I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
XPAU Dual Monitor Extension
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
Accessory
FCA623
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CHIEF FCA623
Summary of Contents for CHIEF FCA623
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Accessory XPAU Dual Monitor Extension Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA623...
-
Page 2: Installation Instructions
WARNING: RISK OF SERIOUS INJURY OR DEATH! Relocating audio and/or video equipment to the cart may Chief® is a registered trademark of Milestone AV Technologies. result in the cart collapsing or overturning onto a child. DO All rights reserved. NOT relocate audio and/or video equipment to the cart! - Page 3 Installation Instructions FCA623 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 4: Tools Required For Installation
FCA623 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8” (included) 3/16” (included) 1/2” PARTS A (2) [Left upright] B (2) [Right upright] H (2) [Hardware bag B - quantities listed per bag] HD (4) HE (4) HA (4) HB (4) HC (4) C (1) 1/4”... -
Page 5: Assembly And Installation
Remove four nuts holding interface head assembly to XPAU column assembly to remove head assembly. (See Figure 3) The FCA623 is specifically designed to convert Chief’s XPAU carts into 2x1 monitor mounting systems. Do not attempt to install the FCA623 onto any other mounting device! Remove two Phillips screws and right side cover from right side of XPAU interface head assembly. - Page 6 Figure 5 Slide two of four connecting brackets from XPAU head assembly into corresponding groove on FCA623 interface. (See Figure 5) Align four connecting brackets with outside four holes on tilt plate. (See Figure 5) Use four nuts removed in Step 4 to secure tilt plate to new head assembly.
-
Page 7: Display Installation
Installation Instructions FCA623 Display Installation Place display face down on a soft, non-abrasive surface. CAUTION: Using screws of improper length may damage your display! Proper screws will have adequate thread NOTE: For best access, route display cables through columns engagement without contacting bottom of display mounting prior to display installation. - Page 8 250 lbs (113.4 kg) or 125 lbs (56.7 kg) per display after the FCA623 accessory has been installed to the XPAU. Hang interface brackets (A and B) to display rails. (See Figure 8) Use 1/4-20 x 1 1/4”...
-
Page 9: Height Adjustment
Installation Instructions FCA623 Adjustments Height Adjustment Use upper knob on back of interface brackets (A and B) to adjust the height of each display. (See Figure 11) NOTE: Adjust both brackets in order to maintain a level mount. Plumb Adjustment... - Page 10 FCA623 Installation Instructions...
- Page 11 Installation Instructions FCA623...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
