  • Page 1 X10DRi X10DRi-T USER’S MANUAL Revision 1.0c...
  • Page 2 This product, including software and docu- mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Motherboard

    It provides information for the installation and use of the X10DRi/X10DRi-T motherboard. About This Motherboard The Super X10DRi/X10DRi-T motherboard supports dual Intel® E5-2600v3 Se- ries Processors (Socket R3) that offer new Intel Microarchitecture 22nm Process Technology, delivering system performance, power efficiency, and feature sets to address the needs of next-generation computer users.

  • Page 4: Conventions Used In The Manual

    X10DRi/X10DRi-T Motherboard User’s Manual Conventions Used in the Manual Pay special attention to the following symbols for proper system installation: Warning: Important information given to ensure proper system installation or to prevent damage to the components or injury to yourself;...

  • Page 5: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 6: Table Of Contents

    X10DRi/X10DRi-T Motherboard User’s Manual Table of Contents Preface Chapter 1 Overview Overview ......................1-1 Processor and Chipset Overview..............1-11 Special Features ................... 1-12 System Health Monitoring ................1-12 ACPI Features ....................1-13 Power Supply ....................1-13 Advanced Power Management ..............1-14 Chapter 2 Installation Standardized Warning Statements ..............
  • Page 7 Table of Contents NMI Button ....................2-22 Power LED ....................2-22 HDD/UID LED ..................2-23 NIC1/NIC2 LED Indicators ............... 2-23 Overheat (OH)/Fan Fail/PWR Fail/UID LED ..........2-24 Power Fail LED ..................2-24 Reset Button ................... 2-25 Power Button ................... 2-25 Connecting Cables ..................
  • Page 8 X10DRi/X10DRi-T Motherboard User’s Manual Chapter 3 Troubleshooting Troubleshooting Procedures ................3-1 Technical Support Procedures ................ 3-5 Battery Removal and Installation ..............3-6 Frequently Asked Questions ................3-7 Returning Merchandise for Service..............3-8 Chapter 4 BIOS Introduction ...................... 4-1 Starting BIOS Setup Utility ................4-1 How To Change the Configuration Data ............

  • Page 9: Chapter 1 Overview

    Checklist Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard.
  • Page 10 X10DRi/X10DRi-T Motherboard User’s Manual Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB Revision available at the time of publishing of the manual. The motherboard you've received may or may not look exactly the same as the graphics...

  • Page 11: Motherboard Layout

    LAN2 BIOS CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 Note: For the latest CPU/Memory updates, please refer to our website at http://www.supermicro.com/products/motherboard/ for details.
  • Page 12 • Jumpers/LED Indicators not indicated are for testing only. • LAN1/LAN2 ports support Gigabit LAN (GLAN) connections on the X10DRi, and 10G (T) LAN connections on the X10DRi-T. • Use only the correct type of onboard CMOS battery as specified by the manufac-...
  • Page 13 JTPM1 TPM (Trusted Platform Module)/Port 80 Header JUIDB1 UID (Unit Identification) Button LAN1/LAN2 G-bit Ethernet (GLAN) Ports 1/2 (X10DRi) 10G-bit Ethernet (TLAN) Ports 1/2 (X10DRi-T) (IPMI) LAN IPMI_Dedicated LAN support by the Aspeed controller (I-)SATA 0-5 SATA 3.0 Connectors supported by Intel PCH (I-SATA 0-5),...
  • Page 14 X10DRi/X10DRi-T Motherboard User’s Manual (CPU2) Slot4 PCI-Express 3.0 x16 Slot from CPU2 (CPU2)Slot5 PCI-Express 3.0 x8 Slot from CPU2 (CPU1)Slot6 PCI-Express 3.0 x16 Slot from CPU2 (T-)SGPIO1/2/3 Seria_Link General Purpose I/O Headers 1/2/3 (for SATA ports), (T-SGPIO1 for I-SATA0-3, T-SGPIO2 for I-SATA4/5, T-...

  • Page 15: Motherboard Features

    Graphics Graphics Controller via Aspeed 2400 BMC • Network Intel® i350 Gigabit (10/100/1000 Mb/s) Ethernet Controller for LAN 1/LAN 2 ports (X10DRi), • Intel X540 10_Gigabit (T) Ethernet Controller for LAN 1/LAN 2 ports (X10DRi-T), • Aspeed 2400 Base-board Controller (BMC) supports IPMI 2.0...

  • Page 16: Peripheral Devices

    Power-on mode for AC power recovery • Intel Intelligent Power Node Manager 3.0 (Avail- ® able when the Supermicro Power Manager [SPM] is installed and special power supply used. See the note on Page 1-14.) • Management Engine (ME) PC Health PC Health/CPU Monitoring •...
  • Page 17 Note 1: CPU Maximum Thermal Design Power (TDP) is subject to chassis and heatsink cooling restrictions. For proper thermal management, please check the chassis and heatsink specifications for proper CPU TDP sizing. Note 2: For IPMI Configuration Instructions, please refer to the Embedded IPMI Configuration User's Guide available @ http://www.supermicro.com/ support/manuals/.

  • Page 18: System Block Diagram

    X10DRi/X10DRi-T Motherboard User’s Manual #1-8 #2-8 #1-7 #2-7 #1-6 #2-6 #1-5 #2-5 #1-4 #2-4 #1-3 #2-3 #1-2 #2-2 Processor #1-1 Processor #2-1 9.6G DDR-IV DDR-IV 9.6G SLOT 2 #1 #3B #2 #3 PCI-E X16 G3 (LANE REVERSE) SLOT 3 PCI-E X8 G3 (LANE REVERSE)

  • Page 19: Processor And Chipset Overview

    Processor and Chipset Overview Built upon the functionality and capability of the Intel® E5-2600v3 Series proces- sors (Socket R3) and the Intel C612 PCH, the X10DRi/X10DRi-T motherboard provides system performance, power efficiency, and feature sets to address the needs of next-generation computer users.

  • Page 20: Special Features

    X10DRi/X10DRi-T Motherboard User’s Manual Special Features Recovery from AC Power Loss The Basic I/O System (BIOS) provides a setting that determines how the system will respond when AC power is lost and then restored to the system. You can choose for the system to remain powered off (in which case you must press the power switch to turn it back on), or for it to automatically return to the power-on state.

  • Page 21: Acpi Features

    It is even more important for processors that have high CPU clock rates. The X10DRi/X10DRi-T motherboard accommodates 24-pin ATX power supplies. Although most power supplies generally meet the specifications required by the CPU, some are inadequate. In addition, two 12V 8-pin power connections are also required to ensure adequate power supply to the system.

  • Page 22: Advanced Power Management

    Intel Intelligent Power Node Manager (NM) (Available ® when the Supermicro Power Manager [SPM] is Installed) The Intel Intelligent Power Node Manager 3.0 (IPNM) provides your system with ® real-time thermal control and power management for maximum energy efficiency.

  • Page 23: Chapter 2 Installation

    The following statements are industry-standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assis- tance. Only certified technicians should attempt to install or configure components.
  • Page 24 X10DRi/X10DRi-T Motherboard User’s Manual Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. ¡Advertencia! Existe peligro de explosión si la batería se reemplaza de manera incorrecta.

  • Page 25: Product Disposal

    Chapter 2: Installation Product Disposal Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. 製品の廃棄 この製品を廃棄処分する場合、 国の関係する全ての法律 ・ 条例に従い処理する必要が あります。 警告 本产品的废弃处理应根据所有国家的法律和规章进行。 警告 本產品的廢棄處理應根據所有國家的法律和規章進行。 Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.

  • Page 26: Static-Sensitive Devices

    X10DRi/X10DRi-T Motherboard User’s Manual ‫القىانين واللىائح الىطنية‬ ‫جميع‬ ‫وفقا ل‬ ‫ينبغي التعامل معه‬ ‫هذا المنتج‬ ‫من‬ ‫التخلص النهائي‬ ‫عند‬ 경고! 이 제품은 해당 국가의 관련 법규 및 규정에 따라 폐기되어야 합니다. Waarschuwing De uiteindelijke verwijdering van dit product dient te geschieden in overeenstemming met alle nationale wetten en reglementen.

  • Page 27: Motherboard Installation

    USB0/1 (2.0) COM1 JUIDB1 LAN CTRL Fan5 LEDM1 IPMI_LAN LAN2 LAN1 BIOS CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 Caution: 1) To avoid damaging the motherboard and its components, please do not use a force greater than 8 lb/inch on each mounting screw during motherboard installation.

  • Page 28: Installing The Motherboard

    X10DRi/X10DRi-T Motherboard User’s Manual Installing the Motherboard Note: Always connect the power cord last, and always remove it before adding, removing or changing any hardware components. 1. Install the I/O shield into the chassis. 2. Locate the mounting holes on the motherboard.

  • Page 29: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the LGA2011 Processor 1. There are two load levers on the LGA2011 socket. To open the socket cover, first press and release the load lever labeled 'Open 1st'.
  • Page 30 X10DRi/X10DRi-T Motherboard User’s Manual 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position. Pull lever away from Press down on Load the socket Lever 'Close 1st' 3.
  • Page 31 Chapter 2: Installation 4. Use your thumb and the index finger to loosen the lever and open the load plate. 5. Using your thumb and index finger, hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys. Socket Keys CPU Keys 6.
  • Page 32 X10DRi/X10DRi-T Motherboard User’s Manual 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. Gently close Push down and lock the the load plate. lever labelled 'Close 1st'.

  • Page 33: Installing A Passive Cpu Heatsink

    Chapter 2: Installation Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the re- quired amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard and the Heatsink Bracket underneath.

  • Page 34: Removing The Heatsink

    X10DRi/X10DRi-T Motherboard User’s Manual Removing the Heatsink Warning: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket.

  • Page 35: Installing And Removing The Memory Modules

    Chapter 2: Installation Installing and Removing the Memory Modules Note: Check Supermicro's website for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs 1. Insert the desired number of DIMMs into the memory slots, starting with DIMM A1.
  • Page 36 X10DRi/X10DRi-T Motherboard User’s Manual Memory Support for the X10DRi/X10DRi-T Motherboard The X10DRi/X10DRi-T Motherboard supports up to 1024 GB of Load Reduced (LRDIMM) or 512 GB of Registered (RDIMM) DDR4 (288-pin) ECC 2133/1866/1600 MHz modules in 16 slots. Memory speed support depends upon the CPUs installed in the motherboard.
  • Page 37 DDR4 Memory POR for Haswell-EP Chapter 2: Installation Populating RDIMM/LRDIMM ECC Memory Modules Speed (MT/s) Speed (MT/s); Voltage (V); Voltage (V) Slot Per Channel (SPC) and DIMM Per Channel (DPC) Ranks Per DIMM DIMM and Capacity (GB) 1 Slot Per 2 Slots Per Channel 3 Slots Per Chann Type...

  • Page 38: Control Panel Connectors And I/O Ports

    3. Back Panel USB 2.0 Port 1 4. IPMI_Dedicated LAN 5. Back Panel USB 3.0 Port 6 6. Back Panel USB 3.0 Port 7 7. Gigabit LAN 1 (X10DRi), (10G) TLAN 1 (X10DRi-T) 8. Gigabit LAN 2 (X10DRi), (10G) TLAN 2 (X10DRi-T) 9.

  • Page 39: Serial Ports

    USB0/1 (2.0) JUIDB1 COM1 2. COM2 LAN CTRL Fan5 LEDM1 IPMI_LAN LAN2 LAN1 BIOS 3. VGA CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 2-17...

  • Page 40: Universal Serial Bus (Usb)

    X10DRi/X10DRi-T Motherboard User’s Manual Universal Serial Bus (USB) Back Panel USB (2.0) 0/1 Pin Definitions Two USB 2.0 ports (USB 0/1) and two Pin# Definition Pin# Definition USB 3.0 ports (USB6/7) are located on the I/O backpanel. In addition, USB_PN1 USB_PN0 two internal USB 2.0 headers (J25/...

  • Page 41: Ethernet Ports

    1_GbE LANs TD0- P3V3SB on the X10 DRi, and 10_GbE LANs TD1+ Link 100 LED on the X10DRi-T. In addition, an (Yellow, +3V3SB) IPMI_Dedicated LAN is located above TD1- Link 1000 LED USB 0/1 ports on the backplane. All (Yellow, +3V3SB) these ports accept RJ45 type cables.

  • Page 42: Unit Identifier Switches/Uid Led Indicators

    X10DRi/X10DRi-T Motherboard User’s Manual Unit Identifier Switches/UID LED UID Switch Indicators Pin# Definition A rear Unit Identifier (UID) switch and a Ground rear UID LED (LE1) are located next to the Ground VGA port on the motherboard. The front Button In...

  • Page 43: Front Control Panel

    These connectors are designed specifically for use with Supermicro's server chassis. See the figure below for the descriptions of the various control panel buttons and LED indicators. Refer to the following section for descriptions and pin definitions.

  • Page 44: Front Control Panel Pin Definitions

    X10DRi/X10DRi-T Motherboard User’s Manual Front Control Panel Pin Definitions NMI Button NMI Button Pin Definitions (JF1) The non-maskable interrupt button Pin# Definition header is located on pins 19 and 20 Control of JF1. Refer to the table on the right Ground for pin definitions.

  • Page 45: Hdd/Uid Led

    C. NIC2 LED IPMI_LAN LAN1 LAN2 BIOS Ground CLOSE 1st CPU2 3.3 V OPEN 1st FP PWRLED X10DRi-(T) UID Switch HDD LED Rev. 1.02 T-SGPIO1 NIC1 Link LED NIC1 Activity LED T-SGPIO2 T-SGPIO3 NIC2 Activity LED NIC2 Link LED Battery...

  • Page 46: Overheat (Oh)/Fan Fail/Pwr Fail/Uid Led

    X10DRi/X10DRi-T Motherboard User’s Manual Overheat (OH)/Fan Fail/PWR Fail/ OH/Fan Fail/ PWR Fail/Blue_UID UID LED LED Pin Definitions (JF1) Pin# Definition Connect an LED cable to pins 7 Blue_UID LED and 8 of Front Control Panel to use the Overheat/Fan Fail/Power Fail OH/Fan Fail/Power Fail and UID LED connections.

  • Page 47: Reset Button

    Fan5 LEDM1 IPMI_LAN LAN1 LAN2 BIOS Ground CLOSE 1st CPU2 3.3 V FP PWRLED OPEN 1st X10DRi-(T) UID Switch HDD LED Rev. 1.02 T-SGPIO1 NIC1 Link LED NIC1 Activity LED T-SGPIO2 T-SGPIO3 NIC2 Activity LED NIC2 Link LED Battery OH/Fan Fail/...

  • Page 48: Connecting Cables

    X10DRi/X10DRi-T Motherboard User’s Manual Connecting Cables Power Connectors ATX Power 24-pin Connector Pin Definitions (JPW1) A 24-pin main power supply connector Pin# Definition Pin # Definition (J24), and two 8-pin CPU power connec- +3.3V +3.3V tors (JPWR1/ JPWR2) are located on the -12V (NC) +3.3V...

  • Page 49: Fan Headers

    C. Fan 3 BIOS D. Fan 4 CLOSE 1st E. Fan 5 CPU2 F. Fan 6 G. Fan A OPEN 1st H. Fan B I. Chassis Intrusion X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2...

  • Page 50: Internal Speaker

    JSD1/JSD2 on Ground the motherboard. These connectors, colored Ground in yellow, are used with Supermicro Super- DOMs, which have power-pins built in and do not require separate external power cables. These connectors are also back-compatible with non-Supermicro SATADOMs that require external power.

  • Page 51: Tpm/Port 80 Header

    COM1 JUIDB1 A. TPM/Port 80 Header LAN CTRL B. JOH1 Fan5 LEDM1 IPMI_LAN LAN1 LAN2 BIOS CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 2-29...

  • Page 52: Power Smb (I 2 C) Connector

    X10DRi/X10DRi-T Motherboard User’s Manual Power SMB (I C) Connector PWR SMB Pin Definitions Power System Management Bus (I Pin# Definition Connector (JPI C1) monitors power Clock supply, fan and system temperatures. Data See the table on the right for pin PMBUS_Alert definitions.

  • Page 53: T-Sgpio 1/2/3 Headers

    JUIDB1 B. T-SGPIO2 LAN CTRL Fan5 LEDM1 IPMI_LAN LAN1 LAN2 BIOS C. T-SGPIO3 D. Standby PWR CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 2-31...

  • Page 54: Power Led/Speaker

    X10DRi/X10DRi-T Motherboard User’s Manual Power LED/Speaker PWR LED Connector Pin Definitions Pins 1-3 of JD1 are used for power Pin Setting Definition LED indication, and pins 4-7 are for Pin 1 JD1_PIN1 the speaker. See the tables on the Pin 2 FP_PWR_LED right for pin definitions.

  • Page 55: Jumper Settings

    LAN Enable/Disable LAN Enable Jumper Settings JPL1 enables or disables Gigabit LAN Jumper Setting Definition ports 1/2 on the X10DRi and 10G-LAN Enabled (default) (TLAN) ports 1/2 on the X10DRi-T. See Disabled the table on the right for jumper- settings.

  • Page 56: Cmos Clear

    X10DRi/X10DRi-T Motherboard User’s Manual CMOS Clear JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads to prevent accidental clearing of CMOS. To clear CMOS, use a metal object such as a small screwdriver to touch both pads at the same time to short the connection.

  • Page 57: Vga Enable

    VGA Enabled USB6/7(3.0) USB0/1 (2.0) COM1 JUIDB1 BMC Enabled LAN CTRL Fan5 LEDM1 IPMI_LAN LAN1 LAN2 BIOS CLOSE 1st CPU2 OPEN 1st X10DRi-(T) Rev. 1.02 T-SGPIO1 T-SGPIO2 T-SGPIO3 Battery CLOSE 1st CPU1 Intel PCH OPEN 1st JSD2 JOH1 JSD1 I-SATA0 2-35...

  • Page 58: I 2 C Bus To Pci-Exp. Slots

    X10DRi/X10DRi-T Motherboard User’s Manual C Bus to PCI-Exp. Slots C for PCI-E slots Jumper Settings Use Jumpers JI C1 and JI C2 to connect Jumper Setting Definition the System Management Bus (I C) to Pins 1-2 Enabled PCI-Express slots to improve PCI per-...

  • Page 59: Onboard Led Indicators

    LEDs. The green LED Green Flashing Active indicates activity, while the other 10G-LAN 1/2 Link LED (Left) GLAN 1/2 Link LED (Left) LED State (For X10DRI-T) LED State (For X10DRi) Link LED may be green, amber or LED Color Definition LED Color Definition...

  • Page 60: Onboard Power Led

    X10DRi/X10DRi-T Motherboard User’s Manual Onboard Power LED Onboard PWR LED Indicator LED States An Onboard Power LED is located at LE2 LED Color Definition on the motherboard. When this LED is on, System Off (PWR cable not connected) the system is on. Be sure to turn off the...

  • Page 61: 2-10 Sata Connections

    Parallel ATA. See the table on SATA_RXN the right for pin definitions. SATA_RXP Ground Note: Supermicro SuperDOMs are yellow SATADOM connectors with power pins built in and do not require separate external power cables. These connectors are back-compatible with non-Supermicro SATADOMs that require external power supply.
  • Page 62 X10DRi/X10DRi-T Motherboard User’s Manual Notes 2-40...

  • Page 63: Chapter 3 Troubleshooting

    Chapter 3: Troubleshooting Chapter 3 Troubleshooting Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter. Note: Always disconnect the power cord before adding, changing or installing any hardware components.

  • Page 64: System Boot Failure

    X10DRi/X10DRi-T Motherboard User’s Manual No Video 1. If the power is on, but you have no video, remove all the add-on cards and cables. 2. Use the speaker to determine if any beep codes exist. Refer to Appendix A for details on beep codes.

  • Page 65: Memory Errors

    2. Memory support: Make sure that the memory modules are supported by test- ing the modules using memtest86 or a similar utility. Note: Refer to the product page on our website http:\\www.supermicro. com for memory and CPU support and updates.
  • Page 66 X10DRi/X10DRi-T Motherboard User’s Manual tings in the IPMI to make sure that the CPU and System temperatures are within the normal range. Also check the front panel Overheat LED, and make sure that the Overheat LED is not on. 5. Adequate power supply: Make sure that the power supply provides adequate power to the system.

  • Page 67: Technical Support Procedures

    Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, please note that as a motherboard manufacturer, Supermicro also sells motherboards through its channels, so it is best to first check with your distributor or reseller for troubleshooting services.

  • Page 68: Battery Removal And Installation

    X10DRi/X10DRi-T Motherboard User’s Manual Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Locate the onboard battery as shown below. 3. Using a tool such as a pen or a small screwdriver, push the battery lock out- wards to unlock it.

  • Page 69: Frequently Asked Questions

    Note: The SPI BIOS chip used on this motherboard cannot be removed. Send your motherboard back to our RMA Department at Supermicro for repair. For BIOS Recovery instructions, please refer to the AMI BIOS Recovery Instructions posted at http://www.supermicro.com.

  • Page 70: Returning Merchandise For Service

    X10DRi/X10DRi-T Motherboard User’s Manual Returning Merchandise for Service A receipt or copy of your invoice marked with the date of purchase is required before any warranty service will be rendered. You can obtain service by calling your ven- dor for a Returned Merchandise Authorization (RMA) number. When returning the...

  • Page 71: Chapter 4 Bios

    BIOS Introduction This chapter describes the AMI BIOS setup utility for the X10DRi/X10DRi-T. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS setup utility screens.

  • Page 72: How To Start The Setup Utility

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential dam- ages arising from a BIOS update. If you have to update the BIOS, do not shut down or reset the system while the BIOS is updating.
  • Page 73 Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. Supermicro X10DRi Version: This item displays the version of the BIOS ROM used in the system. Build Date: This item displays the date when the version of the BIOS ROM used in the system was built.

  • Page 74: Advanced Setup Configurations

    X10DRi/X10DRi-T User’s Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.

  • Page 75: Power Configuration

    Chapter 4: AMI BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...

  • Page 76: Cpu Configuration

    X10DRi/X10DRi-T User’s Manual CPU Configuration  This submenu displays the information of the CPU as detected by the BIOS. It also allows the user to configuration CPU settings. Socket 1 CPU Information/Socket 2 CPU Information This submenu displays the following information regarding the CPU installed in Socket 1 and (or) Socket 2 as detected by the BIOS.
  • Page 77 Chapter 4: AMI BIOS Execute-Disable Bit Capability (Available if supported by the OS & the CPU) Select Enabled to enable the Execute-Disable Bit which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from flooding illegal codes to overwhelm the processor or damage the system during an attack.

  • Page 78: Chipset Configuration

    X10DRi/X10DRi-T User’s Manual Intel® Virtualization Technology (Available when supported by the CPU) Select Enabled to support Intel Virtualization Technology, which will allow one platform to run multiple operating systems and applications in independent parti- tions, creating multiple "virtual" systems in one physical computer. The options are Enable and Disable.
  • Page 79 Chapter 4: AMI BIOS Socket 0 PcieD00F0 - Port 0/DMI Link Speed This item configures the link speed of a PCI-E port specified by the user. The options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5.0 GT/s), and Auto.
  • Page 80 X10DRi/X10DRi-T User’s Manual Socket 0 PcieD01F0 - Port 1A/Socket 0 PcieD02F0 - Port 2A/Socket 0 PcieD03F0 - Port 3A/Socket 0 PcieD03F2 - Port 3C PCIe Port Select Enable to enable a PCI-E port specified by the user. Select Disable to de-activate a PCI-E port specified by the user.
  • Page 81 Chapter 4: AMI BIOS Fatal Err (Error) Over Select Enable to force fatal error propagation to the IIO core error logic for the port specified by the user. The options are Disable and Enable. Non-Fatal Err (Error) Over Select Enable to force non-fatal error propagation to the IIO core error logic for the port specified by the user.
  • Page 82 X10DRi/X10DRi-T User’s Manual Gen3 UP Tx Preset This feature allows the user to select the preset setting for an upstream com- ponent transmitter. The options are Auto, P0 (-6.0/0.0 dB), P1 (-3.5/0.0 dB), P2 (-4.5/0.0 dB), P3 (-2.5/0.0 dB), P4 (0.0/0.0 dB), P5 (0.0/-2.0 dB), P6 (0.0/-2.5 dB), P7 (-6.0/-3.5 dB), P8 (-3.5/-3.5 dB), and P9 (0.0/-3.5 dB).
  • Page 83 Chapter 4: AMI BIOS PCI-E Port Link Use this feature to disable the physical link connected to a PCI-E port specified by a user so that no training will take place on the component-level while the PCI-E configuration commands are still in full force. The options are Enable and Disable.
  • Page 84 X10DRi/X10DRi-T User’s Manual L0s Support When this item is set to Disable, IIO will not put its transmitter in the L0s state. The default setting is Disable. PM ACPI Mode Select Enable to generate an _HPGPE message on a PM ACPI event. Select Disable to generate an MSI message.
  • Page 85 Chapter 4: AMI BIOS IOAT Configuration Enable I/OAT Select Enable to enable Intel I/OAT (I/O Acceleration Technology), which signifi- cantly reduces CPU overhead by leveraging CPU architectural improvements and freeing the system resources for other tasks. The options are Enable and Disable.

  • Page 86: Memory Configuration

    X10DRi/X10DRi-T User’s Manual • Current QPI Link Frequency: This item displays the frequency of the QPI Link. • QPI Global MMIO Low Base / Limit • QPI Global MMIO High Base / Limit • QPI PCI-E Configuration Base / Siz (Size) Link Frequency Select Use this feature to select the desired QPI link frequency.

  • Page 87: Dimm Information

    Chapter 4: AMI BIOS Data Scrambling Select Enabled to enable data scrambling to enhance system performance and data integrity. The options are Auto, Disabled and Enabled. DRAM RAPL (Running Average Power Limit) Baseline Use this feature to set the run-time power-limit baseline for DRAM modules. The options are Disable, DRAM RAPL Mode 0, and DRAM RAPL Mode 1.

  • Page 88: South Bridge Configuration

    X10DRi/X10DRi-T User’s Manual Memory Rank Sparing Select Enable to enable memory-sparing support for memory ranks to improve memory performance. The options are Disabled and Enabled. Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source).
  • Page 89 Chapter 4: AMI BIOS XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Ex- tensible Host Controller Interface) hand-off. The XHCI ownership change should be claimed by the XHCI driver. The settings are Enabled and Disabled. EHCI Hand-Off This item is for operating systems that do not support Enhanced Host Controller Interface (EHCI) hand-off.

  • Page 90: Sata Configuration

    X10DRi/X10DRi-T User’s Manual SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chip and displays the fol- lowing items: SATA Controller This item enables or disables the onboard SATA controller supported by the Intel PCH chip.
  • Page 91 Chapter 4: AMI BIOS Port 0 ~ Port 5 SATA Device Type Use this item to specify if the SATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.

  • Page 92: Ssata Configuration

    X10DRi/X10DRi-T User’s Manual Port 0 ~ Port 5 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system. The options are Enabled and Disabled.
  • Page 93 Chapter 4: AMI BIOS • Software Preserve Support sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a sSATA disk drive installed on this port without shutting down the system.
  • Page 94 X10DRi/X10DRi-T User’s Manual sSATA RAID Option ROM/UEFI Driver Select EFI to load the EFI driver for system boot. Select Legacy to load a legacy driver for system boot. The options are Disabled, EFI, and Legacy. sSATA Port 0~ Port 3 This item displays the information detected on the installed sSATA drives on the particular sSATA port.
  • Page 95 Chapter 4: AMI BIOS • ME Firmware Status #2 • Current State • Error Code Altitude This feature indicates the altitude of the platform this machine is located above the sea level. The value is shown in meters. If the value is unknown, enter the number "80000000".
  • Page 96 X10DRi/X10DRi-T User’s Manual SR-IOV (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support. The options are Enabled and Disabled. Maximum Payload Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance.

  • Page 97: Super Io Configuration

    Chapter 4: AMI BIOS VGA Priority Use this item to select the graphics device to be used as the primary video display for system boot. The options are Onboard and Offboard. Onboard LAN Option ROM Type Select Enabled to enable Option ROM support to boot the computer using a device installed on the slot specified by the user.

  • Page 98: Serial Port Console Redirection

    X10DRi/X10DRi-T User’s Manual Device Mode Use this feature to configure SUART clock source settings. The options are 24MHz/13 and 24MHz. Serial Port 2 Attribute Select SOL to use COM Port 2 as a Serial_Over_LAN (SOL) port for console redi- rection. The options are COM and SOL.
  • Page 99 Chapter 4: AMI BIOS Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 100 X10DRi/X10DRi-T User’s Manual Redirection After BIOS Post Use this feature to enable or disable legacy Console Redirection after BIOS POST. When the option-Bootloader is selected, legacy Console Redirection is disabled before booting the OS. When the option- Always Enable is selected, legacy Console Redirection remains enabled upon OS bootup.
  • Page 101 Chapter 4: AMI BIOS the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark and Space. Stop Bits A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard serial data communication.
  • Page 102 X10DRi/X10DRi-T User’s Manual Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to configure Console Redirection settings to sup- port Out-of-Band Serial Port management. Console Redirection Select Enabled to use a COM port selected by the user for EMS Console Redi- rection.

  • Page 103: Acpi Settings

    Chapter 4: AMI BIOS ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 104: Iscsi Configuration

    X10DRi/X10DRi-T User’s Manual operation. The options are None, Enable Take Ownership, Disable Take Owner- ship, and TPM Clear. Note: Your system will reboot to carry out a pending TPM operation. Current Status Information This item displays the status of the TPM support on this motherboard: •...

  • Page 105: Event Logs

    Chapter 4: AMI BIOS Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 106: View Smbios Event Log

    X10DRi/X10DRi-T User’s Manual Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup. The options are No and Yes. When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full.

  • Page 107: Ipmi

    Chapter 4: AMI BIOS IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...

  • Page 108: Bmc Network Configuration

    X10DRi/X10DRi-T User’s Manual When SEL is Full This feature allows the user to determine what the BIOS should do when the sys- tem event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately.

  • Page 109: Security Settings

    Chapter 4: AMI BIOS Security Settings This menu allows the user to configure the following security settings for the system. Administrator Password Use this feature to set the administrator password which is required before entering the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.

  • Page 110: Boot Settings

    X10DRi/X10DRi-T User’s Manual Boot Settings Use this feature to configure Boot Settings: Boot Mode Select Use this item to select the type of device to be used for system boot. The options are Legacy, UEFI, and Dual. The default setting is Dual.
  • Page 111 Chapter 4: AMI BIOS • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 • Dual Boot Order #14 • Dual Boot Order #15  Delete Boot Option Use this item to select a boot device to delete from the boot priority list. Delete Boot Option Select the target boot device to delete.

  • Page 112: Save & Exit

    X10DRi/X10DRi-T User’s Manual Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 113 Chapter 4: AMI BIOS Restore Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter>. These are manufacture default settings designed for maximum system performance but not for maximum stability. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>.
  • Page 114 X10DRi/X10DRi-T User’s Manual Notes 4-44...

  • Page 115: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 116 X10DRi/X10DRi-T Motherboard User’s Manual Notes...

  • Page 117: Appendix B Software Installation Instructions

    Appendix B Software Installation Instructions B-1 Installing Software Programs The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 118: B-2 Installing Superdoctor5

    X10DRi/X10DRi-T Motherboard User’s Manual B-2 Installing SuperDoctor5 The Supermicro SuperDoctor® 5 is a hardware monitoring program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 119: Appendix C Uefi Bios Recovery Instructions

    Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you need to update the BIOS, do not shut down or reset the system while the BIOS is updating to avoid possible boot failure.
  • Page 120 Root "\" Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM" for BIOS recovery use.
  • Page 121 Appendix C: UEFI BIOS Recovery 4. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start with BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 5.
  • Page 122 X10DRi/X10DRi-T Motherboard User’s Manual 6. After the process of BIOS recovery is completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive. 8. When a DOS prompt appears, enter FLASH.BAT BIOSname.### at the prompt.
  • Page 123 (Disclaimer Continued) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.

This manual is also suitable for:

X10dri-t

Table of Contents

Save PDF
