MINI BRUTUS SWINGSET
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
Model # 2051164B
Owner's Manual & Assembly Instructions
800-856-4445
average 2 person assembly time
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
YOU NEED TO ORDER REPLACEMENT PARTS.
Made in China | INS-2051164B-B-MINI BRUTUS-ENG 12/09/20

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2051164B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Backyard Discovery 2051164B

Summary of Contents for Backyard Discovery 2051164B

  • Page 1 For the most up to date assembly manual, to register your set, or to order replacement parts please visit www.backyarddiscovery.com SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT YOU NEED TO ORDER REPLACEMENT PARTS. Made in China | INS-2051164B-B-MINI BRUTUS-ENG 12/09/20...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Configure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE Th e store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...
  • Page 4 Botanical, Adventure Playsets, and Leisure Time Products. Backyard Discovery warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. Th is one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a fi ve (5) year pro-rated warranty against rot and decay. Refer to the schedule below for charges associated with replacement of parts under this Limited Warranty.
  • Page 5 Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playcenter Suggested Playground Surfacing • Th e playcenter is designed to be installed on a level • Do not install home playground equipment over surface by an adult with an adult helper. Place concrete, asphalt, packed earth, grass, carpet, or any in a fl at area of your yard to minimize ground other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A The following information is from the United States X3.1.3.2 Do not install loose-fi ll surfacing over hard surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...
  • Page 8 • Check all moving parts including swing seats, Backyard Discovery assumes no responsibility or ropes, cables, and chains for wear, rust, or other liability for any charge incurred by the Customer for deterioration.
  • Page 9 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.
  • Page 10 Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep an eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Hardware NUT BARREL SCREW T-NUT WASHER FLAT BOLT HEX BOLT SCREW PWH H100545...
  • Page 11 Owner's Manual Tools Required for Installation...
  • Page 12 Owner's Manual Basic Setup Dimensions & Assembly Notes Place the set on level ground, not less than 6'-7" [2 m] from any structure or obstruction such as a fence, garage, house, overhanging branches, laundry lines, or electrical wires. • While assembling unit, take time before and after each phase to make sure fort is level. If fort is not level, assembly will be difficult and improper assembly may result.
  • Page 13 Hardware Components Parts Identification H100366 BOLT WH WZ (x4) 5/16x4 H100811 BOLT CARRIAGE WZ (x6) 5/16x2 3/4 H100591 BOLT CARRIAGE WZ (x12) 5/16x2 1/2 H100818 BOLT HEX M12x50mm WZ (x4) M12x 50mm H100499 NUT BARREL WH WZ (x22) 5/16x7/8 H100819 H100278 WASHER FLAT WZ LOCK NUT WZ...
  • Page 14 Accessories (Not to Scale) Parts Identification A4M01013 BOTTOM LEG (x4) A4M01015 TOP LEG (x4) A4M01018 SIDE BAR (x2) A4M01019 A4M01020 METAL BRACKET GREY A4M01024 LEG CONNECTING TUBE (x8) METAL BRACKET GREEN (x4) (x2) A4M01294 SWING BEAM END (x2) A4M01022 TOP BEAM CONNECTING TUBE (x1)
  • Page 15 Accessories (Not to Scale) Parts Identification A6P00375 BYD TAG STICKER (SMALL) (x1) A6P00366 SWING SET FOOT (x4) A6P00435 WARNING LABEL STICKER (x1) H100242 QUICK LINK (LONG) WZ (x8) A4M01040 DUCTILE HANGER WITH INSERT WZ (x4) A4M01136 CHAIN GREEN 48.25" (x4) A6P00362 26"...

  • Page 16: Table Of Contents

    STEP 1 H100591 BOLT CARRIAGE WZ (x4) 5/16x2 1/2 A4M01020 LEG CONNECTING TUBE (x4) A4M01013 BOTTOM LEG (x4) H100811 BOLT CARRIAGE WZ (x4) 5/16x2 3/4 A4M01015 TOP LEG (x4) A4M01019 H100499 NUT BARREL WH WZ METAL BRACKET GREY (x8) (x8) 5/16x7/8 NOTE: NOTE...

  • Page 17: Note

    STEP 2 A4M01022 TOP BEAM CONNECTING TUBE H100811 BOLT CARRIAGE WZ (x1) A4M01294 (x2) 5/16x2 3/4 SWING BEAM END (x2) H100818 BOLT HEX M12x50mm WZ (x4) M12x 50mm A4M01024 A4M01040 METAL BRACKET GREEN DUCTILE HANGER WITH INSERT WZ (x2) (x4) H100819 LOCK NUT WZ H100499...

  • Page 18: Bolt Carriage Wz 5/16X2

    STEP 3 A4M01018 SIDE BAR (x2) H100591 H100499 BOLT CARRIAGE WZ NUT BARREL WH WZ (x8) (x8) 5/16x2 1/2 5/16x7/8 A6P00435 WARNING LABEL STICKER (x1) (x8) NUT BARREL - 7/8 (x8) INSERT LEG ASSEMBLIES BOLT - 2 1/2 FROM STEP 1 (x4) NOTE: REMOVE ASSEMBLED HARDWARE SHOWN AND ATTACH BRACE TO...
  • Page 19 STEP 4 H100366 BOLT WH WZ (x4) 5/16x4 H100278 WASHER FLAT WZ (x4) 5/16 A6P00366 A100178 SWING SET FOOT AUGER GROUND STAKE (x4) (x4) H100499 NUT BARREL WH WZ (x4) 5/16x7/8 (x4) NUT BARREL - 7/8 (x4) WASHER FLAT - 5/16 (x4) BOLT - 4 NOTE HOLE ORIENTATION...
  • Page 20 STEP 5 H100242 A4M01136 A6P00362 QUICK LINK (LONG) WZ CHAIN GREEN 48.25" 26" HD BELT SWING (x4) (x4) (x2) TIGHTEN QUICK LINK INSERT CHAIN INTO QUICK LINK (x4) CHAIN GREEN 48.25" (x4) QUICK LINK (LONG) WZ (x2) 26" HD BELT SWING...
