- Page 1 User’s Manual HE-840 Half-size ISA-bus Embedded 5x86-133 CPU Card with AMD Am5x86-133 MHz CPU, 8 MB EDO DRAM, Flat Panel / CRT SVGA, 10/100 Mbps LAN Interfaces, Four Serial Ports and DiskOnChip Socket...
- Page 2 HE-840 User’s Manual Version 1.0 © Copyright 2002,. All rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
- Page 3 Packing List Hardware HE-840VL CPU Card ............X 1 Cable Kit IDE Flat Cable..............X 1 FDD Cable ............... X 1 DB25 LPT Port Cable............X 1 Dual DB9 COM Port Cable..........X 2 Printed Matter and Software User’s Manual ..............X 1 Driver Disk Kit ..............
-
Page 4: Table Of Contents
Table of Contents Introduction..........2 Chapter 1. Product Overview ............2 Specifications ............... 3 Component Placement..........6 Hardware Setup..........7 Chapter 2. Connectors and Jumpers Location ....... 7 Jumpers Settings ............8 Connectors..............9 Switches & Indicators Pin Assignment......10 LCD Connector Pin Assignment ......... -
Page 5: Chapter 1. Introduction
Chapter 1. Introduction 1.1 Product Overview The HE-840 Single Board Computer is an all-in-one industrial half-size ISA-bus CPU card. It integrated with embedded AMD Am5x86-133 CPU and 8 MB of EDO DRAM, PCI-based flat panel / CRT SVGA, 10/100 Mbps Fast Ethernet interfaces, 4 serial ports and DiskOnChip embedded flash disk socket. -
Page 6: Specifications
RTC. CMOS data backup of BIOS setup and BIOS default. ! Keyboard and Mouse Connectors: External 6-pin mini DIN for PS/2 Mouse on bracket External 6-pin mini DIN for PS/2 Keyboard on bracket Onboard 5-pin box header connector for AT keyboard HE-840 User’s Manual... - Page 7 15-pin D-sub connector on bracket for CRT Flash Disk DiskOnChip 2000 Package : Single Chip Flash Disk in 32-pin DIP JEDEC Capacity : up to 288 MB Data Reliability : ECC/EDC error correction Memory Window : 8 KByte HE-840 User’s Manual...
- Page 8 Power Requirement : +5V (4.75~5.25 V) @ 1.8A typical (onboard CPU and EDORAM), +/-12 V Board Dimension : 185mm x 122mm (L x W) Board Weight : 0.24Kg Operating Temperature : 0 to 60℃ (32 to 140℉) HE-840 User’s Manual...
-
Page 9: Component Placement
1.3 Component Placement HE-840 User’s Manual... -
Page 10: Chapter 2. Hardware Setup
Chapter 2. Hardware Setup 2.1 Connectors and Jumpers Location HE-840 User’s Manual... -
Page 11: Jumpers Settings
IO Check Reset Disable SWDT1 Watchdog Timer Timeout Value Setting Timeout (Seconds) JDOC DiskOnChip Address Setting D000h D800h Disable J485 COM2 RS-232C/485 Mode Selection RS-232C RS-485 JVOLT Flat Panel V Voltage Setting 5 Volt 3.3 Volt Default Setting HE-840 User’s Manual... -
Page 12: Connectors
72-pin SIMM Slot 32-pin DiskOnChip Socket PC104AB/CD PC/104 Connector JFRPN1 Switched and Indicators DB15 Female VGA Port on Bracket PS2_K/B 6-pin MiniDIN PS/2 Keyboard on Bracket PS2_MS 6-pin MiniDIN PS/2 Mouse on Bracket LAN_CON1 RJ45 LAN Port on Bracket HE-840 User’s Manual... -
Page 13: Switches & Indicators Pin Assignment
2.4 Switches & Indicators Pin Assignment HE-840 User’s Manual... -
Page 14: Lcd Connector Pin Assignment
2.5 LCD Connector Pin Assignment Connector : LCD Type : onboard 50-pin box header Signal Signal +12V +12V (LCD) ENAVDD ENAVEE SHFCLK ENABKL HE-840 User’s Manual... -
Page 15: Chapter 3. Bios Setup
The BIOS section of the manual is subject to change without notice and is provided here for reference purpose only. The settings and configurations of the BIOS are current at the time of print, and therefore they may not be exactly the same as that displayed on your screen. HE-840 User’s Manual... -
Page 16: Chapter 4. Driver Installation
BIOS ID then please choose your preferred mode of this installation program: Detect and select your motherboard type automatically. Select motherboard type on your own manually. The CD Driver Disk for Single Board Computer’s Chipset Setup includes drivers for IDE, VGA, and LAN interfaces. HE-840 User’s Manual...
