Onboard Power LED

An Onboard Power LED is located at LE2
on the motherboard. When this LED is on,
the system is on. Be sure to turn off the
system and unplug the power cord before
removing or installing components. See
the tables at right for more information.

Power Good LED

The Onboard Power Good LED is located
at LE6 on the motherboard. This LED
indicates the status of all onboard power
supply. See the table at right for more
information.
BMC
LEDM1
BIOS
B
LICENSE
LE6
Battery
SP1
BT1
JSD2
PCH
JSD1
JBT1
A
JWD1
JD1
JF1
JL1
JLAN2 JLAN1
LE1
UID
LAN
CTRL
IPMI_LAN
LAN3/4 LAN1/2
X10DRL-LN4
Rev. 1.00
CPU1
CLOSE 1st
2-39
Onboard PWR LED Indicator
LED Color
Off
Green
Onboard PWR Good
LED States
Color/State
Green:
On
USB0/1
VGA
CPU2
OPEN 1st
CLOSE 1st
OPEN 1st
Chapter 2: Installation
LED States
Definition
System Off (PWR cable
not connected)
System PWR Normal
Definition
All Onboard
Power: Ready
A. PWR LED
B . P W R G O O D
LED
JPWR1
