Summary of Contents for SSV Works GN-3KRC
- Page 1 GN-3KRC Polaris General with Ride Command Kicker 3 Speaker Audio Kit Disassembly, Wire and Amplifier Plate Installation Glovebox Subwoofer Installation Kick Panel Speakers Installation...
-
Page 2: Tools Needed For Installation
All SSV Works enclosures are covered by a limited lifetime warranty against defects in instructions completely before material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty installation to avoid possible injury, or against defects in material or workmanship. All Kicker Speakers are covered by a limited 1 damage to the accessory or vehicle. - Page 3 PANELS AND DASH DISASSEMBLY A. Remove all seats by releasing the handle behind each seat, B. Disconect the negative battery cable from the battery. push forward slightly while lifting up. C. Remove hood by turning locking pins and lifting up. D.
- Page 4 PANELS AND DASH DISASSEMBLY G. Use a panel removal tool to remove the center dash panel. Disconnect all harness connectors attached to the center dash panel. H1. Using a panel removal tool, remove the two (2) push pins holding lower center panel cover located on the passenger side. Slide cover off. I1.
- Page 5 RUNNING AMP POWER CABLE & SPEAKER WIRE J. Unplug the rubber grommet located on the firewall. K. Unwrap the tape from rubber grommet and feed the power/ground wire for the Amp through the grommet as well as the rear speaker harness H1151 (rear speaker harness to be used for rear speaker expansion pods).
- Page 6 AMP PLATE INSTALLATION OUTSIDE DASH VIEW INSIDE DASH VIEW Q. Remove the two (2) T30 torx screws and clips located at the bottom of the dash panel near the center console L. Unclip harness that runs along top cross bar of dash (holes will T.
- Page 7 All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 year installation to avoid possible injury, or warranty against defects in material or workmanship. All Kicker Speakers are covered damage to the accessory or vehicle.
- Page 8 A. For this step you will need the sub enclosure mounting plate as well as two (2) M5 B. Using a T25 torx driver and 8mm socket, tighten the screws, two (2) 8mm nuts and four (4) M5 washers. Place the mounting plate on the screws to secure the plate.
- Page 9 G. Using a ¼ drill bit, drill holes for mounting of the enclosure. H. Place enclosure in location for mounting. I. Line up the holes from the enclosure to the mounting plate and J. Use three (3) M6 screws & washers to hand tighten the use three (3) M6 screws and washers to mount the enclosure.
- Page 11 LEFT SIDE DRILL TEMPLATE 170-GN-UD10 DRILL TEMPLATE...
- Page 13 RIGHT SIDE- DRILL TEMPLATE 170-GN-UD10 DRILL TEMPLATE...
- Page 15 Please read and understand these All SSV Works enclosures are covered by a limited lifetime warranty against defects instructions completely before in material or workmanship. All SSV Works Electronics are covered by a limited 1 WARRANTY INFORMATION: installation to avoid possible injury, or Please read and understand these year warranty against defects in material or workmanship.
- Page 16 1” factory harness. Connect the 300.4 “Rear Input” to the Ride Command “Audio Amp 2” factory harness (for use with additional SSV Works rear speakers - sold seperately). Connect the 500.1 input for the subwoofer to “Audio Amp 3” factory harness.
- Page 17 40A fuse, screw the 2 screws back in and reattach the fuse holder top. from the drive shaft. THIS CONCLUDES THE INSTALLATION PROCESS. REPLACE THE FACTORY PANELS AND SEATS. QUESTIONS? PLEASE CONTACT SSV WORKS AT 818-991-1778 OR EMAIL SUPPORT@SSVWORKS.COM © 2019 SSV Works, Oxnard, CA 93030 GN-3KRC Rev. A 3-21-19...
- Page 18 TRY SSV WORKS CAGE MOUNT 6.5” SPEAKER PODS! SSV Works custom molded Cage Mount Pods are designed for 6.5” speakers and can be used when you need more sound in your Side by Side. Unlike wakeboard towers, these mini pods are designed to provide sound to the passengers without blocking visibility.
