Summary of Contents for CHIEF Fusion FCA802

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Below Cart/Ceiling Below Wall Fusion™ Below Component Shelf Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
  • Page 2: Important Safety Instructions

    Milestone assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document. Chief® is a registered trademark of Milestone AV Technologies. All rights reserved. IMPORTANT SAFETY INSTRUCTIONS WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions.
  • Page 3: Installation Instructions

    Installation Instructions FCA802 DIMENSIONS FUSION WALL BELOW MOUNT SETUP 12.9-15.2 [327.7-386.1] MIN RANGE 15.2-17.7 [386.1-449.6] INTERMEDIATE RANGE 17.7-19.2 (*)NOTES: 18.0 • TYPICAL FUSION INTERFACES ARE 0.625" [15.9] DEEP 457.2 FUSION CEILING BELOW MOUNT SETUP 17.8 453.4 12.4-14.3 [315.0-363.2] OVERALL MIN MIN RANGE 14.3-16.8 24.8...
  • Page 4: Tools Required For Installation

    FCA802 Installation Instructions LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier Serrez les fixations Tournevis à pointe cruciforme Loosen Fastener Open-Ended Wrench Aflojar elemento de fijación Llave de boca...
  • Page 5: Assembly And Installation

    Installation Instructions FCA802 ASSEMBLY AND INSTALLATION Attaching Shelf to Wall Mount NOTE: NOTE: FCA802 shelves may ONLY be installed below If attaching to cart or ceiling mount, proceed to Attach displays. Shelf to Cart/Ceiling Section. Assembling Shelf to Upright Bracket Use two 1/4-20 x 1/4”...
  • Page 6 FCA802 Installation Instructions NOTE: Refer to Table 1 and dimension drawings on page 3 to determine the extension level based on extension (Below wall - minimum) distance from mount center. Below Wall Mount Table 1: Extension distance from center of mount (in.) holes to use for intermediate 12.9-15.2...
  • Page 7 Installation Instructions FCA802 Slide second shelf bracket (C) underneath head assembly, Slide two 3/5” spacers (K) in between shelf bracket (C) and lining up holes on shelf bracket (C) to holes on main bracket main bracket (B). (See Figure 10) (B).
  • Page 8 FCA802 Installation Instructions NOTE: Refer to Table 2 and dimension drawings on page 3 to determine the extension level based on extension (Below Cart/Ceiling Minimum) distance from mount center. (rear view) Table 2: Below Cart/Ceiling Mount Extension distance from center of mount (in.) 12.4-14.3 Minimum 14.3-16.8...
  • Page 9 Installation Instructions FCA802 Installing Components (not included) WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight mounted on the FCA802 does not exceed 20 lbs (9 kg). WARNING: Components must be secured to FCA802 shelf using either adhesive hook and loop squares (T) or screw...
  • Page 10 FCA802 Installation Instructions...
  • Page 11 Installation Instructions FCA802...
  • Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief, a products division of Asia Pacific A Office No. 918 on 9/F, Shatin Galleria Milestone AV Technologies 18-24 Shan Mei Street...
