Table of Contents ELECTRIC SCARIFIER USER'S MANUAL Dear customer, thank you very much for the trust that you have expressed! Before putting this machine into operation, it is imperative to read this user's manual! In it, you will fi nd all the instructions for normal operation and for achieving a long lifetime of the machine. -
Page 3: General Safety Instructions
General safety instruction / Symbols 1. GENERAL SAFETY INSTRUCTIONS Important safety notice Carefully unpack the product and take care not to throw away any part of the packaging before you fi nd all the parts of the product. Store the product in a dry place out of reach of children. Read all warnings and instructions. - Page 4 Symbols Attention! Before putting into operation, carefully read the user's manual and the general safety instructions! Do not work in the rain or in unfavourable climatic conditions! Attention, the blade of the scarifi er continues to rotate for some time after it is turned off! Keep a safe distance! Attention, rotating blades! Sharp blade/s.
-
Page 5: Safety Instructions
Safety Instructions 3. SAFETY INSTRUCTIONS Thank you for purchasing this garden scarifi er. Before you start using it, please carefully read this user's manual and save it for possible future use. Checks before every use Check the electric scarifi er before every use. Do not use the electric scarifi... -
Page 6: Electrical Safety
Intended use The FZV 2004-E Electric Scarifi er is designed for aerating lawns and grass areas in private gardens and yards. It is not intended for use in public facilities, parks, sports fi elds, on roads, in agriculture or forestry. -
Page 7: Description Of The Machine (Fig. 1)
Description of the machine 5. DESCRIPTION OF THE MACHINE (FIG. 1) 1 Switch lock mechanism 7 Working depth adjustment lever 2 Main switch 8 Grass catcher 3 Top part of the handle 9 Grass catcher cover 4 Handle connection screw 0 Power plug 5 Middle part of the handle qa Power cord retainer clip... -
Page 8: Assembling The Machine
Assembly of the machine 6. ASSEMBLING THE MACHINE Assembling the handle Insert the bottom part of the handle into the body of the scarifi er (fi g. 2 – point 1). 2. Fasten the bottom part using the provided screws (fi g. 2 –... -
Page 9: Assembling The Grass Catcher
Assembly of the machine 4. First slide the power cord retainer clip on to the right side of the top handle (fi g. 5 – point 1). Then attach the top part of the handle to the middle part using the provided screws (fi... -
Page 10: Replacing Blades
Blade replacement 7. REPLACING BLADES DANGER! The cylinders may cause injuries! Prior to replacement, disconnect the machine from the power grid and wait for the cylinder to come to a stop. When replacing, wear work gloves. Screw out the bolts 1 on the underside of the chassis (fi... -
Page 11: Setting Up The Scarifier
Setting up the scarifier | Putting into operation 8. SETTING UP THE SCARIFIER ATTENTION! The working depth with the scarifi cation cylinder should be no more than 3 mm. The aeration cylinder with springs should copy the contour of the ground during operation. Setting an excessive working depth may even without visible wear on the blades/springs result in damage to the scarification cylinder or the overloading and destruction of the motor. -
Page 12: Maintenance
Maintenance / Scarification / Aeration 10. MAINTENANCE Cleaning the scarifi er ATTENTION! Danger! A rotating blade may cause injuries. ATTENTION! Prior to maintenance, disconnect the machine from the power grid and wait for the scarifi ca- tion cylinder to come to a stop. ATTENTION! While performing maintenance use work gloves. -
Page 13: Technical Specifications
Technical specifications / Disposal 12. TECHNICAL SPECIFICATIONS Electric scarifi er ..................................FZV 2004-E Voltage/Frequency ............................230 V–240 V / 50 Hz Rated power ....................................1,500 W Working width ....................................32 cm Working depth ................................–12, –8, –4, 4 mm Number of scarifi cation blades .............................. -
Page 14: Declaration Of Ce Conformity
Declaration of CE Conformity ELECTRIC SCARIFIER USER'S MANUAL... - Page 15 FZV 2003 E...
