- Page 1 LED PAR Hex-18 IP65 User Manual LED PAR Hex-18 IP65 www.showtech.com.au...
-
Page 2: Table Of Contents
LED PAR Hex-18 IP65 Table of Contents 1. Safety instructions…………………………………………………………3 1.1 Overhead rigging …………………………………………………….4 1.2 Power Connection …………………………………………………..6 1.3 Cleaning and Maintenance ……………………………………..6 2. Menu Navigation ............7 3. DMX Allocation ...............9 4. Technical Specifications ..........12... -
Page 3: Safety Instructions
LED PAR Hex-18 IP65 1. Safety Instructions FOR SAFE AND EFFICIENT OPERATION Be careful with heat and extreme temperature. Avoid exposing it to direct rays of sun near a heating appliance. Do not put it in a temperature below 41°F/5°C, or exceeding 95°F/35°C. -
Page 4: Overhead Rigging
LED PAR Hex-18 IP65 When not using the unit for an extended period of time be sure to disconnect the plug form the receptacle. 1.1. Overhead Rigging This item must be built in a way that it can hold 10 times more of its weight for 1 hour without causing any damages. - Page 5 LED PAR Hex-18 IP65 Use only professional trussing system if the item shall be lowered from the ceiling or high joists. Never let the device swing freely in a room. CAUTION: Overhead Items may cause serious injuries when crashing down!! If there is concern about the safety then DO NOT INSTALL the device.
-
Page 6: Power Connection
LED PAR Hex-18 IP65 1.2. Power Connection !! CAUTION !! Never leave this device running unattended!! Every person that is involved with this item has to be qualified!! Connect item with main plug. The voltage and frequency must exactly be the same as stated on the device. -
Page 7: Menu Navigation
LED PAR Hex-18 IP65 2. Menu navigation Menu Level 1 Menu Level 2 Menu Level 3 Remark （Default 12CH，d 1） … … Default：C63 … … （Default：P1） （Default：S100） （Default： RGBAWP=255）... - Page 8 LED PAR Hex-18 IP65 Dimmer speed OFF: （ Default：OFF） Dimmer speed Mode1(Fast) Dimmer speed Mode1(Middle) Dimmer speed Mode1(Slow) （Default：ON） If setting pass word to “On”，need to press “UP ，DOWN，UP，DOWN ，ENTER” to release; if press wrong, pls press enter to input again.
-
Page 9: Dmx Allocation
LED PAR Hex-18 IP65 3. DMX Allocation 6-CH Function Value Percent/Setting Remark 000-255 0~100% Green 000-255 0~100% Blue 000-255 0~100% Amber 000-255 0~100% Amber/White White 000-255 0~100% Purple 000-255 0~100% 8-CH Function Value Percent/Setting Remark Dimmer 000-255 0~100% 000-255 0~100%... - Page 10 LED PAR Hex-18 IP65 NO Function 000-010 strobe Strobe slow to fast 011-255 000-010 No Function 011-030 R 100%, G 0~100%, B 0% 031-050 R 100%~0%, G 100%, B 0% 051-070 R 0%, G 100%, B 0~100% 071-090 R 0%...
- Page 11 LED PAR Hex-18 IP65 000-051 Preset dimmer speed from display menu 052-101 Dimmer speed mode off 102-152 Dimmer speed mode1 (fast Dim Mode speed) 153-203 Dimmer speed mode2 (middle speed) 204-255 Dimmer speed mode3 (slow speed)
-
Page 12: Technical Specifications
LED PAR Hex-18 IP65 4. TECHNICAL SPECIFICATIONS Color 3649 405.5 74.5 36.5 9344 1038 373.7 190.7 93.4 1499 166.5 30.6 4159 166.3 84.9 41.6 10652 1184 217.4 106.5 44.08 4.898 1.763 0.44 RGBA RGBW RGBAW 24934 2770 997.4 508.9 249.3 Please note: Information is subject to change without prior notice ©...
