- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S (FCAC3X1M) Fusion Back Covers Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCAC SERIES...
-
Page 2: Important Safety Instructions
ACCESSORY: AN ACCESSORY is the secondary Chief --SAVE THESE INSTRUCTIONS-- product which is attached to a primary Chief product, and may have a component attached or setting on it. COMPONENT: A COMPONENT is an audiovisual item designed to be attached or resting on an accessory or mounting system such as a video camera, CPU, screen, display, projector, etc. - Page 3 Installation Instructions FCAC SERIES DIMENSIONS FCAC1L FCAC1X...
- Page 4 FCAC SERIES Installation Instructions DIMENSIONS (CONTINUED) FCAC2X1M FCAC2X1L...
- Page 5 Installation Instructions FCAC SERIES DIMENSIONS (CONTINUED) FCAC3X1M FCAC3X1L...
- Page 6 FCAC SERIES Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 7: Tools Required For Installation
Installation Instructions FCAC SERIES TOOLS REQUIRED FOR INSTALLATION 3/16" PARTS (QUANTITIES SHOWN = FCAC1L/1X/2X1M/2X1L/3X1M/3X1L) A (1/1/1/1/1/1) [Fabric cover] [FCAC1L cover shown) B (0/0/1/1/1/1) [Center frame] C (2/2/2/2/2/2) [Outside frame] D (0/1/2/2/3/3) E (0/1/1/1/1/1) [Upright w/o flag] [Upright w/flag] G (8/8/12/12/16/16) #12-24 x 3/8"... -
Page 8: Assembly And Installation
Use four #12-24 x 3/8" Phillips tapping screws (G) to secure LCM upright (H) to two center joiner tubes (F). (See Figure IMPORTANT ! : The FCAC Series frames can be assembled at a variety of widths in 2" increments using... - Page 9 Installation Instructions FCAC SERIES NOTE: Example shown (See Figure 7) is to assemble a maximum length frame. Frame can be made shorter (carts/stands installation) and must be shorter for FCAC2X1M. (P) x 4 Use two #12-24 x 3/8" Phillips tapping screws (G) to secure upright (with flag) (E) to center frame (B).
- Page 10 FCAC SERIES Installation Instructions FCAC3X1M/FCAC3X1L Fabric Cover Installation Slide together two outside frames (C), two extension frames Wrap fabric cover (A) over assembled frame. (See Figure (M) and center frame (B). (See Figure 9) (FCAC2X1M shown) (C) x 2 (M) x 2...
- Page 11 Installation Instructions FCAC SERIES Installation to Display Mount FCAC1X/FCAC2X1M/FCAC2X1L/ FCAC3X1M/FCAC3X1L FCAC1L Lift assembled cover onto top edge of mounting rail. (See Use four 5/16-18 x 3/4" button head cap screws (K) to Figure 15) secure LCM upright adapter (J) to back of LCM mount. (See...
- Page 12 FCAC SERIES Installation Instructions USA/International A 6436 City West Parkway, Eden Prairie, MN 55344 P 800.582.6480 / 952.225.6000 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 8800-003061 Rev01 2019 Legrand...
