require service.
Page 122: Rear Cross Path
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The BSM system will not alert you of objects that are WARNING! traveling in the opposite direction of the vehicle in adjacent lanes. The Blind Spot Monitoring system is only an aid to help detect objects in the blind spot zones.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 NOTE: In a parking lot situation, oncoming vehicles can be obscured by vehicles parked on either side. If the sensors are blocked by other structures or vehicles, the system will not be able to alert the driver. When RCP is on and the vehicle is in REVERSE, the driver is alerted using both the visual and audible alarms, including radio muting.
Page 124: Modes Of Operation
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Modes Of Operation turn signal is then activated, and it corresponds to an Three selectable modes of operation are available in the alert present on that side of the vehicle, an audible chime Electronic Vehicle Information Center (EVIC).
Page 125: Uconnect™ Phone - If Equipped
Each time the vehicle websites: is started the previously stored mode will be recalled and • www.chrysler.com/uconnect used. • www.dodge.com/uconnect Uconnect™ Phone — IF EQUIPPED • www.jeep.com/uconnect Uconnect™ Phone is a voice-activated, hands-free, in- vehicle communications system. Uconnect™ Phone al- •...
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bluetooth technology - the global standard that enables Uconnect™ Phone Button different electronic devices to connect to each other without The radio or steering wheel controls (if wires or a docking station, so Uconnect™ Phone works no equipped) will contain the two control buttons matter where you stow your mobile phone (be it your (Uconnect™...
Page 127: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 • For certain operations, compound commands can be The Uconnect™ Phone is fully integrated with the vehi- cle’s audio system. The volume of the Uconnect™ Phone used. For example, instead of saying “Setup” and then can be adjusted either from the radio volume control “Pair a Device”, the following compound command knob or from the steering wheel radio control (right...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Help Command To complete the pairing process, you will need to refer- If you need assistance at any prompt, or if you want to ence your mobile phone Owner’s Manual. The know your options at any prompt, say “Help” following Uconnect™...
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 • For identification purposes, you will be prompted to Dial By Saying A Number give the Uconnect™ Phone a name for your mobile • Press the button to begin. phone. Each mobile phone that is paired should be •...
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will prompt you to say the name of the • After the “Ready” prompt and the following beep, say person you want to call. “Phonebook New Entry”. • After the “Ready” prompt and the following beep, say •...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 • Automatic download and update, if supported, begins The Uconnect™ Phone will allow you to enter up to 32 names in the phonebook with each name having up to as soon as the Bluetooth wireless phone connection is four associated phone numbers and designations.
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • This downloaded phonebook cannot be edited or • Next, choose the number designation (home, work, deleted on the Uconnect™ Phone. These can only be mobile, or other) that you wish to edit. edited on the mobile phone.
Page 133 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 • Press the • Note that only the phonebook entry in the current button to begin. language is deleted. • After the “Ready” prompt and the following beep, say • Automatic downloaded phonebook entries cannot be “Phonebook Delete”.
Page 134: Phone Call Features
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Automatic downloaded phonebook entries cannot be • The selected number will be dialed. deleted or edited. Phone Call Features List All Names In The Uconnect™ Phonebook The following features can be accessed through the Uconnect™...
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Answer Or Reject An Incoming Call — Call in progress. To go back to the first call, refer to “Toggling Currently In Progress Between Calls” in this section. To combine two calls, refer If a call is currently in progress and you have another to “Conference Call”...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conference Call Call Termination When two calls are in progress (one active and one on To end a call in progress, momentarily press the hold), press and hold the button until you hear a button.
Page 137: Uconnect™ Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Call Continuation Uconnect™ Phone Features Call continuation is the progression of a phone call on the Language Selection Uconnect™ Phone after the vehicle ignition key has been To change the language that the Uconnect™ Phone is switched to OFF.
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Assistance Canada and 060 for Mexico). The number dialed may If you are in an emergency and the mobile phone is not be applicable with the available mobile service and reachable: area. •...
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Towing Assistance Paging If you need towing assistance: To learn how to page, refer to “Working with Automated Systems”. Paging works properly except for pagers of • Press the button to begin. certain companies, which time out a little too soon to •...
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When calling a number with your Uconnect™ Phone that The Uconnect™ Phone will then send the corresponding normally requires you to enter in a touch-tone sequence phone number associated with the phonebook entry, as on your mobile phone keypad, you can press the tones over the phone.
Page 141 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Turning Confirmation Prompts ON/OFF Dialing Using The Mobile Phone Keypad Turning confirmation prompts off will stop the system You can dial a phone number with your mobile phone from confirming your choices (e.g., the Uconnect™ keypad and still use the Uconnect™...
Page 142: Advanced Phone Connectivity
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mute/Un-Mute (Mute OFF) from your Uconnect™ Phone paired mobile phone to the When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone or vice versa, press the button able to hear the conversation coming from the other and say “Transfer Call”.
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 • When prompted, say “List Phones”. • The selected phone will be used for the next phone call. If the selected phone is not available, the • The Uconnect™ Phone will play the phone names of Uconnect™...
Page 144: Things You Should Know About Your Uconnect™ Phone
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Things You Should Know About Your Uconnect™ You can either press the Uconnect™ Phone button to Phone restore the factory setting or repeat the words and phrases when prompted by the Uconnect™ Phone. For Uconnect™...
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 • fully closed windows, Voice Command • For best performance, adjust the rearview mirror to • dry weather condition. provide at least ⁄ in (1 cm) gap between the overhead • Even though the system is designed for users speaking console (if equipped) and the mirror.
Page 146 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Numbers must be spoken in single digits. “800” must • fully closed windows, be spoken “eight-zero-zero” not “eight hundred”. • dry weather conditions, and • You can say “O” (letter “O”) for “0” (zero). •...
Page 147 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Send Messages: Uconnect™ Phone can read or send new messages on You can send messages using Uconnect™ Phone. To send your phone. a new message: • Press the Read Messages: button. If you receive a new text message while your phone is •...
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE List of Preset Messages: 11. See You in 15 minutes 1. Yes 12. I am on my way 2. No 13. I’ll be late 3. Where are you? 14. Are you there yet? 4.
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 Turn SMS Incoming Announcement ON/OFF Bluetooth Communication Link Turning the SMS Incoming Announcement OFF will stop Mobile phones have been found to lose connection to the the system from announcing the new incoming mes- Uconnect™...
Page 150 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149...
Page 152 150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
Page 154 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...
Page 155: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 156: Commands
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you ever wish to interrupt the system while it lists The system will best recognize your speech if the win- options, press the Voice Command button, listen dows are closed, and the heater/air conditioning fan is for the beep, and say your command.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 3. Use the ON/OFF VOLUME rotary knob to adjust the Radio AM volume to a comfortable level while the Voice Command To switch to the AM band, say “AM” or “Radio AM”. In system is speaking.
Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Menu Radio” (to switch to the radio menu) Disc To switch to the disc mode, say “Disc”. In this mode, you • “Main Menu” (to switch to the main menu) may say the following commands: Satellite Radio •...
Page 159 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 • “Switch to system setup” − “Continue” (to continue recording) • “Change to setup” − “Delete” (to delete the recording) • “Play Memos” (to play previously recorded memos) • “Main menu setup” or —...
Page 160: Voice Training
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training WARNING! For users experiencing difficulty with the system recog- • It is dangerous to ride in a cargo area, inside or nizing their voice commands or numbers the Uconnect™ Voice “Voice Training” feature may be used. outside of a vehicle.
Page 161 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Adjusting The Seat Forward Or Rearward The seat can be adjusted both forward and rearward. Push the seat switch forward or rearward, the seat will move in the direction of the switch. Release the switch when the desired position has been reached.
Page 162: Passenger's Power Seat - If Equipped
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Reclining The Seatback WARNING! (Continued) The angle of the seatback can be adjusted forward or • Do not ride with the seatback reclined so that the backward. Push the seatback switch forward or rear- shoulder belt is no longer resting against your ward, the seat will move in the direction of the switch.
Page 163 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Adjusting The Seat Forward Or Rearward WARNING! The seat can be adjusted both forward and rearward. • Adjusting a seat while driving may be dangerous. Push the seat switch forward or rearward, the seat will move in the direction of the switch.
Page 164: Power Lumbar - If Equipped
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
Page 165: Manual Front Passenger Seat Forward/Rearward Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Manual Front Passenger Seat Forward/Rearward While sitting in the seat, lift up on the bar located under Adjustment the seat cushion and move the seat forward or rearward. Some models may be equipped with a manual front Release the bar once you have reached the desired passenger seat.
Page 166: Manual Front Passenger Seatback Adjustment - Recline
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Passenger Seatback Adjustment — WARNING! Recline To adjust the seatback, lift the lever located on the Do not ride with the seatback reclined so that the outboard side of the seat, lean back to the desired shoulder belt is no longer resting against your chest.
Page 167: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion or other physical condition must exercise care when using the seat heater.
Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE during a remote start. Refer to “Remote Starting System NOTE: Once a heat setting is selected, heat will be felt — If Equipped” in “Things To Know Before Starting Your within two to five minutes. Vehicle”...
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Press the switch once to select HIGH-level heating. Press the switch a second time to select LOW-level heating. Press the switch a third time to shut the heating elements OFF. NOTE: Once a heat setting is selected, heat will be felt within two to five minutes.
Page 170: Ventilated Seats - If Equipped
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ventilated Seats — If Equipped OFF. When HIGH speed is selected both lights on the On some models, both the driver and passenger seats are switch will be illuminated. When LOW speed is selected ventilated.
Page 171 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 When AHRs deploy during a rear impact, the front half WARNING! of the head restraint extends forward to minimize the gap between the back of the occupant’s head and the AHR. The head restraints for all occupants must be prop- This system is designed to help prevent or reduce the erly adjusted prior to operating the vehicle or occu- extent of injuries to the driver and front passenger in...
Page 172 170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To raise the head restraint, pull upward on the head For comfort the Active Head Restraints can be tilted restraint. To lower the head restraint, press the push forward and rearward. To tilt the head restraint closer to button, located at the base of the head restraint, and push the back of your head, pull forward on the bottom of the downward on the head restraint.
Page 173 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 • In the event of deployment of an Active Head Re- straint, refer to “Occupant Restraints/Resetting Active Head Restraints (AHR)” in “Things To Know Before Starting Your Vehicle” for further information. WARNING! • Do not place items over the top of the Active Head Restraint, such as coats, seat covers or portable DVD players.
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center head restraint has limited adjustment. Lift WARNING! (Continued) upward on the head restraint to raise it, or push down- • Active Head Restraints may be deployed if they ward on the head restraint to lower it. are struck by an object such as a hand, foot or loose cargo.
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Press the power folding switch located WARNING! on the instrument panel to fold the head restraints. Sitting in a seat with the head restraint in its lowered position could result in serious injury or death in a collision.
Page 176: 60/40 Split Rear Seat - If Equipped
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 60/40 Split Rear Seat — If Equipped Fold-Flat The second row seats can be folded flat to carry cargo. Pull upward on the release lever located on the outboard side of the seat. Fold-Flat Second Row Seat Easy Access For Third Row Either side of the rear seat can be tumbled forward to...
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 Release Lever Tumble Strap 2. Tumble the seat forward using the pull strap located behind the seatback.
Page 178 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not drive the vehicle with the second row seats in the tumbled position. The second row seats are only intended to be tumbled for entry and exit to the third row seat. Failure to follow these instructions could result in personal injury.
Page 179: Rear Captain Chairs - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Rear Captain Chairs — If Equipped Fold-Flat The second row seats can be folded flat to carry cargo. Pull upward on the release lever located on the outboard side of the seat. Fold-Flat Second Row Seats Release Lever...
Page 180 178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Easy Access For Third Row 2. Tumble the seat forward using the pull strap located Either captains chair can be tumbled forward to allow behind the seatback. passengers to easily access the third row seats. 1.
Page 181 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 WARNING! Do not drive the vehicle with the second row seats in the tumbled position. The second row seats are only intended to be tumbled for entry and exit to the third row seat. Failure to follow these instructions could result in personal injury.
Page 182: Folding Third Row
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Raise Rear Seat Tumbled the seat rearward and lock it into place. WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position the seat will not provide the proper stability for child seats and/or passengers.
Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 NOTE: The second row seats must be in their full upright position, or tumbled when folding the third row seats. To raise the seat, pull the seat toward you using the strap located on the back of the seat. WARNING! Be certain that the seatback is securely locked into position.
Page 184: Driver Memory Seat - If Equipped
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE DRIVER MEMORY SEAT — IF EQUIPPED Once programmed, the memory buttons 1 and 2 on the driver’s door panel can be used to recall the driver’s seat, driver’s outside mirror, adjustable steering wheel posi- tion (if equipped), and the radio station preset settings.
Page 185: Setting Memory Positions And Linking Remote Keyless Entry Transmitter To Memory
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 Setting Memory Positions And Linking Remote 5. Turn on the radio and set the radio station presets (up Keyless Entry Transmitter To Memory to 12 AM and 12 FM stations can be set). NOTE: Each time the S (SET) button and a numbered 6.
Page 186: Memory Position Recall
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE to “Electronic Vehicle Information Center (EVIC)/ To recall the memory setting for driver two, press Customer-Programmable Features” in “Understanding MEMORY button number 2 on the driver’s door, or the Your Instrument Panel” for further information. UNLOCK button on the RKE transmitter linked to memory position 2.
Page 187: Easy Entry/Exit Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 3. Press and release the memory S (SET) button located Easy Entry/Exit Seat on the driver’s door. This feature provides automatic driver’s seat positioning which will enhance driver mobility out of and into the 4.
Page 188: To Open And Close The Hood
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE driving position when the key is placed into the TO OPEN AND CLOSE THE HOOD ignition, and turned out of the LOCK position toward To open the hood, two latches must be released. the ACC/ON position.
Page 189 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 2. Reach under the hood from outside the vehicle, move CAUTION! the safety latch to the left and lift the hood. To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the center of the hood to ensure that both latches engage.
Page 190: Lights
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is Headlight Switch on the parking lights, taillights, license plate The headlight switch is located on the left side of the light and instrument panel lights are also instrument panel, next to the steering wheel.
Page 191: Automatic Headlights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Headlights On Automatically With Wipers CAUTION! If your vehicle is equipped with Automatic Headlights, it also has this customer-programmable feature. When Do not use abrasive cleaning components, solvents, your headlights are in the automatic mode and the steel wool or other abrasive materials to clean the engine is running, they will automatically turn on when lenses.
Page 192: Smartbeam™ - If Equipped
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: When your headlights come on during the To Activate daytime, the instrument panel lights will automatically 1. Enable the Automatic High Beams. Refer to “Elec- dim to the lower nighttime intensity. Refer to “Lights” in tronic Vehicle Information Center (EVIC)/Customer- this section for further information.
Page 193: Daytime Running Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 2. Push back on the multifunction lever once again to Headlight Delay reactivate the system. To aid in your exit, your vehicle is equipped with a headlight delay that will leave the headlights on for NOTE: Broken, muddy, or obstructed headlights and approximately 90 seconds.
Page 194: Fog Lights - If Equipped
192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fog Lights — If Equipped The fog lights will operate only when the parking lights The fog lights are turned on by rotating the headlight are on or when the vehicle headlights are on low beam. switch to the parking light or headlight position and An indicator light located in the instrument cluster will pushing in the headlight rotary control.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 The brightness of the instrument panel lighting can be regulated by rotating the dimmer control up (brighter) or down (dimmer). When the headlights are on you can supplement the brightness of the odometer, trip odom- eter, radio, overhead console, rear full center console cubby bin (if equipped) and lighted cupholders (if equipped) by rotating the control to its farthest position...
Page 196: Lights-On Reminder
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder NOTE: Battery saver mode is cancelled if the ignition is If the headlights, parking lights, or cargo lights are left on after the ignition is turned OFF, a chime will sound when Front Map/Reading Lights the driver’s door is opened.
Page 197: Courtesy Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 Each light can be turned on by pressing a switch on either Courtesy Lights side of the console. These buttons are backlit for night The courtesy lights can be turned on by pressing the top time visibility.
Page 198: Ambient Light
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ambient Light Multifunction Lever The overhead console is equipped with an ambient light The multifunction lever is located on the left side of the feature. This light casts illumination for improved visibil- steering column. ity of the floor center console and PRNDL area.
Page 199: Turn Signals
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 Turn Signals Flash-To-Pass Move the multifunction lever up or down and the arrows You can signal another vehicle with your headlights by on each side of the instrument cluster flash to show partially pulling the multifunction lever toward the steer- proper operation of the front and rear turn signal lights.
Page 200: Windshield Wipers And Washers
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Windshield Wiper Operation The windshield wiper/washer control lever is located on Rotate the end of the lever to one of the first four detent the left side of the steering column. The front wipers are positions for intermittent settings, the fifth detent for low operated by rotating a switch, located on the end of the wiper operation and the sixth detent for high wiper...
Page 201: Intermittent Wiper System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 CAUTION! Always remove any buildup of snow that prevents the windshield wiper blades from returning to the “park” position. If the windshield wiper switch is turned off, and the blades cannot return to the “park” position, damage to the wiper motor may occur.
Page 202: Windshield Washer Operation
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washer Operation If the end of the lever is pushed while the wipers are in To use the washer, push on the end of the lever (toward the off position, the wipers will operate for several wipe the steering wheel) and hold while spray is desired.
Page 203: Rain Sensing Wipers - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 NOTE: The mist feature does not activate the washer Rain Sensing Wipers — If Equipped pump; therefore, no washer fluid will be sprayed on the This feature senses moisture on the windshield and windshield.
Page 204: Tilt/Telescoping Steering Column
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Rain Sensing feature may not function properly • Transmission In NEUTRAL Position — When the when ice, or dried salt water is present on the windshield. ignition is ON, and the transmission is in the NEU- TRAL position, the Rain Sensing system will not •...
Page 205: Power Tilt/Telescoping Steering Column - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 206: Heated Steering Wheel - If Equipped
204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: For vehicles equipped with Driver Memory HEATED STEERING WHEEL — IF EQUIPPED Seat, you can use your Remote Keyless Entry (RKE) The steering wheel contains a heating element that helps transmitter or the memory switch on the driver’s door warm your hands in cold weather.
Page 207: Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 Press the switch to turn on the heated WARNING! steering wheel. The light on the switch • Persons who are unable to feel pain to the skin will illuminate to indicate the steering wheel heater is on.
Page 208: To Activate
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Electronic Speed Control buttons are located on the the same time. If this occurs, the Electronic Speed Control right side of the steering wheel. System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed.
Page 209: To Set A Desired Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 To Set A Desired Speed To Vary The Speed Setting Turn the Electronic Speed Control ON. When the vehicle When the Electronic Speed Control is set, you can in- has reached the desired speed, press the SET (-) button crease speed by pushing the RES (+) button.
Page 210: To Accelerate For Passing
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing WARNING! Press the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. Electronic Speed Control can be dangerous where the system cannot maintain a constant speed.
Page 211 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 NOTE: WARNING! • If the sensor does not detect a vehicle ahead of you, • Adaptive Cruise Control (ACC) is a convenience ACC will maintain a fixed set speed. system. It is not a substitute for active driving •...
Page 212 210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) WARNING! − Cannot take street, traffic, and weather conditions You should switch off the ACC system: into account, and may be limited upon adverse sight • When driving in fog, heavy rain, heavy snow, distance conditions.
Page 213: Adaptive Cruise Control (Acc) Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 The Cruise Control system has two control modes: • Adaptive Cruise Control mode for maintaining an appropriate distance between vehicles. • Normal (fixed speed) cruise control mode for cruising at a constant preset speed. For additional information, refer to “Normal (Fixed Speed) Cruise Control Mode”...
Page 214: Activating Adaptive Cruise Control (Acc)
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the parking brake is set. NOTE: Any chassis/suspension modifications to the vehicle will effect the performance of the Adaptive Cruise • When the automatic transmission is in PARK, RE- Control. VERSE or NEUTRAL. Activating Adaptive Cruise Control (ACC) •...
Page 215 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 To turn the system OFF, push and release the ON/OFF button again. At this time, the system will turn off and the EVIC will display “Adaptive Cruise Control Off.” WARNING! Leaving the Adaptive Cruise Control (ACC) system on when not in use is dangerous.
Page 216: To Set A Desired Acc Speed
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Set A Desired ACC Speed Remove your foot from the accelerator pedal. If you do When the vehicle reaches the speed desired, push the not, the vehicle may continue to accelerate beyond the set SET - button and release.
Page 217: To Cancel
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 To Cancel The system will disable ACC without erasing the memory if: • You softly tap the brake pedal. • You depress the brake pedal. • You press the CANCEL switch. • An Anti-Lock Brake System (ABS) event occurs. •...
Page 218: To Turn Off
216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • You turn OFF the ignition. NOTE: If ACC is resumed or set with the ESC/TCS off, ESC will automatically be re-engaged. • You switch to Four-Wheel Drive Low. To Resume Speed Press the RES + button and release. Then remove your foot from the accelerator pedal.
Page 219: To Vary The Speed Setting
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 To Vary The Speed Setting Pressing the SET - button once will result in a 1 mph While ACC is set, you can increase the set speed by (1.6 km/h) decrease in set speed. Each subsequent tap of pressing and holding the RES + button.
Page 220: Setting The Following Distance In Acc
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Setting The Following Distance In ACC The specified following distance for ACC can be set by varying the distance setting between 3 (long), 2 (me- dium), and 1 (short). Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead.
Page 221 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 same lane, the EVIC displays the “Sensed Vehicle Indi- cator” icon, and the system adjusts vehicle speed auto- matically to maintain the distance setting, regardless of the set speed. The vehicle will then maintain the set distance until: •...
Page 222 220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The maximum braking applied by ACC is limited; how- The ACC Systems provides Overtake Aid when passing ever, the driver can always apply the brakes manually, if on the left hand side only. When driving with ACC necessary.
Page 223: Adaptive Cruise Control (Acc) Menu
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Adaptive Cruise Control (ACC) Menu ACC SET The EVIC displays the current ACC system settings. The − When ACC is set, the set speed will display. EVIC is located in the upper part of the instrument cluster between the speedometer and the tachometer.
Page 224: Display Warnings And Maintenance
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ACC screen will display once again if any ACC Display Warnings And Maintenance activity occurs, which may include any of the following: “Clean Radar Sensor In Front Of Vehicle” Warning • Set Speed Change The ACC “Clean Radar Sensor In Front Of Vehicle”...
Page 225 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 If weather conditions are not a factor, the driver should examine the sensor. It may require cleaning or removal of an obstruction. The sensor is located in the center of the vehicle behind the lower grille. To keep the ACC System operating properly, it is impor- tant to note the following maintenance items: •...
Page 226 224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Do not attach or install any accessories near the sensor, ACC Unavailable Warning including transparent material or aftermarket grilles. If the system turns off, and the EVIC displays “ACC/ Doing so could cause an ACC system failure or FCW Unavailable, Vehicle System Error”, there may be a malfunction.
Page 227: Precautions While Driving With Acc
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 Precautions While Driving With ACC In certain driving situations, ACC may have detection issues. In these cases, ACC may brake late or unexpect- edly. The driver needs to stay alert and may need to intervene.
Page 228 226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Offset Driving Turns And Bends ACC may not detect a vehicle in the same lane that is When driving on a curve with ACC engaged, the system offset from your direct line of travel. There will not be may decrease the vehicle speed and acceleration for sufficient distance to the vehicle ahead.
Page 229 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 ACC may occasionally provide braking and/or a driver Using ACC On Hills alert that you consider unnecessary. This may be the When driving on hills, ACC may not detect a vehicle in systems response to signs, guardrails, and other station- your lane.
Page 230 228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lane Changing ACC will not detect a vehicle until it is completely in the lane in which you are traveling. In the illustration shown, ACC has not yet detected the vehicle changing lanes and it may not detect the vehicle until it’s too late for the ACC system to take action.
Page 231: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 Stationary Objects And Vehicles General Information ACC does not react to stationary objects and stationary FCC Requirements For Vehicular Radar Systems vehicles. For example, ACC will not react in situations Classification Specifications: where the vehicle you are following exits your lane and 47 C.F.R.
Page 232: Normal (Fixed Speed) Cruise Control Mode
230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Normal (Fixed Speed) Cruise Control Mode WARNING! In addition to Adaptive Cruise Control mode, a normal (fixed speed) Cruise Control mode is available for cruis- In the normal Cruise Control mode, the system will ing at fixed speeds.
Page 233 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 To Vary The Speed Setting To Resume There are two ways to change the set speed: Press the RES + button and then remove your foot from the accelerator pedal. The EVIC will display the last set •...
Page 234: Forward Collision Warning - If Equipped
232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Forward Collision Warning — If Equipped When entering or driving in a curve, the FCW alerts may Forward Collision Warning (FCW) warns the driver of a be triggered on objects other than vehicles such as guard potential collision with the vehicle in front of you and rails or sign posts based on the course prediction.
Page 235 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 NOTE: Changing FCW Status • The minimum speed for FCW activation is 10 mph The FCW feature can be set to far, set to near or turned off (16 km/h). in the Electronic Vehicle Information Center (EVIC) refer to “Electronic Vehicle Information Center (EVIC)”...
Page 236 234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The default status of FCW is the “Far” setting, this allows Changing the FCW status to the “Near” setting, allows the system to warn you of a possible collision with the the system to warn you of a possible collision with the vehicle in front of you when you are farther away.
Page 237 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in front of you. FCW Off Example NOTE: • The system will retain the last setting selected by the driver after ignition shut down.
Page 238 236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • FCW will not react to irrelevant objects such as over- Service FCW Warning head objects, ground reflections, objects not in the path If the system turns off, and the EVIC displays “ACC of the car, stationary objects that are far away, oncom- Unavailable Service Radar Sensor”, it indicates there is an ing traffic, or leading vehicles with the same or higher...
Page 239: Parksense Rear Park Assist - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 PARKSENSE REAR PARK ASSIST — IF ParkSense Sensors EQUIPPED The four ParkSense sensors, located in the rear fascia/ The ParkSense Rear Park Assist system provides visual bumper, monitor the area behind the vehicle that is and audible indications of the distance between the rear within the sensors’...
Page 240: Parksense Display
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ParkSense Warning Display is located in the Instru- ParkSense Display ment cluster’s EVIC display. It provides both visual and When the vehicle is in REVERSE, the warning display audible warnings to indicate the distance between the will turn ON indicating the system status.
Page 241 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 Park Assist System OFF Slow Tone The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 242 240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone Continuous Tone The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle:...
Page 243: Enabling And Disabling Parksense
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 241 WARNING ALERTS Rear Distance Greater than 79-39 in 39-25 in 25-12 in Less than (in/cm) 79 in (200 cm) (200-100 cm) (100-65 cm) (65-30 cm) 12 in (30 cm) Audible Alert None Single 1/2 Slow Fast Continuous...
Page 244: Service The Parksense Rear Park Assist System
242 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Electronic Vehicle Information Center (EVIC)” in “Un- detected a faulted condition, the EVIC will display the derstanding Your Instrument Panel” for further informa- “CLEAN PARK ASSIST SENSORS” or the “SERVICE tion. When the shift lever is moved to REVERSE and the PARK ASSIST SYSTEM”...
Page 245: Parksense System Usage Precautions
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 243 • ParkSense , when on, will MUTE the radio when it is ParkSense System Usage Precautions sounding a tone. NOTE: • Ensure that the rear bumper is free of snow, ice, mud, • Clean the ParkSense sensors regularly, taking care dirt and debris to keep the ParkSense system operat- not to scratch or damage them.
Page 246 244 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • On vehicles equipped with a tailgate, ParkSense WARNING! should be disabled when the tailgate is in the lowered • Drivers must be careful when backing up even or open position and the vehicle is in REVERSE. A lowered tailgate could provide a false indication that when using the ParkSense Rear Park Assist Sys- an obstacle is behind the vehicle.
Page 247: Parkview Rear Back Up Camera - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 245 PARKVIEW REAR BACK UP CAMERA — IF WARNING! (Continued) EQUIPPED • Before using the ParkSense Rear Park Assist Your vehicle may be equipped with the ParkView Rear System, it is strongly recommended that the ball Back Up Camera that allows you to see an on-screen mount and hitch ball assembly is disconnected image of the rear surroundings of your vehicle whenever...
Page 248 246 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When displayed, static grid lines will illustrate the width that will help indicate the distance to the rear of the of the vehicle while a dashed center-line will indicate the vehicle. The following table shows the approximate center of the vehicle to assist with aligning to a hitch/ distances for each zone: receiver.
Page 249: Turning Parkview On Or Off - With Navigation/Multimedia Radio
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247 WARNING! CAUTION! (Continued) • To avoid vehicle damage, the vehicle must be Drivers must be careful when backing up even when driven slowly when using ParkView to be able to using the ParkView Rear Back Up Camera. Always stop in time when an obstacle is seen.
Page 250: Turning Parkview On Or Off - Without Navigation/Multimedia Radio
248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Enable or disable the rear camera feature by selecting the “enable rear camera in reverse” soft-key. 5. Press the “save” soft-key. Turning ParkView On Or Off — Without Navigation/Multimedia Radio 1. Press the “menu” hard-key. 2.
Page 251: Courtesy Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249 Courtesy Lights The courtesy lights can be turned on by pressing the top corner of the lens. To turn the lights off, press the lens a second time. Front Map/Reading Lights To turn the lights off, press the switch a second time. The lights also turn on when a door is opened.
Page 252: Sunglass Bin Door
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunglass Bin Door GARAGE DOOR OPENER — IF EQUIPPED At the front of the console a compartment is provided for HomeLink replaces up to three hand-held transmitters the storage of a pair of sunglasses. The storage compart- that operate devices such as garage door openers, motor- ment access is a “push/push”...
Page 253 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251 HomeLink Buttons/Sunvisor/Headliner HomeLink Buttons/Overhead Consoles NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active.
Page 254: Before You Begin Programming Homelink
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Before You Begin Programming HomeLink NOTE: • Erasing all channels should only be performed when Be sure that your vehicle is parked outside of the garage before you begin programming. programming HomeLink for the first time. Do not erase channels when programming additional buttons.
Page 255 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 253 3. Simultaneously press and hold both the Homelink button you want to program and the hand-held transmit- ter button. 4. Continue to hold both buttons and observe the indi- cator light. The Homelink indicator will flash slowly and then rapidly after Homelink has received the fre- quency signal from the hand-held transmitter.
Page 256: Programming A Non-Rolling Code
254 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: You have 30 seconds in which to initiate the next 2. Press and hold the desired HomeLink button until step after the LEARN button has been pressed. the indicator light begins to flash after 20 seconds. Do not release the button.
Page 257: Canadian/Gate Operator Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 255 4. Continue to hold both buttons and observe the indi- Reprogramming A Single HomeLink Button cator light. The Homelink indicator will flash slowly To reprogram a channel that has been previously trained, and then rapidly after Homelink has received the fre- follow these steps: quency signal from the hand-held transmitter.
Page 258 256 UNDERSTANDING THE FEATURES OF YOUR VEHICLE to pick up the signal during programming. Similar to this 4. Watch for the HomeLink indicator to change flash Canadian law, some U.S. gate operators are designed to rates. When it changes, it is programmed. It may take up time-out in the same manner.
Page 259: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 257 Reprogramming A Single HomeLink Button Security To reprogram a channel that has been previously trained, It is advised to erase all channels before you sell or turn follow these steps: in your vehicle. 1.
Page 260: Troubleshooting Tips
258 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips WARNING! If you are having trouble programming HomeLink , here • Your motorized door or gate will open and close are some of the most common solutions: while you are programming the universal trans- •...
Page 261: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259 General Information POWER SUNROOF — IF EQUIPPED This device complies with FCC rules Part 15 and Industry The power sunroof switch is located between the sun Canada RSS-210. Operation is subject to the following visors on the overhead console.
Page 262: Opening Sunroof - Express
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening Sunroof — Express WARNING! Press the switch rearward and release it within one-half • Never leave children in a vehicle with the key in second and the sunroof will open automatically from any position.
Page 263: Closing Sunroof - Manual Mode
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261 position. The sunroof will close fully and stop automati- NOTE: If three consecutive sunroof close attempts re- cally. This is called “Express Close”. During Express sult in Pinch Protect reversals, the fourth close attempt Close operation, any movement of the switch will stop will be a Manual Close movement with Pinch Protect the sunroof.
Page 264: Wind Buffeting
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Wind Buffeting Ignition OFF Operation Wind buffeting can be described as the perception of For vehicles not equipped with the Electronic Vehicle pressure on the ears or a helicopter-type sound in the Information Center (EVIC), the power sunroof switch ears.
Page 265: Electrical Power Outlets
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263 • To ensure proper operation a MOPAR ELECTRICAL POWER OUTLETS knob and Your vehicle is equipped with 12 Volt (13 Amp) power element must be used. outlets that can be used to power cellular phones, small •...
Page 266 264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The front power outlet is located inside the storage area on the center stack of the instrument panel. Front Center Console Outlet If your vehicle is equipped with a rear full center console, there is also a power outlet located in the lower storage Front Power Outlet area of the rear full center console.
Page 267 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265 Rear Full Center Console Outlet Rear Cargo Power Outlet The rear cargo power outlet is located in the right rear cargo area.
Page 268 266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The rear cargo power outlet can be switched to “battery” powered all the time by switching the power outlet right rear quarter panel fuse in the fuse panel. Power Outlet Fuse Locations 1 —...
Page 269 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.).
Page 270: Power Inverter - If Equipped
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED There is a 115 Volt, 150 Watt inverter outlet located on the back of the center console to convert DC current to AC current. This outlet can power cellular phones, electron- ics and other low power devices requiring power up to 150 Watts.
Page 271 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269 The power inverter is designed with built-in overload NOTE: When the power inverter switch is pressed, protection. If the power rating of 150 Watts is exceeded, there will be a delay of approximately one second before the power inverter will automatically shut down.
Page 272: Cupholders
270 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Rear Cupholders Front Seat Cupholders Rear Center Arm Rest Cupholders — If Equipped There are two cupholders for the front seat passengers There are two cupholders for the rear seat passengers located in the center console. located in the fold-down center armrest.
Page 273 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 271 Rear Full Console Cupholders — If Equipped The rear full console cupholders are equipped with a There are two cupholders for the rear seat passengers light ring that illuminates the cupholders for the rear located in the front of the rear full console.
Page 274: Storage
272 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Mini Console Cupholders — If Equipped STORAGE There are two cupholders for the rear seat passengers Glove Compartment located in the front of the rear mini console. The glove compartment is located on the right side of the instrument panel.
Page 275: Door Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 273 Door Storage Front Center Console Large storage areas are built into the door panels for easy The front center console contains both an upper and a access. lower storage area. Door Panel Storage Storage Compartment...
Page 276 274 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open the upper storage compartment, pull upward on Lift upward on the larger of the latches to access the the small latch located on the lid. lower storage compartment. Storage Compartment Latches Lower Storage Compartment...
Page 277: Rear Full Center Console (If Equipped)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 275 Rear Full Center Console (If Equipped) The rear full center console contains both an upper and a lower storage area. Upper Storage Compartment Lift upward on the larger of the latches to access the lower storage compartment.
Page 278 276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Lower storage compartment light is always on The upper storage compartment may also be lifted for- with ignition in the ON/RUN position. ward. Push in the release button located on the back of the lid.
Page 279 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277 Storage Compartment Rear Push Button Lower Storage Compartment When lifted forward there is access to the lower storage compartment.
Page 280: Rear Mini Center Console (If Equipped)
278 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Open storage areas, or cubby bins with removable liners, Rear Mini Center Console (If Equipped) are located rearward of the cupholders and in the lower An open storage area, or cubby bin with removable liner, front of the console.
Page 281: Cargo Area Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 279 CARGO AREA FEATURES Rechargeable Flashlight The rechargeable flashlight is mounted on the left side of the cargo area. The flashlight snaps out of the bezel when needed. The flashlight features two bright LED light bulbs and is powered by rechargeable lithium batteries that recharge when snapped back into place.
Page 282: Cargo Storage
280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To operate the flashlight, press the switch once for high, Cargo Storage twice for low, and a third time to return to off. There is a removable storage bin located on the left side of the rear cargo area.
Page 283: Cargo Tie-Down Hooks
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 281 3. The liftgate may be opened with the cargo cover in WARNING! place. • To help protect against personal injury, passengers WARNING! should not be seated in the rear cargo area. The rear cargo space is intended for load carrying In a collision, a loose cargo cover in the vehicle could purposes only, not for passengers, who should sit cause injury.
Page 284: Rear Window Features
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES WARNING! (Continued) Rear Window Wiper/Washer • Do not carry loads which exceed the load limits described on the label attached to the left door or The rear wiper/washer is controlled by a rotary switch left door center pillar.
Page 285: Rear Window Defroster
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 283 Rotate the center portion of the lever upward to the If the rear wiper is operating when the ignition is turned first detent for intermittent operation and to the OFF, the wiper will automatically return to the “park” second detent for continuous rear wiper operation.
Page 286: Roof Luggage Rack - If Equipped
284 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED CAUTION! The crossbars and side rails are designed to carry weight on vehicles equipped with a luggage rack. The load must Failure to follow these cautions can cause damage to not exceed 150 lbs (68 kg), and should be uniformly the heating elements: •...
Page 287: Deploying The Crossbars
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285 Deploying the Crossbars Starting with one crossbar, completely loosen the thumb screws at both ends of the crossbar. 1 — Side Rail 2 — Crossbar The roof rack does not increase the total load carrying Thumb Screw capacity of the vehicle.
Page 288 286 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Remove the crossbar from the stowed position by sliding CAUTION! the crossbar towards the center of the roof. Repeat with crossbar on the opposite side. Be careful when handling the crossbars to prevent damage to the vehicle.
Page 289 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 287 Position the crossbars across the roof making sure the Slide the cross bar into to the deploy position by moving letters on the crossbars align with the matching letters on it towards the matching letter in the side rail. Be sure the the side rail.
Page 290: Stowing The Crossbars
288 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Deploy and tighten the second crossbar to complete the Stowing the Crossbars deployment of the crossbars. Starting with one crossbar, completely loosen the thumb screws at both ends. Slide the crossbar away from the matching letter to remove it from the deployed position.
Page 291 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 289 Starting with the one crossbar, bend up the pivot sup- Then, position the crossbar along the correct side rail. ports at each end. Make sure the letters on the crossbar align with the matching letters on the side rail.
Page 292 290 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Slide the crossbar outward, away from the center of the roof. The crossbar will nest fully within the side rail. Tightening Crossbar Repeat the procedure to stow the second crossbar on the opposite side. Crossbar to Side Rail Once the driver’s side crossbar is in place, tighten the thumb screws completely.
Page 293 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 291 CAUTION! • To prevent damage to the roof of your vehicle, DO NOT carry any loads on the roof rack without the crossbars deployed. The load should be secured and placed on top of the crossbars, not directly on the roof.
Page 294 292 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) CAUTION! (Continued) • Load should always be secured to cross bars first, • Travel at reduced speeds and turn corners care- with tie down loops used as additional securing fully when carrying large or heavy loads on the points if needed.
Page 295: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....297 Engine Oil Change Indicator System ..322 Instrument Cluster ....298 Fuel Economy .
Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL Turn Menu Off ..... . 327 Operation Instructions — CD Mode For CD And MP3 Audio Play ....343 Compass / Temperature Display .
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 Operating Instructions (Uconnect™ Phone) Single Video Screen ....373 — If Equipped ..... . 364 Play Video Games .
Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL Replacing The Batteries ....390 Radio Operation And Mobile Phones ..408 Unwired Stereo Headphone Lifetime Climate Controls .
Page 299: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 297 INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Lower Switch Bank 11 — Headlight Switch 2 — Instrument Cluster 7 — Hazard Switch 12 — Hood Release 3 — Radio 8 — Storage Bin 13 —...
Page 300: Instrument Cluster
298 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 301: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 299 INSTRUMENT CLUSTER DESCRIPTIONS As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System 1. Tachometer (TPMS) that illuminates a low tire pressure telltale when Indicates the engine speed in revolutions per minute one or more of your tires is significantly under-inflated.
Page 302 300 UNDERSTANDING YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is The TPMS has been optimized for the original combined with the low tire pressure telltale. When the equipment tires and wheels.
Page 303 UNDERSTANDING YOUR INSTRUMENT PANEL 301 does not come on when turning the key from OFF to WARNING! ON/RUN, have the condition checked promptly. A malfunctioning catalytic converter, as referenced Certain conditions, such as a loose or missing gas cap, above, can reach higher temperatures than in normal poor fuel quality, etc., may illuminate the light after operating conditions.
Page 304 302 UNDERSTANDING YOUR INSTRUMENT PANEL system. If this light remains on after several ignition 5. Electronic Stability Control (ESC) OFF Indicator cycles, and the vehicle has been driven several miles Light — If Equipped (kilometers) at speeds greater than 30 mph (48 km/h), see This light indicates the Electronic Stability Con- your authorized dealer as soon as possible to have the trol (ESC) is off.
Page 305 UNDERSTANDING YOUR INSTRUMENT PANEL 303 brakes. If the ABS light does not turn on when the 10. High Beam Indicator ignition switch is turned to the ON/RUN position, have This light indicates that the headlights are on high the light inspected by an authorized dealer. beam.
Page 306 304 UNDERSTANDING YOUR INSTRUMENT PANEL as it was before the repair or service. If s/he cannot do so, 14. 4 LOW then the odometer must be set at zero, and a sticker must This light alerts the driver that the vehicle is in be placed in the door jamb stating what the mileage was the four-wheel drive LOW mode.
Page 307 UNDERSTANDING YOUR INSTRUMENT PANEL 305 17. Fuel Door Reminder 20. Electronic Vehicle Information Center (EVIC) The fuel pump symbol points to the side of the Amber Telltale Area vehicle where the fuel door is located. This area will display the EVIC reconfigurable amber caution telltales.
Page 308 306 UNDERSTANDING YOUR INSTRUMENT PANEL indicate that the parking brake is applied, that the brake indicated by the Brake Warning Light, which will turn on fluid level is low, or that there is a problem with the when the brake fluid level in the master cylinder has anti-lock brake system reservoir.
Page 309 UNDERSTANDING YOUR INSTRUMENT PANEL 307 Vehicles equipped with the Anti-Lock Brake System 23. TOW/HAUL (ABS), are also equipped with Electronic Brake Force The TOW HAUL button is located on the Distribution (EBD). In the event of an EBD failure, the center stack upper switch bank.
Page 310 308 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Temperature Gauge WARNING! The temperature gauge shows engine coolant tempera- ture. Any reading within the normal range indicates that A hot engine cooling system is dangerous. You or the engine cooling system is operating satisfactorily. others could be badly burned by steam or boiling coolant.
Page 311: Electronic Vehicle Information Center (Evic)
UNDERSTANDING YOUR INSTRUMENT PANEL 309 ELECTRONIC VEHICLE INFORMATION CENTER The EVIC consists of the following: (EVIC) • System Status The Electronic Vehicle Information Center (EVIC) fea- • Vehicle Information Warning Message Displays tures a driver-interactive display that is located in the instrument cluster.
Page 312 310 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by UP Button pressing the following buttons mounted on the steering Press and release the UP button to scroll up- wheel: ward through the main menus (Fuel Economy, ACC (if equipped), Vehicle Speed, Trip Info, Tire PSI, Vehicle Info, Messages, Units, System Setup, Turn Menu Off) and sub-menus.
Page 313: Electronic Vehicle Information Center (Evic) Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 311 BACK Button messages that consist of approximately 60 possible warn- Press the BACK button to scroll back to a ing or information messages. These pop up messages fall previous menu or sub-menu. into several categories: •...
Page 314 312 UNDERSTANDING YOUR INSTRUMENT PANEL of this message type are Turn Signal On (if a turn signal When the appropriate conditions exist, the EVIC displays is left on) and Lights On (if driver leaves the vehicle). the following messages: • Unstored Messages Until RUN •...
Page 315 UNDERSTANDING YOUR INSTRUMENT PANEL 313 • Left front turn signal lamp out • Normal Cruise Ready — When Adaptive Cruise Con- trol (ACC) system is turned off and Normal (Fixed • Right front turn signal lamp out Speed) Cruise Control mode is available. Refer to •...
Page 316 314 UNDERSTANDING YOUR INSTRUMENT PANEL • ACC Cancelled — To disable the ACC system. Refer to • Brake — If the ACC system predicts that its maximum “Adaptive Cruise Control (ACC)” in “Understanding braking level is not sufficient to maintain the set The Features Of Your Vehicle”...
Page 317 UNDERSTANDING YOUR INSTRUMENT PANEL 315 • ACC/FCW Unavailable Service Radar Sensor — If the • Oil temp high Speed may be limited ACC system turns off due to an internal system fault • Oil temp high Speed limited that requires service from an authorized dealer. Refer •...
Page 318 316 UNDERSTANDING YOUR INSTRUMENT PANEL • Memory 2 profile set • Service All Wheel Drive System • Memory system unavailable — Not in Park • All Wheel Drive System in neutral • Memory system unavailable — Seatbelt buckled • ECO — Fuel Saver Indicator •...
Page 319: Evic White Telltale Lights
UNDERSTANDING YOUR INSTRUMENT PANEL 317 • Electronic Speed Control SET EVIC White Telltale Lights This area will show reconfigurable white caution tell- This light will turn on when the electronic tales. These telltales include: speed control is SET. For further information, refer to “Electronic Speed Control”...
Page 320 318 UNDERSTANDING YOUR INSTRUMENT PANEL • Forward Collision Warning (FCW) OFF momentarily until the over temperature condition no This light warns the driver of a potential colli- longer exists. Once driving conditions are safe, then pull sion with the vehicle in front and prompts the over and let vehicle idle.
Page 321: Evic Amber Telltale Lights
UNDERSTANDING YOUR INSTRUMENT PANEL 319 • Windshield Washer Fluid Low Indicator EVIC Amber Telltale Lights This area will show reconfigurable amber caution tell- This light will turn on to indicate the wind- tales. These telltales include: shield washer fluid is low. •...
Page 322 320 UNDERSTANDING YOUR INSTRUMENT PANEL • Liftgate Ajar If the charging system light remains on, it means that the This light will turn on to indicate that liftgate vehicle is experiencing a problem with the charging may be ajar. system. Obtain SERVICE IMMEDIATELY. See an autho- rized dealer.
Page 323 UNDERSTANDING YOUR INSTRUMENT PANEL 321 If the light remains lit with the engine running, your If the light turns on while driving, safely pull over and vehicle will usually be drivable. However, see an autho- stop the vehicle. If the A/C system is on, turn it off. Also, rized dealer for service as soon as possible.
Page 324: Engine Oil Change Indicator System
322 UNDERSTANDING YOUR INSTRUMENT PANEL Engine Oil Change Indicator System CAUTION! Oil Change Due Continuous driving with the Transmission Tempera- Your vehicle is equipped with an engine oil change ture Warning Light illuminated will eventually cause indicator system. The “Oil Change Due” message will severe transmission damage or transmission failure.
Page 325: Fuel Economy
UNDERSTANDING YOUR INSTRUMENT PANEL 323 Vehicles Equipped With Keyless Enter-N-Go Fuel Economy Press and release the UP/DOWN buttons until one of the 1. Without pressing the brake pedal, cycle the ignition to following Fuel Economy Functions displays in the EVIC: the ON/RUN position (Do not start the engine.) •...
Page 326 324 UNDERSTANDING YOUR INSTRUMENT PANEL (MDS) (if equipped) allows the engine to operate on four Distance To Empty (DTE) cylinders, or if you are driving in a fuel efficient manner. Shows the estimated distance that can be traveled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level.
Page 327: Vehicle Speed
UNDERSTANDING YOUR INSTRUMENT PANEL 325 Vehicle Speed Press the UP/DOWN buttons to cycle through all the This feature allows you to monitor your vehicle speed on Trip Computer functions. The Trip Functions mode dis- the EVIC display, press and release the SELECT button to plays the following information: change the units of measure between in MPH or km/h.
Page 328: Vehicle Info
326 UNDERSTANDING YOUR INSTRUMENT PANEL Vehicle Info (Customer Information Features) Units Press and release the UP or DOWN button until “Vehicle Press and release the UP or DOWN button until “Units” Info” displays in the EVIC and press the SELECT button. displays in the EVIC and press the SELECT button.
Page 329: Messages
UNDERSTANDING YOUR INSTRUMENT PANEL 327 Messages # NOTE: The system will display the last known outside Select from Main Menu using the UP or DOWN buttons. temperature when starting the vehicle and may need to This feature shows the number of stored warning mes- be driven several minutes before the updated tempera- sages (in the # place holder).
Page 330 328 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, etc. Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences the variance should be set for the zone where the vehicle is driven, per the zone map.
Page 331 UNDERSTANDING YOUR INSTRUMENT PANEL 329 3. Press the DOWN button until the “Compass Variance” 1. Turn ON the ignition switch. message is displayed in the EVIC, then press the SELECT 2. Press the UP or DOWN button until the Setup button.
Page 332: Customer-Programmable Features (System Setup)
330 UNDERSTANDING YOUR INSTRUMENT PANEL Customer-Programmable Features Italian (Italiano), German (Deutsch), and Dutch (Neder- (System Setup) lands). Then, as you continue, the information will dis- Personal Settings allows you to set and recall features play in the selected language. when the transmission is in PARK. If the transmission is Nav–Turn By Turn out of PARK or the vehicle begins moving, a warning When this feature is selected, the navigation system...
Page 333 UNDERSTANDING YOUR INSTRUMENT PANEL 331 feature showing the system has been activated, or the all doors will unlock no matter which passive entry check-mark is removed showing the system has been equipped door handle is grasped. If Driver Door 1st Press deactivated.
Page 334 332 UNDERSTANDING YOUR INSTRUMENT PANEL button a check-mark appears next to the feature showing Horn With Remote Lock the system has been activated or the check-mark is When this feature is selected, a short horn sound will removed showing the system has been deactivated. Refer occur when the RKE transmitter LOCK button is pressed.
Page 335 UNDERSTANDING YOUR INSTRUMENT PANEL 333 Flash Lamps With Lock Headlamps With Wipers When this feature is selected, the front and rear turn (Available with Automatic Headlamps Only) signals will flash when the doors are locked or unlocked When this feature is selected, and the headlight switch is with the RKE transmitter.
Page 336 334 UNDERSTANDING YOUR INSTRUMENT PANEL Easy Entry/Exit Seat REVERSE position. The mirrors will move back to their (Available with Memory Seat Only) previous position when the transmission is shifted out of This feature provides automatic driver seat positioning to REVERSE. To make your selection, press and release the enhance driver mobility when entering and exiting the SELECT button until a check-mark appears next to the vehicle.
Page 337 UNDERSTANDING YOUR INSTRUMENT PANEL 335 Illuminated Approach Display ECO Symbol — If Equipped When this feature is selected, the headlights will activate The “ECO” message is located in the Compass/ and remain on for 0, 30, 60, or 90 seconds when the doors Temperature display;...
Page 338 336 UNDERSTANDING YOUR INSTRUMENT PANEL Gauge Glow Rings Intermittent Wiper — If Equipped The gauge glow rings that illuminate the tachometer and When this feature is selected, the system will automati- speedometer in the instrument cluster can be turned on cally activate the windshield wipers if it senses moisture or off.
Page 339 UNDERSTANDING YOUR INSTRUMENT PANEL 337 mode the Blind Spot Monitor (BSM) will show a visual of a possible collision with the vehicle in front of you when you are much closer. This allows for a more alert in the outside mirrors as well as an audible alert dynamic driving experience.
Page 340: System Status
338 UNDERSTANDING YOUR INSTRUMENT PANEL the SELECT button until a check-mark appears next to Calibrate Compass the setting, showing that the setting has been selected. Refer to “Compass Display” for more information. Refer to “Rear Park Assist System” in “Understanding Compass Variance The Features Of Your Vehicle”...
Page 341: Media Center 730N/430/430N
UNDERSTANDING YOUR INSTRUMENT PANEL 339 Refer to “Tires-General Information/Tire Inflation Pressures” in “Starting And Operating” for additional information. • Your system can be set to display pressure units in PSI, kPa, or BAR. MEDIA CENTER 730N/430/430N (RHR/RER/RBZ/ RHB) CD/DVD/HDD/NAV — IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate.
Page 342: If Equipped
340 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions (Voice Command System) — If Equipped Refer to “Voice Command” in the Uconnect™ User Manual located on the DVD for further details. Operating Instructions (Uconnect™ Phone) — If Equipped Refer to “Uconnect™ Phone” in the Uconnect™ User Manual located on the DVD for further details.
Page 343 UNDERSTANDING YOUR INSTRUMENT PANEL 341 Power Switch/Volume Control (Rotary) TIME Button Push the ON/VOLUME control knob to turn on the Press the TIME button to alternate display of the time radio. Push the ON/VOLUME control knob a second and radio frequency. time to turn off the radio.
Page 344 342 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
Page 345: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 343 SET/RND Button — To Set the Pushbutton Every time a preset button is used, a corresponding Memory button number will display. When you are receiving a station that you wish to Buttons 1 - 6 commit to pushbutton memory, press the SET/RND These buttons tune the radio to the stations that you button.
Page 346 344 UNDERSTANDING YOUR INSTRUMENT PANEL • This radio is capable of playing compact discs (CD), CAUTION! recordable compact discs (CD-R), rewritable compact • This CD player will accept 4-3/4 in (12 cm) discs discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 347: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 345 NOTE: Ejecting with the ignition OFF is not allowed on AM/FM Button convertible or soft-top models (if equipped). Press the button to select either AM or FM mode. SEEK Button SET/RND Button (Random Play Button) Press the right SEEK button for the next selection on the Press this button while the CD is playing to activate CD.
Page 348 346 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Media (Disc Types) a number instead. With a maximum number of files, The MP3 file recording media supported by the radio are exceeding 20 folders will result in this display. With CDDA, CD-R, CD-RW, MP3, and CDDA+MP3. 200 files, exceeding 50 folders will result in this display.) Supported Medium Formats (File Systems)
Page 349 UNDERSTANDING YOUR INSTRUMENT PANEL 347 Supported MP3 File Formats MPEG Sampling Fre- Bit Rate (kbps) The radio will recognize only files with the *.MP3 exten- Specification quency (kHz) sion as MP3 files. Non-MP3 files named with the *.MP3 320, 256, 224, extension may cause playback problems.
Page 350: Operation Instructions - Auxiliary Mode
348 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files Operation Instructions - Auxiliary Mode When a medium containing MP3 data is loaded, the The auxiliary (AUX) jack is an audio input jack, which radio checks all files on the medium. If the medium allows the user to plug in a portable device, such as an contains a lot of folders or files, the radio will take more MP3 player, or cassette player, and utilize the vehicle’s...
Page 351: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)
UNDERSTANDING YOUR INSTRUMENT PANEL 349 MEDIA CENTER 130 WITH SATELLITE RADIO Operating Instructions — Radio Mode (SALES CODE RES+RSC) NOTE: The ignition switch must be in the ON/RUN or NOTE: The radio sales code is located on the lower right ACC position to operate the radio.
Page 352 350 UNDERSTANDING YOUR INSTRUMENT PANEL to seek up and the left switch to seek down. The radio Phone Button Uconnect™ Phone — If Equipped will remain tuned to the new station until you make Press this button to operate the Uconnect™ Phone feature another selection.
Page 353 UNDERSTANDING YOUR INSTRUMENT PANEL 351 3. After adjusting the hours, press the right side TUNE/ INFO Button SCROLL control knob to set the minutes. The minutes Press the INFO button for an RDS station (one with call will begin to blink. letters displayed).
Page 354 352 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second MUSIC TYPE Button time and MID will display. Turn the TUNE/SCROLL Pressing this button once will turn on the Music Type control knob to the right or left to increase or decrease the mode for five seconds.
Page 355: Setup Button
UNDERSTANDING YOUR INSTRUMENT PANEL 353 Program Type 16-Digit Character Display Program Type 16-Digit Character Display Information Inform Top 40 Top 40 Jazz Jazz Weather Weather News News By pressing the SEEK button when the Music Type icon Nostalgia Nostalga is displayed, the radio will be tuned to the next frequency Oldies Oldies station with the same selected Music Type name.
Page 356: Set/Rnd Button
354 UNDERSTANDING YOUR INSTRUMENT PANEL hours, press the TUNE/SCROLL control knob to set You may add a second station to each pushbutton by the minutes. The minutes will begin to blink. Adjust repeating the above procedure with this exception: Press the minutes using the right side TUNE/SCROLL the SET/RND button twice and SET 2 will show in the control knob.
Page 357: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 355 Operation Instructions — CD MODE for CD and If you insert a disc with the ignition ON/RUN and the MP3 Audio Play radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display NOTE: will show the track number, and index time in minutes •...
Page 358 356 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within RW/FF 10 seconds, it will be reloaded. If the CD is not removed, Press and hold FF (Fast Forward) and the CD player will the radio will reinsert the CD but will not play it.
Page 359: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 357 • Maximum number of files: 255 Notes On Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 • Maximum number of folders. (The radio display of file file recording media and formats are limited. When names and folder names is limited.
Page 360 358 UNDERSTANDING YOUR INSTRUMENT PANEL Discs created with an option such as keep disc open after MPEG Sampling Fre- Bit Rate (kbps) writing are most likely multisession discs. The use of Specification quency (kHz) multisession for CD audio or MP3 playback may result in 320, 256, 224, longer disc loading times.
Page 361: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 359 Playback of MP3 Files LIST Button (CD Mode for MP3 Play) When a medium containing MP3 data is loaded, the Pressing the LIST button will bring up a list of all folders radio checks all files on the medium. If the medium on the disc.
Page 362: Uconnect™ Multimedia (Satellite Radio) - If Equipped
360 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds Uconnect™ Multimedia (Satellite Radio) — to return to elapsed time display. If Equipped Satellite radio uses direct satellite-to-receiver broadcast- Operation Instructions - Auxiliary Mode ing technology to provide clear digital sound, coast to The auxiliary (AUX) jack is an audio input jack which coast.
Page 363 UNDERSTANDING YOUR INSTRUMENT PANEL 361 or visit the Sirius web site at www.sirius.com, or at Sirius ID number will display. The Sirius ID number www.siriuscanada.ca for Canadian residents. display will time out in two minutes. Press any button on the radio to exit this screen. Electronic Serial Number/Sirius Identification Number (ESN/SID) Selecting Uconnect™...
Page 364 362 UNDERSTANDING YOUR INSTRUMENT PANEL Reception Quality SEEK Buttons Satellite reception may be interrupted due to one of the Press and release the SEEK buttons to search for the next following reasons: channel in Satellite mode. Press the right switch to seek up and the left switch to seek down.
Page 365 UNDERSTANDING YOUR INSTRUMENT PANEL 363 RW/FF By pressing the SEEK button when the Music Type Pressing the RW (Rewind) or FF (Fast Forward) buttons function is active, the radio will be tuned to the next causes the tuner to search for the next channel in the channel with the same selected Music Type name.
Page 366: Operating Instructions (Uconnect™ Phone) - If Equipped
364 UNDERSTANDING YOUR INSTRUMENT PANEL Select the button (1-6) you wish to lock onto this channel Operating Instructions (Uconnect™ Phone) — and press and release that button. If a button is not If Equipped selected within five seconds after pressing the SET but- Refer to “Uconnect™...
Page 367: Connecting The Ipod Or External Usb Device
UNDERSTANDING YOUR INSTRUMENT PANEL 365 This feature allows an iPod or external USB device to be Connecting The iPod Or External USB Device plugged into the USB port, located in the center console. Use the connection cable to connect an iPod or external USB device to the vehicle’s USB/AUX connector port iPod control supports Mini, 4G, Photo, Nano, 5G iPod which is located in the center console.
Page 368 366 UNDERSTANDING YOUR INSTRUMENT PANEL be routed through without damaging the cable when Second Row USB Charging Port closing the lid. A factory cut out space for the cable to be The second row USB connector port can be used for routed may be located in the base of the center console on charging purposes only.
Page 369: Using This Feature
UNDERSTANDING YOUR INSTRUMENT PANEL 367 NOTE: If the device battery to be charged is completely on the radio faceplate or press the VR button and say depleted, it may take awhile to charge. USB or Switch to USB . Once in the iPod /USB/MP3 control mode, audio tracks (if available from audio Using This Feature device) start playing over the vehicle’s audio system.
Page 370 368 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it counterclockwise (backward) by one • While a track is playing, press the INFO button to see click, will jump to the previous track in the list or the associated metadata (artist, track title, album, etc.) press the VR button and say Previous Track for that track.
Page 371: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 369 • RND button (available on sales code RES radio only): press the TUNE control knob to select and start Pressing this button toggles between Shuffle ON and playing the track. Turning the TUNE control knob Shuffle OFF modes for the iPod or external USB fast will scroll through the list faster.
Page 372 370 UNDERSTANDING YOUR INSTRUMENT PANEL • Preset 5 – Audiobooks • MUSIC TYPE button: The MUSIC TYPE button is another shortcut button to the genre listing on your • Preset 6 – Podcasts audio device. • Pressing a PRESET button will display the current CAUTION! list on the top line and the first item in that list on the second line.
Page 373: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 371 phone system. Seven devices can be paired to the WARNING! Uconnect™ phone system, but just one can be selected and played. Do not plug in or remove the iPod or external USB device while driving. Failure to follow this warning Selecting Different Audio Device could result in an accident.
Page 374: Uconnect™ Multimedia Video Entertainment System (Ves)™ - If Equipped
372 UNDERSTANDING YOUR INSTRUMENT PANEL Previous Track Use the SEEK DOWN button, or press the VR button on the radio and say “Previous Track” to jump to the previous track music on your cellular phone. Browse Browsing is not available on a BTSA device. Only the current song that is playing will display info.
Page 375: Single Video Screen
UNDERSTANDING YOUR INSTRUMENT PANEL 373 • When the Video Screen are open and a DVD is inserted into the VES™ player, the screen turns on automati- Press the LOAD button then corresponding number (1–6) cally, the headphone transmitters turn on and play- where the DVD is to be loaded (Non-Touch-Screen).
Page 376 374 UNDERSTANDING YOUR INSTRUMENT PANEL Using The Remote Control NOTE: The VES™ system will retain the last setting when turned off. 1. Press the MODE button on the Remote Control. Using The Touch-Screen Radio Controls 2. While looking at the video screen, highlight DISC by either pressing Up/Down/Left/Right buttons or by re- 1.
Page 377 UNDERSTANDING YOUR INSTRUMENT PANEL 375 Rear VES Soft-key Select Channel/Screen 1 And DISC In The MEDIA Column 3. Touch the 1 soft-key and then the DISC soft-key in the NOTE: MEDIA column. To exit touch the back arrow soft-key at •...
Page 378: Play Video Games
376 UNDERSTANDING YOUR INSTRUMENT PANEL • Viewing a DVD on the Touch-Screen radio screen is Play Video Games not available in all states/provinces, and the vehicle Connect the video game console to the Auxiliary RCA must be stopped, and the shift lever must be in the input jacks located on the back of the center console.
Page 379 UNDERSTANDING YOUR INSTRUMENT PANEL 377 When connecting an external source to the AUX input, be sure to follow the standard color coding for the VES™ jacks: NOTE: Certain high-end video games, such as Playsta- tion3 and XBox360 will exceed the power limit of the vehicle’s Power Inverter.
Page 380 378 UNDERSTANDING YOUR INSTRUMENT PANEL Using The Touch-Screen Radio Controls 3. Touch the 1 soft-key and then touch AUX 1 in the VES column. To exit press the back arrow soft-key at the top of 1. Press the MENU hard-key on the radio faceplate. the screen.
Page 381: Listen To An Audio Source On Channel 2 While A Video Is Playing On Channel 1
UNDERSTANDING YOUR INSTRUMENT PANEL 379 Listen To An Audio Source On Channel 2 While A Video Is Playing On Channel 1 Ensure the Remote Control and Headphone switch is on Channel 2. Using The Remote Control 1. Press the MODE button on the Remote Control and the Mode Select Screen will display, unless a video is playing then only a small banner will appear on the bottom of the screen.
Page 382 380 UNDERSTANDING YOUR INSTRUMENT PANEL Using The Touch-Screen Radio Controls 3. To listen to an audio source on Channel 2 while a video is playing on Channel 1, touch the 2 soft-key and 1. Press the MENU hard-key on the radio faceplate. choose an audio source.
Page 383: Important Notes For Single Video Screen System
UNDERSTANDING YOUR INSTRUMENT PANEL 381 Important Notes For Single Video Screen System Play A DVD Using The Touch-Screen Radio • VES™ is able to transmit two channels of stereo audio 1. Press the OPEN/CLOSE or LOAD hard-key on the simultaneously. radio faceplate (Touch-Screen).
Page 384 382 UNDERSTANDING YOUR INSTRUMENT PANEL Using The Remote Control NOTE: • Channel/Screen 1 select mode information is shown 1. Press the MODE button on the Remote Control. on the left side of the screen. 2. While looking at Screen 1, highlight DISC by either •...
Page 385 UNDERSTANDING YOUR INSTRUMENT PANEL 383 Rear VES Soft-key Select Channel/Screen 1 And DISC In The MEDIA Column 3. Touch the 1 or 2 soft-key and then the DISC soft-key in NOTE: the MEDIA column. To exit touch the back arrow at the •...
Page 386: Remote Control
384 UNDERSTANDING YOUR INSTRUMENT PANEL • Viewing a DVD on the Touch-Screen radio screen is Remote Control not available in all states/provinces, and the vehicle must be stopped, and the shift lever must be in the PARK position for vehicles with automatic transmis- sion.
Page 387 UNDERSTANDING YOUR INSTRUMENT PANEL 385 2. Channel Selector Indicators – When a button is / Prev – In radio modes, press to select to the pressed, the currently affected channel or channel button previous station. In disc modes, press to advance to the is illuminated momentarily.
Page 388 386 UNDERSTANDING YOUR INSTRUMENT PANEL disc in a radio with a multiple-disc changer, PROG Up mode is selected and the disc is stopped, press the SETUP selects the next disc and PROG Down selects the previ- button to access the DVD Setup menu. (see the DVD ous disc.
Page 389: Remote Control Storage
UNDERSTANDING YOUR INSTRUMENT PANEL 387 Remote Control Storage The video screen(s) come with a built in storage compart- ment for the remote control which is accessible when the screen is opened. To remove the remote, use your index finger to pull and rotate the remote towards you. Do not try to pull the remote straight down as it will be very difficult to remove.
Page 390: Replacing The Batteries
388 UNDERSTANDING YOUR INSTRUMENT PANEL with a DVD player, follow the radio’s instructions to Headphones Operation turn Video Lock on. The radio and the video screen(s) The headphones receive two separate channels of audio indicate when Video Lock is active. using an infrared transmitter from the video screen.
Page 391: Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 389 NOTE: The rear video system must be turned on before sound can be heard from the headphones. To conserve battery life, the headphones will automatically turn off approximately three minutes after the rear video system is turned off.
Page 392: Replacing The Batteries
390 UNDERSTANDING YOUR INSTRUMENT PANEL 3. If the video screen is displaying a video source (such Replacing The Batteries as a DVD Video), pressing DISPLAY shows the status on Each set of headphones requires two AAA batteries for a popup banner at the bottom of the screen. Pressing the operation.
Page 393 UNDERSTANDING YOUR INSTRUMENT PANEL 391 How Long Does The Coverage Last? This warranty lasts NATURE WHATSOEVER. Some states and jurisdictions as long as you own the Product. may not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not What Does This Warranty Cover? Except as specified apply to you.
Page 394: System Information
392 UNDERSTANDING YOUR INSTRUMENT PANEL You may register your Unwired wireless headphones mode, but not change stations until the radio mode is online at www.unwiredtechnology.com or by phone at changed to a mode that is different from the VES™ 1-888-293-3332. selected radio mode.
Page 395 UNDERSTANDING YOUR INSTRUMENT PANEL 393 The VES™ can even control radio modes or video modes 1. Channel 1 Mode while the radio is turned off. The VES™ can access the 2. Channel 1 Shared Status radio modes or disc modes by navigating to those modes on the VES™...
Page 396 394 UNDERSTANDING YOUR INSTRUMENT PANEL Numeric Keypad Menu When the display for either Channel 1 or Channel 2 shows DIRECT TUNE, pressing the remote control’s ENTER button activates a numeric keypad menu. This screen makes it easy to enter a specific tuner frequency, satellite channel, or track number.
Page 397 UNDERSTANDING YOUR INSTRUMENT PANEL 395 Station List Menu Disc Menu Channel Selection Menu For SIRIUS Backseat TV™ When listening to Satellite audio or watching SIRIUS Backseat TV™ (if equipped), pressing the remote con- Disc Menu For CDs trol’s MENU button displays a list of all available chan- When listening to a CD Audio or CD Data disc, pressing nels.
Page 398 396 UNDERSTANDING YOUR INSTRUMENT PANEL Display Settings settings are already set for optimum viewing, so there is no need to change these settings under normal circum- stances. To change the settings, press the remote control’s navi- gation buttons ( , ) to select an item, then press the remote control’s navigation buttons ( , ) to change the...
Page 399 UNDERSTANDING YOUR INSTRUMENT PANEL 397 • Close the video screen. Disc Formats The VES™ DVD player is capable of playing the follow- • To change the current audio mode, press the remote ing types of discs (12 mm or 8 mm diameter): control’s MODE button.
Page 400 398 UNDERSTANDING YOUR INSTRUMENT PANEL DVD Audio Support If you record a disc using a personal computer, there may be cases where the VES™ DVD player may not be able to When a DVD-Audio disc is inserted in the VES™ DVD play some or the entire disc, even if it is recorded in a player, the DVD-Audio title on the disc is played by compatible format and is playable on other players.
Page 401 UNDERSTANDING YOUR INSTRUMENT PANEL 399 • Mixed media recordable DVD formats will only play end with the extension .mp3 or .MP3 and WMA the Video_TS portion of the disc. files must always end with the extension .wma or .WMA . To prevent incorrect playback, do not use If you are still having trouble writing a disc that is these extensions for any other types of files.
Page 402 400 UNDERSTANDING YOUR INSTRUMENT PANEL between 64 and 192Kbps. Variable bit rates are also If a disc has a damaged track which results in audible or supported. For both formats, the recommended visible errors that persists for 2.0 seconds, the DVD sample rate is either 44.1kHz or 48kHz.
Page 403 UNDERSTANDING YOUR INSTRUMENT PANEL 401 Display All of the Language settings have a special Other setting Other Language Setup to accommodate languages other than Japanese or Eng- lish. These languages are selected using a special four- digit code. To enter a new language code, activate the DVD Setup Menu and follow these additional instructions: •...
Page 404 402 UNDERSTANDING YOUR INSTRUMENT PANEL • When the entire four-digit code is entered, press the them where lower numbers are designated for all audi- remote control’s ENTER button. If the language code ences and higher numbers are designated for more adult is not valid, the numbers all change back to * .
Page 405 UNDERSTANDING YOUR INSTRUMENT PANEL 403 To set the password, activate the DVD Setup Menu and follow these additional instructions: • Using the remote control Left and Right cursor but- tons, select the Rating tab. • Highlight Change Password , and then press the remote control’s ENTER button.
Page 406 404 UNDERSTANDING YOUR INSTRUMENT PANEL • After the four-digit password is entered, press the To set the rating, activate the DVD Setup Menu and remote control’s ENTER button to accept the change. follow these additional instructions: • Using the remote control’s Left and Right cursor buttons, select the Rating tab.
Page 407 UNDERSTANDING YOUR INSTRUMENT PANEL 405 • Using the remote control’s Up and Down cursor Dolby Digital and MLP Lossless Manufactured buttons, select the new rating level, and then press the under license from Dolby Laboratories. Dolby , remote control’s ENTER button to accept the change. MLP Lossless , and the double-D symbol are trademarks of Dolby Laboratories.
Page 408: Steering Wheel Audio Controls
406 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS The right-hand control is a rocker-type switch with a The remote sound system controls are located on the rear pushbutton in the center and controls the volume and surface of the steering wheel. Reach behind the wheel to mode of the sound system.
Page 409: Cd Player
UNDERSTANDING YOUR INSTRUMENT PANEL 407 The button located in the center of the left-hand control CD/DVD DISC MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD in good condition, take the following grammed in the radio preset pushbutton. precautions: CD Player 1.
Page 410: Radio Operation And Mobile Phones
408 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- Dual-Zone Automatic Temperature Control (ATC) lar disc, it may be damaged (i.e., scratched, reflective — If Equipped coating removed, a hair, moisture or dew on the disc) •...
Page 411 UNDERSTANDING YOUR INSTRUMENT PANEL 409 2. Recirculation Control Button Press and release to change the current setting, the indicator illuminates when ON. 3. Left Front Seat Occupant Temperature Display This display shows the temperature setting for the left front seat occupant. 4.
Page 412 410 UNDERSTANDING YOUR INSTRUMENT PANEL will cause the ATC to switch into manual mode. The 11. Blower Control blower will engage immediately if the Defrost mode is There are seven blower speeds, the blower speed in- selected. creases as you move the control to the right from the lowest blower setting.
Page 413 UNDERSTANDING YOUR INSTRUMENT PANEL 411 16. Driver Temperature Control Up Button 3. When the system is set up for your comfort level, it is Provides the driver with independent temperature con- not necessary to change the settings. You will experience trol.
Page 414 412 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Operation selected. This allows the front occupants to control the This system offers a full complement of manual override volume of air circulated in the vehicle and cancel the features. Auto mode. NOTE: Each of these features operate independently The operator can also select the direction of the airflow from each other.
Page 415 UNDERSTANDING YOUR INSTRUMENT PANEL 413 NOTE: In many temperature positions, the BI-LEVEL temperature settings for best windshield and side win- mode is designed to provide cooler air out of the panel dow defrosting. When the defrost mode is selected, the outlets and warmer air from the floor outlets.
Page 416: Rear Climate Control - If Equipped
414 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: NOTE: In cold weather, use of Recirculation mode may • If the system is in Mix, Floor or Defrost Mode, the A/C lead to excessive window fogging. The Recirculation can be turned off, but the A/C system shall remain mode is not allowed in the Defrost modes to improve active to prevent fogging of the windows.
Page 417 UNDERSTANDING YOUR INSTRUMENT PANEL 415 Only when the Rear Control Icon is illuminated do the second row seat occupants have control of the rear blower speed. The rear blower control, located in the rear overhead console, has an off position and a range of blower speeds. This allows the second row seat occupants to control the volume of air circulated in the rear of the vehicle.
Page 418: Operating Tips
416 UNDERSTANDING YOUR INSTRUMENT PANEL Rear Temperature Control NOTE: In many temperature positions, the BI-LEVEL Only when the Rear Control Icon is illuminated do the mode is designed to provide cooler air out of the head- second row seat occupants have control of the rear mode liner outlets and warmer air from the floor outlets.
Page 419 UNDERSTANDING YOUR INSTRUMENT PANEL 417 blower speeds will reduce fogging. Interior fogging on Winter Operation the windshield can be quickly removed by selecting the When operating the system during the winter months, DEFROST mode. make sure the air intake, located directly in front of the windshield, is free of ice, slush, snow, or other Regular cleaning of the inside of the windows with a obstructions.
Page 420: Operating Tips Chart
418 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips Chart...
Page 421: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....424 Automatic Transmission ....430 Automatic Transmission .
Page 422 420 STARTING AND OPERATING All-Wheel Drive Operation ....450 After Driving Off-Road ....460 Single-Speed Operating Instructions/ Power Steering .
Page 423 STARTING AND OPERATING 421 Electronic Stability Control (ESC) ..470 Tires — General Information ... . . 488 Trailer Sway Control (TSC) ... . . 474 Tire Pressure .
Page 424 422 STARTING AND OPERATING Replacement Tires ....496 E-85 Usage In Non-Flex Fuel Vehicles ..512 Tire Chains (Traction Devices) .
Page 425 STARTING AND OPERATING 423 Replacement Parts ....519 Towing Requirements ....533 Maintenance .
Page 426: Starting Procedures
424 STARTING AND OPERATING STARTING PROCEDURES WARNING! (Continued) Before starting your vehicle, adjust your seat, adjust the • Do not leave the key fob in or near the vehicle, and inside and outside mirrors, fasten your seat belt, and if do not leave Keyless Enter-N-Go in the ACC or present, instruct all other occupants to buckle their seat ON/RUN mode.
Page 427: Keyless Enter-N-Go - If Equipped
STARTING AND OPERATING 425 Do not press the accelerator. Use the Fob with Integrated CAUTION! (Continued) Key to briefly turn the ignition switch to the START • Shift into or out of REVERSE only after the position and release it as soon as the starter engages. The vehicle has come to a complete stop and the engine starter motor will continue to run, and it will disengage is at idle speed.
Page 428: Normal Starting
426 STARTING AND OPERATING Installing And Removing The ENGINE NOTE: The ENGINE START/STOP button should only START/STOP Button be removed or inserted with the ignition in the LOCK position (OFF position for Keyless Enter-N-Go). Installing The Button Normal Starting 1. Remove the key fob from the ignition switch. Using The ENGINE START/STOP Button 2.
Page 429 STARTING AND OPERATING 427 To Turn Off The Engine Using ENGINE NOTE: If the ignition switch is left in the ACC or RUN START/STOP Button (engine not running) position and the transmission is in PARK, the system will automatically time out after 1.
Page 430: Extreme Cold Weather (Below -20°F Or 29°C)
428 STARTING AND OPERATING • Press the ENGINE START/STOP button a second time If Engine Fails To Start to change the ignition switch to the RUN position WARNING! (EVIC displays “IGNITION MODE RUN”), • Press the ENGINE START/STOP button a third time •...
Page 431: After Starting
STARTING AND OPERATING 429 Clearing A Flooded Engine release it as soon as the starter engages. The starter motor (Using ENGINE START/STOP Button) will disengage automatically in 10 seconds. Once this If the engine fails to start after you have followed the occurs, release the accelerator pedal, turn the ignition “Normal Starting”...
Page 432: Automatic Transmission
430 STARTING AND OPERATING The engine block heater cord is located: AUTOMATIC TRANSMISSION • 3.6L Engine – coiled and strapped to the engine oil CAUTION! dipstick tube. Damage to the transmission may occur if the follow- • 5.7L Engine – bundled and fastened to the injector ing precautions are not observed: harness.
Page 433 STARTING AND OPERATING 431 WARNING! WARNING! (Continued) • Never leave children alone in a vehicle, or with • Unintended movement of a vehicle could injure access to an unlocked vehicle. Allowing children those in or near the vehicle. As with all vehicles, to be in a vehicle unattended is dangerous for a you should never exit a vehicle while the engine is number of reasons.
Page 434: Key Ignition Park Interlock
432 STARTING AND OPERATING Brake/Transmission Shift Interlock System WARNING! (Continued) This vehicle is equipped with a Brake Transmission Shift • It is dangerous to move the shift lever out of PARK Interlock (BTSI) that holds the shift lever in the PARK or NEUTRAL if the engine speed is higher than position unless the brakes are applied.
Page 435: Gear Ranges
STARTING AND OPERATING 433 The electronically-controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating; therefore, the first few shifts on a new vehicle may be somewhat abrupt. This is a normal condition, and precision shifts will develop within a few hundred miles (kilometers).
Page 436 434 STARTING AND OPERATING PARK WARNING! This range supplements the parking brake by locking the • Never use the PARK position as a substitute for transmission. The engine can be started in this range. Never attempt to use PARK while vehicle is in motion. the parking brake.
Page 437 STARTING AND OPERATING 435 WARNING! (Continued) WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • When leaving the vehicle, always remove the key or NEUTRAL if the engine speed is higher than fob from the ignition and lock your vehicle. •...
Page 438 436 STARTING AND OPERATING • Look at the shift lever position display and verify that CAUTION! it indicates the PARK position. • Before moving the shift lever out of PARK, you • With brake pedal released, verify that the shift lever must turn the ignition switch from the LOCK/OFF will not move out of PARK.
Page 439 STARTING AND OPERATING 437 DRIVE WARNING! This range should be used for most city and highway driving. It provides the smoothest upshifts and down- Do not coast in NEUTRAL and never turn off the shifts, and the best fuel economy. The transmission ignition to coast down a hill.
Page 440 438 STARTING AND OPERATING Transmission Limp Home Mode 3. Turn the ignition switch to the LOCK/OFF position. Transmission function is monitored electronically for 4. Wait approximately 10 seconds. abnormal conditions. If a condition is detected that could result in transmission damage, Transmission Limp Home 5.
Page 441 STARTING AND OPERATING 439 Electronic Range Select (ERS) Operation To exit ERS mode, simply press and hold the shift lever to The Electronic Range Select (ERS) shift control allows the the right (+) until “D” is once again displayed in the shift driver to limit the highest available gear when the shift lever position indicator in the instrument cluster.
Page 442: Six-Speed Automatic Transmission (5.7L Engine) - If Equipped
440 STARTING AND OPERATING Overdrive Operation The electronically-controlled transmission provides a The automatic transmission includes an electronically precise shift schedule. The transmission electronics are controlled Overdrive (fifth gear). The transmission will self-calibrating; therefore, the first few shifts on a new automatically shift into the Overdrive gear if the follow- vehicle may be somewhat abrupt.
Page 443: Gear Ranges
STARTING AND OPERATING 441 PARK This range supplements the parking brake by locking the transmission. The engine can be started in this range. Never attempt to use PARK while vehicle is in motion. Apply the parking brake when leaving vehicle in this range.
Page 444 442 STARTING AND OPERATING WARNING! WARNING! (Continued) • It is dangerous to move the shift lever out of PARK • Never use the PARK position as a substitute for or NEUTRAL if the engine speed is higher than the parking brake. Always apply the parking idle speed.
Page 445 STARTING AND OPERATING 443 WARNING! (Continued) CAUTION! • When leaving the vehicle, always remove the key • Before moving the shift lever out of PARK, you fob from the ignition and lock your vehicle. must turn the ignition switch from the LOCK/OFF •...
Page 446 444 STARTING AND OPERATING • With brake pedal released, verify that the shift lever CAUTION! will not move out of PARK. Towing the vehicle, coasting, or driving for any other REVERSE reason with the transmission in NEUTRAL can result This range is for moving the vehicle backward. Shift into in severe transmission damage.
Page 447 STARTING AND OPERATING 445 To access all six available gears, you must use the If the transmission becomes extremely hot, the “Trans- Electronic Range Select (ERS) feature (refer to “Electronic mission Temperature Warning Light” may illuminate and Range Select (ERS)” in this section). the transmission may downshift out of Overdrive until the transmission cools down.
Page 448 446 STARTING AND OPERATING torque converter clutch and the top overdrive gear are In the event of a momentary problem, the transmission inhibited until the transmission fluid is warm (refer to the can be reset to regain all forward gears by performing the “Note”...
Page 449 STARTING AND OPERATING 447 If the transmission cannot be reset, authorized dealer You can switch between DRIVE and ERS mode at any service is required. vehicle speed. When the shift lever is in the DRIVE position, the transmission will operate automatically, Electronic Range Select (ERS) Operation shifting between all available gears.
Page 450 448 STARTING AND OPERATING • vehicle speed is sufficiently high, Screen Display • the driver is not heavily pressing the accelerator, and Actual Gear(s) 1,2, 1,2, 1,2, Allowed • the TOW/HAUL switch has not been activated. NOTE: To select the proper gear position for maximum When To Use TOW/HAUL Mode deceleration (engine braking), simply press and hold the When driving in hilly areas, towing a trailer, carrying a...
Page 451 STARTING AND OPERATING 449 Torque Converter Clutch A feature designed to improve fuel economy has been included in the automatic transmission on your vehicle. A clutch within the torque converter engages automati- cally at calibrated speeds. This may result in a slightly different feeling or response during normal operation in the upper gears.
Page 452: All-Wheel Drive Operation
450 STARTING AND OPERATING Electronic Range Select (ERS) feature, when the trans- ABS and Traction Control, provides resistance to any mission is sufficiently warm, will demonstrate that the wheel that is slipping to allow additional torque transfer transmission is able to shift into and out of Overdrive. to wheels with traction.
Page 453 STARTING AND OPERATING 451 This electronically shifted transfer case is designed to be driven in the AWD AUTO position for normal street and highway conditions on dry hard surfaced roads. For variable driving conditions, the AWD AUTO mode can be used. In this mode, the front axle is engaged, but the vehicle’s power is sent to the rear wheels.
Page 454 452 STARTING AND OPERATING Transfer Case Position Indicator Messages If One Or More Shift Conditions Are Not Met: The Transfer Case Position Indicator messages (AWD 1. The indicator light for the current position will remain AUTO and LOW RANGE) are located in the EVIC (Electronic Vehicle Information Center) and indicate the current and desired transfer case selection.
Page 455 STARTING AND OPERATING 453 engine start up or illuminates during driving, it means Proper operation of all-wheel drive vehicles depends on that the all-wheel drive system is not functioning prop- tires of equal size, type and circumference on each wheel. erly and that service is required.
Page 456: Shifting Procedure
454 STARTING AND OPERATING For additional information on the appropriate use of each towing behind another vehicle. Refer to “Recreational transfer case mode position, see the information below: Towing” in “Starting and Operating” for further information. AWD AUTO All-Wheel Drive Auto Range - This range sends power to Shifting Procedure the rear wheels.
Page 457 STARTING AND OPERATING 455 will flash until the transfer case completes the shift. 3. While still rolling, rotate the AWD control switch to When the shift is complete, the position indicator light the desired position. for the selected position will stop flashing and remain 4.
Page 458 456 STARTING AND OPERATING continuously while the original position indicator light is ON, until all requirements have been met. NOTE: The ignition switch must be in the ON position for a shift to take place and for the position indicator lights to be operable.
Page 459: On-Road Driving Tips
STARTING AND OPERATING 457 Vehicle Information Center (EVIC)” in “Understanding OFF-ROAD DRIVING TIPS Your Instrument Panel” for further information. When To Use LOW Range – If Equipped When off-road driving, shift to LOW for additional ON-ROAD DRIVING TIPS traction. This range should be limited to extreme situa- Utility vehicles have higher ground clearance and a tions such as deep snow, mud, or sand where additional narrower track to make them capable of performing in a...
Page 460 458 STARTING AND OPERATING and/or the flow rate is reduced. If you must cross CAUTION! flowing water avoid depths in excess of 9 in (23 cm). The flowing water can erode the streambed, causing your When driving through water, do not exceed 5 mph vehicle to sink into deeper water.
Page 461: Driving In Snow, Mud And Sand
STARTING AND OPERATING 459 Driving In Snow, Mud And Sand If you stall or begin to lose forward motion while In heavy snow, when pulling a load, or for additional climbing a steep hill, allow your vehicle to come to a stop control at slower speeds, shift the transmission to a low and immediately apply the brakes.
Page 462: Traction Downhill
460 STARTING AND OPERATING Remember, never drive diagonally across a hill always After Driving Off-Road drive straight up or down. Off-road operation puts more stress on your vehicle than does most on-road driving. After going off-road, it is If the wheels start to slip as you approach the crest of a always a good idea to check for damage.
Page 463: Power Steering
STARTING AND OPERATING 461 • Check for accumulations of plants or brush. These • If you experience unusual vibration after driving in things could be a fire hazard. They might hide damage mud, slush or similar conditions, check the wheels for to fuel lines, brake hoses, axle pinion seals, and impacted material.
Page 464 462 STARTING AND OPERATING occurred, which caused an over temperature condition in CAUTION! the power steering system. You will lose power steering assistance momentarily until the over temperature con- Extreme steering maneuvers may cause the electri- dition no longer exists. Once driving conditions are safe, cally driven pump to reduce or stop power steering then pull over and let vehicle idle for a few moments assistance in order to prevent damage to the system.
Page 465: L Engine
STARTING AND OPERATING 463 • Upon initial start-up in cold weather, the power steer- 5.7L Engine The standard power steering system will give you good ing pump may make noise for a short amount of time. vehicle response and increased ease of maneuverability This is due to the cold, thick fluid in the steering in tight spaces.
Page 466: Power Steering Fluid Check
464 STARTING AND OPERATING Power Steering Fluid Check WARNING! Checking the power steering fluid level at a defined service interval is not required. The fluid should only be Fluid level should be checked on a level surface and checked if a leak is suspected, abnormal noises are with the engine off to prevent injury from moving apparent, and/or the system is not functioning as antici- parts and to ensure accurate fluid level reading.
Page 467: Multi-Displacement System (Mds) (If Equipped) - 5.7L Engine Only
STARTING AND OPERATING 465 MULTI-DISPLACEMENT SYSTEM (MDS) (IF EQUIPPED) — 5.7L ENGINE ONLY This feature offers improved fuel economy by shutting off four of the engine’s eight cylinders during light load and cruise conditions. The system is automatic with no driver inputs or additional driving skills required.
Page 468 466 STARTING AND OPERATING NOTE: WARNING! • When the parking brake is applied and the transmis- • Never use the PARK position as a substitute for sion is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound the parking brake.
Page 469: Electronic Brake Control System
STARTING AND OPERATING 467 WARNING! (Continued) CAUTION! • Do not leave the key fob in or near the vehicle, and If the “Brake Warning Light” remains on with the do not leave Keyless Enter-N-Go in the ACC or parking brake released, a brake system malfunction ON/RUN mode.
Page 470: Anti-Lock Brake System (Abs)
468 STARTING AND OPERATING Anti-Lock Brake System (ABS) Traction Control System (TCS) This system aids the driver in maintaining vehicle control This system monitors the amount of wheel spin of each of under adverse braking conditions. The system controls the driven wheels. If wheel spin is detected, brake hydraulic brake pressure to prevent wheel lock-up and pressure is applied to the slipping wheel(s) and engine help avoid skidding on slippery surfaces during braking.
Page 471: Brake Assist System (Bas)
STARTING AND OPERATING 469 Brake Assist System (BAS) WARNING! The BAS is designed to optimize the vehicle’s braking capability during emergency braking maneuvers. The The BAS cannot prevent the natural laws of physics system detects an emergency braking situation by sens- from acting on the vehicle, nor can it increase the ing the rate and amount of brake application and then traction afforded by prevailing road conditions.
Page 472: Electronic Roll Mitigation (Erm)
470 STARTING AND OPERATING Electronic Roll Mitigation (ERM) WARNING! This system anticipates the potential for wheel lift by monitoring the driver’s steering wheel input and the Many factors, such as vehicle loading, road condi- speed of the vehicle. When ERM determines that the rate tions and driving conditions, influence the chance of change of the steering wheel angle and vehicle speed that wheel lift or rollover may occur.
Page 473 STARTING AND OPERATING 471 counteracting the oversteer or understeer condition. En- flash during acceleration, ease up on the accelerator and gine power may also be reduced to help the vehicle apply as little throttle as possible. Be sure to adapt your maintain the desired path.
Page 474 472 STARTING AND OPERATING The ESC system has two available operating modes in Partial Off AWD AUTO range and two-wheel drive vehicles, and This mode is entered by momentarily pressing the “ESC one operating mode in AWD LOW range. OFF” switch. When in “Partial Off” mode, the TCS portion of ESC, except for the BLD feature described in AUTO Range (All-Wheel Drive Models) Or the TCS section, has been disabled and the “ESC Off...
Page 475 STARTING AND OPERATING 473 Off” mode is overcome, turn ESC back on by momen- tarily pressing the “ESC OFF” switch. This may be done while the vehicle is in motion. WARNING! • When in “Partial Off” mode, the TCS functionality of ESC, (except for the limited slip feature de- scribed in the TCS section), has been disabled and the “ESC Off Indicator Light”...
Page 476: Trailer Sway Control (Tsc)
474 STARTING AND OPERATING AWD Low Range (LOW) and Operating” for further information. When TSC is functioning, the “ESC Malfunction Indicator Light” will Partial Off flash, the engine power may be reduced and you may This is the normal operating mode for ESC in AWD LOW feel the brakes being applied to individual wheels to range.
Page 477 STARTING AND OPERATING 475 brake pedal. If the driver does not apply the throttle HSA will work in REVERSE and all forward gears when during this short period of time, the system will release the activation criteria have been met. The system will not brake pressure and the vehicle will roll down the hill.
Page 478 476 STARTING AND OPERATING WARNING! (Continued) HSA will provide assistance when starting on a grade • HSA is not a parking brake. Always apply the when pulling a trailer. parking brake fully when leaving your vehicle. Also, be certain to leave the transmission in PARK. WARNING! Failure to follow these warnings may cause the •...
Page 479: Ready Alert Braking
STARTING AND OPERATING 477 Ready Alert Braking ESC Malfunction Indicator Light And ESC OFF Ready Alert Braking may reduce the time required to Indicator Light reach full braking during emergency braking situations. The “ESC Malfunction Indicator Light” in the It anticipates when an emergency braking situation may instrument cluster will come on when the occur by monitoring how fast the throttle is released by ignition switch is turned to the ON position.
Page 480: Tire Safety Information
478 STARTING AND OPERATING The “ESC Malfunction Indicator Light” (located in the TIRE SAFETY INFORMATION instrument cluster) starts to flash as soon as the tires lose Tire Markings traction and the ESC system becomes active. The “ESC Malfunction Indicator Light” also flashes when TCS is active.
Page 481 STARTING AND OPERATING 479 • Temporary spare tires are spares designed for tempo- NOTE: • P (Passenger) - Metric tire sizing is based on U.S. rary emergency use only. Temporary high pressure design standards. P-Metric tires have the letter “P” compact spare tires have the letter “T”...
Page 482 480 STARTING AND OPERATING Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 483 STARTING AND OPERATING 481 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 484: Tire Identification Number (Tin)
482 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 485: Tire Terminology And Definitions
STARTING AND OPERATING 483 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 486: Tire Loading And Tire Pressure
484 STARTING AND OPERATING Tire Loading And Tire Pressure Tire And Loading Information Placard Tire And Loading Information Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door.
Page 487 STARTING AND OPERATING 485 axles must not be exceeded. For further information on This placard tells you important information about GAWRs, vehicle loading, and trailer towing, refer to the: “Vehicle Loading” in this section. 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of...
Page 488 486 STARTING AND OPERATING 3. Subtract the combined weight of the driver and pas- NOTE: • The following table shows examples on how to calcu- sengers from XXX lbs or XXX kg. late total load, cargo/luggage, and towing capacities 4. The resulting figure equals the available amount of of your vehicle with varying seating configurations cargo and luggage load capacity.
Page 489 STARTING AND OPERATING 487...
Page 490: Tires - General Information
488 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 491: Tire Inflation Pressures
STARTING AND OPERATING 489 stability of the vehicle and can produce a feeling of WARNING! (Continued) sluggish response or over responsiveness in the steering. • Unequal tire pressures from one side of the ve- Unequal tire pressures can cause erratic and unpredict- hicle to the other can cause the vehicle to drift to able steering response.
Page 492 490 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.
Page 493: Tire Pressures For High Speed Operation
STARTING AND OPERATING 491 Tire Pressures For High Speed Operation Radial-Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 494: Compact Spare Tire - If Equipped
492 STARTING AND OPERATING vehicle. If your vehicle has this option refer to an Compact Spare Tire – If Equipped authorized tire dealer for the recommended tire rotation The compact spare is for temporary emergency use only. pattern. You can identify if your vehicle is equipped with a compact spare by looking at the spare tire description on If your vehicle is not equipped with an original equip- the Tire and Loading Information Placard located on the...
Page 495: Full Size Spare - If Equipped
STARTING AND OPERATING 493 your original equipment tire, replace (or repair) the WARNING! original equipment tire and reinstall on the vehicle at the first opportunity. Compact spares are for temporary emergency use only. With these spares, do not drive more than Limited-Use Spare –...
Page 496: Tire Spinning
494 STARTING AND OPERATING WARNING! WARNING! Limited-use spares are for emergency use only. In- Fast spinning tires can be dangerous. Forces gener- stallation of this limited-use spare tire affects vehicle ated by excessive wheel speeds may cause tire dam- handling. With this tire, do not drive more than the age or failure.
Page 497: Life Of Tire
STARTING AND OPERATING 495 Life Of Tire The service life of a tire is dependent upon various factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 498 496 STARTING AND OPERATING Replacement Tires It is recommended you contact your original equipment The tires on your new vehicle provide a balance of many or an authorized tire dealer with any questions you may characteristics. They should be inspected regularly for have on tire specifications or capability.
Page 499: Tire Chains (Traction Devices)
STARTING AND OPERATING 497 TIRE CHAINS (TRACTION DEVICES) WARNING! (Continued) Use of traction devices require sufficient tire-to-body • Never use a tire with a smaller load index or clearance. Follow these recommendations to guard capacity than what was originally equipped on against damage.
Page 500: Snow Tires
498 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • Do not drive for prolonged period on dry pave- To avoid damage to your vehicle or tires, observe the ment. following precautions: • Observe the traction device manufacturer’s in- • Because of restricted traction device clearance be- structions on the method of installation, operating tween tires and other suspension components, it is speed, and conditions for use.
Page 501: Tire Rotation Recommendations
STARTING AND OPERATING 499 Snow tires generally have lower speed ratings than what These effects can be reduced by timely rotation of tires. was originally equipped with your vehicle and should The benefits of rotation are especially worthwhile with not be operated at sustained speeds over 75 mph aggressive tread designs such as those on On/Off-Road (120 km/h).
Page 502: Tire Pressure Monitor System (Tpms)
500 STARTING AND OPERATING The suggested rotation method is the “forward-cross” TIRE PRESSURE MONITOR SYSTEM (TPMS) shown in the following diagram. The Tire Pressure Monitoring System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold tire pressure.
Page 503 STARTING AND OPERATING 501 The TPMS will warn the driver of a low tire pressure if For example, your vehicle has a recommended cold the tire pressure falls below the low pressure warning (parked for more than three hours) tire pressure of 33 psi threshold for any reason, including low temperature (227 kPa).
Page 504 502 STARTING AND OPERATING NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance, or to provide warning of a tire failure or condition. equipment tires and wheels. TPMS pressures have been established for the tire size equipped on your •...
Page 505: Base System
STARTING AND OPERATING 503 • Seasonal temperature changes will affect tire pressure, A tire pressure monitoring sensor is located in the spare and the TPMS will monitor the actual tire pressure in wheel, if the vehicle is equipped with a matching full-size the tire.
Page 506 504 STARTING AND OPERATING vehicle may need to be driven for up to 20 minutes above 3. Lots of snow or ice around the wheels or wheel 15 mph (24 km/h) to receive this information. housings. The “Tire Pressure Monitoring Telltale Light” will flash 4.
Page 507: Premium System - If Equipped
STARTING AND OPERATING 505 will turn OFF the “Tire Pressure Monitoring Telltale subsequent ignition switch cycle, a chime will sound, Light” as long as none of the road tires are below the a “SERVICE TPM SYSTEM” message will be displayed low pressure warning threshold.
Page 508 506 STARTING AND OPERATING NOTE: It is particularly important, for you to regularly Tire Pressure Monitoring Low Pressure Warnings check the tire pressure in all of your tires and to maintain The “Tire Pressure Monitoring Telltale Light” will the proper pressure. illuminate in the instrument cluster, and an au- dible chime will be activated, when one or more of The Tire Pressure Monitor System (TPMS) consists of the...
Page 509 STARTING AND OPERATING 507 The system will automatically update, the graphic dis- play of the pressure value(s) will stop “flashing,” and the “Tire Pressure Monitoring Telltale Light” will extinguish once the updated tire pressure(s) have been received. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) to receive this information.
Page 510 508 STARTING AND OPERATING NOTE: Your system can be set to display pressure units message will not be present, and a pressure value will be in PSI, kPa, or BAR. displayed instead of dashes. A system fault can occur by any of the following: 1.
Page 511 STARTING AND OPERATING 509 message is then followed by a graphic display, with Pressure Monitoring Telltale Light” as long as none of pressure values still shown. This indicates the pressure road tires are below the low pressure warning thresh- values are still being received from the TPM Sensors but old.
Page 512: General Information
510 STARTING AND OPERATING For each subsequent ignition switch cycle, a chime will General Information sound, the “Tire Pressure Monitoring Telltale Light” This device complies with part 15 of the FCC rules and will flash on and off for 75 seconds and then remain on RSS 210 of Industry Canada.
Page 513: Fuel Requirements
STARTING AND OPERATING 511 FUEL REQUIREMENTS optimum performance. The use of premium gasoline is not recommended, as it will not provide any benefit over 3.6L Engine – If Equipped regular gasoline in these engines. This engine is designed to meet all emis- sions regulations and provide excellent Light spark knock at low engine speeds is not harmful to fuel economy and performance when us-...
Page 514: Reformulated Gasoline
512 STARTING AND OPERATING Reformulated Gasoline CAUTION! Many areas of the country require the use of cleaner burning gasoline referred to as “Reformulated Gasoline.” DO NOT use gasoline containing Methanol or gaso- Reformulated gasoline contains oxygenates and are spe- line containing more than 10% Ethanol. Use of these cifically blended to reduce vehicle emissions and im- blends may result in starting and driveability prob- prove air quality.
Page 515: Mmt In Gasoline
STARTING AND OPERATING 513 If a Non-FFV vehicle is inadvertently fueled with E-85 MMT In Gasoline fuel, the engine will have some or all of these symptoms: MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane. Gasoline •...
Page 516: Materials Added To Fuel
514 STARTING AND OPERATING Materials Added To Fuel CAUTION! (Continued) All gasoline sold in the United States is required to • An out-of-tune engine or certain fuel or ignition contain effective detergent additives. Use of additional malfunctions can cause the catalytic converter to detergents or other additives is not needed under normal overheat.
Page 517: Carbon Monoxide Warnings
STARTING AND OPERATING 515 Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper WARNING! maintenance. Have the exhaust system inspected Carbon monoxide (CO) in exhaust gases is deadly. every time the vehicle is raised. Have any abnor- Follow the precautions below to prevent carbon mal conditions repaired promptly.
Page 518 516 STARTING AND OPERATING the other sections of this manual for information on CAUTION! features that are common between Flexible Fuel and gasoline-only powered vehicles. Only vehicles with the E-85 fuel filler door label can operate on E-85. E-85 Fuel Cap E-85 Badge...
Page 519: Ethanol Fuel (E-85)
STARTING AND OPERATING 517 Ethanol Fuel (E-85) When you do switch fuel types it is recommended that: E-85 is a mixture of approximately 85% fuel ethanol and • you do not switch when the fuel gauge indicates less 15% unleaded gasoline. than 1/4 full •...
Page 520: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
518 STARTING AND OPERATING • Some additives used in regular gasoline are not fully Starting compatible with E-85 and may form deposits in your The characteristics of E-85 fuel make it unsuitable for use engine. To eliminate driveability issues that may be when ambient temperatures fall below 0°F (-18°C).
Page 521: Replacement Parts
STARTING AND OPERATING 519 Replacement Parts Maintenance Many components in your Flexible Fuel Vehicle (FFV) are CAUTION! designed to be compatible with ethanol. Always be sure that your vehicle is serviced with correct ethanol com- Do not use ethanol mixture greater than 85% in your patible parts.
Page 522 520 STARTING AND OPERATING 1. Press the fuel filler door release switch (located under 2. Open the fuel filler door, and remove the fuel filler the headlamp switch). cap. Fuel Filler Door Release Switch Fuel Filler Cap...
Page 523 STARTING AND OPERATING 521 CAUTION! WARNING! • Damage to the fuel system or emission control • Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the cap (gas cap).
Page 524: Loose Fuel Filler Cap Message
522 STARTING AND OPERATING • Tighten the gas cap about one-quarter turn until you hear one click. This is an indication that the cap is properly tightened. • If the gas cap is not tighten properly, the MIL will come on. Be sure the gas cap is tightened every time the vehicle is refueled.
Page 525: Vehicle Loading
STARTING AND OPERATING 523 in “Understanding Your Instrument Panel” for further Gross Vehicle Weight Rating (GVWR) information. Tighten the fuel filler cap properly and press The GVWR is the total permissible weight of your vehicle the SELECT button to turn off the message. If the including driver, passengers, vehicle, options, trailer problem continues, the message will appear the next time tongue weight, and cargo.
Page 526 524 STARTING AND OPERATING springs, tires, or wheels). Heavier axles or suspension capacity conditions, and with no occupants or cargo components, sometimes specified by purchasers for in- loaded into the vehicle. The front and rear curb weight creased durability, does not necessarily increase the ve- values are determined by weighing your vehicle on a hicle’s GVWR.
Page 527: Trailer Towing
STARTING AND OPERATING 525 until the specified weight limitations are met. Store the TRAILER TOWING heavier items down low and be sure that the weight is In this section you will find safety tips and information distributed equally. Stow all loose items securely before on limits to the type of towing you can reasonably do driving.
Page 528 526 STARTING AND OPERATING exceed the GVWR. Refer to “Vehicle Loading/Vehicle Gross Combination Weight Rating (GCWR) Certification Label” in “Starting and Operating” for The GCWR is the total permissible weight of your vehicle further information. and trailer when weighed in combination. Gross Trailer Weight (GTW) NOTE: The GCWR rating includes a 150 lbs (68 kg) The GTW is the weight of the trailer plus the weight of all...
Page 529 STARTING AND OPERATING 527 Trailer Tongue Weight (TW) Weight-Carrying Hitch The TW is the downward force exerted on the hitch ball A weight-carrying hitch supports the trailer tongue by the trailer. In most cases it should not be less than 10% weight, just as if it were luggage located at a hitch ball or or more than 15% of the trailer load.
Page 530 528 STARTING AND OPERATING trailer stability. A friction/hydraulic sway control mecha- nism and a weight distributing (load equalizing) hitch are recommended for heavier trailer tongue weights (TW) and may be required depending on Vehicle and Trailer configuration/loading to comply with gross axle weight rating (GAWR) requirements.
Page 531 STARTING AND OPERATING 529 With Weight-Distributing Hitch (Correct) Improper Adjustment of Weight-Distributing Hitch (Incorrect)
Page 532: Trailer Hitch Classification
530 STARTING AND OPERATING Trailer Hitch Classification Trailer Hitch Classification Definitions Your vehicle may be factory equipped for safe towing of Class Max. Trailer Hitch Industry trailers weighing over 3,500 lbs (1 587 kg) with the Standards optional Trailer Tow Prep Package. See your authorized Class I - Light Duty 2,000 lbs (907 kg) dealer for package content.
Page 533: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING 531 Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Model Model GCWR (Gross Com- Frontal Area Max. GTW (Gross Max. Trailer bined Wt. Rating) Trailer Wt.) Tongue Wt.
Page 534: Trailer And Tongue Weight
532 STARTING AND OPERATING If the gross trailer weight is 3,500 lbs (1 587 kg) or more, it is mandatory to use a weight-distributing hitch to ensure stable handling of your vehicle. NOTE: Vehicles not factory equipped with trailer tow package are limited to 3,500 lbs (350 lbs tongue weight).
Page 535: Towing Requirements
STARTING AND OPERATING 533 NOTE: Remember that everything put into or on the CAUTION! (Continued) trailer adds to the load on your vehicle. Also, additional • Then, during the first 500 miles (805 km) that a factory-installed options, or authorized dealer-installed trailer is towed, do not drive over 50 mph options, must be considered as part of the total load on (80 km/h) and do not make starts at full throttle.
Page 536 534 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Make certain that the load is secured in the trailer • Vehicles with trailers should not be parked on a and will not shift during travel. When trailering grade. When parking, apply the parking brake on cargo that is not fully secured, dynamic load shifts the tow vehicle.
Page 537 STARTING AND OPERATING 535 Towing Requirements – Tires replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle’s − Do not attempt to tow a trailer while using a compact GVWR and GAWR limits. spare tire. Towing Requirements –...
Page 538 536 STARTING AND OPERATING CAUTION! WARNING! (Continued) • Towing any trailer will increase your stopping If the trailer weighs more than 1,000 lbs (454 kg) distance. When towing, you should allow for ad- loaded, it should have its own brakes and they ditional space between your vehicle and the ve- should be of adequate capacity.
Page 539 STARTING AND OPERATING 537 Four-Pin Connector Seven-Pin Connector 1 — Female Pins 4 — Park 1 — Battery 5 — Ground 2 — Male Pin 5 — Left Stop/Turn 2 — Backup Lamps 6 — Left Stop/Turn 3 — Ground 6 —...
Page 540: Towing Tips
538 STARTING AND OPERATING Towing Tips The transmission fluid and filter should be changed if Before setting out on a trip, practice turning, stopping you REGULARLY tow a trailer for more than 45 minutes and backing the trailer in an area away from heavy of continuous operation.
Page 541: Snow Plow
STARTING AND OPERATING 539 Cooling System SNOW PLOW To reduce potential for engine and transmission over- Snow plows, winches, and other aftermarket equipment heating, take the following actions: should not be added to the front end of your vehicle. The airbag crash sensors may be affected by the change in the −...
Page 542: Recreational Towing (Behind Motorhome, Etc.)
540 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Rear-Wheel Drive All-Wheel Drive Models Ground Models See Instructions • Transmission in PARK Flat Tow NONE NOT ALLOWED • Transfer case in NEUTRAL (N) •...
Page 543: Recreational Towing - Rear-Wheel Drive Models
STARTING AND OPERATING 541 Recreational Towing – Rear-Wheel Drive Models 6. Install a suitable clamping device, designed for tow- DO NOT flat tow this vehicle. Damage to the drivetrain ing, to secure the front wheels in the straight position. will result. CAUTION! Recreational towing (for two-wheel drive models) is allowed ONLY if the rear wheels are OFF the ground.
Page 544: Recreational Towing - All-Wheel Drive Models (Two-Speed Transfer Case)
542 STARTING AND OPERATING CAUTION! CAUTION! • Front or rear wheel lifts should not be used. Towing this vehicle in violation of the above require- ments can cause severe transmission and/or transfer Internal damage to the transmission or transfer case damage. Damage from improper towing is not case will occur if a front or rear wheel lift is used covered under the New Vehicle Limited Warranty.
Page 545 STARTING AND OPERATING 543 Shifting Into NEUTRAL (N) CAUTION! (Continued) Use the following procedure to prepare your vehicle for • Failure to follow these procedures can cause se- recreational towing: vere transmission and/or transfer case damage. Damage from improper towing is not covered WARNING! under the New Vehicle Limited Warranty.
Page 546 544 STARTING AND OPERATING 4. Turn the ignition switch to the ON/RUN position, but CAUTION! do not start the engine. It is necessary to follow these steps to be certain that 5. Press and hold the brake pedal. the transfer case is fully in NEUTRAL (N) before 6.
Page 547 STARTING AND OPERATING 545 11. Release the brake pedal for five seconds and ensure that there is no vehicle movement. 12. Repeat steps 9 and 10 with transmission in DRIVE. 13. Turn OFF the engine. 14. Firmly apply the parking brake. 15.
Page 548 546 STARTING AND OPERATING • A flashing NEUTRAL (N) indicator light indicates that 17. Attach the vehicle to the tow vehicle using a suitable tow bar. shift requirements have not been met. 18. Release the parking brake. Shifting Out Of NEUTRAL (N) Use the following procedure to prepare your vehicle for NOTE: normal usage:...
Page 549 STARTING AND OPERATING 547 NOTE: When shifting out of transfer case NEUTRAL (N), turning the engine OFF may be required to avoid gear clash. 9. Shift transmission into PARK. 10. Release the brake pedal. 11. Disconnect vehicle from the tow vehicle. 12.
Page 550 548 STARTING AND OPERATING • The ignition switch must be in the ON/RUN position NOTE: • Steps 1 through 5 are requirements that must be met for a transfer case shift to take place and for the prior to pressing the transfer case NEUTRAL (N) position indicator lights to be operable.
Page 551: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....551 Road Tire Installation ....566 If Your Engine Overheats .
Page 552 550 WHAT TO DO IN EMERGENCIES Towing A Disabled Vehicle ....574 Rear-Wheel Drive Models ....576 Towing Without The Ignition Key Fob .
Page 553: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 551 HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the switch bank just above the climate controls. potential for overheating by taking the appropriate action. •...
Page 554: Jacking And Tire Changing
552 WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING CAUTION! WARNING! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads HOT • Do not attempt to change a tire on the side of the (H), pull over and stop the vehicle.
Page 555: Jack Location
WHAT TO DO IN EMERGENCIES 553 WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 556: Spare Tire Stowage
554 WHAT TO DO IN EMERGENCIES Rotate the thumb screw on the jack to loosen the assem- the square socket extension to rotate the “spare tire bly and remove the jack from the bracket. drive” nut. The nut is located under a plastic cover at the center-rear of the cargo floor area, just inside the liftgate opening.
Page 557: Spare Tire Removal
WHAT TO DO IN EMERGENCIES 555 CAUTION! Do not use power tools to winch the tire up or down. Impact type tools can damage the winch mechanism. Spare Tire Removal 1. Remove the jack tools from the bag. 2. Raise the rubber mat and remove the plug from storage compartment floor.
Page 558 556 WHAT TO DO IN EMERGENCIES 4. Slide the tire out from under the vehicle and rotate it 5. Spread the retaining tabs on the plastic plate and pull vertically behind the rear bumper. the metal stamping toward you to release it from the plastic plate.
Page 559 WHAT TO DO IN EMERGENCIES 557 6. Slide the metal stamping up the steel extension tube 7. Pinch the three short and two long tubes to remove the and winch cable. Rotate the metal stamping and push it protective plate from the steel spare wheel. through the hole in the plastic plate and wheel.
Page 560: Preparations For Jacking
558 WHAT TO DO IN EMERGENCIES Preparations For Jacking Block the diagonally opposite wheel. 1. Park the vehicle on a firm level surface, away from traffic. WARNING! Do not attempt to change a tire on the side of the NOTE: Passengers should not remain in the vehicle vehicle closest to moving traffic, pull far enough off when the vehicle is being jacked.
Page 561: Jacking Instructions
WHAT TO DO IN EMERGENCIES 559 Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. Carefully follow these tire changing warnings to • Do not get under the vehicle when it is on a jack. help prevent personal injury or damage to your •...
Page 562 560 WHAT TO DO IN EMERGENCIES CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. 1. Loosen (but do not remove) the wheel lug nuts by turning them to the left, one turn, while the wheel is still on the ground.
Page 563 WHAT TO DO IN EMERGENCIES 561 Lift Point Symbol On Sill Molding Front Jacking Location...
Page 564 562 WHAT TO DO IN EMERGENCIES 4. For a rear tire, place the jack in the slot on the rear tie-down bracket, just forward of the rear tire (as indi- cated by the triangular lift point symbol on the sill molding).
Page 565 WHAT TO DO IN EMERGENCIES 563 WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove the lug nuts and wheel. 7.
Page 566 564 WHAT TO DO IN EMERGENCIES 8. Lower the vehicle by turning the jack screw counter- clockwise, and remove the jack and wheel blocks. 9. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for increased leverage.
Page 567 WHAT TO DO IN EMERGENCIES 565 Installing Winch Road Wheel Installed In Spare Location 12. Slide the road wheel on the ground using the protec- NOTE: Double check to ensure the tire is snug against tive plate until it is directly under the winch and between the underbody of the vehicle.
Page 568: Road Tire Installation
566 WHAT TO DO IN EMERGENCIES 15. Have the aluminum road wheel and tire repaired as WARNING! soon as possible and properly secure the spare tire, jack and tool kit. Do not use power tools to winch the tire up or down. Impact-type tools may damage the winch mecha- WARNING! nism.
Page 569: Jump-Starting
WHAT TO DO IN EMERGENCIES 567 JUMP-STARTING WARNING! If your vehicle has a discharged battery it can be jump- started using a set of jumper cables and a battery in To avoid the risk of forcing the vehicle off the jack, another vehicle or by using a portable battery booster do not tighten the lug nuts fully until the vehicle is pack.
Page 570: Preparations For Jump-Start
568 WHAT TO DO IN EMERGENCIES WARNING! Do not attempt jump-starting if the battery is frozen. It could rupture or explode and cause personal injury. Preparations For Jump-Start The battery in your vehicle is located under the passen- ger’s front seat. There are remote locations located under the hood to assist in jump-starting.
Page 571: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 569 3. Remove the protective cover over the remote positive WARNING! (+) battery post. Pull upward on the cover to remove it. • Take care to avoid the radiator cooling fan when- 4. If using another vehicle to jump-start the battery, park ever the hood is raised.
Page 572 570 WHAT TO DO IN EMERGENCIES CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 573: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES 571 7. Disconnect the negative end (-) of the jumper cable CAUTION! from the negative (-) post of the booster battery. Accessories that can be plugged into the vehicle 8. Disconnect the opposite end of the positive (+) jumper power outlets draw power from the vehicle’s battery, cable from the positive (+) post of the booster battery.
Page 574 572 WHAT TO DO IN EMERGENCIES CAUTION! CAUTION! (Continued) • Revving the engine or spinning the wheels too fast Racing the engine or spinning the wheels may lead to may lead to transmission overheating and failure. transmission overheating and failure. Allow the en- It can also damage the tires.
Page 575: Emergency Tow Hooks - If Equipped
WHAT TO DO IN EMERGENCIES 573 EMERGENCY TOW HOOKS — IF EQUIPPED CAUTION! If your vehicle is equipped with tow hooks, there will be one in the rear and two mounted on the front of the Tow hooks are for emergency use only, to rescue a vehicle.
Page 576: Towing A Disabled Vehicle
574 WHAT TO DO IN EMERGENCIES 4. Using a screwdriver or similar tool, carefully remove 6. Using the screwdriver or similar tool, reach into the the shift lever override access cover, located on the opening and press and hold the shift lever override bottom of the cupholder.
Page 577 WHAT TO DO IN EMERGENCIES 575 Towing Condition Wheels OFF RWD MODELS AWD MODELS the Ground See instructions in “Recreational Tow- ing” under “Starting and Operating” If transmission is operable: • Transmission in PARK • Transmission in NEUTRAL Flat Tow NONE •...
Page 578: Rear-Wheel Drive Models
576 WHAT TO DO IN EMERGENCIES If the vehicle’s battery is discharged refer to “Shift Lever Rear-Wheel Drive Models Override” in “What To Do In Emergencies” for instruc- The manufacturer recommends towing your vehicle with tions on shifting the automatic transmission out of the all four wheels OFF the ground using a flatbed.
Page 579: All-Wheel Drive Models
WHAT TO DO IN EMERGENCIES 577 If the transmission is not operable, or the vehicle must be wheels on the ground), IF the transfer case is in NEU- towed faster than 30 mph (48 km/h) or farther than TRAL and the transmission is in PARK. Refer to “Recre- 15 miles (24 km), tow with the rear wheels OFF the ational Towing”...
Page 581: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.6L ... . . 581 Engine Oil Filter ..... 590 Engine Compartment —...
Page 582 580 MAINTAINING YOUR VEHICLE Brake System ..... . . 607 Halogen Headlamps – If Equipped ..627 Front/Rear Axle Fluid .
Page 583: Engine Compartment - 3.6L
MAINTAINING YOUR VEHICLE 581 ENGINE COMPARTMENT — 3.6L 1 — Totally Integrated Power Module (Fuses) 6 — Air Cleaner Filter 2 — Engine Oil Dipstick 7 — Washer Fluid Reservoir 3 — Engine Oil Fill 8 — Coolant Pressure Cap (Radiator) 4 —...
Page 584: Engine Compartment - 5.7L
582 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 5.7L 1 — Totally Integrated Power Module (Fuses) 6 — Washer Fluid Reservoir 2 — Automatic Transmission Dipstick 7 — Engine Oil Dipstick 3 — Engine Oil Fill 8 — Coolant Pressure Cap (Radiator) 4 —...
Page 585: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 583 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 586: Emissions Inspection And Maintenance Programs
584 MAINTAINING YOUR VEHICLE the SELECT button to turn off the message. If the Normally, the OBD II system will be ready. The OBD II problem continues, the message will appear the next time system may not be ready if your vehicle was recently the vehicle is started.
Page 587: Replacement Parts
MAINTAINING YOUR VEHICLE 585 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 588: Dealer Service
586 MAINTAINING YOUR VEHICLE DEALER SERVICE MAINTENANCE PROCEDURES Your authorized dealer has the qualified service person- The pages that follow contain the required maintenance nel, special tools, and equipment to perform all service services determined by the engineers who designed your operations in an expert manner.
Page 589: Engine Oil
MAINTAINING YOUR VEHICLE 587 check the engine oil level is about five minutes after a CAUTION! (Continued) fully warmed engine is shut off, or before starting the • Your vehicle has been built with improved fluids engine after it has sat overnight. that protect the performance and durability of Checking the oil while the vehicle is on level ground will your vehicle and also allow extended maintenance...
Page 590 588 MAINTAINING YOUR VEHICLE Change Engine Oil American Petroleum Institute (API) Engine Oil The oil change indicator system will remind you that it is Identification Symbol time to take your vehicle in for scheduled maintenance. This symbol means that the oil has Refer to “Maintenance Schedule”...
Page 591 MAINTAINING YOUR VEHICLE 589 Engine Oil Viscosity – 3.6L Engine The engine oil filler cap also shows the recommended SAE 5W-30 engine oil is recommended for all operating engine oil viscosity for your vehicle. For information on temperatures. This engine oil improves low temperature engine oil filler cap location, refer to “Engine Compart- starting and vehicle fuel economy.
Page 592: Engine Oil Filter
590 MAINTAINING YOUR VEHICLE Materials Added To Engine Oils Engine Oil Filter Do not add any supplemental materials, other than leak The engine oil filter should be replaced with a new filter detection dyes, to your engine oil. Engine oil is an at every oil change.
Page 593: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 591 Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- The air induction system (air cleaner, hoses, etc) can tenance required. provide a measure of protection in the case of engine backfire.
Page 594 592 MAINTAINING YOUR VEHICLE WARNING! (Continued) CAUTION! • Battery gas is flammable and explosive. Keep • It is essential when replacing the cables on the flame or sparks away from the battery. Do not use battery that the positive cable is attached to the a booster battery or any other booster source with positive post and the negative cable is attached to an output greater than 12 Volts.
Page 595: Air Conditioner Maintenance
MAINTAINING YOUR VEHICLE 593 Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.
Page 596 594 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling The A/C air filter is located in the fresh air inlet behind R-134a Air Conditioning Refrigerant is a hydrofluoro- the glove box. Perform the following procedure to re- carbon (HFC) that is endorsed by the Environmental place the filter: Protection Agency (EPA) and is an ozone-saving product.
Page 597: Body Lubrication
MAINTAINING YOUR VEHICLE 595 CAUTION! The A/C air filter is identified with an arrow to indicate airflow direction through the filter. Failure to properly install the filter will result in the need to replace it more often. 7. Rotate the glove compartment door back into position. Body Lubrication Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate,...
Page 598: Windshield Wiper Blades
596 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. Avoid using the wiper blades to wipe frost or ice from the When performing other underhood services, the hood windshield. Keep the blade rubber out of contact with latch, release mechanism and safety catch should be petroleum products such as engine oil, gasoline, etc.
Page 599 MAINTAINING YOUR VEHICLE 597 3. Grab the bottom of the wiper blade and rotate it forward to unsnap the blade pivot pin from the wiper blade holder. 1 — Wiper Arm 2 — Pivot Cap NOTE: The rear wiper arm cannot be raised fully upward unless the pivot cap is raised first.
Page 600: Adding Washer Fluid
598 MAINTAINING YOUR VEHICLE 4. Install the wiper blade pivot pin into the wiper blade windshield washer solvent only (not radiator antifreeze). holder at the end of the wiper arm, and firmly press the When refilling the washer fluid reservoir, take some wiper blade until it snaps into place.
Page 601: Exhaust System
MAINTAINING YOUR VEHICLE 599 Exhaust System WARNING! The best protection against carbon monoxide entry into • Exhaust gases can injure or kill. They contain the vehicle body is a properly maintained engine exhaust system. carbon monoxide (CO), which is colorless and odorless.
Page 602 600 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 603: Cooling System
MAINTAINING YOUR VEHICLE 601 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in You or others can be badly burned by hot engine motion.
Page 604 602 MAINTAINING YOUR VEHICLE accumulation of bugs, leaves, etc. If dirty, clean by gently Cooling System – Drain, Flush, And Refill spraying water from a garden hose vertically down the If the engine coolant (antifreeze) is dirty and contains a face of the condenser.
Page 605 MAINTAINING YOUR VEHICLE 603 Adding Coolant CAUTION! Your vehicle has been built with an improved engine • Mixing of engine coolant (antifreeze), other than coolant (antifreeze) that allows extended maintenance the specified HOAT engine coolant (antifreeze), intervals. This engine coolant (antifreeze) can be used up may result in engine damage and may decrease to 5 Years or 104,000 miles (169 000 km) before replace- corrosion protection.
Page 606 604 MAINTAINING YOUR VEHICLE • Mix a minimum solution of 50% HOAT engine coolant NOTE: Mixing engine coolant (antifreeze) types will (antifreeze) and distilled water. Use higher concentra- decrease the life of the engine coolant (antifreeze) and tions (not to exceed 70%) if temperatures below -34°F will require more frequent engine coolant (antifreeze) (-37°C) are anticipated.
Page 607 MAINTAINING YOUR VEHICLE 605 rules for your community. To prevent ingestion by ani- WARNING! mals and children, do not store ethylene glycol-based • The warning words DO NOT OPEN HOT on the engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 608 606 MAINTAINING YOUR VEHICLE of this. As long as the engine operating temperature is If an examination of your engine compartment shows no satisfactory, the coolant bottle need only be checked once evidence of radiator or hose leaks, the vehicle may be a month.
Page 609: Brake System
MAINTAINING YOUR VEHICLE 607 • Make sure that the radiator and coolant recovery WARNING! bottle hoses are not kinked or obstructed. Riding the brakes can lead to brake failure and • Keep the front of the radiator clean. If your vehicle is possibly a collision.
Page 610 608 MAINTAINING YOUR VEHICLE With disc brakes, the fluid level can be expected to fall as WARNING! (Continued) the brake linings wear. However, an unexpected drop in • To avoid contamination from foreign matter or fluid level may be caused by a leak and a system check moisture, use only new brake fluid or fluid that should be conducted.
Page 611: Front/Rear Axle Fluid
MAINTAINING YOUR VEHICLE 609 The front axle fill and drain plugs should be tightened to WARNING! (Continued) 22 to 29 ft lbs (30 to 40 N·m). • Do not allow petroleum based fluid to contami- nate the brake fluid. Brake seal components could CAUTION! be damaged, causing partial or complete brake Do not over tighten the plugs as it could damage...
Page 612: Transfer Case
610 MAINTAINING YOUR VEHICLE Adding Fluid CAUTION! Add fluid at the filler hole, until it runs out of the hole, when the vehicle is in a level position. Do not over tighten the plugs as it could damage then and cause them to leak. Drain First remove fill plug, then remove drain plug.
Page 613: Automatic Transmission
MAINTAINING YOUR VEHICLE 611 Automatic Transmission CAUTION! Selection Of Lubricant Using a transmission fluid other than the manufac- It is important that the proper lubricant is used in the turer’s recommended fluid may cause deterioration transmission to assure optimum transmission perfor- in transmission shift quality and/or torque converter mance.
Page 614 612 MAINTAINING YOUR VEHICLE CAUTION! CAUTION! • Using a transmission fluid other than the manu- Do not use chemical flushes in your transmission as the chemicals can damage your transmission compo- facturer’s recommended fluid may cause deterio- nents. Such damage is not covered by the New ration in transmission shift quality and/or torque Vehicle Limited Warranty.
Page 615 MAINTAINING YOUR VEHICLE 613 Fluid Level Check – 5.7L Engine 6. Remove the dipstick again, and note the fluid level on Check the fluid level while the transmission is at normal both sides. The fluid level should be between the “HOT” operating temperature.
Page 616: Appearance Care And Protection From Corrosion
614 MAINTAINING YOUR VEHICLE passable in snow and ice, and those that are sprayed on CAUTION! trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle. Be aware that if the fluid temperature is below 50°F (10°C) it may not register on the dipstick.
Page 617 MAINTAINING YOUR VEHICLE 615 Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR Car Wash or a mild such as steel wool or scouring powder, which will car wash soap, and rinse the panels completely with scratch metal and painted surfaces.
Page 618 616 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is • All wheels and wheel trim, especially aluminum and considered the responsibility of the owner.
Page 619 MAINTAINING YOUR VEHICLE 617 Stain Repel Fabric Cleaning Procedure – If Interior Care Equipped Use MOPAR Total Clean or equivalent to clean fabric Stain Repel seats may be cleaned in the following man- upholstery and carpeting. ner: Interior Trim should be cleaned starting with a damp •...
Page 620 618 MAINTAINING YOUR VEHICLE taken to avoid soaking your leather upholstery with any To minimize the possibility of scratching the lenses and liquid. Please do not use polishes, oils, cleaning fluids, reducing light output, avoid wiping with a dry cloth. To solvents, detergents, or ammonia-based cleaners to clean remove road dirt, wash with a mild soap solution fol- your leather upholstery.
Page 621 MAINTAINING YOUR VEHICLE 619 Cleaning Plastic Instrument Cluster Lenses If the belts need cleaning, use MOPAR Total Clean, a The lenses in front of the instruments in this vehicle are mild soap solution, or lukewarm water. Do not remove molded in clear plastic. When cleaning the lenses, care the belts from the vehicle to wash them.
Page 622: Fuses
620 MAINTAINING YOUR VEHICLE FUSES Totally Integrated Power Module The Totally Integrated Power Module is located in the engine compartment. This center contains cartridge fuses and mini fuses. A description of each fuse and compo- nent may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
Page 623 MAINTAINING YOUR VEHICLE 621 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 30 Amp Trailer Tow 30 Amp Headlamp Wash Pink Pink Relay Contact 25 Amp Driver Door Node 30 Amp Drive Train Control Natural Pink Module 25 Amp Passenger Door Node...
Page 624 622 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Powertrain Control 20 Amp Electronic Limit Slip Blue Module/Powertrain Yellow Differential/Air Control Module Suspension Transmission Range 20 Amp Liftgate Unlock/DRL 60 Amp Radiator Fan Motor Yellow Relay...
Page 625 MAINTAINING YOUR VEHICLE 623 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 10 Amp Heating, Ventilation & 10 Amp Occupant Restraint Air Conditioning (Cli- Controller mate Control System) 15 Amp Stop Lamp 30 Amp Radio/Amplifier Blue Green 25 Amp Automatic...
Page 626 624 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Fuel Pump Motor 20 Amp Backup Lamps Yellow Output/Diesel Lift Yellow Pump (Export Only) 10 Amp Occupant Restraint 10 Amp Driver Door Switch Controller Bank 10 Amp...
Page 627: Vehicle Storage
MAINTAINING YOUR VEHICLE 625 Cavity Cartridge Mini Description CAUTION! (Continued) Fuse Fuse • When replacing a blown fuse, it is important to 10 Amp Antilock Brakes/ use only a fuse having the correct amperage rating. Stability Control The use of a fuse with a rating other than indicated System Module/ may result in a dangerous electrical system over- Stoplamp Switch...
Page 628: Replacement Bulbs
626 MAINTAINING YOUR VEHICLE • Anytime you store your vehicle, or keep it out of Exterior Lights Bulb Type service (i.e. vacation) for two weeks or more, run the Headlamp – High Intensity air conditioning system at idle for about five minutes Discharge (HID) .
Page 629: Bulb Replacement
MAINTAINING YOUR VEHICLE 627 Because of this, you should not attempt to service a WARNING! headlamp bulb yourself. If a headlamp bulb fails, take your vehicle to an authorized dealer for service. A transient high voltage occurs at the bulb sockets of High Intensity Discharge (HID) headlamps when the NOTE: Numbers refer to commercial bulb types that headlamp switch is turned ON.
Page 630: Front Turn Signal
628 MAINTAINING YOUR VEHICLE 3. Disconnect the electrical connector and replace the CAUTION! bulb. Do not touch the new bulb with your fingers. Oil CAUTION! contamination will severely shorten bulb life. If the bulb comes in contact with any oily surface, clean the Do not touch the new bulb with your fingers.
Page 631 MAINTAINING YOUR VEHICLE 629 5. Insert the bulb into the housing until the index tabs are CAUTION! engaged in the slots of the collar. • Do not touch the new bulb with your fingers. Oil 6. Firmly and evenly push the bulb straight into the lamp contamination will severely shorten bulb life.
Page 632: Rear Tail, Stop, Turn Signal, And Backup Lamps
630 MAINTAINING YOUR VEHICLE Rear Tail, Stop, Turn Signal, And Backup Lamps 4. Twist socket counter clockwise and remove from lamp. 1. Raise the liftgate. 5. Pull the bulb to remove it from the socket. 2. Remove the two push-pins from the tail lamp housing. 6.
Page 633: Center High-Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 631 Center High-Mounted Stop Lamp (CHMSL) Rear License Lamp The center high-mounted stop lamp is an LED assembly. 1. Use a screw driver to gently pry against the side of the See your authorized dealer for replacement. snap tab to remove the license lamp lens.
Page 634: Fluid Capacities
632 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 3.6L and 5.7L Engines 24 Gallons 91 Liters Engine Oil with Filter 3.6L Engine (SAE 5W-30, API Certified) 6 Quarts 5.6 Liters 5.7L Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System * 3.6L Engine (MOPAR Engine Coolant/Antifreeze...
Page 635 MAINTAINING YOUR VEHICLE 633 U.S. Metric 3.6L Engine (MOPAR Engine Coolant/Antifreeze 12 Quarts 11.4 Liters 5-Year/100,000 Mile Formula or equivalent) – Front and Rear Heat With Trailer Tow Package 5.7 Liter Engine (MOPAR Engine Coolant/Antifreeze 16 Quarts 15.2 Liters 5-Year/100,000 Mile Formula or equivalent) – Front and Rear Heat Without Trailer Tow Package 5.7 Liter Engine (MOPAR Engine Coolant/Antifreeze 17 Quarts...
Page 636: Fluids, Lubricants, And Genuine Parts
634 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. Engine Oil – 3.6L Engine Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 637: Chassis
MAINTAINING YOUR VEHICLE 635 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Transfer Case – 3.6L Engine Shell Automatic Transmission Fluid 3353 or equivalent. Transfer Case – 5.7L Engine MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product.
Page 639 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....638 Required Maintenance Intervals ..640...
Page 640 638 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE On Non-EVIC equipped vehicles, “Change Oil” will flash The Scheduled Maintenance services listed in this in the instrument cluster odometer and a single chime manual must be done at the times or mileages specified will sound, indicating that an oil change is necessary. to protect your vehicle warranty and ensure the best Based on engine operation conditions, the oil change vehicle performance and reliability.
Page 641 MAINTENANCE SCHEDULES 639 NOTE: referring to the steps described under “Electronic Vehicle • The oil change indicator message will not monitor the Information Center (EVIC)/Oil Change Required” in time since the last oil change. Change your vehicle’s “Understanding Your Instrument Panel” or under oil if it has been six months since your last oil change, “Instrument Cluster Description/Odometer/Trip Odom- even if the oil change indicator message is NOT...
Page 642 640 MAINTENANCE SCHEDULES Once A Month At Each Oil Change • Check tire pressure and look for unusual wear or • Change the engine oil filter. damage. • Inspect the brake hoses and lines. • Inspect the battery and clean and tighten the terminals CAUTION! as required.
Page 643 MAINTENANCE SCHEDULES 641 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 644: Service Schedule
642 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 645 MAINTENANCE SCHEDULES 643 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 646 644 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 64,000 Miles (104,000 km) or 48 Months Maintenance Service 42 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 647 MAINTENANCE SCHEDULES 645 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 648 646 MAINTENANCE SCHEDULES 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). Odometer Reading Date Repair Order #...
Page 649 MAINTENANCE SCHEDULES 647 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 650 648 MAINTENANCE SCHEDULES 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 651 MAINTENANCE SCHEDULES 649 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 652 650 MAINTENANCE SCHEDULES 128,000 Miles (208,000 km) or 96 Months Maintenance Service 136,000 Miles (221,000 km) or Schedule 102 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 653 MAINTENANCE SCHEDULES 651 144,000 Miles (234,000 km) or 108 Months Maintenance Service 152,000 Miles (247,000 km) or Schedule 114 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 654 652 MAINTENANCE SCHEDULES † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 655: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......655 Speech Impaired (TDD/TTY) .
Page 656 654 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Traction Grades ..... 661 Quality Grades ......661 Temperature Grades .
Page 657: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 655 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 658: Chrysler Group Llc Customer Center
656 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (800) 423–6343 •...
Page 659: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 657 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 660: Warranty Information
658 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 661: In Canada
IF YOU NEED CONSUMER ASSISTANCE 659 If NHTSA receives similar complaints, it may open an In Canada investigation, and if it finds that a safety defect exists in If you believe that your vehicle has a safety defect, a group of vehicles, it may order a recall and remedy you should contact the Customer Service Department campaign.
Page 662 660 IF YOU NEED CONSUMER ASSISTANCE • Service Manuals • Owner’s Manuals These comprehensive Service Manuals provide the These Owner’s Manuals have been prepared with the information that students and professional technicians assistance of service and engineering specialists to need in diagnosing/troubleshooting, problem solving, acquaint you with specific Chrysler Group LLC ve- maintaining, servicing, and repairing Chrysler Group hicles.
Page 663 IF YOU NEED CONSUMER ASSISTANCE 661 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 664 662 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 665 INDEX...
Page 666 664 INDEX Adaptive Cruise Control (ACC) (Cruise Control) . . 208 Alarm, Panic ......26 Adding Fuel .
Page 667 INDEX 665 Fluid Level Check ....612,613 Master Cylinder ..... 607 Fluid Type .
Page 668 666 INDEX Cargo Area Features ..... . 279 Clean Air Gasoline ..... . . 512 Cargo Compartment .
Page 669 INDEX 667 Cooling System ......601 Defroster, Windshield ....100,413 Adding Coolant (Antifreeze) .
Page 670 668 INDEX Electric Remote Mirrors ....112 Emission Control System Maintenance ..584 Electrical Outlet, Auxiliary (Power Outlet) ..263 Engine Electronic Brake Control System .
Page 671 INDEX 669 Oil Selection ..... 588,632 Engine Oil ......590 Oil Synthetic .
Page 672 670 INDEX Engine Oil ......587 Materials Added ..... 514 Power Steering .
Page 673 INDEX 671 Speedometer ......304 Heater, Engine Block ..... 429 Tachometer .
Page 674 672 INDEX Instrument Panel and Controls ....297 Keyless Go ......14,326 Instrument Panel Lens Cleaning .
Page 675 INDEX 673 Bulb Replacement ....627 Rear Tail ......630 Cargo .
Page 676 674 INDEX Lower Anchors and Tether for Electric Remote ..... . 112 CHildren (LATCH) ..... 85,87 Exterior Folding .
Page 677 INDEX 675 Odometer ......303 Opener, Garage Door (HomeLink®) ... 250 Trip .
Page 678 676 INDEX Placard, Tire and Loading Information ..484 Programming Transmitters Polishing and Waxing ..... 615 (Remote Keyless Entry) .
Page 679 INDEX 677 Rearview Mirrors ......110 Restraints, Child ......81 Reclining Front Seats .
Page 680 678 INDEX Child Restraint ....81,82,91 Selection of Oil ......588 Extender .
Page 681 INDEX 679 Shoulder Belts ......52 Starting and Operating ....424 Side Airbag .
Page 682 680 INDEX Synthetic Engine Oil ..... . 589 Compact Spare ..... . 492 System, Remote Starting .
Page 683 INDEX 681 Tongue Weight/Trailer Weight ....532 Transfer Case ......610 Tow Hooks, Emergency .
Page 684 682 INDEX Uniform Tire Quality Grades ....661 Warnings and Cautions ..... 8 Universal Consumer Interface (UCI) Connector .
Page 685 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 686 Chrysler Group LLC 12WD01-126-AE-R1 5th Edition Printed in U.S.A.

This manual is also suitable for:

Durango 2012
