● Word7: Deceleration
Word Bit Signal name
7 0-15 Deceleration
● Word8: Pushing force
Word Bit Signal name
Pushing force
8 0-15
(Thrust setting value)
● Word9: Trigger LV
Word Bit Signal name
9 0-15. Trigger LV
● Word10: Pushing speed
Word Bit Signal name
10 0-15 Pushing speed
● Word 11: Moving force
Word Bit Signal name
11 0-15 Moving force
● Word12, 13: AREA 1
Word Bit Signal name
12 0-15
AREA 1 (Lower digits) Basic parameter
13 0-15 AREA 1 (Upper digits)
● Word14, 15: AREA 2
Word Bit Signal name
14 0-15 AREA 2 (Lower digits) Basic parameter
15 0-15 AREA 2 (Upper digits)
● Word16, 17: In-Position
Word Bit Signal name
16 0-15 In-Position(Lower digits)
17 0-15 In-Position(Upper digits)
5 Please refer to 21. Handling of sent/received data (P.83) for handling of the data.
7 Change the numerical data input flag and the numerical data only when the start flag is OFF. If the
numerical data input flag or the numerical data are changed when the start flag is ON, it may lead to
unexpected operation.
11 The actuator model determines the limit for the input values. Please refer to the manual of the
actuator for more details.
Input range
1 ~ Basic parameters
"Maximum deceleration speed" (7, 11)
Input range
(7, 11)
Input range
(7, 11)
Input range
(7, 11)
Input range
(7, 11)
Input range
"Stroke (-)" - "Stroke (+)" (5, 7, 11)
Input range
"Stroke (-)" - "Stroke (+)" (5, 7, 11)
Input range
(5, 7, 11)
-40-
Description
1 mm/s
Description
1%
Description
1%
Description
1 mm/s
Description
1%
Description
0.01 mm
Description
0.01 mm
Description
0.01 mm
No.SFOD-OMT0006-F
Min. unit
2
Min. unit
Min. unit
Min. unit
Min. unit
Min. unit
Min. unit
Min. unit
