Commell HS-871P User Manual

Half-size single board computer
Hide thumbs

Advertisement

Quick Links

Download this manual
HS-871P
Half-size Single Board Computer
User's manual
Edition 1.2
2005/3/25

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS-871P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commell HS-871P

Summary of Contents for Commell HS-871P

  • Page 1 HS-871P Half-size Single Board Computer User’s manual Edition 1.2 2005/3/25...
  • Page 2 HS-871P User’s Manual Preface Copyright © Copyright 2004 - 2005. All rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products.

  • Page 3: Cable Kit

    HS-871P User’s Manual Packing List Hardware: HS-871P Single Board Computer x 1 Cable Kit: Floppy flat cable x 1 40-pin ATA100 IDE flat cable x 1 DB25 & DB9 cable with bracket x 1 Dual USB cable with bracket x 1...
  • Page 4 HS-871P User’s Manual Index Index Chapter1 <Introductions>................7 1.1 <Product Overview> ................7 1.2 <Product Specification> ..............8 1.3 <Component Placement>..............10 1.4 <Block Diagram> ................11 Chapter 2 <Hardware Setup>............... 13 2.1 <Connectors Location> ..............13 2.2 <Jumper Reference> ............... 14 2.3 <Connectors Reference>...
  • Page 5 HS-871P User’s Manual Packing List Chapter 4 <BIOS Setup>................37 Appendix A <I/O ports pin assignment> ............39 A.1 <IDE Port>..................39 A.2 <Floppy Port> ................. 41 A.3 < Parallel Port> ................42 A.4 <Serial Port>................... 43 A.4.1 <External DB9 COM> ............43 A.4.2 <Internal COM2>..............
  • Page 6 HS-871P User’s Manual (This Page is Left for Blank) (This Page is Left for Blank)
  • Page 7 Chapter1 <Introductions> 1.1 <Product Overview> The HS-871P is an all-in-one single board computer with PISA bus. Based on Intel Mobile solutions with 852GM chipset, it is bundled with Intel Mobile Celeron 1.2GHz processor, DDR266 SDRAM up to 1GB of capacity, Intel Extreme Graphics Technology of onboard VGA display interface, AC97 2-channel audio, USB2.0 interface and one Gigabit Ethernet...
  • Page 8 HS-871P User’s Manual Introduction 1.2 <Product Specification> General Specification Form Factor Half-size PISA CPU card Intel Pentium 4 –M / Mobile Celeron Processor Supports up to 1.2GHz Battery Mode is not supported Intel Speed Step Technology is not supported Memory...
  • Page 9 HS-871P User’s Manual Introduction Ethernet Interface Chipset Intel PRO/1000+ LAN interface with Intel 82540EM Type 10Base-T / 100Base-TX/1000Base-T, auto-switching Fast Ethernet Full duplex, IEEE802.3U compliant Connector External RJ45 connector with LED on rear I/O panel Audio Interface Chipset Intel ICH4 with Realtek ALC201A AC97 3D audio codec...
  • Page 10 HS-871P User’s Manual Introduction 1.3 <Component Placement> ICH4 Intel Mobile Celeron 1 x DDR266 DIMM up Processor at 400MHz FSB to 1GB BIOS Intel 82540EM Intel 852GM Gigabit LAN Compact Flash Socket Audio Codec Component Placement...
  • Page 11 HS-871P User’s Manual Introduction 1.4 <Block Diagram> Intel Mobile Celeron 1.2GHz processor 400MHz FSB 1 x 184-pin DDR266 DIMM Up to 1GB LVDS 852GM UltraATA100 ATAPI Devices PCI Bus USB2.0 USB Devices ICH4 Audio AC97 Codec Gigabit Ethernet Controller ISA Bus...
  • Page 12 HS-871P User’s Manual (This Page is Left for Blank) (This Page is Left for Blank)
  • Page 13 HS-871P User’s Manual Hardware Setup Chapter 2 <Hardware Setup> 2.1 <Connectors Location> IDE1 DIMM IDE2 FDD CN_USB CN_LPT CN_COM2 CN_AUDIO CN_DIO CN_PS CN_VGA CN_PWR RJ45 CDIN CN_LVDS COM1 CN_ATKB CN_INV CN_WOL CN_IR Connectors Location...
  • Page 14 HS-871P User’s Manual Hardware Setup 2.2 <Jumper Reference> Jumper Function JRTC CMOS Operating/Clear Setting JCFSEL Compact Flash Addressing Setting JDOM IDE1 Pin-20 voltage setting JVLCD LCD Panel Voltage Setting JLAN Ethernet Controller Enable/Disable Setting JDOM JCFSEL JRTC JVLCD JLAN Jumper Reference...
  • Page 15 HS-871P User’s Manual Hardware Setup 2.3 <Connectors Reference> 2.3.1 <Internal Connectors> Connector Function Remark mPGA479 CPU socket Standard DIMM 184 -pin DDR SDRAM DIMM socket Standard IDE1 40-pin primary IDE connector Standard IDE2 44-pin secondary IDE connector Standard 34-pin floppy connector...
  • Page 16 Hardware Setup 2.4 <System Setup> 2.4.1 <CPU setup> HS-871P has one 479-pin CPU socket to support Intel Pentium 4 –M / Mobile Celeron processor up to 1.2GHz. Please follow the instruction to install the processor well. CPU Socket 1. Use flat-type Screw Driver to 2.
  • Page 17 HS-871P User’s Manual Hardware Setup 2.4.2 <Memory Module setup> HS-871P supports one DDR266 SDRAM up to 1GB of capacity, with non-ECC, un-buffered memory supported. DIMM 104-pin 80-pin Please check the pin number to match the socket side well before installing memory module.
  • Page 18 HS-871P User’s Manual Hardware Setup 2.4.3 <CPU cooler setup> There is a cooler attached with the board package, please follow the instructions to install the cooler on the processor. 1. Remove the sticker of the base. 2. Put the base through the fixing hole of the processor and paste on the solder side. Then put the cooler through the base pillar.
  • Page 19 HS-871P User’s Manual Hardware Setup 2.4.4 <Complete the system installation> After installing the CPU, CPU cooler and the memory module, please slot the main board into PISA slot of the backplane carefully. If you connect an ATX power supply with the backplane, you will need to connect an ATX function cable between the main board and the backplane.
  • Page 20 HS-871P User’s Manual Hardware Setup 2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values.
  • Page 21 HS-871P User’s Manual Hardware Setup 2.6 <Watchdog Timer Setting> The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program. Timeout Value Range...
  • Page 22 DOM (DiskOnModule) or M-systems DiskOnChip IDE Pro flash disk with or without the additional VCC power cable. The HS-871P also supports Compact Flash Card Type I/II interface. The jumper JCFSEL provides you to setup the CF card on master or slave mode.
  • Page 23 Hardware Setup 2.8 <Power and Fan Setup> HS-871P has one 4-pin power input connector expect PISA bus powering; it also has two fan connectors. For ATX function, you should connect the ATX connector on the backplane with CN_PS on HS-871P.
  • Page 24 HS-871P User’s Manual Hardware Setup 2.9 <Display Interface> 2.9.1 <Analog VGA interface> The board is integrated with Intel 852G GMCH chipset built-in Intel Extreme Graphics Technology with Intel Dynamic Video Memory up to 64MBytes shared with system memory. The CRT / analog VGA interface includes one external DB15 female connector on bracket and one 8 x 2-pin header connector on board.
  • Page 25 HS-871P User’s Manual Hardware Setup 2.9.2 <Digital VGA interface> The board provides one 20 x 2-pin LVDS interface for LCD panel, it supports 18/24-bit single/dual channel up to 1600 x 1200 of resolution. The jumper JVLCD can let you select your panel whether supports +5V or +3.3V of voltage, and the CN_INV provides panel...
  • Page 26 HS-871P User’s Manual Hardware Setup Connector: CN_INV Connector: JVLCD Type: 5-pin LVDS Power Header Type: 3-pin Power select Header Description Description +12V LCDVCC VCC3 ENABKL Connector: CN_LVDS Type: onboard 40-pin connector for LVDS connector Connector model: HIROSE DF13-40S Signal Signal...
  • Page 27 HS-871P User’s Manual Hardware Setup LCD installing guide: Prepare a panel, inverter and HS-871P. Inverter LCD panel 870P SBC Please check the datasheet of the panel to see the voltage of the panel, and set the jumper JVLCD to +5V or +3.3V.
  • Page 28 HS-871P User’s Manual Hardware Setup After setup the devices well, you need to select the LCD panel type in the BIOS. The panel type mapping is list below: BIOS panel type selection form For 18-bit color For 24-bit color Output format...
  • Page 29 Hardware Setup 2.10 < Ethernet Network Interface> The HS-871P is integrated with Intel PRO/1000+ Gigabit Ethernet interface at the type of 10Base-T/100Base-TX/100Base-T auto-switching Ethernet with full duplex and IEEE 802.3U compliant. The HS-871P Ethernet interface is controlled by Intel 82540EM, and it provides the external RJ45 connector on rear I/O panel.
  • Page 30 HS-871P User’s Manual Hardware Setup 2.11 <Audio Interface> HS-871P provides a stereo audio interface with Realtek ALC201A AC97 Codec. The CN_AUDIO provides the interface to use attached audio cable, the CDIN can let you connect audio output from CD-ROM drives.
  • Page 31 HS-871P User’s Manual Hardware Setup 2.12 <GPIO interface> The board offers 8-bit digital I/O to customize its configuration to your control needs. For example, you may configure the digital I/O to control the opening and closing of the cash drawer or to sense the warning signal from a tripped UPS. The following is a detailed description of how the digital I/O is controlled via software programming.
  • Page 32 HS-871P User’s Manual Hardware Setup 2.13 <Switch and Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Connector: JFRNT Type: onboard 14-pin (2 x 7) 2.54-pitch header Function Signal Signal Function...
  • Page 33 HS-871P User’s Manual Display Mode Setup Chapter 3 <Display Mode Setup> This chapter shows you how to setup the display device under Windows OS. Before you using your display device: 1. Check your software Before you can use the display device properly, please install the VGA driver.
  • Page 34 HS-871P User’s Manual Display Mode Setup For advanced display settings, please click Advanced… button and choose Intel(R) Extreme Graphics. Please click Graphics Properties button to enter the advanced setup. Display Mode Setup...
  • Page 35 HS-871P User’s Manual Display Mode Setup While you entering the Graphics Properties, you will see the options below: This option can let you configure the CRT monitors for Colors, Screen Area (Resolution) and Refresh Rate. This option can let you configure...
  • Page 36 HS-871P User’s Manual Display Mode Setup This option can let you configure the Dual Display for clone mode (same display on two devices) This option can let you configure the Dual Display for Extended Desktop mode Display Mode Setup...
  • Page 37 HS-871P User’s Manual BIOS Setup Chapter 4 <BIOS Setup> The single board computer uses the Award BIOS for the system configuration. The Award BIOS in the single board computer is a customized version of the industrial standard BIOS for IBM PC AT-compatible computers. It supports Intel x86 and compatible CPU architecture based processors and computers.
  • Page 38 HS-871P User’s Manual (This Page is Left for Blank) (This Page is Left for Blank)
  • Page 39 HS-871P User’s Manual Appendix A Appendix A <I/O ports pin assignment> A.1 <IDE Port> Connector: IDE1 Type: 40-pin (20 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY IDESEL DACK- Ground CBLID CS0 (MASTER CS)
  • Page 40 HS-871P User’s Manual Appendix A Connector: IDE2 Type: 44-pin (22 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground IORDY/DDMARDY Ground DACK- Ground ASP1 Ground Ground Ground IDE Port...
  • Page 41 HS-871P User’s Manual Appendix A A.2 <Floppy Port> Connector: FDD Type: 34-pin (2 x 17) 2.54-pitch header Description Description Ground DRIVE DENSITY SELECT 0 Ground DRIVE DENSITY SELECT 1 Ground Ground INDEX- Ground MOTOR ENABLE A- Ground DRIVER SELECT B-...
  • Page 42 HS-871P User’s Manual Appendix A A.3 < Parallel Port> Connector: LPT Type: 26-pin (2 x 13) 2.54-pitch box header Description Description STROBE- AUTO FEED- ERROR- INITIALIZE- SELECT INPUT- Ground Ground Ground Ground Ground ACKNOWLEDGE- Ground BUSY Ground PAPER EMPTY Ground...
  • Page 43 HS-871P User’s Manual Appendix A A.4 <Serial Port> A.4.1 <External DB9 COM> Connector: COM1 Type: 9-pin D-sub male connector on bracket Description Description Ground A.4.2 <Internal COM2> Connector: CN_COM2 Type: 10-pin (2 x 5) 2.54-pitch header Description Description Ground Serial Port...
  • Page 44 HS-871P User’s Manual Appendix A A.5 <USB Port> Connector: CN_USB Type: 10-pin (2 x 5) header for dual USB Ports Description Description Data0- Data1- Data0+ Data1+ Ground Ground Ground A.6 <IrDA Port> Connector: CN_IR Type: 5-pin (1 x 5) 2.54-pitch header for SIR Port...
  • Page 45 HS-871P User’s Manual Appendix A A.9 <AT Keyboard Port> Connector: CN_ATKB Type: 5-pin box header Description DATA Ground A.10 <PS/2 Keyboard & Mouse Port> Connector: PS2 Type: 6-pin Mini-DIN connector on bracket Description Ground Note: The PS/2 connector supports standard PS/2 keyboard directly or both PS/2 keyboard and mouse through the PS/2 Y-type cable.
  • Page 46 HS-871P User’s Manual Appendix B Appendix B <Flash BIOS> B.1 BIOS Auto Flash Tool The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: h ttp://www.award.com...
  • Page 47 HS-871P User’s Manual (This Page is Left for Blank) (This Page is Left for Blank)
  • Page 48 HS-871P User’s Manual Appendix C Appendix C <Watchdog Timer Programming Guide> WDT source from : WinBond 83627HF (1) General Description Winbond has a WDT feature inside its chip. We implement its function into our circuit . There are many configuration Registors ( CR ) in 83627HF. The...
  • Page 49 HS-871P User’s Manual ** Chip ( Global ) Control Register ( CCR ) : CR02 -->CR2F. CR07 = Logical Device Number Register ( LDNR ) ** Logical Device 0 ( LD0 ) = FDC , with CR : CR30 -->CRF5 .
  • Page 50 HS-871P User’s Manual Appendix C LD8-CRF7- Bit[3..0] : Select IRQ resource for WDT time-out ( Setting of 2 selects SMI ) (3) WDT Programmimg guide Step 1 . Enter extended function mode as mentioned as above. Step 2 . Program WDT related CR.
  • Page 51 HS-871P User’s Manual MOV DX,2Fh MOV AL,08H OUT DX,AL ; select logical device 8 MOV DX,2Eh MOV AL,0F5H OUT DX,AL MOV DX,2Fh AL,DX AL,08h ; SELECT MINUTE MOV AH,AL MOV DX,2Eh MOV AL,0F5h OUT DX,AL MOV DX,2Fh MOV AL,AH OUT DX,AL MOV DX,2Eh ;...
  • Page 52 HS-871P User’s Manual Appendix D Appendix D <Hardware Test> D.1 <Power Consumption> Hardware Intel® Mobile Celeron® 1.2GHz Memory UNIGEN DDR333 512MB x 1 Seagate ST340014A (not counted) CDROM SONY DDU1621 DVD-ROM (not counted) Power Supply SEVENTEAM ST-402HLP Software Windows XP SP1 English Version...

  • Page 53: Contact Information

    Taiwan Commate Computer Inc. Address 8F, No. 94, Sec. 1, Shin Tai Wu Rd., Shi Chih Taipei Hsien, Taiwan +886-2-26963909 +886-2-26963911 Website h ttp://www.commell.com.tw E-Mail i nfo@commell.com.tw (General Information) t ech@commell.com.tw (Technical Support) Commell is our trademark of industrial PC division Contact Information...
