Exploded drawings Sigma/ 1
Pos.
Type Quantity Article
001
A
1.000
Liquid end Sigma 1 - 50 SSTH
001
B
1.000
Liquid end Sigma 1 - 65 SSTH
001
C
1.000
Liquid end Sigma 1 - 120 SSTH
100
A
1.000
Hyg.dos. head, complete 96.0 x 42.0 LK80
100
B
1.000
Hyg. dos.h. complete 96.0 x 48.5 HC8
100
C
1.000
Hyg. dos.h. complete 122.0 x 67.0 HC
104
A, B
1.000
Hyg. connection set TCVC DN10
104
C
1.000
Hyg. connection set TCVC DN15
110
A
1.000
Hyg. dos. head welded 96.0 x 42.0
110
B
1.000
Hyg. dos. head welded 96.0 x 48.5
110
C
1.000
Hyg. dos. head welded 122 x 67 LK
121
A-C
2.000
Hyg. valve seal TCVC
122
A-C
2.000
Hyg. valve inner part TCVC with seal
122
A-C
2.000
Hyg. valve, interior, without seal TCVC
123
A, B
1.000
Hyg. valve top part TCVC DN10
123
C
1.000
Hyg. valve top part TCVC DN15
124
A, B
1.000
Hyg. valve bottom part TCVC DN10
124
A
1.000
Hyg. valve bottom part TCVC DN15
125
A- B
2.000
Hyg. clamp connection TRICLAMP TCVC
200
A
1.000
Diaphragm 70 x 32 -M6 PTFE
200
B
1.000
Diaphragm 70 x 37 -M6 PTFE
200
C
1.000
Diaphragm 77.0x 33.5 -M5 PTFE
201
A
1.000
Backplate 96.0x42.0 HC 80 PPE
201
B
1.000
Backplate 96.0x48.5 HC 80 PPE
201
C
1.000
Backplate 105x44 - 2 LK66 PPE
202
A, B
4.000
Cyl. screw DIN 912 M 5x 80
202
C
6.000
Cyl. screw DIN 912 M 5x 80
203
A, B
4.000
Spring washer formerly DIN 7980
203
C
6.000
Spring washer formerly DIN 7980
90
Order no.
1036541
1036542
1036543
1035627
1035730
1035731
1035924
1035945
1035623
1035624
1035625
1035921
1038124
1038922
1035919
1035933
1035920
1035944
1035923
1010279
1010282
1000250
1010288
1010289
1025060
468080
468080
462455
462455
