Operating guide
Instruction
Table of Contents
1. General information
2. Design/features
Pos. Qty. Description
1 1 Housing, main bearing
11, 125, 1 Mounting flange/
211* end flange
121, 181* 1 Port flange
31 1 Swash plate
66 5/7/9 Piston
92 1 Valve plate
91 1 Port plate
61 1 Cylinder barrel
65 1 Retainer plate
64 1 Retainer ball
71 1 Retainer guide
62 1/4 Spring
63 1 Spring guide
142 1 Stop for shaft seal
124, 215* 1 Shaft seal
125 1 Cover/flange for shaft seal
93 5/7/9 Back-up ring
* O-ring (overall)
* Screw (overall)
* Pin (overall)
152 1 Valve cone (flushing valve)
3, 129* 2 Bleeding screw
67 1 Key
* depends on pump size
52 | 180R9264 | AQ115586503043en-000903
Installation, Operation and Maintenance APP 11-13
1. General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
2. Design/features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
3. Appendix 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
This guideline provides information on the
recommended service intervals. The recommen-
dation is based upon good engineering practice
Danfoss APP pumps are designed for long
operation and low maintenance and life cycle
costs.
Provided that the pump has been running
according to the Danfoss specifications, Danfoss
guarantees one year service-free operation,
however, max. 18 months from date of
production. After one year of operation it is
recommended to inspect the pump and replace
worn parts, if any.
Material
Duplex, PEEK
Wetted part: Duplex
Dry part: AISI 316L
Duplex
Super Duplex
Super Duplex and PEEK
Super Duplex
Super Duplex, PEEK
Super Duplex
Super Duplex
Super Duplex
Super Duplex
Duplex
Duplex or PP
PP
Hastelloy and NBR
Super Duplex
PTFE
NBR
AISI 316
AISI 316, Duplex or PEEK
Duplex or PEEK
Duplex
AISI 316
and on experience gained from operation even
under extreme conditions.
The recommendation is for guidance only.
If the Danfoss recommendations concerning
system-design (see our data sheet) are not
followed, the service life of the APP pumps might
be affected.
The recommended service intervals on the
different parts in the APP pumps appear from the
table below:
Service interval
APP 11-22/1200 rpm
No need for service
No wear part
No wear part
48,000 hours
Recommended inspection on a
yearly basis and evaluated acc.
to app. 1
Replace after 24,000 hrs.
32,000 hours
32,000 hours
48,000 hours
24,000 hours
24000 hours
24,000 hours
24000 hours
24,000 hours
No wear part
32,000 hours
No wear part
24,000 hours
24,000 hours
24,000 hours
No wear part
48,000 hours
No wear part
40,000 hours
Service interval
APP 11-22/1500 rpm
No need for service
No wear part
No wear part
32,000 hours
Recommended inspection on
a yearly basis and evaluated
acc. to app. 1
Replace after 16,000 hrs.
32,000 hours
32,000 hours
32,000 hours
24,000 hours
24,000 hours
24,000 hours
24,000 hours
24,000 hours
No wear part
32,000 hours
No wear part
24,000 hours
24,000 hours
24,000 hours
No wear part
48,000 hours
No wear part
40,000 hours
