Difficulties in connecting are usually the result of mis-matched baud rates
between the NAC and the terminal emulator.
The Dual DSX-1 NIC's configurable parameter is accessed differently
depending if it is installed behind the Channelized T1-386 or the T1/PRI
NAC.

Channelized T1-386 NAC

1 From the Main Menu, select option 5 <or 7>, T1 Span Line 1 <2>
Configuration.
This screen displays:
T1 Span Line 1 Configuration
1 T1 Span Line 1 Framing Mode
2 T1 Span Line 1 Line Coding
3 T1 Span Line 1 Remotely Initiated Loopback
4 T1 Span Line 1 Jitter Attenuation
5 T1 Span Line 1 Automatic Busy-out
6 T1 Span Line 1 Fractional T1 Byte Pattern
7 T1 Span Line 1 Short Haul NIC Line Length 0-133
(NOTE: Changing configuration parameters may affect calls in
progress.)
Enter menu selection and press Return or press Esc to exit.
Menu Selection (1-7):
2 Select option 7.
This screen displays:
T1 Span Line 1 Short Haul NIC Line Length
1 0-133 feet
2 134-266 feet
3 267-399 feet
4 400-533 feet
5 534-655 feet
Enter menu selection and press Return or press Esc to exit.
Menu Selection (1-5):
Configuring Software
Current Setting
SF
AMI
Ignore
Receiver
Disabled
FE Hex
3-3
