Backyard Discovery Echo Heights Owner's Manual & Assembly Instructions

Playhouse
Hide thumbs Also See for Echo Heights:
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING
Adult Assembly Required.
Not suitable for children under
two years, due to sharp points
and small parts. Only for
domestic use.
"The play house is intended
for outdoor use"
SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT
Made in China | INS-2102316A-ECHO HEIGHTS-ENG 10/29/20
Echo Heights
Model # 2102316
assembly time may vary based on skill level
For the most up to date assembly manual,
to register your set, or to order replacement parts please visit
www.backyarddiscovery.com
YOU NEED TO ORDER REPLACEMENT PARTS.
Playhouse
Owner's Manual & Assembly Instructions
average 2 person assembly time
MANUFACTURED BY:
Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
800-856-4445
Basepoint Business
Centre
Rivermead Drive
Westlea
Swindon
SN5 7EX

Advertisement

Table of Contents
loading

Related Manuals for Backyard Discovery Echo Heights

Summary of Contents for Backyard Discovery Echo Heights

  • Page 1 For the most up to date assembly manual, to register your set, or to order replacement parts please visit www.backyarddiscovery.com SAVE THIS ASSEMBLY MANUAL FOR FUTURE REFERENCE IN THE EVENT THAT YOU NEED TO ORDER REPLACEMENT PARTS. Made in China | INS-2102316A-ECHO HEIGHTS-ENG 10/29/20...
  • Page 2 INSTALLATION SERVICES AVAILABLE! Need a helping hand? Let our team of professionals handle the installation for you! *Installation services are only available to U.S. customers. With Go Con! gure, we bring you 18 years of experience right to your doorstep. We service a wide array of indoor and outdoor recreation products that most consumers don’t have the time or ability to deliver &...
  • Page 3 Owner’s Manual Please Read This Before Starting Assembly MISSING A PART? CALL US BEFORE GOING BACK TO THE STORE The store where you made your purchase does not stock parts for this item. If you have assembly questions or you are missing or have damaged parts, please call 1-800-856-4445 you can also visit www.backyarddiscovery.com...

  • Page 4: Limited Warranty

    Botanical, Adventure Playsets, and Leisure Time Products. Backyard Discovery warrants that this product is free from defect in materials and workmanship for a period of one (1) year from the original date of purchase. This one (1) year warranty covers all parts including wood, hardware, and accessories. All wood carries a ! ve (5) year pro-rated warranty against rot and decay. Refer to the schedule below for charges associated with replacement of parts under this Limited Warranty.
  • Page 5 Owner’s Manual Operating Instructions and Safety Warnings WARNING: BURN HAZARD • Pay special attention to plastic and metal surfaces as they may be hot enough to cause burns. • Always check the temperature of the product before NOTE: letting your children play on it. •...
  • Page 6 Owner’s Manual Please Read This Before Starting Assembly Positioning Your Playhouse Suggested Playground Surfacing • The playhouse is designed to be installed on a • Do not install home playground equipment over concrete, asphalt, packed earth, grass, carpet, level surface by an Adult with an Adult helper. or any other hard surface.
  • Page 7 Owner’s Manual Please Read This Before Starting Assembly APPENDIX A X3.1.3.2 Do not install loose- ll surfacing over hard The following information is from the United States surfaces such as concrete or asphalt. Consumer Product Safety Commission’s Information X3.1.4 Poured-In-Place Surfaces or Pre-Manufactured Sheet for playground surfacing material;...
  • Page 8 • Check all moving parts including swing seats, Backyard Discovery assumes no responsibility or ropes, cables, and chains for wear, rust, or other liability for any charge incurred by the Customer for deterioration.

  • Page 9: Instructions For Proper Maintenance

    About Our Wood Backyard Discovery uses 100% Cedar (C. Lanceolata) wood. Although we take great care in selecting the best quality lumber available, wood is still a product of nature and susceptible to weathering which can change the appearance of your set.
  • Page 10 Owner’s Manual Assembly Tips Protrusion Hazard Incorrect Correct If you see exposed threads and your bolt protrudes beyond the T-Nut you may have over tightened the bolt or used incorrect hardware. If you’ve overtightened, remove the bolt and add washers to eliminate the protrusion.

  • Page 11: Assembly Tips

    Owner’s Manual Assembly Tips ASSEMBLY TIP: Keep and eye out for these boxes which will contain helpful pictures and information making the assembly process as quick and painless as possible. Sorting Wood When removing the wood from the boxes we recommend arranging them by part number before you begin assembly.
  • Page 12 Electronics Safety Warnings Owner's Manual Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 13 Owner's Manual Tools Required for Installation...
  • Page 14 Owner's Manual Basic Setup Dimensions & Assembly Notes Selecting the correct location for your play product is important for your children’s safety and the product’s longevity The safe play area refers to a zone extending 6'-7" (2m) beyond the play product on all sides, including the space •...

  • Page 15: Parts Identification

    Parts Identification Owner's Manual Wood Components (Not to Scale) LEFT FRONT UPRIGHT - W4L14880 1 3/8"x3 3/8"x62 3/8" (36x86x1584) (x1) RIGHT FRONT UPRIGHT - W4L14881 1 3/8"x3 3/8"x62 3/8" (36x86x1584) (x1) RIGHT REAR UPRIGHT - W4L14882 1 3/8"x3 3/8"x62 3/8" (36x86x1584) (x1) LEFT REAR UPRIGHT - W4L14883 (x1)
  • Page 16 Parts Identification Owner's Manual Wood Components (Not to Scale) WALL RAIL - W4L14896 1"x3 3/8"x16 5/8" (24x86x423) (x2) WALL RAIL - W4L14897 1"x3 3/8"x16 3/4" (24x86x426) (x2) WALL RAIL - W4L14923 1"x3 3/8"x55 7/8" (24x86x1418) (x1) DECK BRACE - W4L14898 1"x3 3/8"x13"...
  • Page 17 Parts Identification Owner's Manual Wood Components (Not to Scale) FLOOR BOARD - W4L14909 (x13) 5/8"x3 3/8"x56 3/4" (16x86x1442) FLOOR BOARD - W4L14886 (x1) 5/8"x3 3/8"x56 3/4" (16x86x1442) WALL BOARD - W4L14887 (x2) 5/8"x3 3/8"x26 1/2" (16x86x673) WALL BOARD - W4L14911 5/8"x3 3/8"x26 1/2"...
  • Page 18 Parts Identification Owner's Manual Wood Components (Not to Scale) FRONT RIGHT CORNER PANEL - W2A03151 REAR RIGHT CORNER PANEL - W2A03154 (x1) (x1) FRONT LEFT CORNER PANEL - W2A03157 REAR LEFT CORNER PANEL - W2A03160 (x1) (x1) REAR CENTER PANEL - W2A03163 LEFT CENTER PANEL - W2A03164 1 1/4"x18 7/8"x20 7/8"...
  • Page 19 Parts Identification Owner's Manual Wood Components (Not to Scale) HEADER ASSEMBLY - W2A03165 (x2) LOWER ROOF PANEL - W2A03166 (x2) 1 3/8"x13"x44 7/8" (35x329x1140) UPPER ROOF PANEL - W2A03167 1 3/8"x12 3/4"x44 7/8" (35x324x1140) (x2) DOOR PANEL - W2A03168 (x1) 1 1/8"x19 1/8"x11 3/8"...

  • Page 20: Hardware Components

    Owner's Manual Parts Identification Hardware Components H100171 BOLT WH BLK (x7) 1/4x1 H100484 BOLT WH BLK (x3) 5/16x3 1/4 H100399 NUT BARREL WH BLK (x4) 1/4x7/8 H100205 BOLT WH BLK (x15) 5/16x2-1/4 H100469 NUT BARREL WH BLK (x8) 5/16x5/8 H100378 BOLT WH BLK (x11) 5/16x1 3/4...
  • Page 21 Owner's Manual Parts Identification Hardware Components H100395 SCREW PFH BLK (x2) 8x3/4 H100385 SCREW PFH BLK (x26) H100458 LAG SCREW WH BLK H100380 SCREW PFH BLK (x26) 5/16x2 (x46) 8x1 1/8 H100387 SCREW PFH BLK (x64) 8x1-1/4 H100200 SCREW PFH BLK (x138) 8x1 1/2 H100403...
  • Page 22 Owner's Manual Parts Identification Accessory Components (Not to Scale) A100314 "A" REVISION TAG A4M00555 (x1) 90° L-BRACKET - BLK (x8) A100028 HAND GRIP GREEN PLASTIC (x2) A4M00528 BYD ID TAG (MEDIUM) AGES 2 TO 10 (x1) A100361 PLASTIC SUNBURST (x2) A4M01047 L BRACKET 2.5x38x55x55 (x3)
  • Page 23 Owner's Manual Parts Identification Accessory Components (Not to Scale) A4M00624 A4M00994 HINGE (DOOR, SPRING LOADED) HINGE (DOOR, NON-SPRING LOADED) (x1) (x1) A4M00933 DOOR STOP (x1) A4M01045 BELL ASSEMBLY (x1) A6P00391 6 FT SLIDE BED (x1)
  • Page 24 Owner's Manual Parts Identification Accessory Components (Not to Scale) A6P00330 INDUCTIVE BURNER KIT (x1) A6P00335 STOVE BASE (x1) A6P00338 FRY PAN (x1) A6P00331 BLENDER (x1) A6P00336 BOIL POT (x1) A6P00339 SPATULA (x1) A6P00337 POT/PAN LID (x2) A6P00340 LADLE (x1) A4M01150 VERTICAL ID PLATE (x1)

  • Page 25: Slide Assembly

    SLIDE ASSEMBLY STEP 1 SLIDE BRACE - W4L13297 5/8"x3 3/8"x14 1/4" (16x86x362) A6P00391 6 FT SLIDE BED H100396 BOLT WH BLK H100379 T-NUT BLK 5/16x1/2 5/16 PLACE 'M77' SLIDE BRACE BOARD 1/2" FROM THE BOTTOM EDGE OF THE SLIDE BED. USING THE BOARD AS A TEMPLATE, MARK WHERE THE PILOT HOLES WILL BE DRILLED.
  • Page 26 SLIDE ASSEMBLY STEP 2 A6P00390 6 FT SLIDE RAIL RIGHT SLIDE BRACE - W4L13298 5/8"x3 3/8"x14 1/4" (16x86x362) A6P00389 6 FT SLIDE RAIL LEFT H100201 SCREW PFH BLK (16) 8x2-1/2 NOTE: 1. PLACE THE SLIDE RAIL ON FLAT SURFACE. STARTING AT THE BOTTOM, INSERT THE SLIDE BED INTO THE CHANNEL ON THE INSIDE OF THE RAIL.

  • Page 27: Ladder Assembly

    LADDER ASSEMBLY STEP 1 LEFT UPRIGHT - W4L14900 1"x3 3/8"x38 3/8" (24x86x976) (x1) H100391 SCREW PFH BLK (x6) LADDER RUNG - W4L14899 1"x3 3/8"x18 1/8" (24x86x460) (x3) (x6) SCREW - 2" (x3) (x1)
  • Page 28 LADDER ASSEMBLY STEP 2 RIGHT UPRIGHT - W4L14901 H100391 SCREW PFH BLK (x1) 1"x3 3/8"x38 3/8" (24x86x976) (x6) (x6) SCREW - 2" (x1)
  • Page 29 LADDER ASSEMBLY STEP 3 H100391 SCREW PFH BLK REAR SUPPORT - W4L14913 (x4) (x1) 5/8"x3 3/8"x19 1/4" (16x86x488) 1 1/4 in (x1) [31 mm] (x4) SCREW - 2"...
  • Page 30 LADDER ASSEMBLY STEP 4 H100391 SCREW PFH BLK H110 ATTACHMENT BOARD - W4L14914 (x4) 1"x3 3/8"x19 1/4" (24x86x488) (x1) H110 (x1) (x4) SCREW - 2" FLUSH...

  • Page 31: Deck Assembly

    DECK ASSEMBLY STEP 1 LEFT FRONT UPRIGHT - W4L14880 FLOOR RAIL - W4L14889 FLOOR SUPPORT BLOCK - W4L14902 1 3/8"x3 3/8"x62 3/8" (36x86x1584) (x1) 1"x3 3/8"x54 7/8" (24x86x1394) (x1) 1"x3 3/8"x3 3/8" (24x86x86) (x1) LEFT REAR UPRIGHT - W4L14883 GROUND BOARD - W4L14885 1 3/8"x3 3/8"x35"...
  • Page 32 DECK ASSEMBLY STEP 2 GROUND BOARD - W4L14884 H100458 LAG SCREW WH BLK 1"x5 1/4"x56 3/4" (24x134x1442) (x2) (x4) 5/16x2 H100198 WASHER LOCK EXT BLK (x4) 8x19 (x2) (x4) WASHER - 8x19 (x4) LAG SCREW - 2"...
  • Page 33 DECK ASSEMBLY STEP 3 FLOOR RAIL - W4L14891 RIGHT FRONT UPRIGHT - W4L14881 FLOOR SUPPORT BLOCK - W4L14902 (x1) 1"x3 3/8"x54 7/8" (24x86x1394) 1 3/8"x3 3/8"x62 3/8" (36x86x1584) (x1) 1"x3 3/8"x3 3/8" (24x86x86) (x2) RIGHT REAR UPRIGHT - W4L14882 GROUND BOARD - W4L14885 1 3/8"x3 3/8"x62 3/8"...
  • Page 34 DECK ASSEMBLY STEP 4 H100458 LAG SCREW WH BLK H100198 WASHER LOCK EXT BLK (x4) 5/16x2 (x4) 8x19 SUBASSEMBLY FROM STEP 3. (x4) LAG SCREW - 2" (x4) WASHER - 8x19...
  • Page 35 DECK ASSEMBLY STEP 5 FLOOR RAIL - W4L14888 H100458 H100198 1"x3 3/8"x56 3/4" (24x86x1442) LAG SCREW WH BLK WASHER LOCK EXT BLK (x1) (x4) (x4) 5/16x2 8x19 NOTE HOLE LOCATION IS CLOSER TO THE TOP EDGE. (x1) (x4) (x4) LAG SCREW - 2" WASHER - 8x19...
  • Page 36 DECK ASSEMBLY STEP 6 FLOOR RAIL - W4L14888 H100458 1"x3 3/8"x56 3/4" (24x86x1442) LAG SCREW WH BLK H100198 (x1) WASHER LOCK EXT BLK (x4) (x4) 5/16x2 8x19 (x4) (x4) WASHER - 8x19 LAG SCREW - 2" NOTE HOLE LOCATION IS CLOSER TO THE TOP EDGE.
  • Page 37 DECK ASSEMBLY STEP 7 H100378 BOLT WH BLK H100198 WASHER LOCK EXT BLK (x8) (x8) 5/16x1 3/4 8x19 H100379 T-NUT BLK DECK BRACE - W4L14898 (x8) 5/16 1"x3 3/8"x13" (24x86x330) (x8) H100403 H100405 LAG SCREW WH BLK WASHER LOCK EXT BLK (x8) (x8) 1/4x1 1/2...
  • Page 38 DECK ASSEMBLY STEP 8 H100201 SCREW PFH BLK FLOOR SUPPORT - W4L14892 (x8) 8x2-1/2 1"x3 3/8"x54 7/8" (24x86x1394) (x2) FLUSH TOPS (x8) ALL LOCATIONS SCREW - 2 1/2" (x2)
  • Page 39 DECK ASSEMBLY STEP 9 FLOOR BOARD - W4L14909 FLOOR BOARD - W4L14904 5/8"x3 3/8"x56 3/4" (16x86x1442) (x13) 5/8"x4 3/8"x52" (16x112x1321) (x1) H100200 SCREW PFH BLK (x96) 8x1 1/2 FLOOR BOARD - W4L14886 FLOOR BOARD - W4L14905 5/8"x3 3/8"x56 3/4" (16x86x1442) (x1) (x1) 5/8"x4 3/8"x54 3/8"...
  • Page 40 DECK ASSEMBLY STEP 1 0 WALL RAIL - W4L14894 WALL RAIL - W4L14895 WALL RAIL - W4L14893 1"x3 3/8"x56 3/4" (24x86x1442) (x1) (x1) 1"x3 3/8"x34 1/4" (24x86x871) 1"x3 3/8"x18 1/2" (24x86x469) (x2) WALL BOARD - W4L14887 WALL RAIL - W4L14923 A4M01047 (x2) 5/8"x3 3/8"x26 1/2"...
  • Page 41 DECK ASSEMBLY STEP 1 1 H100469 NUT BARREL WH BLK (x1) 5/16x5/8 A100028 WALL BOARD - W4L14911 HAND GRIP GREEN PLASTIC (x2) 5/8"x3 3/8"x26 1/2" (16x86x673) (x1) A4M01047 L BRACKET 2.5x38x55x55 H100398 T-NUT BLK (x1) (x2) H100403 H100171 LAG SCREW WH BLK BOLT WH BLK H100407 H100396...
  • Page 42 DECK ASSEMBLY STEP 1 2 H100205 BOLT WH BLK WALL RAIL - W4L14896 H100198 WASHER LOCK EXT BLK (x2) 5/16x2-1/4 (x2) 8x19 1"x3 3/8"x16 5/8" (24x86x423) (x2) RAIL BOARD - W4L14920 H100200 SCREW PFH BLK H100379 T-NUT BLK 1"x1"x26 3/4" (24x24x679) (x1) (x4) 8x1 1/2...
  • Page 43 DECK ASSEMBLY STEP 13 WALL RAIL - W4L14897 H100458 LAG SCREW WH BLK H100198 WASHER LOCK EXT BLK (x2) 5/16x2 1"x3 3/8"x16 3/4" (24x86x426) (x2) (x2) 8x19 RAIL BOARD - W4L14920 H100200 SCREW PFH BLK (x4) 8x1 1/2 1"x1"x26 3/4" (24x24x679) (x1) NOTE HOLE LOCATION FOR PROPER INSTALLATION.
  • Page 44 DECK ASSEMBLY STEP 14 H100380 SCREW PFH BLK PICKET - W4L14918 (x6) 8x1 1/8 (x3) 5/8"x1 3/8"x20 1/2" (16x34x520) PICKET PAL 2 1/8 in [54 mm] (x3) (x6) SCREW - 1 1/8" 1 7/8 in " [49 mm]...
  • Page 45 DECK ASSEMBLY STEP 15 H100380 SCREW PFH BLK PICKET - W4L14918 (x12) 8x1 1/8 (x6) 5/8"x1 3/8"x20 1/2" (16x34x520) 2 1/4 in 2 1/4 in (x6) [56 mm] [56 mm] (x12) SCREW - 1 1/8" 1 7/8 in " TYP [49 mm]...
  • Page 46 DECK ASSEMBLY STEP 16 H100380 SCREW PFH BLK PICKET - W4L14918 (x14) 8x1 1/8 (x7) 5/8"x1 3/8"x20 1/2" (16x34x520) 2 1/4 in [58 mm] (x7) (x14) SCREW - 1 1/8" 1 7/8 in [49 mm]...
  • Page 47 DECK ASSEMBLY STEP 17 H100380 SCREW PFH BLK PICKET - W4L14918 (x6) 8x1 1/8 (x3) 5/8"x1 3/8"x20 1/2" (16x34x520) 2 5/8 in (x3) [66 mm] (x6) SCREW - 1 1/8" 1 7/8 in [49 mm]...
  • Page 48 PLAYHOUSE STEP 1 ASSEMBLY FRONT RIGHT CORNER PANEL - W2A03151 REAR RIGHT CORNER PANEL - W2A03154 (x1) (x1) FRONT LEFT CORNER PANEL - W2A03157 REAR LEFT CORNER PANEL - W2A03160 (x1) (x1) NOTE: STAND THE (4) CORNER WALL (x1) ASSEMBLIES AS SHOWN BELOW. LEFT BACK NOTE THE PROFILE OF...
  • Page 49 PLAYHOUSE STEP 2 ASSEMBLY H100385 SCREW PFH BLK (x12) LEFT CENTER PANEL - W2A03164 1 1/4"x18 7/8"x20 7/8" (32x478x536) (x1) (x12) SCREW - 1" BACK LEFT (x1) FRONT RIGHT...
  • Page 50 PLAYHOUSE STEP 3 ASSEMBLY H100385 SCREW PFH BLK (x12) REAR CENTER PANEL - W2A03163 (x1) 1 1/4"x18 7/8"x20 7/8" (32x478x536) (x12) SCREW - 1" (x1) BACK LEFT RIGHT FRONT...
  • Page 51 PLAYHOUSE STEP 4 ASSEMBLY H100201 SCREW PFH BLK (x4) 8x2-1/2 HEADER ASSEMBLY - W2A03165 (x2) ALL INTERIOR SURFACES ARE FLUSH. (x4) (x1) SCREW - 2 1/2" LEFT BACK (x1) RIGHT FRONT...
  • Page 52 PLAYHOUSE STEP 5 ASSEMBLY H100387 SCREW PFH BLK (x32) 8x1-1/4 TIE STRAP - W4L14915 5/8"x3 3/8"x3 3/8" (16x86x86) (x8) (x8) INSTALL WITH THE EDGE SURFACE OF 'N1' FLUSH WITH THE END OF WALL BOARD, AS SHOWN. (x32) SCREW - 1 1/4" DRILL 1/8"...
  • Page 53 PLAYHOUSE STEP 6 ASSEMBLY H100405 H100171 WASHER LOCK EXT BLK BOLT WH BLK (x4) (x4) 6x15 1/4x1 GABLE BOARD - W4L14906 5/8"x4 3/8"x25 3/8" (16x112x644) (x4) H100399 NUT BARREL WH BLK H100400 WASHER LOCK EXT BLK (x4) 1/4x7/8 (x4) 8x15 (x4) (x4) WASHER - 6x15...
  • Page 54 PLAYHOUSE STEP 7 ASSEMBLY H100387 SCREW PFH BLK (x4) 8x1-1/4 H100392 SCREW PWH BLK (x8) 8x3/4 A100361 PLASTIC SUNBURST (x2) (x2) PLASTIC SUNBURST (x8) SCREW - 3/4" (x4) SCREW - 1 1/4"...
  • Page 55 PLAYHOUSE STEP 8 ASSEMBLY H100200 SCREW PFH BLK (x8) 8x1 1/2 UPPER ROOF PANEL - W2A03167 1 3/8"x12 3/4"x44 7/8" (35x324x1140) (x2) (x8) SCREW - 1 1/2" (x1) (x1)
  • Page 56 PLAYHOUSE STEP 9 ASSEMBLY H100200 SCREW PFH BLK (x8) 8x1 1/2 LOWER ROOF PANEL - W2A03166 1 3/8"x13"x44 7/8" (35x329x1140) (x2) (x1) (x1) (x8) SCREW - 1 1/2"...
  • Page 57 PLAYHOUSE STEP 1 0 ASSEMBLY H100387 SCREW PFH BLK WINDOW SHELF - W4L14917 (x2) 8x1-1/4 5/8"x2 3/8"x19 1/8" (16x60x485) (x1) (x2) SCREW - 1 1/4" (x1) FLUSH SURFACES...
  • Page 58 PLAYHOUSE STEP 1 1 ASSEMBLY H100387 SCREW PFH BLK WINDOW SHELF - W4L14917 (x2) 8x1-1/4 5/8"x2 3/8"x19 1/8" (16x60x485) (x1) (x2) SCREW - 1 1/4" (x1) FLUSH SURFACES...
  • Page 59 PLAYHOUSE STEP 1 2 ASSEMBLY H100202 SCREW PWH BLK (x8) 8x5/8 A4M00555 90° L-BRACKET - BLK (x8) ALIGN BRACKETS WITH PILOT HOLES. (x8) SCREW - 5/8" (x8) 90° L-BRACKET - BLK EDGES FLUSH IN DOOR OPENINGS.
  • Page 60 PLAYHOUSE STEP 13 ASSEMBLY H100200 SCREW PFH BLK (x2) 8x1 1/2 COUNTER TOP SUPPORT - W4L14919 (x1) 1"x3 3/8"x8 3/8" (24x86x214) (x2) SCREW - 1 1/2" (x1) ALIGN PILOT HOLES IN H3 WITH HOLES IN WALL PANEL.
  • Page 61 PLAYHOUSE STEP 14 ASSEMBLY H100387 SCREW PFH BLK (x4) 8x1-1/4 COUNTER TOP SUPPORT - W4L14903 1"x2 3/8"x9 1/4" (24x60x234) (x2) LEFT RIGHT (x2) (LEFT & RIGHT SIDE) 1/8 in [2 mm] (x4) SCREW - 1 1/4"...
  • Page 62 PLAYHOUSE STEP 15 ASSEMBLY H100200 SCREW PFH BLK COUNTER TOP - W4L14907 (x10) 8x1 1/2 1"x4 3/8"x36 3/4" (24x112x934) (x2) 9/32 in [7 mm] (x2) (x10) SCREW - 1 1/2"...
  • Page 63 PLAYHOUSE STEP 16 ASSEMBLY H100392 SCREW PWH BLK (x2) 8x3/4 A100314 "A" REVISION TAG (x1) (x2) SCREW - 3/4" (x1) "A" REVISION TAG...
  • Page 64 PLAYHOUSE STEP 17 ASSEMBLY H100200 SCREW PFH BLK (x2) 8x1 1/2 A6P00024 FAUCET KIT (x1) (x2) SCREW - 1 1/2" (x1) FAUCET KIT 1 1/2 in [37 mm] (FAUCET LOCATION)
  • Page 65 PLAYHOUSE STEP 18 ASSEMBLY H100202 SCREW PWH BLK (x2) 8x5/8 A6P00032 SURFACE MOUNT BASIN (x1) 3/8 in [9 mm] (x2) SCREW - 5/8" (x1) SURFACE MOUNT BASIN...
  • Page 66 PLAYHOUSE STEP 19 ASSEMBLY WINDOW TRIM - W4L14921 1"x1"x21 1/2" (24x24x545) (x2) H100387 SCREW PFH BLK (x8) 8x1-1/4 WINDOW TRIM - W4L14922 1"x1"x23 3/8" (24x24x594) (x2) (x2) (x2) 9 1/8 in [231 mm] (x8) SCREW - 1 1/4"...

  • Page 67: Stove Assembly

    STOVE ASSEMBLY A6P00330 INDUCTIVE BURNER KIT (x1) A6P00335 STOVE BASE (x1) NOTE: -DO NOT MIX OLD AND NEW BATTERIES. -DO NOT MIX ALKALINE, STANDARD (CARBON-ZINC), OR RECHARGEABLE (NI-CAD, NI-MH, ETC.) BATTERIES. -NON-RECHARGEABLE BATTERIES ARE NOT TO BE RECHARGED. -ONLY BATTERIES OF THE SAME OR EQUIVALENT TYPE AS RECOMMENDED ARE TO BE USED.
  • Page 68 PLAYHOUSE STEP 20 ASSEMBLY H100797 SCREW PWH BLK (x4) A6P00335 STOVE BASE (x1) 1 3/4 in [45 mm] (x4) SCREW - 1" (x1) STOVE BASE...
  • Page 69 PLAYHOUSE STEP 21 ASSEMBLY H100387 SCREW PFH BLK (x4) 8x1-1/4 FASCIA BOARD - W4L14912 5/8"x3 3/8"x25 5/8" (16x86x652) (x2) (x2) (x4) SCREW - 1 1/4"...
  • Page 70 PLAYHOUSE STEP 22 ASSEMBLY H100387 SCREW PFH BLK (x4) 8x1-1/4 FASCIA BOARD - W4L14912 5/8"x3 3/8"x25 5/8" (16x86x652) (x2) (x2) (x4) SCREW - 1 1/4"...
  • Page 71 PLAYHOUSE STEP 23 ASSEMBLY A6P00067 A4M00933 KNOB - BLK DOOR STOP (x1) (x1) HINGE (DOOR, HINGE (DOOR, DOOR PANEL - W2A03168 A4M00994 A4M00624 NON-SPRING SPRING (x1) (x1) 1 1/8"x19 1/8"x11 3/8" (27x486x288) (x1) LOADED) LOADED) H100395 H100382 H100806 H100804 SCREW PFH BLK SCREW PFH BLK SCREW POH BLK T-NUT...
  • Page 72 PLAYHOUSE STEP 24 ASSEMBLY H100806 H100804 SCREW POH BLK T-NUT (x6) (x6) 8/32x1 1/8 8/32 DOOR SUBASSEMBLY (x1) (x6) T-NUT - 8/32" (x6) SCREW - 1 1/8"...
  • Page 73 PLAYHOUSE STEP 25 ASSEMBLY H100797 SCREW PWH BLK (x2) A4M01045 BELL ASSEMBLY (x1) (x1) (x2) BELL ASSEMBLY SCREW - 1"...

  • Page 74: Final Assembly

    FINAL ASSEMBLY STEP 1 H100378 BOLT WH BLK H100198 WASHER LOCK EXT BLK (x2) (x2) 5/16x1 3/4 8x19 LADDER SUBASSEMBLY (x1) (x2) WASHER - 8x19 (x2) BOLT - 1 3/4"...
  • Page 75 FINAL ASSEMBLY STEP 2 H100382 SCREW PFH BLK H100408 SCREW PWH BLK (x8) 8x1 3/4 (x8) 8x1/2 PLAYHOUSE SUBASSEMBLY (x1) (x4) SCREW - 1 3/4" PICKET MAY NEED TO BE TEMPORARILY REMOVED TO ASSEMBLE THE HOUSE TO THE DECK. (x8) SCREW - 1/2"...
  • Page 76 FINAL ASSEMBLY STEP 3 H100202 SCREW PWH BLK (x2) 8x5/8 A4M00528 BYD ID TAG (MEDIUM) AGES 2 TO 10 (x1) (x2) SCREW - 5/8" (x1) BYD ID TAG (MEDIUM) AGES 2 TO 10 12 1/4 in [312 mm]...
  • Page 77 FINAL ASSEMBLY STEP 4 H100380 SCREW PFH BLK GROWTH BOARD - W4L14908 (x4) 8x1 1/8 5/8"x3 3/8"x60 1/4" (16x86x1530) (x1) (x4) SCREW - 1 1/8" (x1) 3 1/8 in [80 mm]...
  • Page 78 FINAL ASSEMBLY STEP 5 H100396 H100379 BOLT WH BLK T-NUT BLK (x2) (x2) 5/16x1/2 5/16 9208032 6 FT SPEEDY SLIDE (x1) 2 5/8 in 7 1/8 in [66 mm] [180 mm] 1 in [25 mm] 3.5 in 2 in [89mm] [52 mm] DRILLING LOCATIONS (x2)
  • Page 79 STEP 6 FINAL ASSEMBLY A100178 H100468 H100199 H100469 BOLT WH BLK WASHER LOCK EXT BLK NUT BARREL WH BLK AUGER GROUND STAKE (x4) (x4) (x4) (x4) 5/16x1 12x19 5/16x5/8 NOTE: FAILURE TO USE GROUND STAKES CAN VOID WARRANTY & CAUSE INJURY! LEFT FRONT (x4)
  • Page 80 FINAL ASSEMBLY STEP 7 H100360 SCREW PPH WZ (x4) 4x1/2 A4M01150 VERTICAL ID PLATE (x1) 1/2 in [12mm] (x1) VERTICAL ID PLATE (x4) SCREW - 4x1/2" WZ NOTE: CENTER ID PLATE ON UPRIGHT...
