3-6 C 3: N
HAPTER ETWORK
Configuring Total
Control Manager
Software
Configuring MIB
Manager Software
I C C
NTERFACE ARD ABLING
5 From the Main Menu, select option 3, Card Configuration.
This screen displays:
Card Configuration
1 Save current Configuration to NVRAM
2 Restore NVRAM Configuration
3 Restore Default Configuration
4 Timing Source Priority Assignment
BUS=0
(NOTE: Changing configuration parameters may effect calls in
progress.)
Enter menu selection and press Return or press Esc to exit.
Menu Selection (1-4):
6 Select option 1 to save your configuration to NVRAM and then press
Enter.
The Span Line Jitter Attenuation parameter found under option
5 <and 6> of the Main Menu (Span Line 1 <2> Configuration), is
permanently enabled on the receive side.
Use the Programmed Settings option Short Haul NIC group in Total
Control Manager to configure the NIC at the NAC's channel level.
Use the following MIB object, found in the UDS1 MIB, to configure the
NIC.
MIB Object: uds1ShrtHaulDist
Description: Various distance ranges supported by the Short Haul NIC
Settings: notApplicable
len0thru133Ft
len133thru266Ft
len266thru399Ft
len399thru533Ft
len533thru655Ft
Default: len0thru133Ft
Current Setting
T1-1=1 T1-2=2 INT=0
