I N S T A L L A T I O N I N S T R U C T I O N S
FCASFP
FMSIML
FMSITL
Menu Board Interface Kits
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCASFP / FMSIML / FMSITL
Advertisement
Related Manuals for CHIEF FMSITL
Summary of Contents for CHIEF FMSITL
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S FCASFP FMSIML FMSITL Menu Board Interface Kits Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCASFP / FMSIML / FMSITL...
- Page 2 Do not use attachments not ACCESSORY: AN ACCESSORY is the secondary Chief recommended by the manufacturer. product which is attached to a primary Chief product, and may have a component attached or setting on it. WARNING: Never operate this accessory if it is damaged.
- Page 3 Installation Instructions FCASFP / FMSIML / FMSITL DIMENSIONS FCASFP 12.50 317.5 DIMENSIONS: INCHES [MILLIMETERS] LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella...
- Page 4 FCASFP / FMSIML / FMSITL Installation Instructions TOOLS REQUIRED FOR INSTALLATION - FCASFP 3/8" PARTS - FCASFP DISPLAY ATTACH HARDWARE BAG (Letters correspond to letters on bag) A (4) D (4) B (4) C (4) M4x12mm M4x20mm M5x12mm M4x25mm E (4)
- Page 5 Installation Instructions FCASFP / FMSIML / FMSITL INSTALL INTERFACE BRACKETS TO IMPORTANT ! : The M8 screws do NOT require a washer. Use the universal washer (N) ONLY with M4, M5 DISPLAYS and M6 screws. Raise the latch mechanism on both interface brackets (R •...
- Page 6 FCASFP / FMSIML / FMSITL Installation Instructions ATTACH DISPLAYS TO MOUNTING RAIL Adjust tilt as required. (See Figure 5) The tilt may be locked at 0°, 10° and 20° using one 10-24 x 5/8" Phillips head screw (P) and one 10-24 lock nut (Q) per interface bracket.
- Page 7 FCASFP / FMSIML / FMSITL Installation Instructions DIMENSIONS FMSIML 2.54 1.59 64.6 40.5 1.75 44.5 0.63 3/4" TOTAL 15.9 0.49 HEIGHT ADJUST 12.5 6.00 3/4" TOTAL 152.4 IN/OUT ADJUSTMENT 1.97 50.0 7.87 200.0 2.41 15.75 61.1 400.0 3/4" TOTAL IN/OUT ADJUSTMENT 0.69...
- Page 8 Installation Instructions FCASFP / FMSIML / FMSITL TOOLS REQUIRED FOR INSTALLATION - FMSIML 3/16" PARTS - FMSIML DISPLAY ATTACH HARDWARE BAG (Letters correspond to letters on bag) A (4) B (4) M6 x 12mm C (4) D (4) M6 x 16mm M6 x 30mm 1/4"...
- Page 9 Installation Instructions FCASFP / FMSIML / FMSITL INSTALL INTERFACE BRACKETS TO Select screw length: (See Figure 6) DISPLAYS • By hand, insert SHORTEST length screw of selected diameter (A or F) through 1/4" washer Place displays face down on a soft, non-abrasive surface.
- Page 10 FCASFP / FMSIML / FMSITL Installation Instructions ATTACH DISPLAYS TO MOUNTING RAIL Interface Bracket Adjustment WARNING: CAUTION: ALWAYS keep a small distance between IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL screens when making adjustments! Damage to screens possible if placed too close together.
- Page 11 Installation Instructions FCASFP / FMSIML / FMSITL DIMENSIONS FMSITL 1.83 46.6 2.67 0.92 67.8 23.3 2.10 0.50 0.49 TYP. 53.4 12.7 20° 12.5 4.05 103.0 5.73 145.7 7.87 200.0 14.23 361.6 16.75 5.00 425.5 15.75 127.0 400.0 2.04 HOLES FOR FIXING TILT AT 0°, 10°, &...
- Page 12 Installation Instructions FCASFP / FMSIML / FMSITL TOOLS REQUIRED FOR INSTALLATION - FMSITL 3/8" 1/8" (included) M5 (included) PARTS - FMSITL DISPLAY ATTACH HARDWARE BAG (Letters correspond to letters on bag) C (6) A (8) D (6) B (6) Q (2)
- Page 13 Installation Instructions FCASFP / FMSIML / FMSITL INSTALL INTERFACE BRACKETS TO NOTE: The diamond-shape hole in the bracket corresponds to the vertical center of the mount. DISPLAYS Use selected screws (A-K), universal washers (N-if required) Lower the latch mechanism on each interface bracket (R).
- Page 14 FCASFP / FMSIML / FMSITL Installation Instructions ATTACH DISPLAYS TO MOUNTING RAIL WARNING: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The displays must be located approximately evenly across the length of the rail.
- Page 15 Installation Instructions FCASFP / FMSIML / FMSITL Interface Bracket Adjustment OPTIONAL: Security OPTIONAL: Add padlock (not included) to each interface bracket to lock display to menu board. (See Figure 14) CAUTION: ALWAYS keep a small distance between screens when making adjustments! Damage to screens possible if placed too close together.
- Page 16 FCASFP / FMSIML / FMSITL Installation Instructions USA/International A 6436 City West Parkway, Eden Prairie, MN 55344 P 800.582.6480 / 952.225.6000 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845...
