Quantum dxi6701 Planning Manual

DXi6701 and DXi6702 Site

Product Overview

The DXi6701 and DXi6702 disk backup and replication appliances use
Quantum's data deduplication technology to expand the amount of
backup data users can retain on fast-recovery RAID systems by 10 to 50
times. The result is a cost-effective way for IT departments to store backup
data on disk for months instead of days, providing high speed, reliable
restores, increasing available data recovery points, and reducing media
management.
For disaster recovery in distributed environments, the DXi6701 and
DXi6702 systems make automated WAN replication practical by
dramatically reducing the bandwidth required to move backup data
securely between sites.
DXi6701 and DXi6702 solutions are integrated systems that are easy to
install and use with all leading backup applications. They provide best-in-
class performance with flexible, easy-to-use interface options including
NAS, OST, virtual library, or mixed presentations, as well as Ethernet and
Fibre Channel connectivity. DXi6701 and DXi6702 appliances are part of a
comprehensive set of backup solutions, serviced and supported by
Quantum, the leading global specialist in backup, recovery, and archive.
Note: This guide is for DXi6701 and DXi6702 with DXi 2.2 Software.
Planning Guide
DXi6701 or DXi6702
Node
DXi6701 or DXi6702
Expansion Module
DXi6701 and DXi6702
Contents
Product Overview................................... 1
Included With Your DXi6701 and
DXi6702.................................................. 2
Licenses .............................................. 2
DXi Accent.......................................... 3
Installation ............................................. 3
Rack Compatibility ............................. 3
DXi6701 and DXi6702 Setup and
Configuration..................................... 3
Network Configuration...................... 4
Firewall Ports ..................................... 4
Installation and Integration Services . 6
Service .................................................... 7
DXi6701 and DXi6702 Warranty ........ 7
Service Package Upgrades ................. 7
Email Reports ..................................... 8
StorageCare™ Guardian..................... 8
DXi Advanced Reporting.................... 8
DXi6701 and DXi6702 Configurations... 9
DXi6701 and DXi6702 Shipping
Information .......................................... 10
DXi6701 and DXi6702 Specifications... 10
Physical Characteristics.................... 12
Environmental Specifications .......... 17
www.quantum.com
