M U
ODEM SE WITH THE
C
ONFERENCE
C
OMPOSER
O S
N ITE WITH THE
V
ORTEX
Figure 19. Modem settings on Conference Composer O
© Polycom, Inc.
V
You will need Conference Composer version 1.62 or later. You can find the latest
version of the software on our website at www.aspi.com, on the Vortex page.
At the local site with the Vortex, use Conference Composer to enable the modem to
auto answer:
1. On the O page, choose the default initialization string from the I
PTIONS
S pull-down menu. If a default is not listed, enter the following
IZATION TRING
string:
ATE0F1&B1S0=2
2. Enable the initialization string by clicking on the E
3. Disconnect the RS-232 cable from the Vortex and connect it to your modem.
You may need to use a null modem for your modem. Connect your modem to the
Vortex.
4. Cycle power on the Vortex. As it powers up, it will send the initialization string
to the modem. Make sure the modem is On before cycling power on the Vortex.
If you don't have Conference Composer on site,
1. Using a terminal program, send the following strings to the Vortex:
F**MINISTRATF1E0&B1S0=2
F**MINI1
This will enter the initialization string and enable it.
2. Disconnect the RS-232 cable from the Vortex and connect it to your modem.
You may need to use a null modem for your modem. Connect your modem to the
Vortex.
3. Cycle power on the Vortex. As it powers up, it will send the initialization string
to the modem. Make sure the modem is On before cycling power.
25
M
ODEM
ORTEX
page.
PTIONS
Conference Composer User Guide
U V
SE WITH THE ORTEX
NITIAL
button.
NABLE
-
