Quantum DX3000 Quick Start Manual

DX3000 and DX5000
Quick Start Guide

TABLE OF CONTENTS

Introduction .......................................1
Notational Conventions .................1
Choosing a Location ..........................2
Rack Space Requirements...............2
Environmental Conditions .............2
Preparing for the Installation ...........2
Providing Necessary Tools ..............2
Taking ESD Precautions ..................2
Unpacking the DX3000/DX5000.........2
Installing the DX3000/DX5000 System3
Locating the Mounting Position ....3
Installing the DX3000/DX5000
Chassis .............................................4
Cabling the DX3000/DX5000..............7
Cabling a DX3000 System...............7
Cabling a DX5000 System...............8
Initial Configuration ..........................8

Introduction

This quick start guides provides basic installation and configuration instructions for
both the DX3000 and DX5000 systems (see
Quantum DX3000 and DX5000 User's Guide
the
provided with your DX3000 or DX5000 system.

Notational Conventions

This instruction uses the following conventions:
N : Notes emphasize important information related to the main topic.
OTE
C :
Cautions indicate potential hazards to equipment and are included
AUTION
to prevent damage to equipment.
W : Warnings indicate potential hazards to personal safety and are
ARNING
included to prevent injury.
Figure 1 PX3000 and DX5000
figure 1). For more information, see
on the documentation CD
