  • Page 1 Introduction Marine generator sets Operator’s manual 29 GS/GSC 32 GSA/GSAC 35 GT/GTC 40 GTA/GTAC 45 GT/GTC 54 GTA/GTAC 50 GT/GTC 60 GTA/GTAC 68 GT/GTC 84 GTA/GTAC U_CTGR7481_EN Revision 1 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.soleDiesel.com · info@soleDiesel.com Operator’s Manual Marine Diesel Gensets...

  • Page 3: Introduction

    Introduction Introduction Presentation Dear Customer, First, we would like to thank you for choosing a Solé Diesel product. We recommend that you read this manual carefully before carrying out any of the operations and keep it close at hand, near the genset, as it can be of great use in the future.

  • Page 4: Table Of Contents

    Table of contents Table of contents Introduction ............................2 Table of contents ..........................3 Safety precautions and instructions ..................... 6 Engine labels ............................8 Solé Diesel warranty ..........................9 Section 1 – Genset Information ......................12 1.1. Genset Identification....................... 12 1.2.
  • Page 5 Table of contents 5.5. Fuel System ..........................29 Circuit description ..........................29 Fuel specifications ..........................29 Maintenance task. Fuel level inspection..................29 Maintenance task. Fuel tank clean ....................29 Maintenance task. Water separator filter purge ................29 Maintenance task. Fuel filter change ....................30 Maintenance task.
  • Page 6 Table of contents Section 9 – Technical Appendices ..................... 59 9.1. Wiring diagrams ........................59 9.2. Alternator connections......................64 Connection’s type 1 .......................... 64 Connection Type 2 ..........................65 Connection Type 3 ..........................66 9.3. Regulator connections ......................67 Connection Type 1 ..........................67 Connection Type 2 ..........................

  • Page 7: Safety Precautions And Instructions

    Safety, precautions and instructions Safety precautions and instructions Solé Diesel is concerned for your safety and your machine’s condition. Safety Precautions and Instructions are one of the primary ways to call your attention to the potential hazards associated with our engine operation. Follow the precautions listed throughout the manual before and during operation and maintenance procedures for your safety, the safety of others and the performance of your engine.
  • Page 8 Safety, precautions and instructions Carbon monoxide (CO) can cause severe nausea, fainting or death. Engine exhaust gases contains carbon monoxide gas. Carbon monoxide is an odourless, colourless, tasteless, no irritating gas that can cause death if inhaled for even a short time. Get fresh air and do not sit, lie down or fall asleep if anyone shows signs of carbon monoxide poisoning: - Light-headedness, dizziness - Physical fatigue, weakness in joints and muscles.

  • Page 9: Engine Labels

    Safety, precautions and instructions Engine labels If the engine does not start after several attempts to crank may cause water entering the engine. In this situation it is recommended: 1) Close the seacock. 2) Drain the water from the exhaust system in the water trap.

  • Page 10: Solé Diesel Warranty

    Sole Diesel warranty Solé Diesel warranty Read the manual and documents delivered with each engine before carrying out any of the operations or presenting any queries. The engine is supplied without any liquids. Ensure that the liquids used match the specifications contained in Solé Diesel manuals.
  • Page 11 Sole Diesel warranty Restrictions Coverage: a) To validate the warranty is necessary fill and send the inspection prior to the delivery of propulsion engines or genset to Solé Diesel through an official installer. See SECTION 11. b) The warranty covers any failure of the product under normal opera- ting conditions caused by a defect in manufacturing.
  • Page 12 Sole Diesel warranty Responsibilities Responsibilities of the manufacturer: The obligations of Solé Diesel are restricted to repairing the defective parts or, IF DEEMED APPROPRIATE BY Solé Diesel, returning the amount of the purchase or replacing the parts to prevent poor operation resulting from defective materials or faults in the manufacture covered by the warranty.

  • Page 13: Section 1 - Genset Information

    Genset information Section 1 – Genset Information 1.1. Genset Identification Identification label The nameplate is located above the rocker cover. The characteristics plate of genset it’s located above the alternator case. The characteristics plate of canopy genset it’s located outside, as shown in the following picture: GENSET SERIAL NUMBER: In addition, all gensets are marked with the serial number on the block, on the fuel injection pump.

  • Page 14: Genset Parts Identification

    Genset information 1.2. Genset parts identification Gensets 29 GSC / 35 GTC / 32 GSAC / 40 GTAC: PIECE ELEMENT Oil filter Oil dipstick Oil filler plug Oil drain pipe Fuel filter Manual priming pump Injection pump Fuel pump Injectors Air inlet elbow Wet exhaust elbow Relay set...
  • Page 15 Genset information Gensets 45 GTC / 54 GTAC: PIECE ELEMENT Turbocharger Cooler body Coolant drain plug DC alternator V-Belt Silentblocks Starter assy Genset chasis Silentblocks Coolant drain plug Fuel filter Injection pipe Injection pump Seawater pump Manual priming pump Oil filter Oil drain tube Oil dipstick AC alternator...
  • Page 16 Genset information Gensets 50 GTC / 60 GTAC: PIECE ELEMENT Oil filter Oil dipstick Oil filler plug Oil drain pipe Fuel filter Priming pump Oil drain plug Fuel pump Injectors Air inlet elbow Wet exhaust elbow Relay set Air filter Seawater pump Raw water pump Cooler body...
  • Page 17 Genset information Gensets 68 GTC / 84 GTAC: PIECE ELEMENT Oil filter Oil dipstick Oil filler plug Oil drain pipe Fuel filter Priming pump Fuel pump Fuel feed pump Injectors Air inlet elbow Wet exhaust elbow Turbocharger Air filter Seawater pump Raw water pump Cooler body Anode...

  • Page 18: Section 2 - Transport, Handling And Storage

    Transport, handling and storage Section 2 – Transport, Handling and Storage 2.1. Reception When the genset is delivered make sure that the packing has not been damaged during transport and that it has not been tampered with or that components inside the packing have been removed (see information marked on covers, bases and cartons).

  • Page 19: Transporting And Handling The Unpacked Genset

    Transport, handling and storage 2.3. Transporting and Handling the Unpacked Genset When the genset is unpacked and ready for transport, use EXCLUSIVELY the appropriate lifting eyebolts. For gensets 29 GSC / 32 GSAC / 35 GTC / For gensets 68 GTC / 84 GTAC: 40 GTAC / 45 GTC/54 GTC/ 50 GTC/60 GTAC: 2.4.

  • Page 20: Section 3 - Installation

    Installation Section 3 – Installation 3.1. Angle of Installation Make sure the genset is installed on a level surface. Otherwise, the following angular operation maximum is permitted: Continuously Temporary 29 GSC / 32 GSAC / 35 GTC / 40 GTAC / 45 GTC / 54 15º...

  • Page 21: Section 4 - Operation

    Operation Section 4 – Operation 4.1. Prestart checklist Follow these checks and inspections to ensure the correct genset operation. In addition, some checks require verification after unit starts. AIR CLEANER: Check for a clean and installed air cleaner element to prevent unfiltered air from entering the genset.

  • Page 22: Winterzation And Preservation

    Operation 4. Cover battery with an adequate material to protect it against the cold. Check that the battery is fully charged. It is also advisable to use a dielectric spray on the electrical connections. 5. When starting the genset, make sure that the glow plugs become hot enough. 6.

  • Page 23: Maintenance During The Storage

    Operation 4.4. Maintenance during the storage During the long genset storage, it has to be stored inside a ventilated area and free of humidity. When the genset stay stopped for 3 months or more, inside parts can be oxidize and lost the oil film.

  • Page 24: Section 5 - Systems And Scheduled Maintenance

    Systems and scheduled maintenance Section 5 – Systems and Scheduled Maintenance 5.1. Operating Description Information of special tools required and basic safety precautions. Disassembly: ✓ Use the correct tools and instruments. Serious injury or damage to the genset can result from using the wrong tools and instruments.
  • Page 25 Systems and scheduled maintenance Intervals Every Every Every Every 2 Winter storage and Inspection Item Daily 1st 20h-50h Every year 200h 400h 800h years Preservation Screw tightening, fastening. Engine block. General Valve clearance. Exhaust gas, noise and vibrations. Compression pressure. Lubrication Genset oil.

  • Page 26: General

    Systems and scheduled maintenance 5.3. General Solé Diesel offers several maintenance packs for its gensets, you can find more information about on the website: • Welcome pack. • On board pack. • 50 hours Maintenance pack • 1600 hours Maintenance pack •...

  • Page 27: Maintenance Task. Compression Pressure Inspection

    Systems and scheduled maintenance Maintenance task. Compression pressure inspection Start by: 1. Make sure the genset oil level, air cleaner, starting motor battery well- conditioned. 2. Start the genset and allow it to warm up thoroughly, until 50ºC or more coolant temperature.

  • Page 28: Lubrication System

    Systems and scheduled maintenance 5.4. Lubrication System Circuit description The lubrication circuit is forced by the trochoid gear pump, and it is composed of the following elements. PIECE ELEMENT Main gallery Oil pump Oil strainer Oil pan Oil filter Pressure relief valve *Oil circuit capacity (L) 29 GSC / 32 GSAC /35 GTC / 40 GTAC / 45 GTC / 54 GTAC...

  • Page 29: Maintenance Task. Oil Level Check

    Systems and scheduled maintenance Maintenance task. Oil level check Check the oil level in the crankcase daily or before each start-up to ensure that the level is between the upper (Max mark) and lower (Min mark) lines on the dipstick. To check the oil level: 1.

  • Page 30: Fuel System

    Systems and scheduled maintenance 5.5. Fuel System Circuit description The fuel system is based on a fuel feed pump and an in-line mechanical injection pump. PIECE ELEMENT Fuel injection nozzle Fuel injection pipe Fuel leak-off pipe Injection pump Feed fuel pump Fuel filter Tank (supplied as accessory) Fuel decanting filter (supplied...

  • Page 31: Maintenance Task. Fuel Filter Change

    Systems and scheduled maintenance 3. Check for any leakage. Maintenance task. Fuel filter change Procedure to change the fuel filter: 1. Close the fuel supply valve. 2. Disconnect fuel pipes from the fuel filter. 3. Remove fuel filter with a bell key. 4.

  • Page 32: Maintenance Task. Bleeding Air From The Fuel System

    Systems and scheduled maintenance 6. Look at the orifice discharge pattern (shape of discharge) when fluid begins to flow through the injection nozzle. The discharge must be finely and uniformly atomized. Any change is an indication of a bad nozzle. 7.

  • Page 33: Cooling System

    Systems and scheduled maintenance 5.6. Cooling system The genset cooling system is based on coolant circulation controlled by centrifugal pump with thermostatic control and heat exchanger, where the coolant is refrigerated by sea water. Moreover, the exhaust manifold is cooled also by sea water. Coolant circuit description Seawater circuit description PIECE ELEMENT...

  • Page 34: Maintenance Task. Coolant Fill / Change

    Systems and scheduled maintenance Maintenance task. Coolant fill / change 1. Drain off all the coolant by opening the two drain plugs, one in the heat exchanger and the other in the cylinder block. 2. Close the drain plugs. 3. Remove bleeding bolt of thermostat holder. 4.

  • Page 35: Maintenance Task. Zinc Anode Inspection

    Systems and scheduled maintenance Maintenance task. Zinc anode inspection In order to avoid the corrosion produced by galvanic currents, the genset is fitted with a zinc anode located on the front lid of the coolant-seawater heat exchanger. Anticorrosion zinc anode inspection and replacement: 1.

  • Page 36: Maintenance Task. Air Filter Inspection

    Systems and scheduled maintenance Type 1 installation. When between water injection point of wet exhaust and waterline is minimum 150 mm. Type 2 installation. When between water injection point of wet exhaust and waterline there is less than 150 mm or the point of injection is below waterline. The wet exhaust is the genset’s standard equipment.

  • Page 37: Maintenance Task. Exhaust Gas, Noise And Vibrations Inspection

    Systems and scheduled maintenance Maintenance task. Exhaust gas, noise and vibrations inspection Inspect the exhaust system components for cranks, leaks and corrosion. Exhaust system inspection points 1. Check the hoses for softness, cranks or dents. Replace the hoses as needed. 2.
  • Page 38 Systems and scheduled maintenance Function table Coolant temperature sensor specifications (two pole) Temperature Resistance Tolerance Operating voltage: 6-24V (ºC) (ohm) (ohm) Operating current: <85mA, Pmax<0.25W 287.4 ±32.8 Operating temperature: -40°C to +120°C ±13.5 Measuring range: -40°C to +120°C 69.1 ±6.5 Absolute max.

  • Page 39: Battery

    Systems and scheduled maintenance Battery The minimum recommended capacity is from 55-120 Ah. However, this value serves as a general reference since it relates to the maximum intensity it can offer for starting the generator set. The connection of the battery for a standard engine: •...

  • Page 40: Maintenance Task. Starter Motor Inspection

    Systems and scheduled maintenance Maintenance task. Starter motor inspection 1. Check if there is any impurity in pinion teeth. 2. Make sure that the pinion shaft turns freely when turned in the direction of driving (clockwise) and it is locked when turned in the opposite direction.

  • Page 41: Maintenance Task. Control Of Bearings

    Systems and scheduled maintenance Maintenance task. Control of bearings During maintenance control the condition of the bearing and check that no grease has leaked: the lifespan of the bearings depends on the vibrations and axial strains they undergo (vibrations can increase considerably with a bad alignment) and on the working conditions.

  • Page 42: Section 6 - Troubleshooting

    If a fault occurs in the genset, proceed as follows: ➢ Within the period of warranty: Contact to Sole Diesel Official Service. See Solé Diesel WARRANTY. ➢ Outside the period of warranty: Contact to Sole Diesel Official Service. See Solé Diesel WARRANTY.
  • Page 43 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Replace the fuse in the installation. If fuse blows again, check Power cable fuse (red). electrical system for overloads or short circuits. Discharged or empty battery. Charge the battery or replace it with a new one. ELECTRICAL SYSTEM Loose or corroded battery connections.
  • Page 44 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS GENERAL The fuel regulator is not operational. Contact an Official Solé Diesel Service. Faulty or clogged fuel pump Check fuel pump inlet. Clogged fuel filter Replace fuel filter. FUEL SYSTEM Air in fuel system Bleed fuel system.
  • Page 45 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Strangled oil pressure-relief valve Clean the valve and check its operation. OIL PRESSURE TOO Faulty oil pressure valve Contact an Official Solé Diesel Service. LUBRICATION SYSTEM HIGH. Oil level too high. Reset oil level. Obstruction of oil lines.
  • Page 46 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS Faulty coolant water pump. Check coolant pump (impeller, pump sealing). Clean the tap, check if the salt water pump impeller is Plugged or restricted-pitch salt water tap. damaged. Faulty salt water pump. Check sea water pump (impeller, pump sealing).
  • Page 47 Troubleshooting GENSET FAILURE SYSTEM PROBABLE CAUSES RECOMMENDED ACTIONS CA open output breaker. Close the CA output breaker. Open wiring, terminals or exciter field pin. Check continuity. The main field (rotor) is not operational (open or Test and/or replace alternator assembly. earthed).

  • Page 48: Section 7 - Technical Specifications

    Technical specifications Section 7 – Technical specifications Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 49 MARINE GENERATORS 29 GS/GSC Single-Phase General data Maximum power*: 28,4 kW (28,4 kVA) Voltage: 230 V Prime Power**: 25,8 kW Amperage: 123,5 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1437 mm Total lenght with canopy:...
  • Page 50 MARINE GENERATORS 35 GT/GTC Three-Phase General data Maximum power*: 28 kW (35 kVA) Voltage: 400/230 V Prime Power**: 25,5 kW Amperage: 50,5 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1308 mm Total lenght with canopy: 1445 mm Total width without canopy: 630 mm...
  • Page 51 MARINE GENERATORS 32 GSA/GSAC Single-Phase General data Maximum power*: 31,6 kW (31,6 kVA) Voltage: 240 V Prime Power**: 28,7 kW Amperage: 131,7 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1437 mm Total lenght with canopy: 1600 mm Total width without canopy: 740 mm...
  • Page 52 MARINE GENERATORS 40 GTA/GTAC Three-Phase General data Maximum power*: 31,2 kW (39 kVA) Voltage: 480/277 V Prime Power**: 28,4 kW Amperage: 46,9 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1308 mm Total lenght with canopy: 1445 mm Total width without canopy: 630 mm...
  • Page 53 MARINE GENERATORS 50 GT/GTC Three-Phase General data Maximum power*: 39,1 kW (48,9 kVA) Voltage: 400/230 V Prime Power**: 35,6 kW Amperage: 70,6 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1680 mm Total lenght with canopy: 1875 mm Total width without canopy: 841 mm...
  • Page 54 MARINE GENERATORS 60 GTA/GTAC 240V Three-Phase General data Maximum power*: 46,6 kW (58,3 kVA) Voltage: 240 V Prime Power**: 42,3 kW Amperage: 140 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1675 mm Total lenght with canopy: 1875 mm Total width without canopy: 840 mm...
  • Page 55 MARINE GENERATORS 45 GT/GTC Three-Phase General data Maximum power*: 36 kW (45 kVA) Voltage: 400/230 V Prime Power**: 32,7 kW Amperage: 65 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1428 mm Total lenght with canopy: 1605 mm Total width without canopy: 740 mm...
  • Page 56 MARINE GENERATORS 54 GTA/GTAC Three-Phase General data Maximum power*: 42,8 kW (53,5 kVA) Voltage: 480/277 V Prime Power**: 38,9 kW Amperage: 64,4 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1428 mm Total lenght with canopy: 1605 mm Total width without canopy: 740 mm...
  • Page 57 MARINE GENERATORS 68 GT/GTC Three-Phase General data Maximum power*: 54,7 kW (68,4 kVA) Voltage: 400/230 V Prime Power**: 49,7 kW Amperage: 98,7 A Frequency: 50 Hz Phases: Dimensions and weights Total lenght without canopy: 1723 mm Total lenght with canopy: 1903 mm Total width without canopy: 700 mm...
  • Page 58 MARINE GENERATORS 84 GTA/GTAC Three-Phase General data Maximum power*: 66,9 kW (83,6 kVA) Voltage: 480/277 V Prime Power**: 60,8 kW Amperage: 100,6 A Frequency: 60 Hz Phases: Dimensions and weights Total lenght without canopy: 1723 mm Total lenght with canopy: 1903 mm Total width without canopy: 700 mm...

  • Page 59: Section 8 - Tightening Torques

    Tightening torques Section 8 – Tightening torques Important nuts and bolts: 29 GSC / 32 GSAC / 35 GTC / 40 GTAC / 45 GTC/ 54 TIGHTENING VALUES THREAD GTAC/ 50 GTC/ 60 GTAC/ 68 GTC/ 84 GTAC N · m (kgf · m) Cylinder head M12 x 1.75 113 to 123 (11.5 to 12.5)

  • Page 60: Section 9 - Technical Appendices

    Technical appendices remove Section 9 – Technical Appendices 9.1. Wiring diagrams Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 61 TRANSMISOR DE TEMPERATURA / TEMPERATURE SENSOR CPC PIN 16 Negro-Blanco/Black-White / From alternator Phase L1 TRANSMISOR DE PRESIÓN / PRESSURE SENSOR N.S. MODELO GRUPO / GENSET MODEL: 29 GS-GSC / 32 GSA-GSAC N.S. CONEXIONADO GENERADOR / MONOFÁSICO / SINGLE-PHASE GENSET CONEXION: LEYENDA / LEGEND:...
  • Page 62 ARRANQUE / CRANKING OPT. STD. CANOPY PARO DE EMERGENCIA EMERGENCY STOP N.C. CONTACT DETALLE RELE DE ARRANQUE Y BUJIAS DE PRECALENTAMIENTO / STARTER RELAY AND PREHEATIN RELAY ALTERNADOR / ALTERNATOR MOTOR DE ARRANQUE / STARTER Diodo 25 A DETALLE PIN L ALTERNADOR / DETAIL PIN L ALTERNATOR CPC PIN 2 CPC PIN 12 Negro/Black...
  • Page 63 Negro-Blanco/Black-White / From Alternator Phase L1 TRANSMISOR DE PRESIÓN / PRESSURE SENSOR N.S. N.S. MODELO GRUPO / GENSET MODEL: 29 GS-GSC / 32 GSA-GSAC LIBRE MASA-ISOLATED CONEXIONADO GENERADOR / MONOFÁSICO / SINGLE-PHASE GENSET CONEXION: LEYENDA / LEGEND: MODELO MOTOR / ENGINE MODEL:...
  • Page 64 Precalentamiento Arranque Relé desconexión de tierra Preheating Cranking Earth disconnecting relay DETALLE RELE BUJIAS PRECALENTAMIENTO 24V / PREHEATING RELAY 24V BB0A 85/86 Diodos 25 A Diodos 2,5 A DETALLE PIN L ALTERNADOR / MOTOR DE ARRANQUE / STARTER OPT. DETAIL PIN L ALTERNATOR STD.

  • Page 65: 9.2. Alternator Connections

    Technical appendices remove 9.2. Alternator connections According to genset model, consult the alternator’s connection: • Connection type 1: Meccalte alternator 1 • Connection type 2: Meccalte alternator 3 • Connection type 3: Sincro alternator Connection’s type 1 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets.

  • Page 66: Connection Type 2

    Technical appendices remove Connection Type 2 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 67: Connection Type 3

    Technical appendices remove Connection Type 3 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 68: Regulator Connections

    Technical appendices remove 9.3. Regulator connections According to genset model, consult the regulator’s connection: • Connection type 1: Meccalte alternator 1 • Connection type 2: Meccalte alternator 3 • Connection type 3: Sincro alternator Connection Type 1 Connection Type 2 Solé, S.A.

  • Page 69: Connection Type 3

    Technical appendices remove Connection type 3 Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 70: 9.4. Overall Dimensions

    Technical appendices remove 9.4. Overall dimensions Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 71 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM - OPTIONAL KIT) 1385 1422.5 (29 GSC / 32 GSAC) (29 GS / 32 GSA) VIEW A VIEW D FIRE EXTINGUISHER FAN INSIDE GENERATOR AIR INLET ACCESS HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD...
  • Page 72 WET EXHAUST (G-35T-15) 1230 1382 (35 GT / 40 GTA) 1230 1308 SIPHON BREAK CONNECTIONS VIEW B (AIR VENT SYSTEM - OPTIONAL KIT) 177.5 532.5 (35 GTC / 40 GTAC) VIEW D VIEW A VIEW C GENERATOR AIR INLET FIRE EXTINGUISHER FAN INSIDE ACCESS HOLE AC BREAKER...
  • Page 73 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM-OPTIONAL KIT) 16.24 26.8 1660 (50 GTC / 60 GTAC) 1667 (50 GT / 60 GTA) VIEW C VIEW B FAN INSIDE FIRE EXTINGUISHER GENERATOR AIR INLET ACCES HOLE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION...
  • Page 74 FIRE EXTINGUISHER ACCES HOLE (45 GT / 54 GTA) 1395 1428 AIR OUTLET (45 GTC / 54 GTAC) FAN INSIDE AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION EQUIPMENT GROUND CONNECTION BATTERY CONNECTIONS WET EXHAUST OUTLET (Ø76) 1600 1525 LEAKS COOLANT...
  • Page 75 SIPHON BREAK CONNECTIONS (AIR VENT SYSTEM-OPTIONAL KIT) 1600 1682 (68 GTC / 84 GTAC) (68 GT / 84 GTA) VIEW B VIEW C AC BREAKER EMERGENCY STOP CUSTOMER LOAD LEAD ACCESS CUSTOMER PANEL CONNECTION AIR OUTLET BATTERY CONNECTIONS WET EXHAUST OUTLET (Ø88,9) 1800 1903...

  • Page 76: Section 10 - Instructions To Replace And Remove

    Instructions to replace and remove Section 10 – Instructions to replace and remove When you decide to replace the genset, please contact Solé Diesel S.A.; will provide relevant instructions regarding the laws in force at the time. When disposing of the whole or parts of this genset, meets LAWS IN FORCE IN THE COUNTRY OF INSTALLATION.

  • Page 77: Section 11 - Inspection Prior To The Delivery Of Generator Sets

    Inspection prior to the delivery of generator sets Section 11 – Inspection prior to the delivery of generator sets Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 78 Inspection prior to the delivery of generator sets Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.

  • Page 79: Section 12 - Maintenance Log

    Maintenance log Section 12 - Maintenance log DATE HOURS DESCRIPTION SERVICE NAME Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 80 Maintenance log DATE HOURS DESCRIPTION SERVICE NAME Solé, S.A. C-243 b, km 2 · 08760 Martorell (Barcelona) ·Tel. +34 93 775 14 00 · www.solediesel.com · info@solediesel.com Marine Diesel gensets. Operator’s Manual.
  • Page 82 U_CTGR7481_EN Revision 1 07/2022...
