Introduction
Marine
generator sets
Operator's manual
7 GS/GSC
8 GSA/GSAC
8 GT/GTC
10 GTA/GTAC
10 GS/GSC
12 GSA/GSAC
11 GT/GTC
14 GTA/GTAC
U_CTGR2663_EN
Revision 1
Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.soleDiesel.com · info@soleDiesel.com
Operator's Manual Marine Diesel Gensets
U_GFAU_EN
Revision 7
14 GS/GSC
17 GSA/GSAC
17 GT/GTC
20 GTA/GTAC
20 GS/GSC
25 GSA/GSAC
25 GT/GTC
30 GTA/GTAC
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7 GS and is the answer not in the manual?

Questions and answers

Related Manuals for Sole Diesel 7 GS

Summary of Contents for Sole Diesel 7 GS

  • Page 1 Introduction Marine generator sets Operator’s manual 7 GS/GSC 14 GS/GSC 8 GSA/GSAC 17 GSA/GSAC 8 GT/GTC 17 GT/GTC 10 GTA/GTAC 20 GTA/GTAC 10 GS/GSC 20 GS/GSC 12 GSA/GSAC 25 GSA/GSAC 11 GT/GTC 25 GT/GTC 14 GTA/GTAC 30 GTA/GTAC U_CTGR2663_EN Revision 1 Solé, S.A.

  • Page 3: Introduction

    Introduction Introduction Presentation Dear Customer, First, we would like to thank you for choosing a Solé Diesel product. We recommend that you read this manual carefully before carrying out any of the operations and keep it close at hand, near the genset, as it can be of great use in the future.

  • Page 4: Table Of Contents

    Table of contents Table of contents Introduction ..............................2 Table of contents ............................3 Safety precautions and instructions......................6 Solé Diesel warranty ........................... 9 Section 1 – Genset Information ......................12 1.1. Genset Identification....................... 12 1.2. Genset parts identification ..................... 13 Section 2 –...
  • Page 5 Table of contents Circuit description ..........................28 Fuel specifications ..........................28 Maintenance task. Fuel level inspection..................28 Maintenance task. Fuel tank clean ....................28 Maintenance task. Water separator filter purge ................28 Maintenance task. Fuel filter change ....................29 Maintenance task. Injection pump inspection................29 Maintenance task.
  • Page 6 Table of contents 9.1. Wiring diagrams ........................64 9.2. Alternator connections......................73 Connection’s type 1 .......................... 73 Connection Type 2 ..........................74 Connection Type 3 ..........................75 9.3. Regulator connections ......................76 Connection Type 1 ..........................76 Connection Type 2 ..........................76 Connection type 3..........................

  • Page 7: Safety Precautions And Instructions

    Safety precautions and instructions Safety precautions and instructions Solé Diesel is concerned for your safety and your machine’s condition. Safety Precautions and Instructions are one of the primary ways to call your attention to the potential hazards associated with our engine operation. Follow the precautions listed throughout the manual before and during operation and maintenance procedures for your safety, the safety of others and the performance of your engine.
  • Page 8 Safety precautions and instructions Carbon monoxide (CO) can cause severe nausea, fainting or death. Engine exhaust gases contains carbon monoxide gas. Carbon monoxide is an odourless, colourless, tasteless, no irritating gas that can cause death if inhaled for even a short time. Get fresh air and do not sit, lie down or fall asleep if anyone shows signs of carbon monoxide poisoning: - Light-headedness, dizziness - Physical fatigue, weakness in joints and muscles.
  • Page 9 Safety precautions and instructions Engine labels If the engine does not start after several attempts to crank may cause water entering the engine. In this situation it is recommended: 1) Close the seacock. 2) Drain the water from the exhaust system in the water trap.

  • Page 10: Solé Diesel Warranty

    Solé Diesel warranty Solé Diesel warranty Read the manual and documents delivered with each engine before carrying out any of the operations or presenting any queries. The engine is supplied without any liquids. Ensure that the liquids used match the specifications contained in Solé Diesel manuals. The application of the conditions described in this document shall only be effective for engines or generator sets that have been invoiced after November 4, 2011.
  • Page 11 Solé Diesel warranty Restrictions Coverage: a) To validate the warranty is necessary fill and send the inspection prior to the delivery of propulsion engines or genset to Solé Diesel through an official installer. See SECTION 11. b) The warranty covers any failure of the product under normal opera- ting conditions caused by a defect in manufacturing.
  • Page 12 Solé Diesel warranty Responsibilities Responsibilities of the manufacturer: The obligations of Solé Diesel are restricted to repairing the defective parts or, IF DEEMED APPROPRIATE BY Solé Diesel, returning the amount of the purchase or replacing the parts to prevent poor operation resulting from defective materials or faults in the manufacture covered by the warranty. Solé...

  • Page 13: Section 1 - Genset Information

    Solé Diesel warranty Section 1 – Genset Information 1.1. Genset Identification Identification label The nameplate is located above the rocker cover. The characteristics plate of genset it’s located above the alternator case. The characteristics plate of canopy genset it’s located outside, as shown in the following picture: GENSET SERIAL NUMBER: In addition, all gensets are marked with the serial number on the block, on the fuel injection pump.

  • Page 14: Genset Parts Identification

    Solé Diesel warranty 1.2. Genset parts identification Gensets: 7GSC / 8 GSCAC / 10 GTAC / 10 GSC / 11 GTC / 12 GSAC PIECE ELEMENT Oil filter Oil dipstick Oil filler Oil outlet pipe Fuel filter Oil drain plug Injection pump Electrical fuel pump Injectors...
  • Page 15 Solé Diesel warranty Gensets: 14 GTAC / 14 GSC / 17 GSAC / 17 GTC / 20 GTAC PIECE ELEMENT Oil filter Oil dipstick Oil fill cap Oil drain tube Fuel filter Relay set Fuel pump Electrical fuel pump Injectors Air inlet elbow Wet exhaust elbow Air filter...
  • Page 16 Solé Diesel warranty Gensets: 19 GSC / 20 GTC / 20 GSC / 25 GTC / 23 GSAC / 25 GTAC / 25 GSAC / 30 GTAC PIECE ELEMENT Oil filter Oil level stick Oil fill cap Oil drain tube Fuel filter Drain cap Governor...

  • Page 17: Section 2 - Transport, Handling And Storage

    Transport, handling and storage Section 2 – Transport, Handling and Storage 2.1. Reception When the genset is delivered make sure that the packing has not been damaged during transport and that it has not been tampered with or that components inside the packing have been removed (see information marked on covers, bases and cartons).

  • Page 18: Transporting And Handling The Unpacked Genset

    Transport, handling and storage 2.3. Transporting and Handling the Unpacked Genset When the genset is unpacked and ready for transport, use EXCLUSIVELY the appropriate lifting eyebolts. For gensets: 8 GTC / 10 GTAC / 7 GSC / 8 GSAC 11 GTC / 14 GTAC / 10 GSC / 12 GSAC / 17 GTC / 20 GTAC / 14 GSC / 17 GSAC / 25 GTC / 30 GTAC / 20 GSC / 25 GSAC 2.4.

  • Page 19: Section 3 - Installation

    Installation Section 3 – Installation 3.1. Angle of Installation Make sure the genset is installed on a level surface. Otherwise, the following angular operation maximum is permitted: Continuously Temporary 8 GTC / 10 GTAC / 7 GSC / 8 GSAC / 11 GTC / 14 GTAC 25º...

  • Page 20: Section 4 - Operation

    Installation Section 4 – Operation 4.1. Prestart checklist Follow these checks and inspections to ensure the correct genset operation. In addition, some checks require verification after unit starts. AIR CLEANER: Check for a clean and installed air cleaner element to prevent unfiltered air from entering the genset.

  • Page 21: Winterzation And Preservation

    Installation 4. Cover battery with an adequate material to protect it against the cold. Check that the battery is fully charged. It is also advisable to use a dielectric spray on the electrical connections. 5. When starting the genset, make sure that the glow plugs become hot enough. 6.

  • Page 22: Maintenance During The Storage

    Installation 4.4. Maintenance during the storage During the long genset storage, it has to be stored inside a ventilated area and free of humidity. When the genset stay stopped for 3 months or more, inside parts can be oxidize and lost the oil film.

  • Page 23: Section 5 - Systems And Scheduled Maintenance

    Systems and scheduled maintenance Section 5 – Systems and Scheduled Maintenance 5.1. Operating Description Information of special tools required and basic safety precautions. Disassembly: ✓ Use the correct tools and instruments. Serious injury or damage to the genset can result from using the wrong tools and instruments.
  • Page 24 Systems and scheduled maintenance Intervals Every Every Every Every 2 Winter storage and Inspection Item Daily 1st 20h-50h Every year 200h 400h 800h years Preservation Screw tightening, fastening. Engine block. General Valve clearance. Exhaust gas, noise and vibrations. Compression pressure. Lubrication Genset oil.

  • Page 25: General

    Systems and scheduled maintenance 5.3. General Solé Diesel offers several maintenance packs for its gensets, you can find more information about on the website: • Welcome pack. • On board pack. • 50 hours Maintenance pack • 1600 hours Maintenance pack •...

  • Page 26: Maintenance Task. Compression Pressure Inspection

    Systems and scheduled maintenance Maintenance task. Compression pressure inspection Start by: 1. Make sure the genset oil level, air cleaner, starting motor battery well- conditioned. 2. Start the genset and allow it to warm up thoroughly, until 50ºC or more coolant temperature.

  • Page 27: Lubrication System

    Systems and scheduled maintenance 5.4. Lubrication System Circuit description The lubrication circuit is forced by the trochoid gear pump, and it is composed of the following elements. PIECE ELEMENT Main gallery Oil pump Oil strainer Oil pan Oil filter Pressure relief valve *Oil circuit capacity (L) 8 GTC / 10 GTAC / 7 GSC / 8 GSAC 11 GTC / 14 GTAC / 10 GSC / 12 GSAC...

  • Page 28: Maintenance Task. Oil Level Check

    Systems and scheduled maintenance Maintenance task. Oil level check Check the oil level in the crankcase daily or before each start-up to ensure that the level is between the upper (Max mark) and lower (Min mark) lines on the dipstick. To check the oil level: 1.

  • Page 29: Fuel System

    Systems and scheduled maintenance 5.5. Fuel System Circuit description The fuel system is based on a fuel feed pump and an in-line mechanical injection pump. PIECE ELEMENT Fuel injection nozzle Fuel injection pipe Fuel leak-off pipe Injection pump Feed fuel pump Fuel filter Tank (Not supplied) Fuel decanting filter (supplied...

  • Page 30: Maintenance Task. Fuel Filter Change

    Systems and scheduled maintenance 3. Check for any leakage. Maintenance task. Fuel filter change Procedure to change the fuel filter: 1. Close the fuel supply valve. 2. Disconnect fuel pipes from the fuel filter. 3. Remove fuel filter with a bell key. 4.

  • Page 31: Maintenance Task. Bleeding Air From The Fuel System

    Systems and scheduled maintenance 6. Look at the orifice discharge pattern (shape of discharge) when fluid begins to flow through the injection nozzle. The discharge must be finely and uniformly atomized. Any change is an indication of a bad nozzle. 7.

  • Page 32: Cooling System

    Systems and scheduled maintenance 5.6. Cooling system The genset cooling system is based on coolant circulation controlled by centrifugal pump with thermostatic control and heat exchanger, where the coolant is refrigerated by sea water. Moreover, the exhaust manifold is cooled also by sea water. Coolant circuit description Seawater circuit description PIECE ELEMENT...

  • Page 33: Maintenance Task. Coolant Fill / Change

    Systems and scheduled maintenance Maintenance task. Coolant fill / change 1. Drain off all the coolant by opening the two drain plugs, one in the heat exchanger and the other in the cylinder block. 2. Close the drain plugs. 3. Remove bleeding bolt of thermostat holder. 4.

  • Page 34: Maintenance Task. Zinc Anode Inspection

    Systems and scheduled maintenance Maintenance task. Zinc anode inspection In order to avoid the corrosion produced by galvanic currents, the genset is fitted with a zinc anode located on the front lid of the coolant-seawater heat exchanger. Anticorrosion zinc anode inspection and replacement: 1.

  • Page 35: Maintenance Task. Air Filter Inspection

    Systems and scheduled maintenance Type 1 installation. When between water injection point of wet exhaust and waterline is minimum 150 mm. Type 2 installation. When between water injection point of wet exhaust and waterline there is less than 150 mm or the point of injection is below waterline. The wet exhaust is the genset’s standard equipment.

  • Page 36: Maintenance Task. Exhaust Gas, Noise And Vibrations Inspection

    Systems and scheduled maintenance Maintenance task. Exhaust gas, noise and vibrations inspection Inspect the exhaust system components for cranks, leaks and corrosion. Exhaust system inspection points 1. Check the hoses for softness, cranks or dents. Replace the hoses as needed. 2.
  • Page 37 Systems and scheduled maintenance Function table Coolant temperature sensor specifications (two pole) Temperature Resistance Tolerance Operating voltage: 6-24V (ºC) (ohm) (ohm) Operating current: <85mA, Pmax<0.25W 287.4 ±32.8 Operating temperature: -40°C to +120°C ±13.5 Measuring range: -40°C to +120°C 69.1 ±6.5 Absolute max.

  • Page 38: Battery

    Systems and scheduled maintenance Battery The minimum recommended capacity is from 55-120 Ah. However, this value serves as a general reference since it relates to the maximum intensity it can offer for starting the generator set. The connection of the battery for a standard engine: •...

  • Page 39: Maintenance Task. Starter Motor Inspection

    Systems and scheduled maintenance Maintenance task. Starter motor inspection 1. Check if there is any impurity in pinion teeth. 2. Make sure that the pinion shaft turns freely when turned in the direction of driving (clockwise) and it is locked when turned in the opposite direction.

  • Page 40: Maintenance Task. Control Of Bearings

    Systems and scheduled maintenance Maintenance task. Control of bearings During maintenance control the condition of the bearing and check that no grease has leaked: the lifespan of the bearings depends on the vibrations and axial strains they undergo (vibrations can increase considerably with a bad alignment) and on the working conditions.

  • Page 41: Section 6 - Troubleshooting

    If a fault occurs in the genset, proceed as follows: ➢ Within the period of warranty: Contact to Sole Diesel Official Service. See Solé Diesel WARRANTY. ➢ Outside the period of warranty: Contact to Sole Diesel Official Service. See Solé Diesel WARRANTY.
  • Page 42 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Replace the fuse in the installation. If fuse blows again, check Power cable fuse (red). electrical system for overloads or short circuits. Discharged or empty battery. Charge the battery or replace it with a new one. ELECTRICAL SYSTEM Loose or corroded battery connections.
  • Page 43 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS GENERAL The fuel regulator is not operational. Contact an Official Solé Diesel Service. Faulty or clogged fuel pump Check fuel pump inlet. Clogged fuel filter Replace fuel filter. FUEL SYSTEM Air in fuel system Bleed fuel system.
  • Page 44 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Strangled oil pressure-relief valve Clean the valve and check its operation. OIL PRESSURE TOO Faulty oil pressure valve Contact an Official Solé Diesel Service. LUBRICATION SYSTEM HIGH. Oil level too high. Reset oil level. Obstruction of oil lines.
  • Page 45 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Faulty coolant water pump. Check coolant pump (impeller, pump sealing). Clean the tap, check if the salt water pump impeller is Plugged or restricted-pitch salt water tap. damaged. Faulty salt water pump. Check sea water pump (impeller, pump sealing).
  • Page 46 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS CA open output breaker. Close the CA output breaker. Open wiring, terminals or exciter field pin. Check continuity. The main field (rotor) is not operational (open or Test and/or replace alternator assembly. earthed).

  • Page 47: Section 7 - Technical Specifications

    Technical specifications Section 7 – Technical specifications Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 48 MARINE GENERATORS 7 GS/GSC Single-Phase General data Maximum power*: 6,6 kW (6,6 kVA) Voltage: 230 V Prime Power**: 6 kW Amperage: 28,7 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 757 mm Total lenght with canopy:...
  • Page 49 MARINE GENERATORS 8 GSA/GSAC Single-Phase General data Maximum power*: 8 kW (8 kVA) Voltage: 240 V Prime Power**: 7,3 kW Amperage: 33,3 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 757 mm Total lenght with canopy: 892 mm Total width without canopy: 560 mm...
  • Page 50 MARINE GENERATORS 8 GT/GTC Three-Phase General data Maximum power*: 6,2 kW (7,8 kVA) Voltage: 400/230 V Prime Power**: 5,7 kW Amperage: 11,3 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 757 mm Total lenght with canopy: 892 mm Total width without canopy: 560 mm...
  • Page 51 MARINE GENERATORS 10 GTA/GTAC Three-Phase General data Maximum power*: 7,5 kW (9,4 kVA) Voltage: 480/277 V Prime Power**: 6,8 kW Amperage: 11,3 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 757 mm Total lenght with canopy: 892 mm Total width without canopy: 560 mm...
  • Page 52 MARINE GENERATORS 10 GS/GSC Single-Phase General data Maximum power*: 9,4 kW (9,4 kVA) Voltage: 230 V Prime Power**: 8,5 kW Amperage: 40,9 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 885 mm Total lenght with canopy: 1032 mm Total width without canopy: 580 mm...
  • Page 53 MARINE GENERATORS 12 GSA/GSAC Single-Phase General data Maximum power*: 12 kW (12 kVA) Voltage: 240 V Prime Power**: 10,9 kW Amperage: 50 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 885 mm Total lenght with canopy: 1032 mm Total width without canopy: 580 mm...
  • Page 54 MARINE GENERATORS 11 GT/GTC Three-Phase General data Maximum power*: 8,4 kW (10,5 kVA) Voltage: 400/230 V Prime Power**: 7,6 kW Amperage: 15,2 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 885 mm Total lenght with canopy: 1032 mm Total width without canopy: 580 mm...
  • Page 55 MARINE GENERATORS 14 GTA/GTAC Three-Phase General data Maximum power*: 10,9 kW (13,6 kVA) Voltage: 480/277 V Prime Power**: 9,9 kW Amperage: 16,4 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 885 mm Total lenght with canopy: 1032 mm Total width without canopy: 580 mm...
  • Page 56 MARINE GENERATORS 14 GS/GSC Single-Phase General data Maximum power*: 13,9 kW (13,9 kVA) Voltage: 230 V Prime Power**: 12,6 kW Amperage: 60,4 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1036 mm Total lenght with canopy: 1181 mm Total width without canopy: 580 mm...
  • Page 57 MARINE GENERATORS 17 GSA/GSAC Single-Phase General data Maximum power*: 16,4 kW (16,4 kVA) Voltage: 240 V Prime Power**: 14,9 kW Amperage: 68,3 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1036 mm Total lenght with canopy: 1181 mm Total width without canopy: 580 mm...
  • Page 58 MARINE GENERATORS 17 GT/GTC Three-Phase General data Maximum power*: 13,1 kW (16,4 kVA) Voltage: 400/230 V Prime Power**: 11,9 kW Amperage: 23,7 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1036 mm Total lenght with canopy: 1181 mm Total width without canopy: 580 mm...
  • Page 59 MARINE GENERATORS 20 GTA/GTAC Three-Phase General data Maximum power*: 15,6 kW (19,5 kVA) Voltage: 480/277 V Prime Power**: 14,2 kW Amperage: 23,5 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1036 mm Total lenght with canopy: 1181 mm Total width without canopy: 580 mm...
  • Page 60 MARINE GENERATORS 20 GS/GSC Single-Phase General data Maximum power*: 20,1 kW (20,1 kVA) Voltage: 230 V Prime Power**: 18,3 kW Amperage: 87,4 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1140 mm Total lenght with canopy: 1310 mm Total width without canopy: 610 mm...
  • Page 61 MARINE GENERATORS 25 GSA/GSAC Single-Phase General data Maximum power*: 25,1 kW (25,1 kVA) Voltage: 240 V Prime Power**: 22,8 kW Amperage: 104,6 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1140 mm Total lenght with canopy: 1310 mm Total width without canopy: 610 mm...
  • Page 62 MARINE GENERATORS 25 GT/GTC Three-Phase General data Maximum power*: 19,4 kW (24,3 kVA) Voltage: 400/230 V Prime Power**: 17,7 kW Amperage: 35,1 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1140 mm Total lenght with canopy: 1310 mm Total width without canopy: 610 mm...
  • Page 63 MARINE GENERATORS 30 GTA/GTAC Three-Phase General data Maximum power*: 24 kW (30 kVA) Voltage: 480/277 V Prime Power**: 21,8 kW Amperage: 36,1 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1140 mm Total lenght with canopy: 1310 mm Total width without canopy: 610 mm...

  • Page 64: Section 8 - Tightening Torques

    Tightening torques Section 8 – Tightening torques Important nuts and bolts: 8 GTC / 10 GTAC / 7 GSC / 8 TIGHTENING VALUES THREAD N · m (k gf · m ) 73.5 to 83.4 (7.5 to 8.5) Cylinder head 4.9 to 6.9 (0.5 to 0.7) Rocker cover 98.1 to 117.7 (10.0 to 12.0)

  • Page 65: Section 9 - Technical Appendices

    Technical appendices Section 9 – Technical Appendices 9.1. Wiring diagrams Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 66 ARRANQUE / CRANKING OPT. DETALLE RELE BUJIAS PRECALENTAMIENTO / PREHEATING RELAY BOMBA DE ALIMENTACIÓN DE CUMBUSTIBLE / STD. CANOPY FUEL FEED PUMP PARO DE EMERGENCIA EMERGENCY STOP 85/86 N.C. CONTACT Diodos 25 A ALTERNADOR / ALTERNATOR DETALLE RELE DE ARRANQUE / STARTER RELAY MOTOR DE ARRANQUE / STARTER CPC PIN 2...
  • Page 67 DETAIL STOP SOLENOID CONNECRTOR TRANSMISOR DE PRESIÓN / PRESSURE SENSOR N.S. [G-8M-3(X)] / [G-15M-3 / 7 GS-GSC / 8 GSA-GSAC] / [10 GS-GSC MODELO GRUPO / GENSET MODEL: / 12 GSA-GSAC] / [G-25M-3 / 14 GS-GSC / 17 GSA-GSAC] CONEXIONADO GENERADOR / MONOFÁSICO / SINGLE-PHASE...
  • Page 68 ARRANQUE / CRANKING OPT. STD. CANOPY PARO DE EMERGENCIA EMERGENCY STOP N.C. CONTACT Diodos 25 A ALTERNADOR / ALTERNATOR DETALLE PIN L ALTERNADOR / DETAIL PIN L ALTERNATOR MOTOR DE ARRANQUE / STARTER DETALLE RELE DE ARRANQUE / STARTER RELAY CPC PIN 2 85/86 CPC PIN 12...
  • Page 69 ARRANQUE / CRANKING OPT. STD. CANOPY DETALLE RELE BUJIAS PRECALENTAMIENTO / PREHEATING RELAY PARO DE EMERGENCIA EMERGENCY STOP N.C. CONTACT 85/86 Diodos 25 A ALTERNADOR / ALTERNATOR DETALLE RELE DE ARRANQUE / STARTER RELAY MOTOR DE ARRANQUE / STARTER DETALLE PIN L ALTERNADOR / DETAIL PIN L ALTERNATOR CPC PIN 2 CPC PIN 12 Negro/Black...
  • Page 70 BOMBA DE ALIMENTACIÓN DE CUMBUSTIBLE Precalentamiento Arranque Relé desconexión de tierra / FUEL FEED PUMP Preheating Cranking Earth disconnecting relay BB0A DETALLE RELE BUJIAS PRECALENTAMIENTO / PREHEATING RELAY 85/86 Diodos 25 A Diodos 2,5 A MOTOR DE ARRANQUE / STARTER OPT.
  • Page 71 TRANSMISOR DE PRESIÓN / PRESSURE SENSOR N.S. N.S. [G-8M-3] / [G-15M-3 / 7 GS-GSC / 8 GSA-GSAC] / [10 GS-GSC / MODELO GRUPO / GENSET MODEL: 12 GSA-GSAC] / [G-25M-3 / 14 GS-GSC / 17 GSA-GSAC] ISOLATED CONEXIONADO GENERADOR / MONOFÁSICO / SINGLE-PHASE...
  • Page 72 Precalentamiento Arranque Relé desconexión de tierra Preheating Cranking Earth disconnecting relay BB0A DETALLE RELE BUJIAS PRECALENTAMIENTO / PREHEATING RELAY 85/86 Diodos 25 A Diodos 2,5 A MOTOR DE ARRANQUE / STARTER OPT. STD. CANOPY EMERGENCY STOP N.C. CONTACT DETALLE RELE DE ARRANQUE / STARTER RELAY C.I.
  • Page 73 Precalentamiento Arranque Relé desconexión de tierra Preheating Cranking Earth disconnecting relay DETALLE RELE BUJIAS PRECALENTAMIENTO / PREHEATING RELAY BB0A 85/86 Diodos 25 A Diodos 2,5 A MOTOR DE ARRANQUE / STARTER OPT. DETALLE RELE DE ARRANQUE / STD. CANOPY STARTER RELAY EMERGENCY STOP N.C.

  • Page 74: 9.2. Alternator Connections

    Technical appendices 9.2. Alternator connections According to genset model, consult the alternator’s connection: • Connection type 1: Meccalte alternator 1 • Connection type 2: Meccalte alternator 3 • Connection type 3: Sincro alternator Connection’s type 1 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets.

  • Page 75: Connection Type 2

    Technical appendices Connection Type 2 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 76: Connection Type 3

    Technical appendices Connection Type 3 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 77: 9.3. Regulator Connections

    Technical appendices 9.3. Regulator connections According to genset model, consult the regulator’s connection: • Connection type 1: Meccalte alternator 1 • Connection type 2: Meccalte alternator 3 • Connection type 3: Sincro alternator Connection Type 1 Connection Type 2 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets.

  • Page 78: Connection Type 3

    Technical appendices Connection type 3 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 79: 9.4. Overall Dimensions

    Technical appendices 9.4. Overall dimensions Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 80 (ONLY DRY EXHAUST) SEA WATER INLET (Ø20) FUEL INLET (Ø8) FUEL OUTLET (Ø6) GRUPO 7 GS - 7 GSC / 8 GSA - 8 GSAC GENSET 7 GS - 7 GSC / 8 GSA - 8 GSAC MATERIAL ACABADO ESCALA TRATAMIENTO PRESENTACIÓN...
  • Page 81 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 49.3 756.3 (8 GT / 10 GTA) (8 GTC / 10 GTAC) VIEW D VIEW C FIRE EXTINGUISHER GENERATOR AIR INLET AC BREAKER ACCESS HOLE EMERGENCY STOP CUSTOMER LOAD LEAD ACCES CUSTOMER PANEL CONNECTION EQUIPMENT GROUND...
  • Page 82 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 44.5 885.5 (10 GS / 12 GSA) (10 GSC / 12 GSAC) VIEW C VIEW D FIRE EXTINGUISHER GENERATOR AIR INLET ACCESS HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION EQUIPMENT GROUND...
  • Page 83 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 44.5 885.5 (11 GT / 14 GTA) (11 GTC / 14 GTAC) VIEW C VIEW D FIRE EXTINGUISHER GENERATOR AIR INLET ACCESS HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION EQUIPMENT GROUND...
  • Page 84 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM-OPTIONAL KIT) 31.4 1029.4 (14 GS / 17 GSA) (14 GSC / 17 GSAC) view C view D AC BREAKER GENERATOR FIRE EXTINGUISHER ACCESS HOLE AIR INLET EMERGENCY STOP CUSTOMER LOAD LEAD ACCES CUSTOMER PANEL CONNECTION EQUIPMENT GROUND CONNECTION...
  • Page 85 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM-OPTIONAL KIT) 31.4 1029.4 (17 GT / 20 GTA) (17 GTC / 20 GTAC) view C view D AC BREAKER GENERATOR FIRE EXTINGUISHER ACCESS HOLE AIR INLET EMERGENCY STOP CUSTOMER LOAD LEAD ACCES CUSTOMER PANEL CONNECTION EQUIPMENT GROUND CONNECTION...
  • Page 86 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 1095 23.5 1139.5 (20 GSC / 25 GSAC) (20 GS / 25 GSA) VIEW B VIEW C GENERATOR AIR INLET FIRE EXTINGUISHER ACCESS HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION EQUIPMENT GROUND...
  • Page 87 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 1095 23.5 1139.5 (25 GTC / 30 GTAC) (25 GT / 30 GTA) VIEW B VIEW C GENERATOR AIR INLET FIRE EXTINGUISHER ACCESS HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION EQUIPMENT GROUND...

  • Page 88: Section 10 - Instructions To Replace And Remove

    Instructions to replace and remove Section 10 – Instructions to replace and remove When you decide to replace the genset, please contact Solé Diesel S.A.; will provide relevant instructions regarding the laws in force at the time. When disposing of the whole or parts of this genset, meets LAWS IN FORCE IN THE COUNTRY OF INSTALLATION.

  • Page 89: Section 11 - Inspection Prior To The Delivery Of Generator Sets

    Inspection prior to the delivery of generator sets Section 11 – Inspection prior to the delivery of generator sets Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 90 Inspection prior to the delivery of generator sets Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 91: Section 12 - Maintenance Log

    Maintenance log Section 12 - Maintenance log DATE HOURS DESCRIPTION SERVICE NAME Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 92 Maintenance log DATE HOURS DESCRIPTION SERVICE NAME Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 94 U_CTGR2663_EN Revision 1 07/2022...

This manual is also suitable for:

7 gsc8 gsa8 gsac8 gt8 gtc10 gta ... Show all

Table of Contents
