I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
(shown with XPAU cart)
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Large Shelf for Fusion™ Cart
Portuguese Product Description
Spanish Product Description
German Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCA613
Advertisement
Table of Contents
Related Manuals for CHIEF FCA613
Summary of Contents for CHIEF FCA613
- Page 1 Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation (shown with XPAU cart) Large Shelf for Fusion™ Cart Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA613...
-
Page 2: Important Safety Instructions
Chief product to which an accessory and/or component is attached. ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may have a component attached or setting on it. COMPONENT: A COMPONENT is an audiovisual item *FCA613 shelf weighs 25 lbs (11.34 kg) -
Page 3: Installation Instructions
Installation Instructions FCA613 DIMENSIONS HOLE LOCATIONS FOR XPAU CART HOLE LOCATIONS FOR XPA1U AND XFA1U 48.00 1219.2 5.19 131.9 20.86 529.7... - Page 4 FCA613 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions FCA613 TOOLS REQUIRED FOR INSTALLATION 5/32” (included) 7/16” 1/8” (security) (included) PARTS B (1) [Right shelf support] C (1) [Left shelf support] A (1) [Large storage shelf] F (10) K (2) H (4) 1/4-20 x 3/8” 1/4” 1/4-20 x 1/2”... -
Page 6: Assembly And Installation
(E) and display attached. accessory bracket (D). (See Figure 3) IMPORTANT ! : The FCA613 shelf has been designed specifically for Chief’s Fusion™ Series Carts and Stands. DO NOT attempt to install this shelf onto any other cart or... - Page 7 Installation Instructions FCA613 Hang shelf support (B or C) onto top screw installed in Step NOTE: The exact holes to use will depend on the model of the 6. (See Figure 5) mounting system. Refer to Figure 7 to determine which holes to use.
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
