- Page 1 Dual T1 DS-1 Network Interface Card Getting Started Guide Part No. 1.024.1303-00...
- Page 2 Dual T1 DS-1 ® Network Interface Card Getting Started Guide http://www.3com.com/ Part No. 1.024.1303-00...
- Page 3 3Com Corporation reserves the right to revise this documentation and to make changes in content from time 95052-8145 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
-
Page 4: Table Of Contents
ONTENTS VERVIEW Contacting 3Com............1-1 Document Conventions ..........1-2 Product Description ............1-3 Product Compatibility ........... 1-3 NSTALLATION Installation Tools ............2-1 Installation Procedure ........... 2-1 ETWORK NTERFACE ABLING Physical Interfaces............3-1 Accessing the User Interface ......... 3-2 ECHNICAL PECIFICATIONS Certification ..............A-1... - Page 5 Physical Dimensions ............A-3 Monitor Port..............A-3...
-
Page 6: Overview
VERVIEW This chapter provides an overview of: Contacting 3Com Document conventions Product description Product compatibility Contacting 3Com Call the appropriate toll free number listed below for technical support. For European countries that do not have a toll free number listed, call +31 30 602 9900. -
Page 7: Document Conventions
Refer to the Total Control Hub Documentation CD-ROM for more information regarding product warranty. For information about Customer Service, including support, training, contracts, and documentation, visit our website at http://totalservice.3com.com Document These tables list conventions used throughout this guide. Conventions... -
Page 8: Product Description
Product Description Product The Dual T1 DS-1 Network Interface Card (NIC), also known as the Long Description Haul NIC, performs critical functions of a channel service unit (CSU) within the 3Com Total Control Enterprise Network Hub. Used in conjunction with the Dual T1 Network Application Card (NAC), the DS-1 NIC terminates two T1 span lines that equate to 48 DSOs. -
Page 9: Installation
NSTALLATION This chapter contains Dual T1 DS-1 Network Interface Card (NIC) installation information. Installation Tools To install this NIC in the Total Control chassis, you need a #2 Phillips and flat-head screwdriver. Installation To install this NIC: Procedure ESD: To reduce the risk of electrostatic discharge (ESD), take proper grounding precautions before handling the NIC. - Page 10 2: I HAPTER NSTALLATION 2 Select a slot at the rear of the Total Control chassis for installing the NIC. Install this NIC in slot(s): 1–17 For managed chassis, slot 17 is reserved for the Network Management Card (NMC) NIC. 3 Use a #2 Phillips screwdriver to remove the safety panel covering this slot.
- Page 11 Installation Procedure 4 Insert the NIC between the slot’s upper and lower card guides. 5 Slide the NIC into the chassis, until the front of the NIC is flush with the chassis.
- Page 12 2: I HAPTER NSTALLATION 6 Use a flat-head screwdriver to tighten the screws on the front panel. 7 Cover any unused chassis slots with safety panels. 8 Install the Network Application Card (NAC) corresponding to this NIC. Refer to the NAC’s Getting Started Guide for more information.
-
Page 13: Network Interface Card Cabling
ETWORK NTERFACE ABLING This chapter provides information about the physical interfaces of the Dual T1 DS-1 Network Interface Card (NIC) and instructions for accessing the corresponding Network Application Card (NAC) through the user interface (UI). Physical Interfaces The Dual T1 DS-1 NIC has the following physical interfaces:... -
Page 14: Accessing The User Interface
3: N HAPTER ETWORK NTERFACE ABLING Accessing the User To access the UI of the corresponding NAC, connect the following cables Interface to the NIC’s console port. Callout Number Description RJ-45 connector to NIC’s console port DB-25 male connector to modem for remote operations DB-25 female-to-female null modem adapter to PC or terminal COM port... -
Page 15: Technical Specifications
ECHNICAL PECIFICATIONS Certification EMI/RFI FCC 15A EN55022A Safety UL 1950 C-UL EN 60950 JATE Telco FCC 68 IC CS-03 Regulatory United States Compliance FCC Part 15 Compliance Statement Statements This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 16: Interface Specifications
A: T PPENDIX ECHNICAL PECIFICATIONS Interface Specifications Serial Ports Electrical Specification: RS-232-C (EIA/TIA-232-E standard) Connector: RJ-45, 8 position modular jack Configuration: Data Terminal Equipment (DTE) Transmission Method: Unbalanced RS-232 Transmission Rate: 38,400 bps maximum Span 1 Port Electrical Specification: T1/E1 span line interface Connector: RJ-48C, 8 position modular jack Specifications:... -
Page 17: Current Draw
Current Draw Current Draw +5.2 vDC @ 500 mA typical maximum Typical maximum refers to the maximum current draw under most typical configurations. Environment Shipping and Storage ° ° Temperature: -25 to 75 C, -13 to 167 Relative Humidity: 0 to 100%, Non-condensing Operating °... - Page 18 3Com Corporation 5400 Bayfront Plaza P.O. Box 58145 Santa Clara, CA 95052-8145 ©1999 3Com Corporation All rights reserved Printed in the U.S.A. Part No. 1.024.1303-00...
