Type
Sigma 10022, 10044,
07065 SST-relief valve-
A/sv-a
Sigma 07042, 04085,
04120 PVT / TTT
Sigma 07042, 04085,
04120 PVT-relief valve-
A/sv-a
Sigma 07042, 04085,
04120 SST
Sigma 07042, 04085,
04120 SST-relief valve-
A/sv-a
Tab. 6: Dimensions in mm
Standard motor
L 379
Connector A B
DN10 231 142
DN15 242 165
DN15 242 165
DN15 242 165
DN15 242 165
Motor, controllable EExe motor
416 420
C D E F
G 3/4 91 275 88
male
G 1 96 286 -
male
G 1 96 296 74
male
G 1 95 285 -
male
G 1 95 285 88
male
Motor with fre‐
quency converter
519
Dimensional drawings
G I K
105 100 45
122 - -
122 138 63
122 - -
122 112 51
1-phase motor
399
