2
Installation Tools
Installation
Procedure
I
NSTALLATION
This chapter contains Dual DSX-1 Network Interface Card (NIC)
installation information.
To install this NIC in the Total Control chassis, you need a #2 Phillips and
flat-head screwdriver.
To install this NIC:
ESD: To reduce the risk of electrostatic discharge (ESD), take proper
grounding precautions before handling the NIC.
Install the NIC with or without power applied to the chassis.
1 Configure the NIC via the jumpers.
For proper operation, confirm that the 10-position jumper is at NORMAL.
